I88NWD2105Wireless N-lite USB Adapter

www.zyxel.com www.zyxel.com NWD2105 Wireless N-lite USB Adapter Copyright © 2010 ZyXEL Communications Corporation Version 1.0 Edition 1, 05/2010 About This User's Guide NWD2105 User’s Guide 3 About This User's Guide Intended Audience This manual is intended for people who want to configure the NWD2105 using the ZyXEL utility. Tips for Reading User’s Guides On-Screen When reading a ZyXEL User’s Guide On-Screen, keep the following in mind: •If you don’t already have the latest version of Adobe Reader, you can download it from http://www.adobe.com. •Use the PDF’s bookmarks to quickly navigate to the areas that interest you. Adobe Reader’s bookmarks pane opens by default in all ZyXEL User’s Guide PDFs. •If you know the page number or know vaguely which page-range you want to view, you can enter a number in the toolbar in Reader, then press [ENTER] to jump directly to that page. •Type [CTRL]+[F] to open the Adobe Reader search utility and enter a word or phrase. This can help you quickly pinpoint the information you require. You can also enter text directly into the toolbar in Reader. •To quickly move around within a page, press the [SPACE] bar. This turns your cursor into a “hand” with which you can grab the page and move it around freely on your screen. •Embedded hyperlinks are actually cross-references to related text. Click them to jump to the corresponding section of the User’s Guide PDF. Related Documentation •Quick Start Guide The Quick Start Guide is designed to help you get up and running right away. It contains information on setting up your network and configuring for Internet access. •Online Help Embedded web help for descriptions of individual screens and supplementary information. •Support Disc Refer to the included CD for support documents. Documentation Feedback Send your comments, questions or suggestions to: [email protected] About This User's Guide NWD2105 User’s Guide 4 Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 30099, Taiwan. Need More Help? More help is available at www.zyxel.com . •Download Library Search for the latest product updates and documentation from this link. Read the Tech Doc Overview to find out how to efficiently use the documentation in order to better understand how to use your product. •Knowledge Base If you have a specific question about your product, the answer may be here. This is a collection of answers to previously asked questions about ZyXEL products. •Forum This contains discussions on ZyXEL products. Learn from others who use ZyXEL products and share your experiences as well. Customer Support Should problems arise that cannot be solved by the methods listed above, you should contact your vendor. If you cannot contact your vendor, then contact a ZyXEL office for the region in which you bought the device. See http://www.zyxel.com/web/contact_us.php for contact information. Please have the following information ready when you contact an office. •Product model and serial number. •Warranty Information. •Date that you received your device. •Brief description of the problem and the steps you took to solve it. Document Conventions NWD2105 User’s Guide 5 Document Conventions Warnings and Notes These are how warnings and notes are shown in this User’s Guide. Warnings tell you about things that could harm you or your NWD2105. Note: Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations. Syntax Conventions •The NWD2105 may be referred to as the “NWD2105”, the “device”, the “system” or the “product” in this User’s Guide. •Product labels, screen names, field labels and field choices are all in bold font. •A key stroke is denoted by square brackets and uppercase text, for example, [ENTER] means the “enter” or “return” key on your keyboard. •“Enter” means for you to type one or more characters and then press the [ENTER] key. “Select” or “choose” means for you to use one of the predefined choices. •A right angle bracket ( > ) within a screen name denotes a mouse click. For example, Maintenance > Log > Log Setting means you first click Maintenance in the navigation panel, then the Log sub menu and finally the Log Setting tab to get to that screen. •Units of measurement may denote the “metric” value or the “scientific” value. For example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000” or “1048576” and so on. •“e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”. Document Conventions NWD2105 User’s Guide 6 Icons Used in Figures Figures in this User’s Guide may use the following generic icons. Wireless Access PointComputerNotebook computer ServerModemTelephone InternetWireless Signal Safety Warnings NWD2105 User’s Guide 7 Safety Warnings •Do NOT use this product near water, for example, in a wet basement or near a swimming pool. •Do NOT expose your device to dampness, dust or corrosive liquids. •Do NOT store things on the device. •Do NOT install, use, or service this device during a thunderstorm. There is a remote risk of electric shock from lightning. •Connect ONLY suitable accessories to the device. •Ground yourself (by properly using an anti-static wrist strap, for example) whenever working with the device’s hardware or connections. •ONLY qualified service personnel should service or disassemble this device. •Antenna Warning! This device meets ETSI and FCC certification requirements when using the included antenna(s). Only use the included antenna(s). Your product is marked with this symbol, which is known as the WEEE mark. WEEE stands for Waste Electronics and Electrical Equipment. It means that used electrical and electronic products should not be mixed with general waste. Used electrical and electronic equipment should be treated separately. Safety Warnings NWD2105 User’s Guide 8 Contents Overview NWD2105 User’s Guide 9 Content…

