HARDWARE GUIDE JTOUCH INF6501 009-1544-00 c CONTENTS Declaration of Conformity ...................................................................................................................................................3 Safety Considerations .........................................................................................................................................................4 What’s Included ..................................................................................................................................................................6 Setup ...................................................................................................................................................................................7 Mounting ......................................................................................................................................................................7 Connecting to Other Devices ........................................................................................................................................8 Connecting AC Power .................................................................................................................................................11 External PC Touchscreen Control Setup ....................................................................................................................11 Turning the Monitor On/Off ...............................................................................................................................................11 Using the Remote ..............................................................................................................................................................12 Using the Keypad ..............................................................................................................................................................14 OSD (On-Screen Display) Menu System ...........................................................................................................................15 Picture Menu ...............................................................................................................................................................16 Screen Menu ...............................................................................................................................................................17 Audio menu .................................................................................................................................................................18 PIP menu .....................................................................................................................................................................19 Configuration 1 ............................................................................................................................................................20 Configuration 2 ............................................................................................................................................................21 Advanced Option ........................................................................................................................................................22 Troubleshooting ................................................................................................................................................................23 Specifications ....................................................................................................................................................................25 Limited Warranty ...............................................................................................................................................................26 Page 3INF6501 Hardware Guide DECLARATION OF CONFORMITY Manufacturer: InFocus Corporation, 13190 SW 68th Parkway, Suite 200, Portland, Oregon 97223-8368 USA Trademarks Apple, Mac and Facetime are trademarks or registered trademarks of Apple, Inc. Microsoft, Windows, PowerPoint, Excel and Word are trademarks or registered trademarks of Microsoft Corporation. Adobe and Acrobat are trademarks or registered trademarks of Adobe Systems Incorporated. HDMI logo and “High Definition Multimedia Interface” are registered trademarks of HDMI Licensing LLC. Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. SRS TruSurround HD and SRS TruVolume are trademarks of SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, INFOCUS (stylized), MondoCenter, Mondopad, BigTouch, and JTouch are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference. There is no implied sponsorship, affiliation, certification, approval or endorsement if we use one of these terms. FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of the equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by InFocus Corpora…
Text truncated - open the document above for the full version.
Project No.: 1412C151 Page 2 of 19 Project No.: 1412C151 Page 3 of 19 Project No.: 1412C151 Page 4 of 19 Project No.: 1412C151 Page 5 of 19 Project No.: 1412C151 Page 6 of 19
2015020920150209 Daty CaoFian Wang W: 11.393mmH: 9mm W: 8.291mmH: 6mm W: 9.53mmH: 7.033mm W: 6.855mmH:6mm W: 13.248mmH: 5.711mm AFTER on-line print InFocus-FXN-Jtouch65c-ID label 50642P650202H**(A)** BUWF44600001 Y-Pb-Pr VGA HDMI VIDEO HDMI HDMI LBL SAFETY NA Jtouch65c InFocus Jtouch65c 50642P650202H06(A)SW BEFORE on-line print 40mm 260mm CONSUMO DE ENERGÍA: 1) En OPERACIÓN: XXXW/h 2) En modo de ESPERA: XXXW/h 260*40mm USB 2.0 LIGHTCAST LAN USB 2.0 LIGHTCAST LAN Change “LIGHTCAST LAN” &” LIGHTCAST USB 2.0” to XXXXXX 080-513-0880 HONGFUJIN PRECISION MSIP-REM-DPB-INF6501cXXXXXXXXXX XXXXXX XXXXXX IC:CMIIT ID: XXXXXX Input V oltage / :100-240VAC Intput Current / :4A Input Frequency / :50/60Hz Output V oltage / :100-240VAC Output Current / :2A Output Frequency / :50/60Hz 50642P650202H**(A)** Y-Pb-Pr VGA HDMI VIDEO HDMI HDMI CONSUMO DE ENERGÍA: 1) En OPERACIÓN: XXXW/h 2) En modo de ESPERA: XXXW/h USB 2.0 LIGHTCAST LAN IC:CMIIT ID: XXXXXX Input V oltage / :100-240VAC Intput Current / :4A Input Frequency / :50/60Hz Output V oltage / :100-240VAC Output Current / :2A Output Frequency / :50/60Hz 20141114201411172014111920141122 201412032014120420141222201501122015011420150209 Remove Singapore Korea Taiwan logo RemoveAdd output:100-240V,2A,50/60Hz and input Change 2.5A to 4A 141114/lawrence 141117 Mail Lawrence 141122 TEL Lawrence&Merry 141203 Mail Merry 141204 MailMerry and 141204 Mail Merry and 150112 Mail Merry 150114 Mail 20150209 Mail 141119Mail 1.Please group this to as with line and name Lightcast while keep the LAN and USB 2.0 label2.USB 3.0 port at the back should also change to “ USB Touch Access”3.Add NCC IDA logo4.FCC IC CMIIT ID XXXXX-XX CAN ICES-3 (A)/NMB-3 (A)CAN ICES-3 (A)/NMB-3 (A) I46INF6501C 8150B-INF6501C I46INF6501C 8150B-INF6501C Page 9INF6501a Hardware Guide 50642P650202H**(B)** ӝ〦: ӈࣞᕅ⭫ᆆⲳᶵᱴ示ಞ Product: TouchScreen Displays Model/ ශਭINF6501c Regulatory Model/ 䇚䇷ශਭ: INF6501c Part Number: INF6501c Voltage /⭫Ⓠ: 100-240VAC Current: 2.5A Frequency: 50/60Hz Manufacturer: InFocus Corporation Address: 13190 SW 68th Parkway Suite 200, Portland, OR 97223-8368 Part No./ INF6501c Y-Pb-Pr VGAHDMIHDMIVIDEOUSB 3.0USB 2.0HDMIHDMILAN Audio IN 1 Audio OUT RS232 ON/OFFPOWER INPOWER OUT Audio IN 2 Bottom panel (left to right) Power switchPress it to the ON position to turn on the monitor, and press it to the OFF position to turn the monitor off. Power In Connect the power cord from the monitor to a power outlet. Power Out Connect a power cord from an external soundbar or speakers to the monitor. LAN For Lightcast use only. Connect to an Ethernet network. USB Type A 2.0 For Lightcast use only. Connect a wireless mouse, USB thumb drive or other USB device to this USB Type A 2.0 connector. USB 3.0 Type B Connect a Type A to Type B USB cable from the monitor to an external computer in order to use the touchscreen gestures on the monitor. Video Connect a composite video cable from the monitor to an external device (such as a VCR or DVD player). HDMI Connect an HDMI cable from the monitor to an HDMI external device (such as a VCR or DVD player). HDMI Connect an HDMI cable from the monitor to an HDMI external device (such as a VCR or DVD player). HDMI Connect an HDMI cable from the monitor to an HDMI external device (such as a VCR or DVD player). HDMI Connect an HDMI cable from the monitor to an HDMI external device (such as a VCR or DVD player). ODEHOORFDWLRQ
