I46-IN3924Digital Projector

1 D e c l a r a t i o n o f C o n f o r m i t y Manufacturer: InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, Oregon 97223-8368 USAWe declare under our sole responsibility th at this projector conforms to the following directives and norms: ErP Directive 2009/125/ECEMC Directive 2004/108/ECEMC: EN 55024:2010, EN 55022:2010, EN 61000-3-2:2006+A1:2009+A2:2009,  EN 61000-3-3:2008 Low Voltage Directive 2006/95/ECSafety: IEC 60950-1: 2005;EN 60950-1:2006 +A11:2009 R&TTE Directive: 1999/5/ECETSI: EN 300 440, EN 301 489The receiver portion of this product is a Catego ry III device, as sp ecified in EN 300 440. T r a d e m a r k s Apple, Macintosh, and PowerBook are trademarks or registered trademarks of Apple Computer, Inc. IBM is a trademark or registered trademark of International Business Machines, Inc. Microsof t, PowerPoint, and Windows are trademarks or registered trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or registered trademarks of Adobe Systems Incorporated. DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. N O T E : This product is covered electrical and electronic equipment under the European Union's Waste from Electrical and Electronic Equipment ("WEEE") Directive (2002/96/EC). The WEEE Directive requires that covered equipment be collected and managed separately from typical household waste in all EU member states. Please follow the guidance of your local environmental authority or ask the shop where you purchased the product for collection or recycling options. F C C W a r n i n g This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This de vice may not cause harmful interference, and (2) this device must accept any interference received, includ ing interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:--Reorient or relocate the receiving antenna.--Increase the separation betwee n the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.--Consult the dealer or an experienced radio/TV technician for help.Changes or modifications not expressly approved by InFocus Corporation may void authority to operate the equipment. C a n a d a This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions:1) this device may not cause interference and2) this device must accept any interference, including interference that may cause undesired operation of the device.Ce dispositif est conforme à la norme CNR-210 d'Industr ie Canada appl icable aux appareils radio exempts de licence. Son fonc tionnement est sujet aux d eux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et(2) ce dispositif doit accept er tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. 2 A g e n c y A p p r o v a l s cULusOther specific Country Approvals may apply. Pleas e see product certification label. This document applies to regulatory model IN3924/IN3926.Input ratings: 100-240Vac, 3.2A, 50-60HzInFocus reserves the right to alter product offerings and specifications at any time without notice. 3 T a b l e o f C o n t e n t s Introduction 5Positioning the projector 7 Connecting a computer source 8 VGA connection 8 HDMI connection 8 Connecting power 8 Optional computer connections 8 Displaying an image 9 Adjusting the image 10 Connecting a video device 11 Video device connections 11 Composite video connection 11 VGA connection 11 Component video connection 11 S-video connection 11 Shutting down the projector 12 Troubleshooting your setup 12 Using the remote control 20 Using the audio 21 Using the keypad buttons 22 Optimizing computer images 23 Presentation features 23 Optimizing video images 24 Customizing the projector 24 Using the menus 25 Basic Menu 26 Advanced Menu 27 Controlling the projector through a LAN environment 31 Controlling the projector remotely through a web browser 32 Displaying images through ifPresenter 36 Displaying pictures with a USB storage device 39 LiteBoard™ Wand 41 Charging the Wand’s Battery 41 How to Use the Wand 41 Wand Position and Avoiding Shadows 41 Using More than One Wand 42 Wand Features 42 Buttons and Wand Tip 42 Troubleshooting LiteBoard 43 Maintenance 45 Cleaning the lens 45 Using the security lock 45 Replacing the projection lamp 46 4 I m p o r t a n t O p e r a t i n g C o n s i d e r a t i o n s f o r S a f e t y • Refer to this guide for proper startup and shutdown procedures. • Follow all warnings and cautions in this manual and on the projector. • Place the projector in a horizontal position no greater than 15 degrees off axis. • Locate the projector at least 4' (1.2m) away from any heating or cooling vents. • Do n…

Text truncated - open the document above for the full version.

