I88WAC6553D-E802.11 ac Unified Pro Access Point

Quick Start Guide www.zyxel.com NWA5000/WAC6500 Series NWA5121-N / NWA5121-NI / NWA5123-NI / NWA5301-NJ / WAC6502D-E / WAC6502D-S / WAC6503D-S / WAC6553D-E 802.11 a/b/g/n/ac Unified Access Point Version 4.20 Edition 1, 04/2015 Copyright © 2015 ZyXEL Communications Corporation User’s Guide Default Login Details LAN IP Addresshttp://192.168.1.2 User Nameadmin Password1234 NWA5000 / WAC6500 Series User’s Guide 2 IMPORTANT! READ CAREFULLY BEFORE USE. KEEP THIS GUIDE FOR FUTURE REFERENCE. This is a User’s Guide for a series of products. Not all products support all firmware features. Screenshots and graphics in this book may differ slightly from your product due to differences in your product firmware or your computer operating system. Every effort has been made to ensure that the information in this manual is accurate. Related Documentation •Quick Start Guide The Quick Start Guide shows how to connect the NWA/WAC and access the Web Configurator. • CLI Reference Guide The CLI Reference Guide explains how to use the Command-Line Interface (CLI) and CLI commands to configure the NWA/WAC. Note: It is recommended you use the Web Configurator to configure the NWA/WAC. • Web Configurator Online Help Click the help icon in any screen for help in configuring that screen and supplementary information. Contents Overview NWA5000 / WAC6500 Series User’s Guide 3 Contents Overview User’s Guide ....................................................................................................................................... 10 Introduction ............................................................................................................................................. 11 The Web Configurator .............................................................................................................................27 Technical Reference .......................................................................................................................... 38 Dashboard ...............................................................................................................................................39 Monitor ....................................................................................................................................................44 Network ...................................................................................................................................................57 Wireless ..................................................................................................................................................65 User .........................................................................................................................................................77 AP Profile ................................................................................................................................................84 MON Profile ...........................................................................................................................................102 WDS Profile ...........................................................................................................................................106 Certificates ............................................................................................................................................108 System ..................................................................................................................................................125 Log and Report .....................................................................................................................................150 File Manager .........................................................................................................................................162 Diagnostics ............................................................................................................................................173 LEDs .....................................................................................................................................................175 Reboot ...................................................................................................................................................178 Shutdown ..............................................................................................................................................179 Troubleshooting ....................................................................................................................................180 Table of Contents NWA5000 / WAC6500 Series User’s Guide 4 Table of Contents Contents Overview .............................................................................................................................. 3 Table of Contents ................................................................................................................................. 4 Part I: User’s Guide ......................................................................................... 10 Chapter 1 Introduction ......................................................................................................................................... 11 1.1 Overview .......................................................................................................................................... 11 1.1.1 Management Mode ..................................................................................................................12 1.1.2 MBSSID ...................................................................................................................................13 1.1.3 Dual-Radio ...............................................................................................................................14 1.1.4 Root AP ..................................................................................................…

Text truncated - open the document above for the full version.

ZyXEL Communications Corporation No.2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan Date: 2015/4/15 Federal Communications Commission 7435 Oakland Mills Rd, Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: I88WAC6553D-E To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model WAC6553D-E to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Hsiang, Tao Yuan Hsein 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Emma Bao / Section Manager ZyXEL Communications Corporation Te l : 886 3 578-3942 # 88582 E-mail: [email protected]

ZyXEL Communications Corporation No.2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan Confidentiality Request Letter Date: 2015/4/15 Federal Communications Commission Authorization and Evaluation Division FCC ID：I88WAC6553D-E Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Emma Bao / Section Manager ZyXEL Communications Corporation Te l : 886 3 578-3942 # 88582 E-mail: [email protected]

ZyXEL Communications Corporation No.2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan Date: April 15, 2015 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, We, ZyXEL Communications Corporation declare that the device does not support any non-US channels and country code selection in all the operational mode(s) for the following product. FCC ID: I88WAC6553D-E Regards, Emma Bao / Section Manager ZyXEL Communications Corporation Te l : 886 3 578-3942 # 88582 E-mail: [email protected]

ZyXEL Communications Corporation No.2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Date: April 15, 2015 Subject: FCC Application for FCC ID: I88WAC6553D-E To Whom it may concern, We, the undersigned, would like to declare that the composite portion catagorized as computer peripheral has been authorized under the Declaration of Conformity procedures, which the report issued from International Certification Corp..(report number: FD521102) Emma Bao / Section Manager ZyXEL Communications Corporation Te l : 886 3 578-3942 # 88582 E-mail: [email protected]