Project No.: 1412C151 Page 7 of 19 Project No.: 1412C151 Page 8 of 19 Project No.: 1412C151 Page 9 of 19 Project No.: 1412C151 Page 10 of 19 Project No.: 1412C151 Page 11 of 19 Project No.: 1412C151 Page 12 of 19 Project No.: 1412C151 Page 13 of 19 Project No.: 1412C151 Page 14 of 19 Project No.: 1412C151 Page 15 of 19 Project No.: 1412C151 Page 16 of 19 Project No.: 1412C151 Page 17 of 19 Panel: INNOLUX / V650HP1 Project No.: 1412C151 Page 18 of 19 Project No.: 1412C151 Page 19 of 19
FCC RF EXPOSURE REPORT FCC ID: I46INF6501C Project No. : 1412C151 Equipment : TouchScreen Displays Model : INF6501c Applicant : InFocus Corporation Address : 13190 SW 68th Parkway Suite 200 Portland, OR 97223-8368 According: : FCC Guidelines for Human Exposure IEEE C95.1 BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna Ant. Brand Model Name Antenna Type Connector Gain(dBi) Note 1 ANTS71L-DJ65 1-DH Internal N/A -2.92 TX/RX TEST RESULTS EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-1/TX A Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 12.97 19.8153 0.002295891 Complies -2.35 0.5821 13.03 20.0909 0.002327831 Complies -2.35 0.5821 13.01 19.9986 0.002317131 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-1/TX N20 Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 10.75 11.8850 0.001377051 Complies -2.35 0.5821 11.01 12.6183 0.001462011 Complies -2.35 0.5821 10.86 12.1899 0.001412381 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-2A/TX A Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 13.03 20.0909 0.002327831 Complies -2.35 0.5821 13.05 20.1837 0.002338571 Complies -2.35 0.5821 12.97 19.8153 0.002295891 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-2A/TX N20 Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 10.79 11.9950 0.001389791 Complies -2.35 0.5821 10.92 12.3595 0.001432021 Complies -2.35 0.5821 10.72 11.8032 0.001367571 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-2C/TX A Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 13.06 20.2302 0.002343961 Complies -2.35 0.5821 12.81 19.0985 0.002212841 Complies -2.35 0.5821 12.27 16.8655 0.001954121 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-2C/TX N20 Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 11.01 12.6183 0.001462011 Complies -2.35 0.5821 10.76 11.9124 0.001380231 Complies -2.35 0.5821 10.59 11.4551 0.001327241 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-3/ TX A Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 13.06 20.2302 0.002343961 Complies -2.35 0.5821 13.04 20.1372 0.002333191 Complies -2.35 0.5821 13.05 20.1837 0.002338571 Complies EUT: TouchScreen Displays Model Name : InFocus Temperature: 25 °C Relative Humidity: 55 % Test Voltage : AC 120V/60Hz Test Mode : UNII-3/TX N20 Mode Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Te s t Result -2.35 0.5821 11.01 12.6183 0.001462011 Complies -2.35 0.5821 11.06 12.7644 0.001478941 Complies -2.35 0.5821 11.07 12.7938 0.001482351 Complies Note: the calculated distance is 20 cm.
Report No.: BTL-FCCP-3-1412C151 Page 1 of 18 FCC DFS Test Report FCC ID: I46INF6501C This report concerns (check one): Original Grant Class II Change Project No. : 1412C151 Equipment : TouchScreen Displays Model Name : INF6501c Applicant : InFocus Corporation Address : 13190 SW 68th Parkway Suite 200 Portland, OR 97223-8368 Date of Receipt : Dec. 23, 2014 Date of Test : Dec. 23, 2014 ~ Feb. 06, 2015 Issued Date : Feb. 09, 2015 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: BTL-FCCP-3-1412C151 Page 2 of 18 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-3-1412C151 Page 3 of 18 Table of Contents Page 1 . CERTIFICATION 5 2 . EUT INFORMATION 6 2.1 EUT SPECIFICATION TABLE 6 2.4 EUT MAXIMUM AND MINIMUM E.I.R.P. POWER 7 3 . U-NII DFS RULE REQUIREMENTS 8 3.1 WORKING MODES AND REQUIRED TEST ITEMS 8 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS 9 4 . TEST INSTRUMENTS 11 5 . EMC EMISSION TEST 12 5.1 DFS MEASUREMENT SYSTEM: 12 5.