Text truncated - open the document above for the full version.

Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 111 5Select Internet Protocol Version 4 (TCP/IPv4) and then select Properties. Figure 80 Windows 7: Local Area Connection Properties Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 112 6The Internet Protocol Version 4 (TCP/IPv4) Properties window opens. Figure 81 Windows 7: Internet Protocol Version 4 (TCP/IPv4) Properties 7Select Obtain an IP address automatically if your network administrator or ISP assigns your IP address dynamically. Select Use the following IP Address and fill in the IP address,Subnet mask, andDefault gateway fields if you have a static IP address that was assigned to you by your network administrator or ISP. You may also have to enter a Preferred DNS server and an AlternateDNS server, if that information was provided. ClickAdvanced if you want to configure advanced settings for IP, DNS and WINS. 8ClickOK to close the Internet Protocol (TCP/IP) Properties window. 9ClickOK to close the Local Area Connection Properties window. Verifying Settings 1ClickStart > All Programs > Accessories > Command Prompt. 2In the Command Prompt window, type "ipconfig" and then press [ENTER]. Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 113 3The IP settings are displayed as follows. Figure 82 Windows 7: Internet Protocol Version 4 (TCP/IPv4) Properties Mac OS X: 10.3 and 10.4 The screens in this section are from Mac OS X 10.4 but can also apply to 10.3. 1ClickApple > System Preferences. Figure 83 Mac OS X 10.4: Apple Menu Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 114 2In the System Preferences window, click the Networkicon. Figure 84 Mac OS X 10.4: System Preferences 3When the Network preferences pane opens, select Built-in Ethernet from the network connection type list, and then click Configure. Figure 85 Mac OS X 10.4: Network Preferences Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 115 4For dynamically assigned settings, select Using DHCP from the Configure IPv4 list in the TCP/IP tab. Figure 86 Mac OS X 10.4: Network Preferences > TCP/IP Tab. 5For statically assigned settings, do the following: •From the Configure IPv4 list, select Manually. •In the IP Address field, type your IP address. •In the Subnet Mask field, type your subnet mask. Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 116 •In the Router field, type the IP address of your device. Figure 87 Mac OS X 10.4: Network Preferences > Ethernet 6ClickApply Now and close the window. Verifying Settings Check your TCP/IP properties by clicking Applications > Utilities > Network Utilities, and then selecting the appropriate Network Interface from the Info tab. Figure 88 Mac OS X 10.4: Network Utility Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 117 Mac OS X: 10.5 and 10.6 The screens in this section are from Mac OS X 10.5 but can also apply to 10.6. 1ClickApple > System Preferences. Figure 89 Mac OS X 10.5: Apple Menu 2InSystem Preferences, click the Network icon. Figure 90 Mac OS X 10.5: Systems Preferences Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 118 3When the Network preferences pane opens, select Ethernet from the list of available connection types. Figure 91 Mac OS X 10.5: Network Preferences > Ethernet 4From the Configure list, select Using DHCP for dynamically assigned settings. 5For statically assigned settings, do the following: •From the Configure list, select Manually. •In the IP Address field, enter your IP address. •In the Subnet Mask field, enter your subnet mask. Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 119 •In the Router field, enter the IP address of your NWD2105. Figure 92 Mac OS X 10.5: Network Preferences > Ethernet 6ClickApply and close the window. Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 120 Verifying Settings Check your TCP/IP properties by clicking Applications > Utilities > Network Utilities, and then selecting the appropriate Network interface from the Info tab. Figure 93 Mac OS X 10.5: Network Utility Linux: Ubuntu 8 (GNOME) This section shows you how to configure your computer’s TCP/IP settings in the GNU Object Model Environment (GNOME) using the Ubuntu 8 Linux distribution. The procedure, screens and file locations may vary depending on your specific distribution, release version, and individual configuration. The following screens use the default Ubuntu 8 installation. Note: Make sure you are logged in as the root administrator. Follow the steps below to configure your computer IP address in GNOME: Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 121 1ClickSystem > Administration > Network. Figure 94 Ubuntu 8: System > Administration Menu 2When the Network Settings window opens, click Unlock to open the Authenticate window. (By default, the Unlock button is greyed out until clicked.) You cannot make changes to your configuration unless you first enter your admin password. Figure 95 Ubuntu 8: Network Settings > Connections Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 122 3In the Authenticate window, enter your admin account name and password then click the Authenticate button. Figure 96 Ubuntu 8: Administrator Account Authentication 4In the Network Settings window, select the connection that you want to configure, then click Properties. Figure 97 Ubuntu 8: Network Settings > Connections Appendix ASetting Up Your Computer’s IP Address NWD2105 User’s Guide 123 5The Properties dialog box opens. Figure 98 Ubuntu 8: Network Settings > Properties •In the Configuration list, select Automatic Configuration (DHCP) if you have a dynamic IP address. •In the Configuration list, select Static IP address if you have a static IP address. Fill in the IP address,Subnet mask, and Gateway address fields. 6ClickOK to save the changes and close the Properties dialog box and return to the Net…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: I88NWD2105 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, __________________________________ Wang Yi EMC/Safety Engineering Section ZyXEL Communications Corporation 2010/5/14

