www.zyxel.com 802.11n Wireless ADSL2+ 4-port Gateway Firmware v1.10 Edition 1, 7/2010 P-660HN-51 DEFAULT LOGIN DETAILS IP Address:http://192.168.1.1 User Name:admin Password:password1 Copyright 2010 ZyXEL Communications Corporation 2 Device Panels POWER LAN1-4 INTERNET WPS/WLAN DSL RESET LAN PORT 1-4 POWER DSL PORT P-660HN-51 3 Overview The P-660HN-51 is an ADSL router with a four-port built-in Ethernet switch and IEEE 802.11n wireless capability. The P-660HN-51 allows wired and wireless clients to safely access the Internet. The built-in firewall blocks unauthorized access to your network. It supports other helpful features, including Quality of Service (QoS) which allows time- sensitive services and applications to flow more smoothly. Hardware Connections This section shows you how to set up your P-660HN-51. 2 1 3 4 1. DSL: Use a telephone cable to connect your P-660HN-51’s DSL port to a telephone jack (or to a splitter, if one is already installed). 2. LAN: Use an Ethernet cable to connect a computer to a LAN port for initial configuration and/or Internet access. 3. POWER: Use the power adaptor provided with your P-660HN-51 to connect an appropriate power source to the POWER socket. Make sure the power at the outlet is on. After connecting the power adapter, look at the lights on the front panel. • The POWER light blinks while your P-660HN-51 starts up and then stays on once it is ready. The DSL light turns on when the P- 660HN-51 has a DSL connection. The WPS light turns on when the wireless LAN is ready. The INTERNET light turns on when the gateway is able to access the Internet and will blink when the P- 660HN-51 is sending or receiving data. • Each LAN light stays on if the corresponding LAN port is properly connected and blinks when there is traffic. If the POWER, DSL, or connected LAN lights are not on, please check your connections and inspect your cables for damage. If the lights are still off, contact technical support. P-660HN-51 5 Set Up a Wireless Network You can set up a wireless network using the following methods: Using Wireless Protected Setup (WPS) Press the WPS button on the P-660HN-51’s front panel for more than 5 seconds to turn the WPS function on. Follow these steps to add a WPS-enabled device to the wireless network using the WPS/WLAN button. Place the devices you want to connect near one another. Press the WPS button on the P-660HN-51. The WPS light blinks. Press the WPS button on a compatible device within 2 minutes of pressing the button on the P-660HN-51. The WPS light on the P-660HN-51 shines steadily when connected. 1 1 2 3 6 Set Up a Wireless Network Manually The wireless LAN on your P-660HN-51 is enabled by default. To add a wireless client to the network, use the settings found on the bottom panel of your P-660HN-51, which will look similar to the following example: Configure wireless devices that you want to connect to the wireless network to use the same wireless settings as the P-660HN-51. The default wireless settings vary for each P-660HN-51. Refer to the bottom panel of your device and use the provided information. Log into the Web Configurator Your device may already be set up for Internet access. However, you may want or need to log on to the P-660HN-51 Web Configurator to perform tasks: • Configure your Internet access settings manually • Customize the Quality of Service (QoS) and routing features • Create firewall and web filter rules • Edit remote management, as well as other features 1. In your browser, go to http://192.168.1.1. SSID: ZyXEL00561 Security Mode: WPA-PSK Pre-Shared Key: FB373BD356 P-660HN-51 7 2. Enter the default user name admin and password password1. Click Login. If the login screen does not open, make sure you allow web browser pop-up windows, JavaScripts and Java permissions. Your computer should be also set to get an IP address automatically from a DHCP server. See the appendices in your User’s Guide for more information. 3. A welcome screen appears showing a summary of your last login, such as the time, number of failed login attempts, and when the password expires. It also shows if you are logged on from an IP address or through a console. Select Show this page next time to see the welcome screen on your next login. Otherwise, deselect it. Click Continue. 8 4. In the next screen to appear, you can change the login password. This is a recommended step. To do so, enter your new password in the New Password field. Re-type your new password in the second field and then click Apply. If you prefer not to change the password, leave the two fields blank and click Skip. We recommend you write down your new password in the space provided below. New Password: _________________________ P-660HN-51 9 5. The Network Map page appears. This shows whether the P-660HN- 51 and computers/devices connected to it have Internet access. Click on Status to display the following screen, where you can view the P-660HN-51 device, interface and system information. 10 See your User’s Guide for how to use the rest of the Web Configurator screens. You will need to refer to the section on how to setup the Broadband connection if the INTERNET LED (light) remains off. Viewing Certifications • Go to www.zyxel.com. • Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. • Select the certification you wish to view from this page or click on the Specifications tab to see the certifications list. Customer Information Statement The information informing the user of his and the telephone company's rights and obligations is outlined on the following pages. This information will be included in the final version of the manual. 1.If this equipment DL causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required. But if advance notice isn't practical, the telephone company will notify the customer as soon aspossible. Also you will be advi…

Text truncated - open the document above for the full version.