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL: 14 5.3 DEVIATION FROM TEST STANDARD 14 6 . TEST RESULTS 15 6.1 SUMMARY OF TEST RESULT 15 6.2 DETELED TEST RESULTS 16 6.2.1 TEST MODE: DEVICE OPERATING IN MASTER MODE. 16 6.2.5 NON- OCCUPANCY PERIOD 18 Report No.: BTL-FCCP-3-1412C151 Page 4 of 18 REPORT ISSUED HISTORY Issued No. Description Issued Date BTL-FCCP-3-1412C151 Original Report. Feb. 09, 2015 Report No.: BTL-FCCP-3-1412C151 Page 5 of 18 1. CERTIFICATION Equipment : TouchScreen Displays Trade Name InFocus Model Name. INF6501c Applicant : InFocus Corporation Manufacturer : InFocus Corporation Address : 13190 SW 68th Parkway Suite 200 Portland, OR 97223-8368 Factory : HONGFUJIN PRECISION ELECTRONICS (CHONGQING)CO.,LTD Address : NO.1 EAST DISTRICT 1ST RD.,SHAPINGBADISTRICT,CHONGQING Date of Test: : Dec. 23, 2014 ~ Feb. 06, 2015 Test Item : ENGINEERING SAMPLE Standard(s) : FCC Part 15, Subpart E (Section 15.407) FCC 06-96 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-3-1412C151) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: BTL-FCCP-3-1412C151 Page 6 of 18 2. EUT INFORMATION 2.1 EUT SPECIFICATION TABLE Table 1: Specification of EUT Product name TouchScreen Displays Brand Name InFocus Model INF6501c Model difference N/A FCC ID I46INF6501C Operational Mode Slave Operating Frequency Range 5250~5350MHz&5470~5725MHz Modulation OFDM . Note: This device was functioned as a Master Slave device during the DFS 2.2 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT Table 2: Antenna list. Ant. Brand Model Antenna Type Connector Gain (dBi) Note 1 ANTS71L-DJ651-DHInternal N/A -2.35 TX/RX Report No.: BTL-FCCP-3-1412C151 Page 7 of 18 2.3 CONDUCTED OUTPUT POWER AND EIRP POWER TABLE 3: THE CONDUCTED OUTPUT POWER LIST TX (11a) FREQUENCY BAND (MHz) MAX. POWER OUTPUT POWER(dBm) OUTPUT POWER(mW) 5250~5350 13.05 20.184 5470~5725 13.06 20.230 2.4 EUT MAXIMUM AND MINIMUM E.I.R.P. POWER TABLE 4: THE MAX EIRP LIST TX (11a) FREQUENCY BAND (MHz) MAX. POWER OUTPUT POWER(dBm) OUTPUT POWER(mW) 5250~5350 10.70 11.749 5470~5725 10.71 11.776 Report No.: BTL-FCCP-3-1412C151 Page 8 of 18 3. U-NII DFS RULE REQUIREMENTS 3.1 WORKING MODES AND REQUIRED TEST ITEMS The manufacturer shall state whether the UUT is capable of operating as a Master and/or a Client. If the UUT is capable of operating in more than one operating mode then each operating mode shall be tested separately. See tables 1 and 2 for the applicability of DFS requirements for each of the operational modes. Table 5: Applicability of DFS requirements prior to use a channel Requirement Operational Mode Master Client without radar detection Client with radar detection Non-Occupancy Period Not required DFS Detection Threshold Not required Channel Availability Check Time Not required Not required Uniform Spreading Not required Not required U-NII Detection Bandwidth Not required Table 6: Applicability of DFS requirements during normal operation. Requirement Operational Mode Master Client without radar detection Client with radar detection DFS Detection Threshold Not required Channel Closing Transmission Time Channel Mo…
Text truncated - open the document above for the full version.
Report No.: BTL-FCCP-2-1412C151Page 1 of 220 FCC Radio Test Report FCC ID: I46INF6501C This report concerns (check one):Original GrantClass I ChangeClass II Change Project No.: 1412C151 Equipment: TouchScreen Displays Model Name: INF6501c Applicant: InFocus Corporation Address: 13190 SW 68th Parkway Suite 200 Portland, OR 97223-8368 Date of Receipt: Dec. 23, 2014 Date of Test: Dec. 23, 2014 ~ Feb. 06, 2015 Issued Date: Feb. 09, 2015 Tested b y: BTL Inc. Testing Engineer: (David Mao) Technical Manager: (Leo Hung) Authorized Signatory: (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. TEL: +86-769-8318-3000FAX: +86-769-8319-6000 Report No.: BTL-FCCP-2-1412C151Page 2 of 220 Declaration BTLrepresents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measuremen t Laboratory (NML)ofR.O.C., or National Institute of Standards and Technology (NIST) ofU.