I88NBG6503Simultaneous Dual-Band Wireless AC750 Home Router

Quick Start Guide www.zyxel.com NBG6503 Simultaneous Dual-band Wireless AC750 Home Router Version 1.00 Edition 1, 04/2013 Copyright © 2013 ZyXEL Communications Corporation User’s Guide Default Details LAN IP Address - Router Mode (Default mode) http://192.168.1.1 - AP Modehttp://192.168.1.2 User Nameadmin Password1234 SSIDZyXEL Pre-shared Key00000000 NBG6503 User’s Guide2 IMPORTANT! READ CAREFULLY BEFORE USE. KEEP THIS GUIDE FOR FUTURE REFERENCE. Related Documentation •Quick Start Guide The Quick Start Guide shows how to connect the NBG6503 and access the Web Configurator wizards. It also contains a connection diagram and package contents list. Note: It is recommended you use the Web Configurator to configure the NBG6503. Contents Overview NBG6503 User’s Guide 3 Contents Overview User’s Guide ....................................................................................................................................... 13 Getting to Know Your Router ..................................................................................................................15 Connection Wizard ..................................................................................................................................21 Introducing the Web Configurator ...........................................................................................................31 Monitor ....................................................................................................................................................37 Router Modes ..........................................................................................................................................43 Easy Mode ..............................................................................................................................................45 Router Mode ...........................................................................................................................................57 Access Point Mode .................................................................................................................................65 Tutorials ..................................................................................................................................................73 Technical Reference .......................................................................................................................... 81 Wireless LAN ..........................................................................................................................................83 WAN ........................................................................................................................................................99 LAN .......................................................................................................................................................109 DHCP Server ........................................................................................................................................ 113 Network Address Translation (NAT) ...................................................................................................... 117 Dynamic DNS ........................................................................................................................................123 Static Route ...........................................................................................................................................125 Firewall ..................................................................................................................................................129 Content Filter .........................................................................................................................................133 Bandwidth Management .......................................................................................................................137 Remote Management ............................................................................................................................145 Universal Plug-and-Play (UPnP) ...........................................................................................................147 Maintenance ..........................................................................................................................................155 Troubleshooting ....................................................................................................................................165 Contents Overview NBG6503 User’s Guide 4 Table of Contents NBG6503 User’s Guide 5 Table of Contents Contents Overview .............................................................................................................................. 3 Table of Contents ................................................................................................................................. 5 Part I: User’s Guide ......................................................................................... 13 Chapter 1 Getting to Know Your Router............................................................................................................. 15 1.1 Overview ...........................................................................................................................................15 1.2 Applications .......................................................................................................................................15 1.3 Ways to Manage the Router .............................................................................................................15 1.4 Good Habits for Managing the Router ..............................................................................................16 1.5 LEDs .................................................................................................................................................17 1.6 The…

Text truncated - open the document above for the full version.

Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 1 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Photographs of EUT Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 2 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 3 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Ant. 1 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 4 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Ant. 2 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 5 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Power Adapter Model No. DSA-12G-12 FUS 120120 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 6 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255

:M74-ZYL09-672 :56X85mm :+ () :M74-ZYL09-612 4.78 4.78 產品名稱:無線AC 750同步雙頻家用寬頻分享器 NBG6503 I88NBG6503IC:2468C-NBG6503 5.65mm 8.101mm 5mm 5mm7.006mm 5mm5mm 6.377mm 7.075mm 5mm Connectto power adapterConnectto broadband modem Connectto PC

Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 1 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Photographs of EUT Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 2 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 3 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 4 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 5 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255 Report No.: 331410-02 SPORTON International Inc. PAGE NUMBER : 6 OF 6 TEL : 886-2-2696-2468 ISSUED DATE : May. 28, 2013 FAX : 886-2-2696-2255

Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Average RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : B3 of B3 1.3. Calculated Result and Limit For 5GHz UNII Band: Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11n HT40 : 16.96 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2.00 1.5849 16.9600 49.6592 0.015666 1 Complies For 5GHz ISM Band: Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11n HT40: 22.66 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2.00 1.5849 22.6600 184.5015 0.058204 1 Complies For 2.4GHz Band: Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11n HT20: 25.96 dBm Antenna Gain (dBi) Antenna Gain (numeric) Average Output Power (dBm) Average Output Power (mW) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2.00 1.5849 25.9629 394.7199 0.124520 1 Complies CONCULSION: Both of the WLAN 2.4GHz Band and WLAN 5GHz Band can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.058204 / 1 + 0.124520 / 1 = 0.182724, which isless than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : C1 of C3 Appendix C. Co-location Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : C2 of C3 1. Results of Radiated Emissions for Co-located Temperature 25.6°C Humidity 56% Test Engineer Andre Zhuo Configurations 2.4G + 5G Normal Link Horizontal Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : C3 of C3 Vertial

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company ZyXEL Communications Corporation Applicant Address No. 2, Gongye E. 9th Rd., East Dist., Hsinchu City 300, Taiwan(R.O.C.) FCC ID I88NBG6503 Manufacturer’s company ZyXEL Communications Corporation Manufacturer Address No. 2, Gongye E. 9th Rd., East Dist., Hsinchu City 300, Taiwan(R.O.C.) Product Name Simultaneous Dual-Band Wireless AC750 Home Router Brand Name ZyXEL Model No. NBG6503 Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz / 5725 ~ 5850MHz Received Date Jan. 30, 2013 Final Test Date May 11, 2013 Submission Type Original Equipment Statement Test result included is only for the IEEE 802.11n, IEEE 802.11b/g part and IEEE 802.11a/ac (5725 ~ 5850MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009, 47 CFR FCC Part 15 Subpart C, KDB 558074 D01 v03 and KDB 662911 D01 v01r02. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR331410-02AA Report Format Version: 01 Page No. : i of ii FCC ID: I88NBG6503 Issued Date : May 28, 2013 Table of Contents 1. CERTIFICATE OF COMPLIANCE.......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT........................................................................................................................... 2 3. GENERAL INFORMATION................................................................................................................................... 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories.........................................................................................................................................................................................5 3.3. Table for Filed Antenna.......................................................................................................................................................................6 3.4. Table for Carrier Frequencies...............................................................................................................................................................7 3.5. Table for Test Modes............................................................................................................................................................................8 3.6. Table for Testing Locations.................................................................................................................................................................10 3.7. Table for Supporting Units..................................................................................................................................................................10 3.8. Table for Parameters of Test Software Setting.....................................................................................................................................11 3.9. EUT Operation during Test..................................................................................................................................................................12 3.10. Test Configurations............................................................................................................................................................................13 4. TEST RESULT.................................................................................................................................................... 15 4.1. AC Power Line Conducted Emissions Measurement..........................................................................................................................15 4.2. Maximum Conducted Output Power Measurement.........................................................................................................................19 4.3. Power Spectral Density Measurement...............................................................................................................................................22 4.4. 6dB Spectrum Bandwidth Measurement...........................................................................................................................................31 4.5. Radiated Emissions Measurement.....................................................................................................................................................39 4.6. Emissions Measurement....................................................................................................................................................................66 4.7. Antenna Requirements......................................................................................................................................................................91 5. LIST OF MEASURING EQUIPMENTS.................................................................................................................... 92 6. TEST LOCATION.............................................................................................................................................. 94 APPENDIX A. TEST PHOTOS ............................................................................................................................ A1 ~ A5 APPENDIX B. MAXIMUM PERMISSIBLE …

Text truncated - open the document above for the full version.

Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : A1 of A5 Appendix A. Test Photos Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : A2 of A5 1. Photographs of Conducted Emissions Test Configuration Test Mode: Mode 1 FRONT VIEW REAR VIEW Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : A3 of A5 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : A4 of A5 Test Configuration: 30MHz~1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW Report No.: FR331410-02 FCC ID: I88NBG6503 Page No. : A5 of A5 Test Configuration: Above 1GHz / Test Mode: Mode 1 FRONT VIEW REAR VIEW
