  1. Home/
  2. ZyXEL Communications Corporation/
  3. I88P330W

I88P330W802.11g Wireless Broadband Router

ZyXEL Communications Corporation
802.11g Wireless Broadband Router - FCC ID I88P330W - ZyXEL Communications Corporation
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Jul 26, 2007
Application Purpose
Original Equipment
Date of Application
Jul 26, 2007
Equipment Note
802.11g Wireless Broadband Router
Frequency Range
2412.00000000 - 2462.00000000
Company
ZyXEL Communications Corporation
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Multi-Function 802.11b+g Wireless Router 802.11g/802.11b Wireless Access Point Broadband Internet Access 4-Port Switching Hub User’s Manual Table of Contents INTRODUCTION ............................................................................................................... 2 Wireless Router Features............................................................................................. 2 Package Contents ......................................................................................................... 4 Physical Details ............................................................................................................ 5 INSTALLATION................................................................................................................. 7 Requirements ............................................................................................................... 7 Procedure ..................................................................................................................... 7 SETUP.................................................................................................................................. 9 Overview....................................................................................................................... 9 Configuration Program................................................................................................ 9 Setup Wizard.............................................................................................................. 11 Configuration via Web ............................................................................................... 13 PC CONFIGURATION..................................................................................................... 33 Overview..................................................................................................................... 33 Windows Clients......................................................................................................... 33 Macintosh Clients....................................................................................................... 45 Linux Clients .............................................................................................................. 45 Other Unix Systems.................................................................................................... 45 Wireless Station Configuration.................................................................................. 46 APPENDIX A TROUBLESHOOTING .............................................................. 47 Overview..................................................................................................................... 47 General Problems....................................................................................................... 47 Internet Access ........................................................................................................... 47 Wireless Access .......................................................................................................... 48 APPENDIX B ABOUT WIRELESS LANS ........................................................ 49 Modes ......................................................................................................................... 49 BSS/ESS...................................................................................................................... 49 Channels ..................................................................................................................... 49 WEP............................................................................................................................ 50 Wireless LAN Configuration ..................................................................................... 50 APPENDIX C SPECIFICATIONS ................................................................................... 51 Multi-Function Wireless Router ................................................................................ 51 Wireless Interface ...................................................................................................... 51 Regulatory Approvals ................................................................................................ 52 2      This Chapter provides an overview of the Wireless Router's features and capabilities. Congratulations on the purchase of your new Wireless Router. The Wireless Router is a multi- function device providing the following services:  Shared Broadband Internet Access for all LAN users.  4-Port Switching Hub for 10BaseT or 100BaseT connections.  Wireless Access Point for 802.11b and 802.11g Wireless Stations. Wireless Router Features The Wireless Router incorporates many advanced features, carefully designed to provide sophisticated functions while being easy to use. Internet Access Features  Shared Internet Access. All users on the LAN or WLAN can access the Internet through the Wireless Router, using only a single external IP Address. The local (invalid) IP Addresses are hidden from external sources. This process is called NAT (Network Address Translation).  DSL & Cable Modem Support. The Wireless Router has a 10/100BaseT Ethernet port for connecting a DSL or Cable Modem. All popular DSL and Cable Modems are supported. SingTel RAS and Big Pond (Australia) login support is also included.  PPPoE, and PPTP. The Internet (WAN port) connection supports PPPoE (PPP over Ethernet), PPTP (Peer-to-Peer Tunneling Protocol), as well as "Direct Connection" type services. Unnumbered IP with PPPoE is also supported.  Fixed or Dynamic IP Address. On the Internet (WAN port) connection, the Wireless Router supports both Dynamic IP Address (IP Address is allocated on connection) and Fixed IP Address. Introduction 3 Advanced Internet Functions  Communication Applications. Support for Internet communication applications, …

Text truncated - open the document above for the full version.

External Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A6 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A7 OF A7 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255

ID Label/Location Info

59mm 39mm

Internal Photos

SPORTON International Inc. PAGE NUMBER : A1 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 APPENDIX A. Photographs of EUT SPORTON International Inc. PAGE NUMBER : A2 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A3 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A4 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255 SPORTON International Inc. PAGE NUMBER : A5 OF A5 TEL : 886-2-2696-2468 ISSUED DATE : Jul. 24, 2007 FAX : 886-2-2696-2255

RF Exposure Info

Report No.: FR752310-01 FCC ID: I88P330W Page No. : 1 of 3 Appendix C. Maximum Permissible Exposure Report No.: FR752310-01 FCC ID: I88P330W Page No. : 2 of 3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) = d GP××30 Power Density: Pd (W/m²) = 377 2 E E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 377 30 d GP × ×× From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR752310-01 FCC ID: I88P330W Page No. : 3 of 3 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11b/g : 19.04dBm Antenna Gain (dBi) Antenna Gain (numeric) Peak Output Power (dBm) Peak Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 2 1.5849 19.0400 80.1678 0.025290 1 Complies

Test Report

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company ZyXEL Communications Corporation Applicant Address No. 6, Innovation Road II, Science Park, Hsin-Chu, Taiwan FCC ID I88P330W Manufacturer’s company ZyXEL Communications Corporation Manufacturer Address No. 6, Innovation Road II, Science Park, Hsin-Chu, Taiwan Product Name 802.11g Wireless Broadband Router Brand Name ZyXEL Model Name P-330W Test Rule 47 CFR FCC Part 15 Subpart C § 15.247 Test Freq. Range 2400 ~ 2483.5MHz Received Date Mar. 27, 2007 Final Test Date Jun. 01, 2007 Submission Type Original Equipment Statement Test result included is only for the 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR752310-01 Report Format Version: 01 Page No. : i of ii FCC ID: I88P330W Issued Date : Jul. 24, 2007 Table of Contents 1. CERTIFICATE OF COMPLIANCE ......................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................3 3.3. Table for Filed Antenna.......................................................................................................................................................................3 3.4. Table for Carrier Frequencies .............................................................................................................................................................3 3.5. Table for Test Modes ...........................................................................................................................................................................4 3.6. Table for Testing Locations..................................................................................................................................................................4 3.7. Table for Supporting Units ...................................................................................................................................................................4 3.8. Table for Parameters of Test Software Setting .....................................................................................................................................5 3.9. Test Configurations .............................................................................................................................................................................6 4. TEST RESULT ..................................................................................................................................................... 8 4.1. AC Power Line Conducted Emissions Measurement...........................................................................................................................8 4.2. Maximum Peak Output Power Measurement ...................................................................................................................................12 4.3. Power Spectral Density Measurement ..............................................................................................................................................14 4.4. 6dB Spectrum Bandwidth Measurement ..........................................................................................................................................19 4.5. Radiated Emissions Measurement ....................................................................................................................................................24 4.6. Band Edge Emissions Measurement .................................................................................................................................................42 4.7. Antenna Requirements .....................................................................................................................................................................49 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 50 6. TEST LOCATION.............................................................................................................................................. 52 7. TAF CERTIFICATE OF ACCREDITATION ............................................................................................................. 53 APPENDIX A. PHOTOGRAPHS OF EUT.........................................................................................................A1 ~ A12 APPENDIX B. TEST PHOTOS.......................................................................................................................... B1 ~ B5 APPENDIX C. MAXIMUM PERMISSIBLE EXPOSURE....................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: FR752310-01 FCC ID: I88P330W Page No. : 1 of 5 Appendix B. Test Photos Report No.: FR752310-01 FCC ID: I88P330W Page No. : 2 of 5 1. Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Report No.: FR752310-01 FCC ID: I88P330W Page No. : 3 of 5 2. Photographs of Radiated Emissions Test Configuration 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR752310-01 FCC ID: I88P330W Page No. : 4 of 5 30MHz~1GHz FRONT VIEW REAR VIEW Report No.: FR752310-01 FCC ID: I88P330W Page No. : 5 of 5 Above 1GHz FRONT VIEW REAR VIEW

Contact Information

Applicant

Emma Bao(Section Manager)
[email protected]886 3 578-3942Fax: 886 3 578-2439

Technical Contact

Sporton International Inc.Wayne Hsu
[email protected]

No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park · Tao Yuan · Taiwan

Test Firm

Sporton International Inc.Alex Chen
[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz80.20 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is Conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