Attestation for FCC Declaration of Conformity FCC ID: I88P660HN51 Date: Jul 26, 2010 Please be notified that we, the undersigned, Cerpass technology Coporation declares that the product which bears the above FCC ID is a;so compliant with the FCC requirements for DOC. The test report number supporting the DOC is SEFD1007018. Testing in regards to this report was done by Cerpass technology Coporation, located at No. 7-2, Moshihkeng, Fongtian Village, Shihding Township, Taipei County, Taiwan, R.O.C., which has been accredited in accordance to all of the requirements of 47 CFR 2.948(d) and(e)of the FCC rules and KDB349827. Sincerely, Anson Chou / Manager Tel: +886-2-26558100#5301 Fax: +886-2-26558200 Email: [email protected]

AHTHORIZATION LETTER FCC ID: I88P660HN51 Date: Jul 26, 2010 To whom it may concern: We, the undersigned, hereby authorize Cerpass Technology (Suzhou) Co., Ltd. of China to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Cerpass Technology (Suzhou) Co., Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 weeks from original data. If you have any questions regarding the authorization, please don’t hesitate to contact me. Thank you. Yours Sincerely, Engineer ZyXEL Communications Corporation

ZyXEL Communications Corporation Date: Jul 26, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: I88P660HN51 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Operational Description 3 Block Diagram. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Wang Yi , engineer ZyXEL Communications Corporation

802.11n ADSL2+ 4-port WiFi Gateway (Model name: P-660HN-51) Exterior Photographs: 1) 2) 3) 4) 5) 6) 7)

802.11n ADSL2+ 4-port WiFi Gateway (Model name: P-660HN-51) FCC ID Position: FCC ID

802.11n ADSL2+ 4-port WiFi Gateway (Model name: P-660HN-51) Inside photo: 1) 2) 3) 4) 5) 6) 7)

Page: 1 of 3 RF Exposure Evaluation Declaration Product: 802.11n ADSL2+ 4-port WiFi Gateway Test Item: RF Exposure Evaluation Declaration 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Page: 2 of 4 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. 1.3. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.4. Test Result of RF Exposure Evaluation Antenna Gain: Ant0: antenna type: Dipole antenna antenna gain:3.5dBi Ant1: antenna type: Dipole antenna antenna gain: 3.5dBi Output Power Into Antenna & RF Exposure Evaluation Distance: 1) 802.11b Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 01 2412.00 158.1248 0.0704025 06 2437.00 156.6751 0.0697797 11 2462.00 158.1248 0.0704254 2) 802.11g Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 01 2412.00 230.1442 0.1025013 06 2437.00 241.5461 0.1075794 11 2462.00 154.8817 0.0689810 Page: 3 of 4 3) 802.11n(20MHz) (An0) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 01 2412.00 76.2079 0.0339414 06 2437.00 245.4709 0.1093274 11 2462.00 86.2979 0.0384352 4) 802.11n(20MHz) (An1) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 01 2412.00 66.9885 0.0298352 06 2437.00 339.6253 0.1512618 11 2462.00 88.3080 0.0393305 3) 802.11n(20MHz) (An1 and An0) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 01 2412.00 142.8894 0.0636399 06 2437.00 584.7901 0.2604529 11 2462.00 174.5822 0.0777551 5) 802.11n(40MHz) (An0) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 03 2422.00 70.1455 0.0312413 06 2437.00 84.1395 0.0374739 09 2452.00 58.8844 0.0262258 Page: 4 of 4 6) 802.11n(40MHz) (An1) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 03 2422.00 97.9490 0.0436244 06 2437.00 104.9542 0.0467443 09 2452.00 55.3350 0.0246450 7) 802.11n(40MHz) (An1 and An0) Test date: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 03 2422.00 157.3983 0.0701018 06 2437.00 189.2344 0.0842809 09 2452.00 114.2878 0.0509013 Note: The power density Pd (4th column) at a distance of 20 cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm2.
