I88NBG5715Simultaneous Dual-Band Wireless N Media Router

www.zyxel.com www.zyxel.com NBG5715 Simultaneous Dual-Band Wireless N Media Router Copyright © 2011 ZyXEL Communications Corporation Firmware Version 1.0 Edition 1, 3/2011 Default Login Details IP Addresshttp://192.168.1.1 Password1234 About This User's Guide NBG5715 User’s Guide 3 About This User's Guide Intended Audience This manual is intended for people who want to configure the NBG5715 using the Web Configurator. You should have at least a basic knowledge of TCP/IP networking concepts and topology. Tips for Reading User’s Guides On-Screen When reading a ZyXEL User’s Guide On-Screen, keep the following in mind: •If you don’t already have the latest version of Adobe Reader, you can download it from http:// www.adobe.com. •Use the PDF’s bookmarks to quickly navigate to the areas that interest you. Adobe Reader’s bookmarks pane opens by default in all ZyXEL User’s Guide PDFs. •If you know the page number or know vaguely which page-range you want to view, you can enter a number in the toolbar in Reader, then press [ENTER] to jump directly to that page. •Type [CTRL]+[F] to open the Adobe Reader search utility and enter a word or phrase. This can help you quickly pinpoint the information you require. You can also enter text directly into the toolbar in Reader. •To quickly move around within a page, press the [SPACE] bar. This turns your cursor into a “hand” with which you can grab the page and move it around freely on your screen. •Embedded hyperlinks are actually cross-references to related text. Click them to jump to the corresponding section of the User’s Guide PDF. Related Documentation •Quick Start Guide The Quick Start Guide is designed to help you get your NBG5715 up and running right away. It contains information on setting up your network and configuring for Internet access. •Support Disc Refer to the included CD for support documents. Documentation Feedback Send your comments, questions or suggestions to: [email protected] Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 30099, Taiwan. About This User's Guide NBG5715 User’s Guide 4 Need More Help? More help is available at www.zyxel.com. •Download Library Search for the latest product updates and documentation from this link. Read the Tech Doc Overview to find out how to efficiently use the User Guide, Quick Start Guide and Command Line Interface Reference Guide in order to better understand how to use your product. •Knowledge Base If you have a specific question about your product, the answer may be here. This is a collection of answers to previously asked questions about ZyXEL products. •Forum This contains discussions on ZyXEL products. Learn from others who use ZyXEL products and share your experiences as well. Customer Support Should problems arise that cannot be solved by the methods listed above, you should contact your vendor. If you cannot contact your vendor, then contact a ZyXEL office for the region in which you bought the device. See http://www.zyxel.com/web/contact_us.php for contact information. Please have the following information ready when you contact an office. •Product model and serial number. •Warranty Information. •Date that you received your device. Document Conventions NBG5715 User’s Guide 5 Document Conventions Warnings and Notes These are how warnings and notes are shown in this User’s Guide. Warnings tell you about things that could harm you or your device. Note: Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations. Syntax Conventions •The NBG5715 may be referred to as the “NBG5715”, the “device”, the “product” or the “system” in this User’s Guide. •Product labels, screen names, field labels and field choices are all in bold font. •A key stroke is denoted by square brackets and uppercase text, for example, [ENTER] means the “enter” or “return” key on your keyboard. •“Enter” means for you to type one or more characters and then press the [ENTER] key. “Select” or “choose” means for you to use one of the predefined choices. •A right angle bracket ( > ) within a screen name denotes a mouse click. For example, Maintenance > Log > Log Setting means you first click Maintenance in the navigation panel, then the Log sub menu and finally the Log Setting tab to get to that screen. •Units of measurement may denote the “metric” value or the “scientific” value. For example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000” or “1048576” and so on. •“e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”. Document Conventions NBG5715 User’s Guide 6 Icons Used in Figures Figures in this User’s Guide may use the following generic icons. The NBG5715 icon is not an exact representation of your device. NBG5715ComputerNotebook computer ServerDSLAMFirewall TelephoneSwitchRouter Modem Safety Warnings NBG5715 User’s Guide 7 Safety Warnings •Do NOT use this product near water, for example, in a wet basement or near a swimming pool. •Do NOT expose your device to dampness, dust or corrosive liquids. •Do NOT store things on the device. •Do NOT install, use, or service this device during a thunderstorm. There is a remote risk of electric shock from lightning. •Connect ONLY suitable accessories to the device. •Do NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. ONLY qualified service personnel should service or disassemble this device. Please contact your vendor for further information. •Make sure to connect the cables to the correct ports. •Place connecting cables carefully so that no one will step on them or stumble over them. •Always disconnect all cables from this device before servicing or disassembling. •Use ONLY an appropriate power adaptor or cord for your device. •Connect the power adaptor or cord to the right supply voltage (for e…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

