I88WX3310-1AX5400 Gigabit Wireless Extender

Zyxel Communications Corporation No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Date: October 31, 2022 Subject: Ad Hoc Mode Function Declaration FCC ID: I88WX3310-1 IC ID: I88WX3310-1 To Whom it may concern, We, Zyxel Communications Corporation declare that the device does not support any non-US channels and country code selection in all the operational mode(s). Emma Bao / Manager Zyxel Communications Corporation Tel: 886 3 578-3942 # 88582 E-mail: [email protected]

Zyxel Communications Corporation No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Date: 2022/10/31 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: I88WX3310-1 Product name: AX5400 Gigabit Wireless Extender To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model WX3310-B1 to the FCC Rules and Regulations. International Certification Corp. Address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e-mail : [email protected] Webs We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Emma Bao / Manager Zyxel Communications Corporation Tel: 886 3 578-3942 # 88582 E-mail: [email protected]

Date: October 31, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: I88WX3310-1 To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after issue date. ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operational Description ☐ Bill of Materials ☐ Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Emma Bao / Manager Zyxel Communications Corporation Tel: 886 3 578-3942 # 88582 E-mail: [email protected]

Project No.: EP282601 Page No. : 1 of 19 Photographs of EUT Project No.: EP282601 Page No. : 2 of 19 Project No.: EP282601 Page No. : 3 of 19 Project No.: EP282601 Page No. : 4 of 19 Project No.: EP282601 Page No. : 5 of 19 Project No.: EP282601 Page No. : 6 of 19 Project No.: EP282601 Page No. : 7 of 19 Project No.: EP282601 Page No. : 8 of 19

Project No.: EP282601 Page No. : 9 of 19 Project No.: EP282601 Page No. : 10 of 19 Project No.: EP282601 Page No. : 11 of 19 Project No.: EP282601 Page No. : 12 of 19 Project No.: EP282601 Page No. : 13 of 19 Project No.: EP282601 Page No. : 14 of 19 Project No.: EP282601 Page No. : 15 of 19 Project No.: EP282601 Page No. : 16 of 19 Project No.: EP282601 Page No. : 17 of 19 Project No.: EP282601 Page No. : 18 of 19 Project No.: EP282601 Page No. : 19 of 19