ZyXEL Communications Corporation No.2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan Professional Installation Attestation 15 April 2015 To Whom It May Concern: Please be advised that due to the unique Market and function targeted by this product (FCC ID: I88WAC6553D-E) will need special trained professional in configuring and installing the product. We hereby declare that the product will be distributed through controlled distribution channel which has special trained professional to install this product and will not be sold directly to the general public through retail store. Thank you for your attention. Yours sincerely, __________________ Emma Bao / Section Manager ZyXEL Communications Corporation Te l : 886 3 578-3942 # 88582 E-mail: [email protected]

Project No.: EP521102 Page No. : 1 of 17 Photographs of EUT Project No.: EP521102 Page No. : 2 of 17 Project No.: EP521102 Page No. : 3 of 17 Project No.: EP521102 Page No. : 4 of 17 Project No.: EP521102 Page No. : 5 of 17

PANTONE BLACK Diecut display only Colors Printed/Dimensions/ LENGTH WIDTH 95 mm x 50mm Models Name/Part Name/ Artwork Number/ Artwork Rev./ Unit:mm SPEC LABEL03 Designed/Date/ 11 Feb.‘15amy3264223000ZyXEL WAC6553D-E DELTA NETWORKS, INC. THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF DELTA NETWORKS. AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SELL OF APPARATUSES OR DEVICES WITHOUT PERMISSION . Graphic Layout Scale/ 1:1 Comment/ 95.00 50.00 R1.00 內含射頻模組 Model Number: WAC6553D-E 802.11 ac Unied Pro Access Point / 802.11 ac Power Rating: Input 48V , 0.53A Power Consumption: 25.5 Watt Max. FCC ID: I88WAC6553D-E This device complies with Part 15 of the FCC Rules/Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3(B)/NMG-3(B) UA.TR.008 ICONDIMENSION 4.8x7.0mm 5.0x7.0mm 5.25x7.0mm 7.4x7.0mm 6.0x6.0mm 5.1x6.0mm 8.5x6.0mm 16.3x6.0mm UA.TR.008 IC: 2468C-WAC6553DE Note: 1. Font : Myriad Pro 2. Chinese Font : 文鼎新粗黑 3. BACKGROUND COLOR: 台灣製造 Made in Taiwan Label Location

Project No.: EP521102 Page No. : 6 of 17 Project No.: EP521102 Page No. : 7 of 17 Project No.: EP521102 Page No. : 8 of 17 Project No.: EP521102 Page No. : 9 of 17 Project No.: EP521102 Page No. : 10 of 17 Project No.: EP521102 Page No. : 11 of 17 Project No.: EP521102 Page No. : 12 of 17 Project No.: EP521102 Page No. : 13 of 17 Project No.: EP521102 Page No. : 14 of 17 Project No.: EP521102 Page No. : 15 of 17 Project No.: EP521102 Page No. : 16 of 17 Project No.: EP521102 Page No. : 17 of 17