Report No.: SA110421E04 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110421E04 MODEL NO.: NBG5715, HGW-501HN-M FCC ID: I88NBG5715 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 8 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110421E04 Report Format Version 4.0.0 2 TABLE OF CONTENTS RELEASE CONTROL RECORD....................................................................................3 1. CERTIFICATION..............................................................................................4 2. RF EXPOSURE LIMIT.....................................................................................5 3. MPE CALCULATION FORMULA.....................................................................5 4. CLASSIFICATION............................................................................................5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER...................6 Report No.: SA110421E04 Report Format Version 4.0.0 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA110421E04 Original release Aug. 03, 2011 Report No.: SA110421E04 Report Format Version 4.0.0 4 1. CERTIFICATION PRODUCT: Simultaneous Dual-Band Wireless N Media Router MODEL: NBG5715, HGW-501HN-M BRAND: ZyXEL, MitraStar APPLICANT: ZyXEL Communications Corporation TEST SAMPLE: MASS-PRODUCTION STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: NBG5715) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Aug. 03, 2011 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: Aug. 03, 2011 (May Chen, Deputy Manager ) Report No.: SA110421E04 Report Format Version 4.0.0 5 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 5. ANTENNA GAIN There are three antennas provided to this EUT, please refer to the following table: Transmitter Circuit Manufacturer Model name Peak Gain (Included Cable loss) Antenna Type Connecter Type Chain (0) 2.4G & 5G: 2dBi Dipole R-SMA Chain (1) 2.4G & 5G: 2dBi Dipole R-SMA Chain (2) ARISTOTLE RFA-25-C2M2-M10-1 2.4G & 5G: 2dBi Dipole R-SMA The EUT incorporates CDD function with 802.11a, 802.11b, 802.11g and MIMO function with 802.11n. Report No.: SA110421E04 Report Format Version 4.0.0 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): 802.11b: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 53.7 2 20 0.017 1.00 Directional gain = gain of antenna element + 10 log (# of TX antenna elements) Effective Legacy Gain (dBi)=6.5 802.11g: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 501.9 6.8 20 0.478 1.00 Directional gain = gain of antenna element + 10 log ( 3 ) Effective Legacy Gain (dBi)=6.8 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 483.6 2 20 0.152 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2422-2452 501.9 2 20 0.158 1.00 Report No.: SA110421E04 Report Format Version 4.0.0 7 For 15.247(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 275.7 6.8 20 0.263 1.00 Directional gain = gain of antenna element + 10 log ( 3 ) Effective Legacy Gain (dBi)=6.8 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 276.2 2 20 0.087 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5755 ~ 5795 280.2 2 20 0.088 1.00 Report No.: SA110421E04 Report Format Version 4.0.0 8 For 15.407(5GHz): 802.11a: FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 22.9 6.8 20 0.022 1.00 Directional gain = gain of antenna element + 10 log ( 3 ) Effective Legacy Gain (dBi)=6.8 802.11n(20MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 29.6 2 20 0.009 1.00 802.11n(40MHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTAN…

Text truncated - open the document above for the full version.