Report No.: FA282601 Page : 1 of 8 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : I88WX3310-1 Equipment : AX5400 Gigabit Wireless Extender Model No. : WX3310-B1 Brand Name : ZYXEL Applicant : Zyxel Communications Corporation Address : No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Standard : 47 CFR FCC Part 2.1091 Received Date : Aug. 26, 2022 Tested Date : Sep. 06 ~ Oct. 07, 2022 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA282601 Page : 2 of 8 Report Version: Rev. 01 Table of Contents 1 RF EXPOSURE TEST EXEMPTIONS ................................................................................................... 4 1.1 1-mW TEST EXEMPTION ..................................................................................................................... 4 1.2 SAR-BASED EXEMPTION .................................................................................................................... 4 1.3 MPE-BASED EXEMPTION .................................................................................................................... 4 1.4 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 5 1.5 MEASUREMENT UNCERTAINTY ......................................................................................................... 5 1.6 EXEMPTION CALCULATION ................................................................................................................ 6 2 TEST LABORATORY INFORMATION ................................................................................................. 8 Report No.: FA282601 Page : 3 of 8 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA282601 Rev. 01 Initial issue Oct. 26, 2022 Report No.: FA282601 Page : 4 of 8 Report Version: Rev. 01 1 RF Exposure Test Exemptions 1.1 1-mW TEST EXEMPTION Available maximum time-averaged power is no more than 1 mW. 1.2 SAR-BASED EXEMPTION This exemption is applicable to the frequency range between 300 MHz and 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. The maximum time-averaged power or effective radiated power (ERP), whichever is greater, ≤ Pth Pth (mW) = ERP 20cm (d/20) x d≤20cm Pth (mW) = ERP 20cm 20 cm < d ≤40cm Where = - log 10 Pth (mW) = ERP 20cm (mW) = 2040f 0.3GHz ≤ f < 1.5 GHz Pth (mW) = ERP 20cm (mW) = 3060 1.5GHz ≤ f < 6 GHz Frequency (MHz) Power Thresholds mW dBm 663 1353 31.31 699 1426 31.54 704 1436 31.57 777 1585 32.00 824 1681 32.26 902 1840 32.65 1500 ~ 6000 3060 34.86 1.3 MPE-BASED EXEMPTION For a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. Radio Source Frequency Minimum Distance Threshold ERP F L MHz F H MHz λ L / 2π λ H / 2π W 0.3 - 1.34 159 m - 35.6 m 1920 R 2 1.34 - 30 35.6 m - 1.6 m 3450 R 2 /f 2 30 - 300 1.6 m - 159 mm 3.83 R 2 300 - 1500 159 mm - 31.8 mm 0.0128 R 2 f 1500 - 100000 31.8 mm - 0.5 mm 19.2 R 2 Note: R is the antenna-person separation distance. Report No.: FA282601 Page : 5 of 8 Report Version: Rev. 01 1.4 REFERENCE GUIDANCE 447498 D04 Interim General RF Exposure Guidance v01 1.5 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.6 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA282601 Page : 6 of 8 Report Version: Rev. 01 1.7 EXEMPTION CALCULATION Single RF Source Frequency Range (MHz) Maximum Conducted Power (dBm) Maximum tune up limit (dBm) Antenna Gain (dBi) EIRP (dBm) ERP (dBm) SAR-Based Exemption Thresholds (dBm) *Ratio Pass/ Fail Non-beamforming mode 2412~2462 29.67 30.0 3.28 33.28 31.13 34.86 0.424 Pass 5180~5240 29.45 29.5 5.01 35.01 32.86 34.86 0.562 Pass 5260~5320 23.90 24.0 4.10 28.10 25.95 34.86 0.129 Pass 5500~5720 23.88 24.0 4.08 28.08 25.93 34.86 0.128 Pass 5745~5825 29.57 30.0 4.21 34.21 32.06 34.86 0.525 Pass Beamforming mode 2412~2462 28.70 29.0 3.61 32.61 30.46 34.86 0.363 Pass 5180~5240 29.38 29.5 5.11 34.61 32.46 34.86 0.575 Pass 5260~5320 23.62 24.0 5.21 29.21 27.06 34.86 0.166 Pass 5500~5720 23.83 24.0 4.93 28.93 26.78 34.86 0.156 Pass 5745~5825 29.53 30.0 4.77 34.77 32.62 34.86 0.597 Pass Note: Minimum separation distance = 20 cm. Report No.: FA282601 Page : 7 of 8 Report Version: Rev. 01 Simultaneous Transmission Test Exemption Non-beamforming mode Mode Max Ratio of Each Mode WLAN 2.4GHz 0.424 WLAN 5GHz 0.562 Sum 0.986 Limit 1 Pass / Fail Pass Beamforming mode Mode Max Ratio of Each Mode WLAN 2.4GHz 0.363 WLAN 5GHz 0.597 Sum 0.960 Limit 1 Pass / Fail Pass Conclusion Wi-Fi transmitters are qualify for Simultaneous Transmission SAR exemption Report No.: FA282601 Page : 8 of 8 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in t…

Text truncated - open the document above for the full version.