1 1 C o n n e c t i n g a v i d e o d e v i c e You can connect video devices such as VCRs, DVD players, camcorders, digital cameras, video game consoles, HDTV receivers, and TV tuners to the projector. You can connect the audio directly to the projector to get sound from the built-in speaker, or you can bypass the projector’s audio system and connect the audio directly from your source to a stereo or home theater system.You can connect the projector to most video devices that can output video. You cannot directly connect the coaxial cable that enters your house from a cable or satellite company, the signal must pass through a tuner first. Examples of tuners are digital cable boxes, VCRs, digital video recorders, and satellite TV boxes. Basically, any device that can change channels is considered a tuner.Before connecting your projector, you should decide which aspect ratio you want to use. The projector’s Aspect Ratio setting is accessed through the Resize button on the remote or through the projector’s Basic Menu. See page 26 for more information. V i d e o d e v i c e c o n n e c t i o n s No video cables are provided with the projector. You can order cables from InFocus or provide your own.H D M I c o n n e c t i o n HDMI is a standard, uncompressed, all-digital audio/video interface. HDMI provides an interface between sources, such as set-top boxes, DVD players, and receivers and your projector. Plug an HDMI cable into the video-out connector on the video device and into the HDMI connector on the projector.C o m p o s i t e v i d e o c o n n e c t i o n Plug the composite video cable’s yellow connector into the video-out connector on the video device. Plug the othe r yellow connector into the yellow V V i d e o connector on the projector. V G A c o n n e c t i o n If your video device has a 15-pin VGA output, plug one end of the included computer cable into the VGA connector on your video source. This connector may be labeled “To Monitor” on the video source. Plug the computer cable into either the C C o m p u t e r 1 or C C o m p u t e r 2 connector on the projector. C o m p o n e n t v i d e o c o n n e c t i o n If your HD video device has component connectors, an optional Component to VGA adapter can be used. Plug the component cable into the video device. Plug the other end of the component cable into the adapter and plug the adapter into the C C o m p u t e r 1 or C C o m p u t e r 2 connector. S - v i d e o c o n n e c t i o n Plug the S-video cable’s connector into the video-out connector on the video device. Plug the other connector into the S S - V i d e o connector on the projector. A u d i o For PC audio jack, connect a 3.5mm stereo cable to the A A u d i o I n connector on the projector and to your source. If your source uses RCA audio connectors, a Y-cable or adapter may be used. For RCA audio jack, connect a RCA stereo cable to the A A u d i o / L and A A u d i o / R connectors on the projector and to your source. (Note: A separate audio connection is not required for HDMI source inputs.) 1 2 S h u t t i n g d o w n t h e p r o j e c t o r A u t o O f f T i m e The projector also has an Auto Off Time feature that automatically turns the projector off after no active sources are detected and no user interaction with the projector is performed for 30 minutes. By default, this feature is off. You can change the length of time, see page 30. T u r n i n g o f f t h e p r o j e c t o r To turn the projector off, press the P P o w e r button on the remote or keypad. The lamp turns off and the Power LED blinks orange for 1 minute while the fans continue to run to cool the lamp. If the Power Saving Mode feature is on and when the lamp has cooled, the LED lights orange and the fans stop. If the Power Saving Mode feature is off and when the lamp has cooled, the LED blinks orange and the fans stop. Unplug the power cable to completely power off the projector. T r o u b l e s h o o t i n g y o u r s e t u p If your image appears correctly on the screen, skip to the next section. If it does not, troubleshoot the setup. The Status Indicator Panel on top of the projector indicates the state of the projector and can help you troubleshoot. T a b l e 3 : S t a t u s i n d i c a t o r l i g h t b e h a v i o r a n d m e a n i n g S t a t u s I n d i c a t o r L i g h t M e a n i n g POWER: Solid orangePOWER: Blinking orange 1. If the Power Saving Mode feature is on, the projector is plugged in.2. The projector is on and initialized.3. The projector is in normal operation.1. If the Power Saving Mode is off, the projector is plugged in.2. The projector is powering down and the fans are cooling the projector. POWER: Blinking orangeTEMP: Blinking redLAMP: Blinking redPOWER: Solid orangeTEMP: Blinking redLAMP: Blinking red The projector fan(s) are not operating correctly and the projector has been shut down.The lamp failed to ignite.Contact Technical Support if the problem persists. Visit www.infocus.com/support to contact service. POWER: Solid orangeTEMP: OffLAMP: Blinking red The lamp has reached its end of life and must be replaced. The lamp will continue to operate until it fails.Contact Technical Support. Repair may be needed. POWER: Solid orangeTEMP: Blinking redLAMP: Off 1. The projector is overheating and the lamp will be shut off. The fans will continue to run.2. The projector will not turn back on until the cooling process is complete . P r o b l e m S o l u t i o n R e s u l t NN o s t a r t u p s c r e e n PP l u g p o w e r c o r d i n t o t h e p r o j e c t o r p r e s s p o w e r b u t t o n Startup Screen C o r r e c t i m a g e A Startup Screen OO n l y s t a r t u p s c r e e n a p p e a r s Restart laptop P r e s s t h e S o u r c e b u t t o n a c t i v a t e l a p t o p ’ s e x t e r n a l p o r t A A C o m p u t e r i m a g e p r o j e c t e d 1 3 1 4 P r o b l e m S o l u t i o n R e s u l t N o c o m p u t e r i m a g e , j u s t t h e w o r d s “ S i g n a l o u t o …