Report No.: RF110421E04 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF110421E04 MODEL NO.: NBG5715, HGW-501HN-M FCC ID: I88NBG5715 RECEIVED: Apr. 21, 2011 TESTED: Apr. 28 to May 12, 2011 ISSUED: Aug. 03, 2011 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 119 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110421E04 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD........................................................................................5 1. CERTIFICATION....................................................................................................6 2. SUMMARY OF TEST RESULTS............................................................................7 2.1 MEASUREMENT UNCERTAINTY..........................................................................9 3. GENERAL INFORMATION...................................................................................10 3.1 GENERAL DESCRIPTION OF EUT.....................................................................10 3.2 DESCRIPTION OF TEST MODES.......................................................................13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL........................14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................18 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................19 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................20 4. TEST TYPES AND RESULTS (802.11b & g, 2400 ~ 2483.5MHz Band)...............22 4.1 CONDUCTED EMISSION MEASUREMENT........................................................22 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................22 4.1.2 TEST INSTRUMENTS..........................................................................................22 4.1.3 TEST PROCEDURES..........................................................................................23 4.1.4 DEVIATION FROM TEST STANDARD.................................................................23 4.1.5 TEST SETUP.......................................................................................................24 4.1.6 EUT OPERATING CONDITIONS.........................................................................24 4.1.7 TEST RESULTS...................................................................................................25 4.2 RADIATED EMISSION MEASUREMENT.............................................................27 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................27 4.2.2 TEST INSTRUMENTS..........................................................................................28 4.2.3 TEST PROCEDURES..........................................................................................29 4.2.4 DEVIATION FROM TEST STANDARD.................................................................29 4.2.5 TEST SETUP.......................................................................................................30 4.2.6 EUT OPERATING CONDITIONS.........................................................................30 4.2.7 TEST RESULTS...................................................................................................31 4.3 6dB BANDWIDTH MEASUREMENT....................................................................60 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT..................................................60 4.3.2 TEST INSTRUMENTS..........................................................................................60 4.3.3 TEST PROCEDURE.............................................................................................60 4.3.4 DEVIATION FROM TEST STANDARD.................................................................60 4.3.5 TEST SETUP.......................................................................................................60 4.3.6 EUT OPERATING CONDITIONS.........................................................................60 4.3.7 TEST RESULTS...................................................................................................61 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................65 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.....................65 4.4.2 INSTRUMENTS....................................................................................................65 4.4.3 TEST PROCEDURES..........................................................................................65 Report No.: RF110421E04 3 Report Format Version 4.0.0 4.4.4 DEVIATION FROM TEST STANDARD.................................................................65 4.4.5 TEST SETUP.......................................................................................................65 4.4.6 EUT OPERATING CONDITIONS.........................................................................65 4.4.7 TEST RESULTS...................................................................................................66 4.5 POWER SPECTRAL DENSITY MEASU…

Text truncated - open the document above for the full version.

Report No.: RF110421E04-1 1 Report Format Version 4.0.0 FCC TEST REPORT (15.407) REPORT NO.: RF110421E04-1 MODEL NO.: NBG5715, HGW-501HN-M FCC ID: I88NBG5715 RECEIVED: Apr. 21, 2011 TESTED: Apr. 28 to May 12 ISSUED: Aug. 03, 2011 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 78 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110421E04-1 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD........................................................................................4 1. CERTIFICATION....................................................................................................5 2. SUMMARY OF TEST RESULTS............................................................................6 2.1 MEASUREMENT UNCERTAINTY..........................................................................7 3. GENERAL INFORMATION.....................................................................................8 3.1 GENERAL DESCRIPTION OF EUT.......................................................................8 3.2 DESCRIPTION OF TEST MODES.......................................................................11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.......................12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................15 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................16 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................17 4. TEST TYPES AND RESULTS..............................................................................19 4.1 CONDUCTED EMISSION MEASUREMENT........................................................19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................19 4.1.2 TEST INSTRUMENTS..........................................................................................19 4.1.3 TEST PROCEDURES..........................................................................................20 4.1.4 DEVIATION FROM TEST STANDARD.................................................................20 4.1.5 TEST SETUP.......................................................................................................21 4.1.6 EUT OPERATING CONDITIONS.........................................................................21 4.1.7 TEST RESULTS...................................................................................................22 4.2 RADIATED EMISSION MEASUREMENT.............................................................24 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................24 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS..........25 4.2.3 TEST INSTRUMENTS..........................................................................................26 4.2.4 TEST PROCEDURES..........................................................................................27 4.2.5 DEVIATION FROM TEST STANDARD.................................................................27 4.2.6 TEST SETUP.......................................................................................................28 4.2.7 EUT OPERATING CONDITION............................................................................28 4.2.8 TEST RESULTS...................................................................................................29 4.3 OUTPUT TRANSMIT POWER MEASUREMENT.................................................50 4.3.1 LIMITS OF OUTPUT TRANSMIT POWER MEASUREMENT...............................50 4.3.2 TEST INSTRUMENTS..........................................................................................50 4.3.3 TEST PROCEDURE.............................................................................................51 4.3.4 DEVIATION FROM TEST STANDARD.................................................................51 4.3.5 TEST SETUP.......................................................................................................51 4.3.6 EUT OPERATING CONDITIONS.........................................................................51 4.3.7 TEST RESULTS...................................................................................................52 4.4 PEAK POWER EXCURSION MEASUREMENT...................................................58 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT.................................58 4.4.2 TEST INSTRUMENTS..........................................................................................58 Report No.: RF110421E04-1 3 Report Format Version 4.0.0 4.4.3 TEST PROCEDURE.............................................................................................58 4.4.4 DEVIATION FROM TEST STANDARD.................................................................58 4.4.5 TEST SETUP.......................................................................................................59 4.4.6 EUT OPERATING CONDITIONS.........................................................................59 4.4.7 TEST RESULTS.........................................................…

