I88B122Wireless LAN PCMCIA Card

ZyAIR Wireless LAN Utility User's Guide Version 2.10 September 2003 ZyAIR Wireless LAN Utility ii Copyright Copyright Copyright ©2003 by ZyXEL Communications Corporation The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written permission of ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patents' rights of others. ZyXEL further reserves the right to make changes in any products described herein without notice. This publication is subject to change without notice. Trademarks Trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective owners. ZyAIR Wireless LAN Utility ZyXEL Limited Warranty iii ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to one (1) year from the date of purchase. During the warranty period and upon proof of purchase, should the product have indications of failure due to faulty workmanship and/or materials, ZyXEL will, at its discretion, repair or replace the defective products or components without charge for either parts or labor and to whatever extent it shall deem necessary to restore the product or components to proper operating condition. Any replacement will consist of a new or re-manufactured functionally equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty shall not apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. NOTE Repair or replacement, as provided under this warranty, is the exclusive remedy of the purchaser. This warranty is in lieu of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular use or purpose. ZyXEL shall in no event be held liable for indirect or consequential damages of any kind of character to the purchaser. To obtain the services of this warranty, contact ZyXEL's Service Center for your Return Material Authorization (RMA) number. Products must be returned Postage Prepaid. It is recommended that the unit be insured when shipped. Any returned products without proof of purchase or those with an out-dated warranty will be repaired or replaced (at the discretion of ZyXEL) and the customer will be billed for parts and labor. All repaired or replaced products will be shipped by ZyXEL to the corresponding return address, Postage Paid. This warranty gives you specific legal rights, and you may also have other rights that vary from country to country. Online Registration Register online at www.zyxel.com .for free future product updates and information. ZyAIR Wireless LAN Utility iv Information for Canadian Users Information for Canadian Users The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective operation and safety requirements. The Industry Canada does not guarantee that the equipment will operate to a user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company's inside wiring associated with a single line individual service may be extended by means of a certified connector assembly. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. For their own protection, users should ensure that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas. Caution Users should not attempt to make such connections themselves, but should contact the appropriate electrical inspection authority, or electrician, as appropriate. Note This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the radio interference regulations of Industry. ZyAIR Wireless LAN Utility FCC Statement v Federal Communications Commission (FCC) Interference Statement The Wireless LAN Adapter has been tested to the FCC exposure requirements (Specific Absorption Rate). The device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operations. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. If this equipment does cause harmful interference to radio/televisi…

Text truncated - open the document above for the full version.

Photo 1: Exterior photo ZyXEL B-122 Photo 2: Exterior photo ZyXEL B-122

FCC ID Label Location

Photo 1: Interior photo ZyXEL B-122 Photo 2: Interior photo ZyXEL B-122 Photo 3: Interior photo ZyXEL B-122 Photo 4: Interior photo ZyXEL B-122