General Declaration We, ZyXEL Communications Corporation, located at No.6, Innovation Rd II, Science-Park, Hsin-Chu, 300, Taiwan, R.O.C, declares that device does not have “Ad Hoc on non-US frequencies” while applying for the follow product. FCC ID: I88NWD2105 If you have any question regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, __________________________________ Wang Yi EMC/Safety Engineering Section 2010/5/14

Power of Attorney To whom it may concern: We, ZyXEL Communications Corporation, located at No.6, Innovation Rd II, Science- Park, Hsin-Chu, 300, Taiwan, R.O.C, hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. FCC ID: I88NWD2105 If you have question regarding the authorization or need further information, please don’t hesitate to contact us Thank you! Sincerely yours, __________________________________ Wang Yi EMC/Safety Engineering Section 2010/5/14

Page 1 CONSTRUCTION PHOTOS OF EUT

Label Location FCC ID: I88NWD2105

Page 2 Page 3

FCC ID: I88NWD2105 Report No.: RF990210H04A Operational Description This device is a Wireless N-lite USB Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 150Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 150Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is chip antenna without antenna connector. The other instruction, please have a look at the users manual.

D2: DOSIMETRIC E-FIELD PROBE D3: DAE

D4: SYSTEM VALIDATION DIPOLE

Report No.: SA990210H04A 1 Report Format Version 3.0.1 Reference no.: 990429E03 SAR TEST REPORT REPORT NO.: SA990210H04A MODEL NO.: NWD2105 RECEIVED: Apr. 29, 2010 TESTED: May 06, 2010 ISSUED: May 10, 2010 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 23 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: SA990210H04A 2 Report Format Version 3.0.1 Reference no.: 990429E03 TABLE OF CONTENTS 1. CERTIFICATION .............................................................................................................. 3 2. GENERAL INFORMATION .............................................................................................. 4 2.1 GENERAL DESCRIPTION OF EUT................................................................................. 4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................. 5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ........................................................ 6 2.4 TEST EQUIPMENT .......................................................................................................... 9 2.5 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................... 10 3. DESCRIPTION OF SUPPORT UNITS........................................................................... 13 4. DESCRIPTION OF TEST MODES AND CONFIGURATIONS ....................................... 14 4.1. DESCRIPTION OF TEST CONDITION.......................................................................... 14 5. TEST RESULTS ............................................................................................................. 15 5.1 TEST PROCEDURES .................................................................................................... 