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibilit y to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components.BTLshall have no liability for any declarations, inferences or generalizations drawn by the client or others fromBTLissued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full withBTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with theISO Guide 17025requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: BTL-FCCP-2-1412C151Page 3 of 220 Table of ContentsPage 1 . CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 . GENERAL INFORMATION10 3.1 GENERAL DESCRIPTION OF EUT10 3.2 DESCRIPTION OF TEST MODES13 3.3 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING14 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 15 3.5 DESCRIPTION OF SUPPORT UNITS15 4 . EMC EMISSION TEST16 4.1 CONDUCTED EMISSION MEASUREMENT16 4.1.1 POWER LINE CONDUCTED EMISSION16 4.1.2 TEST PROCEDURE16 4.1.3 DEVIATION FROM TEST STANDARD16 4.1.4 TEST SETUP17 4.1.5 EUT OPERATING CONDITIONS17 4.1.6 EUT TEST CONDITIONS17 4.1.7 TEST RESULTS17 4.2 RADIATED EMISSION MEASUREMENT18 4.2.1 RADIATED EMISSION LIMITS18 4.2.2 TEST PROCEDURE19 4.2.3 DEVIATION FROM TEST STANDARD19 4.2.4 TEST SETUP19 4.2.5 EUT OPERATING CONDITIONS20 4.2.6 EUT TEST CONDITIONS20 4.2.7 TEST RESULTS (9K TO 30MHz)21 4.2.8 TEST RESULTS (BETWEEN 30 TO 1000 MHz)21 4.2.9 TEST RESULTS (ABOVE 1000 MHz)21 5 . 26dB SPECTRUM BANDWIDTH22 5.1 APPLIED PROCEDURES / LIMIT22 5.1.1 TEST PROCEDURE22 5.1.2 DEVIATION FROM STANDARD22 5.1.3 TEST SETUP22 5.1.4 EUT OPERATION CONDITIONS22 5.1.5 EUT TEST CONDITIONS23 5.1.6 TEST RESULTS23 6 . MAXIMUM CONDUCTED OUTPUT POWER24 Report No.: BTL-FCCP-2-1412C151Page 4 of 220 Table of ContentsPage 6.1 APPLIED PROCEDURES / LIMIT24 6.1.1 TEST PROCEDURE24 6.1.2 DEVIATION FROM STANDARD25 6.1.3 TEST SETUP25 6.1.4 EUT OPERATION CONDITIONS25 6.1.5 EUT TEST CONDITIONS25 6.1.6 TEST RESULTS25 7 . ANTENNA CONDUCTED SPURIOUS EMISSION26 7.1 APPLIED PROCEDURES / LIMIT26 7.1.1 TEST PROCEDURE26 7.1.2 DEVIATION FROM STANDARD26 7.1.3 TEST SETUP26 7.1.4 EUT OPERATION CONDITIONS26 7.1.5 EUT TEST CONDITIONS26 7.1.6 TEST RESULTS26 8 . POWER SPECTRAL DENSITY TEST27 8.1 APPLIED PROCEDURES / LIMIT27 8.1.1 TEST PROCEDURE27 8.1.1 DEVIATION FROM STANDARD28 8.1.2 TEST SETUP28 8.1.3 EUT OPERATION CONDITIONS28 8.1.4 EUT TEST CONDITIONS28 8.1.5 TEST RESULTS28 9 . FREQUENCY STABILITY MEASUREMENT29 9.1 APPLIED PROCEDURES / LIMIT29 9.1.1 TEST PROCEDURE29 9.1.2 DEVIATION FROM STANDARD29 9.1.3 TEST SETUP30 9.1.4 EUT OPERATION CONDITIONS30 9.1.5 EUT TEST CONDITIONS30 9.1.6 TEST RESULTS30 10 . MEASUREMENT INSTRUMENTS LIST31 11 . EUT TEST PHOTOS33 ATTACHMENT A - CONDUCTED EMISSION37 ATTACHMENT B - RADIATED EMISSION (9KHZ TO 30MHZ)40 ATTACHMENT C - RADIATED EMISSION (30MHZ TO 1000MHZ)42 ATTACHMENT D - RADIATED EMISSION (ABOVE 1000MHZ)67 ATTACHMENT E - BANDWIDTH166 Report No.: BTL-FCCP-2-1412C151Page 5 of 220 Table of ContentsPage ATTACHMENT F - MAXIMUM OUTPUT POWER183 ATTACHMENT G - ANTENNA CONDUCTED SPURIOUS EMISSION190 ATTACHMENT H - POWER SPECTRAL DENSITY199 ATTACHMENT I - FREQUENCY STABILITY216 Report No.: BTL-FCCP-2-1412C151Page 6 of 220 REPORT ISSUED HISTORY Issued No.DescriptionIssued Date BTL-FCCP-2-1412C151Original Issue.Feb. 09, 2015 Report No.: BTL-FCCP-2-1412C151Page 7 of 220 1. CERTIFICATION Equipment : TouchScreen Displays Brand Name : InFocus Model Name : INF6501c Applicant: InFocus Corporation Manufacturer : InFocus Corporation Address: 13190 SW 68th Parkway Suite 200 Portland, OR 97223-8368 Factory: HONGFUJIN PRECISION ELECTRONICS (CHONGQING)CO.,LTD Address: NO.1 EAST DISTRICT 1ST RD.,SHAPINGBADISTRICT,CHONGQING Date of Test : Dec. 23, 2014 ~ Feb. 06, 2015 Test Sample : ENGINEERING SAMPLE Standard(s) : FCC Part15, Subpart E(15.407) / ANSI C63.4: 2009 FCC KDB 789033 D02 General UNII Test Procedures New Rules v01. The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. BTL-FCCP-2-1412C151) were obtained utilizing the testprocedures, test instruments, test sites that has been accredited by the Authority of TAFaccording to the ISO-17025 …
Text truncated - open the document above for the full version.