0597 ILAC MRA Specific Absorption Rate (SAR) Test Report for ZyXEL Communications Corporation on the CardBus 11Mbps Wireless LAN Card Model Number: ZyAIR B-122 Test Report: EME-031071 Date of Report: Sep. 24, 2003 Date of test: Sep. 23, 2003 Total No of Pages Contained in this Report: 70 Accredited for testing to FCC Part 15 Tested by: Kevin Chen Reviewed by: Elton Chen Review Date: Sep. 25, 2003 All services undertaken are subject to the following general policy: Reports are submitted for exclusive use of the client to whom they are addressed. Their significance is subject to the adequacy and representative character of the samples and to the comprehensiveness of the tests, examinations or surveys made. This report shall not be reproduced except in full, without written consent of Intertek Testing Services, Taiwan Ltd. FCC ID. : I88B122 Report No.: EME-031071 Page 2 of 70 Table of Contents 1.0 Job Description...........................................................................................................4 1.1 Client Information...................................................................................................4 1.2 Equipment under test (EUT)...................................................................................4 1.3 Test plan reference..................................................................................................5 1.4 System test configuration........................................................................................5 1.4.1 System block diagram & Support equipment......................................................5 1.4.2 Test Position.........................................................................................................6 1.4.3 Test Condition......................................................................................................6 1.5 Modifications required for compliance...................................................................7 1.6 Additions, deviations and exclusions from standards.............................................7 2.0 SAR Evaluation..........................................................................................................8 2.1 SAR Limits.............................................................................................................8 2.2 Configuration Photographs.....................................................................................9 2.3 SAR measurement system....................................................................................13 2.4 SAR measurement system validation...................................................................14 2.5 Test Result.............................................................................................................15 3.0 Test Equipment.........................................................................................................17 3.1 Equipment List......................................................................................................17 3.2 Body Tissue Simulating Liquid for evaluation test..............................................18 3.3 Head Tissue Simulating Liquid for System performance Check test...................18 3.4 E-Field Probe Calibration.....................................................................................18 3.5 Measurement Uncertainty.....................................................................................19 3.6 Measurement Traceability.....................................................................................20 4.0 WARNING LABEL INFORMATION - USA..........................................................21 REFERENCES...............................................................................................................22 DOCUMENT HISTORY................................................................................................23 APPENDIX A - SAR Evaluation Data...........................................................................24 APPENDIX B – 2450MHz body liquid Calibration Data..............................................45 APPENDIX C - E-Field Probe Certificate and Calibration Data...................................50 FCC ID. : I88B122 Report No.: EME-031071 Page 3 of 70 STATEMENT OF COMPLIANCE The ZyXEL sample device, model # ZyAIR B-122 was evaluated in accordance with the requirements for compliance testing defined in FCC OET Bulletin 65, Supplement C (Edition 01-01). Testing was performed at the Intertek Testing Services facility in Hsinchu, Taiwan. For the evaluation, the dosimetric assessment system INDEXSAR SARA2 was used. The phantom employed was the box phantom of 2mm thick in one wall. The total uncertainty for the evaluation of the spatial peak SAR values averaged over a cube of 1g tissue mass had been assessed for this system to be ±20.6%. The device was tested at their maximum output power declared by the ZyXEL. In summary, the maximum spatial peak SAR value for the sample device averaged over 1g was found to be: Phantom Position SAR 1g , mW/g 2mm thick box phantom wall The EUT inserted into the left side of notebook PC, with EUT perpendicular to the phantom, 0 mm separatio 0.180 mW/g. In conclusion, the tested Sample device was found to be in compliance with the requirements defined in OET Bulletin 65, Supplement C (Edition 01-01) for body configurations. FCC ID. : I88B122 Report No.: EME-031071 Page 4 of 70 1.0 Job Description 1.1 Client Information The ZyAIR B-122 has been tested at the request of: Company: ZyXEL Communications Corporation No. 6, Innovation Rd II, Science-Based Industrial Park, Hsin-Chu, Taiwan 1.2 Equipment under test (EUT) Product Descriptions: Equipment CardBus 11Mbps Wireless LAN Card Trade Name ZyXEL Model No: ZyAIR B-122 FCC ID I88B122 S/N No. Not Labeled Category Portable RF Exposure Uncontrolled Environment Frequency Band 2412 – 2462 MHz System DSSS EUT Antenna Description Type Ceramic Configuration Fixed Dimensions 116 x 54 …

Text truncated - open the document above for the full version.

FCC ID. : I88B122 Report No.: EME-031034 Page 1 of 34 EMC TEST REPORT Report No. : EME-031034 Model No. : ZyAIR B-122 Issued Date : Sep. 15, 2003 Applicant : ZyXEL Communications Corporation No. 6, Innovation Rd II. Science-Based Industrial Park, Hsin-Chu, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 34 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result in this report only applies to the tested sample. Jerry Liu Project Engineer Reviewed By Elton Chen FCC ID. : I88B122 Report No.: EME-031034 Page 2 of 34 Table of Contents Summary of Tests..........................................................................................................3 1. General information..................................................................................................4 1.1 Identification of the EUT....................................................................................4 1.2 Additional information about the EUT................................................................4 1.3 Antenna description............................................................................................5 1.4 Peripherals equipment.........................................................................................5 2. Test specifications.....................................................................................................6 2.1 Test standard.......................................................................................................6 2.2 Operation mode..................................................................................................6 2.3 Test equipment....................................................................................................7 3. Minimum 6dB Bandwidth test...................................................................................8 3.1 Operating environment.......................................................................................8 3.2 Test setup & procedure........................................................................................8 3.3 Measured data of Minimum 6dB Bandwidth test results......................................8 4. Maximum Output Power test...................................................................................12 4.1 Operating environment.....................................................................................12 4.2 Test setup & procedure......................................................................................12 4.3 Measured data of Maximum Output Power test results......................................12 5. Radiated Emission test............................................................................................13 5.1 Operating environment.....................................................................................13 5.2 Test setup & procedure......................................................................................13 5.3 Emission limits.................................................................................................14 5.4 Radiated spurious emission test data.................................................................15 5.4.1 Measurement results: frequencies equal to or less than 1 GHz........................15 5.4.2 Measurement results: frequency above 1GHz.................................................16 6. Power Spectrum Density test...................................................................................19 6.1 Operating environment.....................................................................................19 6.2 Test setup & procedure......................................................................................19 6.3 Measured data of Power Spectrum Density test results......................................19 7. Emission on the band edge §FCC 15.247(C)...........................................................23 7.1 Band-edge (Conducted method)........................................................................24 7.2 Band-edge (Radiated method)...........................................................................26 8. Power Line Conducted Emission test §FCC 15.207.................................................30 8.1 Operating environment.....................................................................................30 8.2 Test setup & procedure......................................................................................30 8.3 Power Line Conducted Emission test data.........................................................32 FCC ID. : I88B122 Report No.: EME-031034 Page 3 of 34 Summary of Tests CardBus 11Mbps Wireless LAN Card-Model: ZyAIR B-122 FCC ID: I88B122 Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies FCC ID. : I88B122 Report No.: EME-031034 Page 4 of 34 1. General information 1.1 Identification of the EUT Applicant : ZyXEL Communications Corporation Product : CardBus 11Mbps Wireless LAN Card Model No. : ZyAIR B-122 FCC ID. : I88B122 Frequency Range : 2412~2462MHz Channel Number : 11channels Frequency of Each Channel : 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Type of Modulation : CCK (11Mbps, 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) Rated Power : 3.3Vdc Power Cord : N/A Sample Received : Sep. 8, 2003 Test Date(s) : Sep. 8, 2003 ~ Sep. 10, 2003 A FCC DoC report has been generated for the client. 1.2 Additional information about the EUT The ZyAIR B-122 is an 802.11b wireless LAN Cardb…