15 5.2 SAR LIMITS ................................................................................................................... 16 5.3 MEASURED SAR RESULT............................................................................................ 16 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ........................................................... 17 6. SYSTEM VALIDATION................................................................................................... 20 6.1 TEST PROCEDURE ...................................................................................................... 20 6.2 VALIDATION RESULTS ................................................................................................. 21 6.3 SYSTEM VALIDATION UNCERTAINTIES ..................................................................... 22 7. INFORMATION ON THE TESTING LABORATORIES ................................................... 23 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA990210H04A 3 Report Format Version 3.0.1 Reference no.: 990429E03 1. CERTIFICATION PRODUCT: Wireless N-lite USB Adapter MODEL: NWD2105 BRAND: ZyXEL APPLICANT: ZyXEL Communications Corporation TESTED: May 06, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) RSS-102 The above equipment (model: NWD2105) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :May 10, 2010 Joanna Wang / Senior Specialist TECHNICAL ACCEPTANCE : , DATE :May 10, 2010 Responsible for RF Mason Chang / Engineer APPROVED BY : , DATE :May 10, 2010 Gary Chang / Assistant Manager Report No.: SA990210H04A 4 Report Format Version 3.0.1 Reference no.: 990429E03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT EUT Wireless N-lite USB Adapter MODEL NO. NWD2105 FCC ID I88NWD2105 POWER SUPPLY 5Vdc from host equipment MODULATION TYPE CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM MODULATION TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b: 11 / 5.5 / 2 / 1Mbps 802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6Mbps 802.11n (20MHz, 800ns GI): 65 / 58.5 / 52 / 39 / 26 / 19.5 / 13 / 6.5Mbps 802.11n (40MHz, 800ns GI): 135 / 121.5 / 108 / 81 / 54 / 40.5 / 27 / 13.5Mbps 802.11n (20MHz, 400ns GI): 72.2 / 65 / 57.8 / 43.3 / 28.9 / 21.7 / 14.4 / 7.2Mbps 802.11n (40MHz, 400ns GI): 150 / 135 / 120 / 90 / 60 / 45 / 30 / 15Mbps OPERATING FREQUENCY 2412 ~ 2462MHz NUMBER OF CHANNEL 11 for 802.11b, 802.11g, 802.11n (20MHz) 7 for 802.11n (40MHz) CONDUCTED POWER (dBm) CHANNEL FREQUENCY (MHz) PEAK AVERAGE 802.11b 1 2412 20.1 17.6 6 2437 19.7 17.3 11 2462 19.9 17.4 802.11g 1 2412 23.3 13.4 6 2437 23.2 13.7 11 2462 22.8 13.4 802.11n (20MHz) 1 2412 23.6 13.6 6 2437 23.4 13.5 11 2462 22.5 13.5 802.11n (40MHz) 1 2422 22.9 13.4 4 2437 23.0 13.7 CHANNEL FREQUENCIES UNDER TEST AND ITS CONDUCTED OUTPUT POWER 7 2452 22.9 13.6 Report No.: SA990210H04A 5 Report Format Version 3.0.1 Reference no.: 990429E03 MAXIMUM SAR (1g) 0.733W/kg ANTENNA TYPE Chip antenna without connector (Antenna Gain: 3.1dBi) DATA CABLE NA I/O PORTS NA ACCESSORY DEVICES…

Text truncated - open the document above for the full version.