Report No.: BTL-FCCP-2-1412C151 Page 111 of 220 Orthogonal Axis : X Test Mode : UNII-2A/ TX N20 Mode 5300MHz Horizontal No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 10600.5500 37.90 11.00 48.90 68.30 -19.40 Peak 2 10602.0599 26.77 11.01 37.78 54.00 -16.22 AVG Report No.: BTL-FCCP-2-1412C151 Page 112 of 220 Orthogonal Axis : X Test Mode : UNII-2A/ TX N20 Mode 5320MHz Vertical No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 5319.1000 49.27 39.56 88.83 54.00 34.83 AVG No Limit 2 5320.1000 57.12 39.56 96.68 68.30 28.38 Peak No Limit 3 5350.0000 7.45 39.66 47.11 68.30 -21.19 Peak 4 5350.0000 -1.57 39.66 38.09 54.00 -15.91 AVG Report No.: BTL-FCCP-2-1412C151 Page 113 of 220 Orthogonal Axis : X Test Mode : UNII-2A/ TX N20 Mode 5320MHz Vertical No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 10640.3099 25.88 11.04 36.92 54.00 -17.08 AVG 2 10641.0100 37.31 11.04 48.35 68.30 -19.95 Peak Report No.: BTL-FCCP-2-1412C151 Page 114 of 220 Orthogonal Axis : X Test Mode : UNII-2A/ TX N20 Mode 5320MHz Horizontal No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 5318.9000 55.42 39.56 94.98 68.30 26.68 Peak No Limit 2 5319.1000 47.95 39.56 87.51 54.00 33.51 AVG No Limit 3 5350.0000 9.51 39.66 49.17 68.30 -19.13 Peak 4 5350.0000 -1.30 39.66 38.36 54.00 -15.64 AVG Report No.: BTL-FCCP-2-1412C151 Page 115 of 220 Orthogonal Axis : X Test Mode : UNII-2A/ TX N20 Mode 5320MHz Horizontal No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 10640.1000 38.83 11.04 49.87 68.30 -18.43 Peak 2 10641.3800 27.20 11.04 38.24 54.00 -15.76 AVG Report No.: BTL-FCCP-2-1412C151 Page 116 of 220 Orthogonal Axis : X Test Mode : UNII-2C/ TX A Mode 5500MHz Vertical No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 5460.0000 10.37 40.03 50.40 68.30 -17.90 Peak 2 5460.0000 -1.02 40.03 39.01 54.00 -14.99 AVG 3 5470.0000 11.51 40.06 51.57 68.30 -16.73 Peak 4 5470.0000 1.73 40.06 41.79 54.00 -12.21 AVG 5 5499.1000 51.18 40.16 91.34 54.00 37.34 AVG No Limit 6 5499.8000 59.28 40.16 99.44 68.30 31.14 Peak No Limit Report No.: BTL-FCCP-2-1412C151 Page 117 of 220 Orthogonal Axis : X Test Mode : UNII-2C/ TX A Mode 5500MHz Vertical No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 11000.0500 25.86 11.38 37.24 54.00 -16.76 AVG 2 11001.3700 37.49 11.38 48.87 68.30 -19.43 Peak Report No.: BTL-FCCP-2-1412C151 Page 118 of 220 Orthogonal Axis : X Test Mode : UNII-2C/ TX A Mode 5500MHz Horizontal No. Freq. Reading Level Correct Factor Measure ment Limit Over MHz dBuV/m dB dBuV/m dBuV/m dB Detector Comment 1 5460.0000 9.87 40.03 49.90 68.30 -18.40 Peak 2 5460.0000 -1.03 40.03 39.00 54.00 -15.00 AVG 3 5470.0000 10.98 40.06 51.04 68.30 -17.26 Peak 4 5470.0000 1.93 40.06 41.99 54.00 -12.01 AVG 5 5498.8000 57.08 40.16 97.24 68.30 28.94 Peak No Limit 6 5499.2000 49.66 40.16 89.82 54.00 35.82 AVG No Limit Report No.: BTL-FCCP-2-1412C151 Page 119 of 220 Orthogonal Axis : X Test Mode : UNII-2C/ TX A Mode 5500MHz Horizontal No. Freq. Reading Level Correct Fa…
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 4 | 15E | 5.75 GHz - 5.83 GHz | 20.00 mW |