Text truncated - open the document above for the full version.

FCC ID. : I88B122 Report No.: EME-031034 Page 1 of 34 EMC TEST REPORT Report No. : EME-031034 Model No. : ZyAIR B-122 Issued Date : Sep. 15, 2003 Applicant : ZyXEL Communications Corporation No. 6, Innovation Rd II. Science-Based Industrial Park, Hsin-Chu, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 34 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result in this report only applies to the tested sample. Jerry Liu Project Engineer Reviewed By Elton Chen FCC ID. : I88B122 Report No.: EME-031034 Page 2 of 34 Table of Contents Summary of Tests..........................................................................................................3 1. General information..................................................................................................4 1.1 Identification of the EUT....................................................................................4 1.2 Additional information about the EUT................................................................4 1.3 Antenna description............................................................................................5 1.4 Peripherals equipment.........................................................................................5 2. Test specifications.....................................................................................................6 2.1 Test standard.......................................................................................................6 2.2 Operation mode..................................................................................................6 2.3 Test equipment....................................................................................................7 3. Minimum 6dB Bandwidth test...................................................................................8 3.1 Operating environment.......................................................................................8 3.2 Test setup & procedure........................................................................................8 3.3 Measured data of Minimum 6dB Bandwidth test results......................................8 4. Maximum Output Power test...................................................................................12 4.1 Operating environment.....................................................................................12 4.2 Test setup & procedure......................................................................................12 4.3 Measured data of Maximum Output Power test results......................................12 5. Radiated Emission test............................................................................................13 5.1 Operating environment.....................................................................................13 5.2 Test setup & procedure......................................................................................13 5.3 Emission limits.................................................................................................14 5.4 Radiated spurious emission test data.................................................................15 5.4.1 Measurement results: frequencies equal to or less than 1 GHz........................15 5.4.2 Measurement results: frequency above 1GHz.................................................16 6. Power Spectrum Density test...................................................................................19 6.1 Operating environment.....................................................................................19 6.2 Test setup & procedure......................................................................................19 6.3 Measured data of Power Spectrum Density test results......................................19 7. Emission on the band edge §FCC 15.247(C)...........................................................23 7.1 Band-edge (Conducted method)........................................................................24 7.2 Band-edge (Radiated method)...........................................................................26 8. Power Line Conducted Emission test §FCC 15.207.................................................30 8.1 Operating environment.....................................................................................30 8.2 Test setup & procedure......................................................................................30 8.3 Power Line Conducted Emission test data.........................................................32 FCC ID. : I88B122 Report No.: EME-031034 Page 3 of 34 Summary of Tests CardBus 11Mbps Wireless LAN Card-Model: ZyAIR B-122 FCC ID: I88B122 Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies FCC ID. : I88B122 Report No.: EME-031034 Page 4 of 34 1. General information 1.1 Identification of the EUT Applicant : ZyXEL Communications Corporation Product : CardBus 11Mbps Wireless LAN Card Model No. : ZyAIR B-122 FCC ID. : I88B122 Frequency Range : 2412~2462MHz Channel Number : 11channels Frequency of Each Channel : 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Type of Modulation : CCK (11Mbps, 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) Rated Power : 3.3Vdc Power Cord : N/A Sample Received : Sep. 8, 2003 Test Date(s) : Sep. 8, 2003 ~ Sep. 10, 2003 A FCC DoC report has been generated for the client. 1.2 Additional information about the EUT The ZyAIR B-122 is an 802.11b wireless LAN Cardb…

Text truncated - open the document above for the full version.

Photo 1: Conducted set-up photo Photo 2: Conducted set-up photo Photo 3: Conducted set-up photo

Photo 1: Spurious set-up photo Photo 2: Spurious set-up photo Photo 3: Spurious set-up photo