Report No.: FR282601CO Page : 1 of 12 Report Version: Rev. 01 FCC Co-Location Test Report FCC ID : I88WX3310-1 Equipment : AX5400 Gigabit Wireless Extender Model No. : WX3310-B1 Brand Name : ZYXEL Applicant : Zyxel Communications Corporation Address : No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Standard : 47 CFR FCC Part 15.247 47 CFR FCC Part 15.407 Received Date : Aug. 26, 2022 Tested Date : Sep. 13 ~ Oct. 07, 2022 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR282601CO Page : 2 of 12 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 The Equipment List ................................................................................................................................ 6 1.3 Test Standards ....................................................................................................................................... 7 1.4 Reference Guidance .............................................................................................................................. 7 1.5 Deviation from Test Standard and Measurement Procedure ................................................................. 7 1.6 Measurement Uncertainty ...................................................................................................................... 7 2 TEST CONFIGURATION ....................................................................................................................... 8 2.1 Testing Facility ....................................................................................................................................... 8 2.2 The Worst Test Modes and Channel Details ......................................................................................... 8 3 TRANSMITTER TEST RESULTS ......................................................................................................... 9 3.1 Unwanted Emissions into Restricted Frequency Bands ........................................................................ 9 4 TEST LABORATORY INFORMATION ............................................................................................... 11 Appendix A. Unwanted Emissions Into Restricted Frequency Bands Report No.: FR282601CO Page : 3 of 12 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR282601CO Rev. 01 Initial issue Oct. 26, 2022 Report No.: FR282601CO Page : 4 of 12 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.247(d) 15.407(b) 15.209 Radiated Emissions [dBuV/m at 3m]: 47.22MHz 36.11 (Margin -3.89dB) - QP Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR282601CO Page : 5 of 12 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) Operating Frequency 802.11b/g/n: 2412 MHz ~ 2462 MHz 802.11a/n/ac/ax: 5180 MHz ~ 5240 MHz; 5260 MHz ~ 5320 MHz; 5500 MHz ~ 5700 MHz, 5745 ~ 5825 MHz Modulation Type 802.11b: DSSS (DBPSK / DQPSK / CCK) 802.11a/g/n/ac/ax: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM) 1.1.2 Antenna Details Ant. Model Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 2400~2483.5 5150~5250 5250~5350 5470~5725 5725~5850 Ant1 (RFPCA242309IMLB901) PIFA ipex 2.99 2.33 2.99 4.08 4.06 Ant2 (RFPCA242311IMLB901) PIFA ipex 3.28 1.27 1.18 1.51 2.11 Ant3 (RFPCA221116IM5B901) PIFA ipex -- 5.01 4.1 3.76 3.67 Ant4 (RFPCA232007IMLB901) PIFA ipex -- 4.09 3.32 2.64 4.21 1.1.3 Power Supply Type of Equipment under Test (EUT) Power Supply Type 12Vdc from AC adapter Report No.: FR282601CO Page : 6 of 12 Report Version: Rev. 01 1.2 The Equipment List Test Item Radiated Emission below 1GHz Test Site 966 chamber1 / (03CH01-WS) Tested Date Sep. 13, 2022 Instrument Brand Model No. Serial No. Calibration Date Calibration Until Receiver R&S ESR3 101657 Mar. 15, 2022 Mar. 14, 2023 Spectrum Analyzer R&S FSV40 101498 Nov. 29, 2021 Nov. 28, 2022 Loop Antenna R&S HFH2-Z2 100330 Nov. 08, 2021 Nov. 07, 2022 Bilog Antenna SCHWARZBECK VULB9168 VULB9168-522 Aug. 03, 2022 Aug. 02, 2023 Horn Antenna 1G-18G SCHWARZBECK BBHA 9120 D BBHA 9120 D 1096 Dec. 03, 2021 Dec. 02, 2022 Horn Antenna 18G-40G SCHWARZBECK BBHA 9170 BBHA 9170517 Nov. 04, 2021 Nov. 03, 2022 Preamplifier EMC EMC02325 980225 Jun. 28, 2022 Jun. 27, 2023 Preamplifier EMC EMC118A45SE 980898 Jul. 16, 2022 Jul. 15, 2023 Preamplifier EMC EMC184045B 980192 Jul. 08, 2022 Jul. 07, 2023 Loop Antenna Cable KOAX KABEL 101354-BW 101354-BW Oct. 05, 2021 Oct. 04, 2022 LF cable 3M Woken CFD400NL-LW CFD400NL-001 Oct. 05, 2021 Oct. 04, 2022 LF cable 11M EMC EMCCFD400-NW-N W-11000 200801 Oct. 05, 2021 Oct. 04, 2022 LF cable 1M EMC EMCCFD400-NM-N M-1000 160502 Oct. 05, 2021 Oct. 04, 2022 RF Cable EMC EMC104-35M-35M- 8000 210920 Oct. 05, 2021 Oct. 04, 2022 RF Cable HUBER+SUHNER SUCOFLEX104 MY16019/4 Oct. 05, 2021 Oct. 04, 2022 Measurement Software AUDIX e3 6.120210g NA NA Note: Calibration Interval of instruments …

Text truncated - open the document above for the full version.