Report No.: RF990210H04A 1 Report Format Version 3.0.1 Reference No.: 990429E03 FCC TEST REPORT REPORT NO.: RF990210H04A MODEL NO.: NWD2105 RECEIVED: Feb. 10, 2010 TESTED: Feb. 15 to 25, 2010 ISSUED: May 18, 2010 APPLICANT: ZyXEL Communications Corporation ADDRESS: No. 6, Innovation Road II, Science-Park, Hsin-Chu, 300, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 75 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990210H04A 2 Report Format Version 3.0.1 Reference No.: 990429E03 Table of Contents 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY................................................................6 3. GENERAL INFORMATION...........................................................................7 3.1 GENERAL DESCRIPTION OF EUT..............................................................7 3.2 DESCRIPTION OF TEST MODES................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..............10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................12 3.4 DESCRIPTION OF SUPPORT UNITS........................................................13 3.5 CONFIGURATION OF SYSTEM UNDER TEST.........................................13 4. TEST TYPES AND RESULTS.....................................................................14 4.1 CONDUCTED EMISSION MEASUREMENT..............................................14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................14 4.1.2 TEST INSTRUMENTS................................................................................14 4.1.3 TEST PROCEDURES.................................................................................15 4.1.4 DEVIATION FROM TEST STANDARD.......................................................15 4.1.5 TEST SETUP..............................................................................................16 4.1.6 EUT OPERATING CONDITIONS................................................................16 4.1.7 TEST RESULTS..........................................................................................17 4.2 RADIATED EMISSION MEASUREMENT...................................................19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................19 4.2.2 TEST INSTRUMENTS................................................................................20 4.2.3 TEST PROCEDURES.................................................................................21 4.2.4 DEVIATION FROM TEST STANDARD.......................................................21 4.2.5 TEST SETUP..............................................................................................22 4.2.6 EUT OPERATING CONDITIONS................................................................22 4.2.7 TEST RESULTS..........................................................................................23 4.3 6dB BANDWIDTH MEASUREMENT..........................................................52 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................52 4.3.2 TEST INSTRUMENTS................................................................................52 4.3.3 TEST PROCEDURE...................................................................................52 4.3.4 DEVIATION FROM TEST STANDARD.......................................................52 4.3.5 TEST SETUP..............................................................................................52 4.3.6 EUT OPERATING CONDITIONS................................................................52 4.3.7 TEST RESULTS..........................................................................................53 4.4 MAXIMUM PEAK OUTPUT POWER..........................................................57 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........57 Report No.: RF990210H04A 3 Report Format Version 3.0.1 Reference No.: 990429E03 4.4.2 INSTRUMENTS..........................................................................................57 4.4.3 TEST PROCEDURES.................................................................................57 4.4.4 DEVIATION FROM TEST STANDARD.......................................................57 4.4.5 TEST SETUP..............................................................................................57 4.4.6 EUT OPERATING CONDITIONS................................................................57 4.4.7 TEST RESULTS..........................................................................................58 4.5 POWER SPECTRAL DENSITY MEASUREMENT......................................60 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT...................60 4.5.2 TEST INSTRUMENTS................................................................................60 4.5.3 TEST PROCEDURE...................................................................................60 4.5.4 DEVIATION FROM TEST STANDARD.......................................................60 4.5.5 TEST SETUP..............................................................................................60 4.5.6 EUT OPERATING CONDITION..................................................................60 4.5.7 TEST RESULTS..................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (SAR Test Set Up Photos) Horizontal-Up Horizontal-Down Vertical-Front Vertical-Back Tip Test Setup Photo NOTE: The EUT face to the phantom with 5mm-separation distance. EUT 2 DESCRIPTION OF ANTENNA LOCATION:

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