Report No.: FA521102 Page : 1 of 5 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : I88WAC6553D-E Equipment : 802.11 ac Unified Pro Access Point Model No. : WAC6553D-E Brand Name : ZyXEL Applicant : ZyXEL Communications Corporation Address : No. 2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan. Standard : 47 CFR FCC Part 2.1091 Received Date : Feb. 11, 2015 Tested Date : Mar. 10 ~ Mar. 26, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FA521102 Page : 2 of 5 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 MPE EVALUATION RESULTS .............................................................................................................. 4 2 TEST LABORATORY INFORMATION ................................................................................................. 5 Report No.: FA521102 Page : 3 of 5 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA521102 Rev. 01 Initial issue Apr. 15, 2015 Report No.: FA521102 Page : 4 of 5 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducted Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412~2462 29.72 4.5 30 0.234 1 5180~5240 18.26 7 30 0.030 1 5745~5825 28.38 7 30 0.305 1 CONCULSION: Both of the WLAN 2.4G & 5.0G can transmit simultaneously, the formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density 1. WLAN 2.4G + WLAN 5.0G = 0.234 / 1 + 0.305 / 1 = 0.539 Therefore, the maximum calculation of this situation is 0.539, which is less than the “1” limit. Report No.: FA521102 Page : 5 of 5 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corp, it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan Hsiang. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No. 30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan, R.O.C. No. 3-1, Lane 6, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. No. 14-1, Lane 19, Wen San 3rd St., Kwei Shan Hsiang, Tao Yuan Hsien 333, Taiwan, R.O.C. If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR521102AC Page : 1 of 64 Report Version: Rev. 01 FCC Test Report FCC ID : I88WAC6553D-E Equipment : 802.11 ac Unified Pro Access Point Model No. : WAC6553D-E Brand Name : ZyXEL Applicant : ZyXEL Communications Corporation Address : No. 2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan. Standard : 47 CFR FCC Part 15.247 Received Date : Feb. 11, 2015 Tested Date : Mar. 10 ~ Mar. 26, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR521102AC Page : 2 of 64 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 8 1.4 The Equipment List ................................................................................................................................ 9 1.5 Test Standards ..................................................................................................................................... 10 1.6 Measurement Uncertainty .................................................................................................................... 10 2 TEST CONFIGURATION ..................................................................................................................... 11 2.1 Testing Condition ................................................................................................................................. 11 2.2 The Worst Test Modes and Channel Details ....................................................................................... 11 3 TRANSMITTER TEST RESULTS ........................................................................................................ 12 3.1 Conducted Emissions ........................................................................................................................... 12 3.2 6dB and Occupied Bandwidth .............................................................................................................. 15 3.3 RF Output Power .................................................................................................................................. 18 3.4 Power Spectral Density ........................................................................................................................ 20 3.5 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 22 3.6 Emissions in Non-Restricted Frequency Bands ................................................................................... 50 4 TEST LABORATORY INFORMATION ............................................................................................... 64 Report No.: FR521102AC Page : 3 of 64 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR521102AC Rev. 01 Initial issue Apr. 15, 2015 Report No.: FR521102AC Page : 4 of 64 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions [dBuV]: 0.328MHz 46.46 (Margin -3.04dB) - AV Pass 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 2483.50MHz 52.97 (Margin -1.03dB) - AV Pass 15.247(b)(3) Maximum Output Power Max Power [dBm]: 29.72 Pass 15.247(a)(2) 6dB Bandwidth Meet the requirement of limit Pass 15.247(e) Power Spectral Density Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass Report No.: FR521102AC Page : 5 of 64 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) Data Rate / MCS 2400-2483.5 b 2412-2462 1-11 [11] 3 1-11 Mbps 2400-2483.5 g 2412-2462 1-11 [11] 3 6-54 Mbps 2400-2483.5 n (HT20) 2412-2462 1-11 [11] 3 MCS 0-23 2400-2483.5 n (HT40) 2422-2452 3-9 [7] 3 MCS 0-23 Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. Note 2: 802.11b uses a combination of DSSS-DBPSK, DQPSK, CCK modulation. Note 3: 802.11g/n uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM modulation. 1.1.2 Antenna Details Ant. No. Model Type Antenna Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5725~5850 1 ZXL04-22008A Dipole N type 4.5 7 7 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 48Vdc from POE (support unit only) 1.1.4 Accessories N/A Report No.: FR521102AC Page : 6 of 64 Report Version: Rev. 01 1.1.5 Channel List Frequency band (MHz) 2400~2483.5 802.11 b / g / n HT20 802.11n HT40 Channel Frequency(MHz) Channel Frequency(MHz) 1 2412 3 2422 2 2417 4 2427 3 2422 5 2432 4 2427 6 2437 5 2432 7 2442 6 2437 8 2447 7 2442 9 2452 8 2447 --- --- 9 2452 --- --- 10 2457 --- --- 11 2462 --- --- 1.1.6 Test Tool and Duty Cycle Test Tool ART2-GUI, version: 2.3 Duty Cycle and Duty Factor Mode Duty cycle (%) Duty factor (dB) 11b 100.00% 0.00 11g 98.26% 0.08 HT20 98.13% 0.08 HT40 96.71% 0.15 Report No.: FR521102AC Page : 7 of 64 Report Version: Rev. 01 1.1.7 Power Setting Modulation Mode Test Frequency (MHz) Powe…

Text truncated - open the document above for the full version.