Text truncated - open the document above for the full version.

Report No.: RF110421E04-2 1 Report Format Version 4.0.0 Supplemental “Transmit Simultaneously” Test Report REPORT NO.: RF110421E04-2 MODEL NO.: NBG5715, HGW-501HN-M FCC ID: I88NBG5715 RECEIVED: Apr. 21, 2011 TESTED: Sep. 09 to 15, 2011 ISSUED: Sep. 16, 2011 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110421E04-2 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD........................................................................................3 1. CERTIFICATION....................................................................................................4 2. SUMMARY OF TEST RESULTS............................................................................5 2.1 MEASUREMENT UNCERTAINTY..........................................................................5 3. GENERAL INFORMATION.....................................................................................6 3.1 GENERAL DESCRIPTION OF EUT.......................................................................6 3.2 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL:..........................9 3.3 DESCRIPTION OF SUPPORT UNITS..................................................................10 3.4 CONFIGURATION OF SYSTEM UNDER TEST...................................................11 4. TEST TYPES AND RESULTS..............................................................................13 4.1 CONDUCTED EMISSION MEASUREMENT........................................................13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................13 4.1.2 TEST INSTRUMENTS..........................................................................................13 4.1.3 TEST PROCEDURES..........................................................................................14 4.1.4 DEVIATION FROM TEST STANDARD.................................................................14 4.1.5 TEST SETUP.......................................................................................................15 4.1.6 EUT OPERATING CONDITIONS.........................................................................15 4.1.7 TEST RESULTS...................................................................................................16 4.2 RADIATED EMISSION MEASUREMENT.............................................................18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................18 4.2.2 TEST INSTRUMENTS..........................................................................................19 4.2.3 TEST PROCEDURES..........................................................................................20 4.2.4 DEVIATION FROM TEST STANDARD.................................................................20 4.2.5 TEST SETUP.......................................................................................................21 4.2.6 EUT OPERATING CONDITIONS.........................................................................21 4.2.7 TEST RESULTS...................................................................................................22 5. INFORMATION ON THE TESTING LABORATORIES..........................................24 Report No.: RF110421E04-2 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF110421E04-2 Original release Sep. 16, 2011 Report No.: RF110421E04-2 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT : Simultaneous Dual-Band Wireless N Media Router BRAND NAME : ZyXEL, MitraStar MODEL NO. : NBG5715, HGW-501HN-M TEST ITEM: MASS-PRODUCTION APPLICANT : ZyXEL Communications Corporation TESTED: Sep. 09 to 15, 2011 STANDARDS : FCC Part 15, Subpart C (Section 15.247) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment (Model: NBG5715) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 16, 2011 ( Phoenix Huang, Specialist ) APPROVED BY : , DATE: Sep. 16, 2011 (May Chen, Deputy Manager ) Report No.: RF110421E04-2 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Section Test Type and Limit Result Remark 15.207 AC Power Conducted Emission PASS Meet the requirement of limit. Minimum passing margin is -21.71dB at 0.184MHz 15.247(d) Radiated Emissions Limit: Table 15.209 PASS Meet the requirement of limit Minimum passing margin is -0.60 dB at 1624.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty repre…

Text truncated - open the document above for the full version.