Text truncated - open the document above for the full version.

ftrhsrs August 6,2OLz Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC lD:146-1N3924 Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Darla Baldoni Regulatory Affairs Manager 13190 SW 68"'Parkway, Suite 20O Portland, OR 97223, ph 1-800-388-835O www.infocus.com

August 6,2012 To whom it maY concern: We, the undersigned lnFocus Corporation hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan to act on our behalf in all matters relating to all processes required for FCC Part 15C approval. Any and all acts carried out by BV CPS Taoyuan Branch on our behalf shall have the same effects as acts of our own. lf you have any questions regarding the authorization, please don't hesitate to contact us. Sincerely yours, Regulatory Affairs Manager 13190 SW 68tr' Parkway, Suite 200, Portland, OR97223, ph 1-800-388-8360, wwuinfocus'com

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

王銘杰 12.8 11.8 10.19.1 10 10 10 10 IPD-X6035 IN3924 2012.08.13 PL738-5000-00 *本部品須符合UL認證規范 (原材質/成品/供應商需經認證,報告需符合我司要求) IN3924 3.2A IN3924 制造商：INFOCUS CORPORATION PL738-5000-00 I46-IN3924 8150A-IN3924 王銘杰 12.8 11.8 10.19.1 10 10 10 10 IPD-W6035 IN3926 2012.08.13 PL838-5000-00 *本部品須符合UL認證規范 (原材質/成品/供應商需經認證,報告需符合我司要求) IN3926 3.2A IN3926 制造商：INFOCUS CORPORATION PL838-5000-00 I46-IN3924 8150A-IN3924

Label Location

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19

FCC ID: I46-IN3924 Report No.: RF990419D14C Operational Description The transmitter of the EUT (Digital Projector) is powered by 100-240Vac from AC power board. The type of antenna is Printed antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF990419D14C 1 of 28 Report Format Version 5.0.0 Reference No.: 120717D22 FCC TEST REPORT REPORT NO.: RF990419D14C MODEL NO.: IN3924, IN3926 FCC ID: I46-IN3924 RECEIVED: Jul. 17, 2012 TESTED: Aug. 6, 2012 ISSUED: Aug. 7, 2012 APPLICANT: InFocus Corporation ADDRESS: 13190 SW 68th Pkwy, Suite 200 Portland Oregon 97223-8368 United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF990419D14C 2 of 28 Report Format Version 5.0.0 Reference No.: 120717D22 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY................................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT..............................................................6 3.2 DESCRIPTION OF TEST MODES................................................................7 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................8 3.3 DESCRIPTION OF SUPPORT UNITS..........................................................9 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST...........................................9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................10 4. TEST TYPES AND RESULTS......................................................................11 4.1 CONDUCTED EMISSION MEASUREMENT...............................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT.............................11 4.1.2 TEST INSTRUMENTS................................................................................12 4.1.3 TEST PROCEDURES.................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD.......................................................13 4.1.5 TEST SETUP..............................................................................................13 4.1.6 EUT OPERATING CONDITIONS................................................................13 4.1.7 TEST RESULTS..........................................................................................14 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT.....................16 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................16 4.2.2 TEST INSTRUMENTS................................................................................17 4.2.3 TEST PROCEDURES.................................................................................18 4.2.4 DEVIATION FROM TEST STANDARD.......................................................18 4.2.5 TEST SETUP..............................................................................................19 4.2.6 EUT OPERATING CONDITIONS................................................................19 4.2.7 TEST RESULTS..........................................................................................20 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................26 6. INFORMATION ON THE TESTING LABORATORIES................................27 7. APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.....................................................28 Report No.: RF990419D14C 3 of 28 Report Format Version 5.0.0 Reference No.: 120717D22 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF990419D14C Original release Aug. 7, 2012 Report No.: RF990419D14C 4 of 28 Report Format Version 5.0.0 Reference No.: 120717D22 1. CERTIFICATION PRODUCT: Digital Projector BRAND: InFocus MODEL NO.: IN3924, IN3926 APPLICANT: InFocus Corporation TESTED: Aug. 6, 2012 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment (Model: IN3924) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Annie Chang / Supervisor ) APPROVED BY : …

Text truncated - open the document above for the full version.

Report No.: RF990419D14C 1 of 2 Report Format Version 5.0.0 Reference No.: 120717D22 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RF990419D14C 2 of 2 Report Format Version 5.0.0 Reference No.: 120717D22 RADIATED EMISSION TEST