Report No.: FR521102CO Page : 1 of 14 Report Version: Rev. 01 FCC Co-Location Test Report FCC ID : I88WAC6553D-E Equipment : 802.11 ac Unified Pro Access Point Model No. : WAC6553D-E Brand Name : ZyXEL Applicant : ZyXEL Communications Corporation Address : No. 2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan. Standard : 47 CFR FCC Part 15.247 47 CFR FCC Part 15.407 Received Date : Feb. 11, 2015 Tested Date : Mar. 16 ~ Mar. 17, 2015 We, International Certification Corp., would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Approved & Reviewed by: Gary Chang / Manager Ty: XXX Report No.: FR521102CO Page : 2 of 14 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information .............................................................................................................................................. 5 1.2 The Equipment List ................................................................................................................................ 6 1.3 Test Standards ....................................................................................................................................... 6 1.4 Measurement Uncertainty ...................................................................................................................... 6 2 TEST CONFIGURATION ....................................................................................................................... 7 2.1 Testing Condition ................................................................................................................................... 7 2.2 The Worst Test Modes and Channel Details ......................................................................................... 7 3 TRANSMITTER TEST RESULTS .......................................................................................................... 8 3.1 Unwanted Emissions into Restricted Frequency Bands ........................................................................ 8 4 TEST LABORATORY INFORMATION ............................................................................................... 14 Report No.: FR521102CO Page : 3 of 14 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR521102CO Rev. 01 Initial issue Apr. 15, 2015 Report No.: FR521102CO Page : 4 of 14 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.247(d) 15.407(b) 15.209 Radiated Emissions [dBuV/m at 3m]: 32.91MHz 36.52 (Margin -3.48dB) – QP Pass Report No.: FR521102CO Page : 5 of 14 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) Operating Frequency 802.11b/g/n: 2412 MHz ~ 2462 MHz 802.11a/n/ac: 5180 MHz ~ 5240 MHz, 5745 ~ 5825 MHz Modulaton Type 802.11b : DSSS (DBPSK / DQPSK / CCK) 802.11a/g/n/ac : OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM) 1.1.2 Antenna Details Ant. No. Model Type Antenna Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5725~5850 1 ZXL04-22008A Dipole N type 4.5 7 7 1.1.3 Accessories N/A Report No.: FR521102CO Page : 6 of 14 Report Version: Rev. 01 1.2 The Equipment List Test Item Radiated Emission Test Site 966 chamber1 / (03CH01-WS) Instrument Manufacturer Model No. Serial No. Calibration Date Calibration Until Spectrum Analyzer R&S FSV40 101498 Dec. 09, 2014 Dec. 08, 2015 Receiver R&S ESR3 101658 Nov. 10, 2014 Nov. 09, 2015 Bilog Antenna SCHWARZBECK VULB9168 VULB9168-522 Sep. 05, 2014 Sep. 04, 2015 Horn Antenna 1G-18G SCHWARZBECK BBHA 9120 D BBHA 9120 D 1096 Dec. 11, 2014 Dec. 10, 2015 Horn Antenna 18G-40G SCHWARZBECK BBHA 9170 BBHA 9170517 Nov. 10, 2014 Nov. 09, 2015 Loop Antenna R&S HFH2-Z2 11900 Nov. 10, 2014 Nov. 09, 2015 Preamplifier Burgeon BPA-530 SN:100219 Sep. 09, 2014 Sep. 08, 2015 Preamplifier Agilent 83017A MY39501308 Oct. 09, 2014 Oct. 08, 2015 Preamplifier EMC EMC184045B 980192 Aug. 26, 2014 Aug. 25, 2015 RF Cable HUBER+SUHNER SUCOFLEX104 MY16014/4 Dec. 15, 2014 Dec. 14, 2015 RF Cable HUBER+SUHNER SUCOFLEX104 MY16019/4 Dec. 15, 2014 Dec. 14, 2015 RF Cable HUBER+SUHNER SUCOFLEX104 MY16139/4 Dec. 15, 2014 Dec. 14, 2015 LF cable 3M Woken CFD400NL-LW CFD400NL-001 Dec. 15, 2014 Dec. 14, 2015 LF cable 10M Woken CFD400NL-LW CFD400NL-002 Dec. 15, 2014 Dec. 14, 2015 Measurement Software AUDIX e3 6.120210g NA NA Note: Calibration Interval of instruments listed above is one year. 1.3 Test Standards According to the specification of EUT, the EUT must comply with following standards and KDB documents. 47 CFR FCC Part 15.247 47 CFR FCC Part 15.407 ANSI C63.10-2013 FCC KDB 789033 D02 General UNII Test Procedures New Rules v01 FCC KDB 644545 D03 Guidance for IEEE 802 11ac New Rules v01 FCC KDB 558074 D01 DTS Meas Guidance v03r02 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 FCC KDB 412172 D01 Determining ERP and EIRP v01 1.4 Measurement Uncertainty ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test results be included in the report. The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Measurement Uncertainty Parameters Uncertainty Radiated emission ≤ 1GHz ±3.72 dB Radiated emission > 1GHz ±5.65 dB Report No.: FR521102CO Page : 7 of 14 Report Version: Rev. 01 2 Test Configuration 2.1 Testing Condition Test Item Test Site Ambient Condition Tested By Radiated Emissions 03CH01-WS 21-23°C / 64-66% Brad Wu  FCC site registration No.: 657002  IC site registration No.: 1…

Text truncated - open the document above for the full version.

Report No.: FR521102 Page: : 1 of 4 Report Version: Rev. 01 Photographs of the Test Configuration Conducted Emission Test Report No.: FR521102 Page: : 2 of 4 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR521102 Page: : 3 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR521102 Page: : 4 of 4 Report Version: Rev. 01