Report No.: FZ282601-1 Page : 1 of 20 Report Version: Rev. 01 FCC DFS Test Report FCC ID : I88WX3310-1 Equipment : AX5400 Gigabit Wireless Extender Model No. : WX3310-B1 Brand Name : ZYXEL Applicant : Zyxel Communications Corporation Address : No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Standard : 47 CFR FCC Part 15.407 Received Date : Aug. 26, 2022 Tested Date : Oct. 19, 2022 Operating Mode : Client Without Radar Detection We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FZ282601-1 Page : 2 of 20 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Support Equipment List .......................................................................................................................... 6 1.3 The Equipment List ................................................................................................................................ 6 1.4 Testing Condition ................................................................................................................................... 7 1.5 Testing Facility ....................................................................................................................................... 7 1.6 Test Standards ....................................................................................................................................... 7 1.7 Deviation from Test Standard and Measurement Procedure ................................................................. 7 1.8 Measurement Uncertainty ...................................................................................................................... 7 2 TECHNICAL REQUIREMENTS FOR DFS ............................................................................................ 8 2.1 Applicability of DFS Requirements ......................................................................................................... 8 2.2 DFS Detection Thresholds and Response Requirement ....................................................................... 9 2.3 Radar Test Waveforms ........................................................................................................................ 10 3 DFS TEST RESULT ............................................................................................................................. 14 3.1 DFS Detection Threshold levels ........................................................................................................... 14 3.2 In-Service Monitoring ........................................................................................................................... 15 4 TEST LABORATORY INFORMATION ............................................................................................... 20 Report No.: FZ282601-1 Page : 3 of 20 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FZ282601-1 Rev. 01 Initial issue Oct. 26, 2022 Report No.: FZ282601-1 Page : 4 of 20 Report Version: Rev. 01 Summary of Test Results FCC Rules Description of Test Result FCC 15.407 KDB 905462 D02 Non-Occupancy Period Pass FCC 15.407 KDB 905462 D02 Channel Closing Transmission Time Pass FCC 15.407 KDB 905462 D02 Channel Move Time Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FZ282601-1 Page : 5 of 20 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) Frequency Range (GHz) 5.15~5.25, 5.25~5.35, 5.47~5.725, 5.725~5.85 Wireless Function 11a / HT20 / HT40 / VHT20 / VHT40 / VHT80 / VHT160 / HE20 / HE40 / HE80 / HE160 Operating Mode at DFS Band Client without radar detection and ad hoc function Firmware / Software Version V1.00(ABSF.5)b2_20221017 1.1.2 Antenna Details Ant. No. Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 5250~5350 5470~5725 1 PIFA I-pex 2.99 4.08 2 PIFA I-pex 1.18 1.51 3 PIFA I-pex 4.1 3.76 4 PIFA I-pex 3.32 2.64 Note: Lowest gain antenna is selected for DFS test. Report No.: FZ282601-1 Page : 6 of 20 Report Version: Rev. 01 1.2 Support Equipment List Support Equipment List No. Equipment Brand Name Model Name Remark 1 AP (Master) ZYXEL WAX650S FCC ID: I88WAX650S 2 Notebook DELL LATITUDE-E6430 Model: 9ZFB4X1 1.3 The Equipment List Test Site DF01-WS Tested Date Oct. 19, 2022 Instrument Brand Model No. Serial No. Calibration Date Calibration Until Spectrum Analyzer R&S FSV7 101607 Jan. 28, 2022 Jan. 27, 2023 Horn Antenna 1G-18G ETS-LINDGREN 3115 00149268 Oct. 12, 2022 Oct. 11, 2023 RF Cable HUBER+SUHNER SUCOFLEX_104 MY15686/4 Oct. 13, 2022 Oct. 12, 2023 RF Cable HUBER+SUHNER SUCOFLEX_104 296081/4 Oct. 13, 2022 Oct. 12, 2023 RF Cable HUBER+SUHNER SUCOFLEX_104 329023/4 Oct. 13, 2022 Oct. 12, 2023 RF Cable HUBER+SUHNER SUCOFLEX_104 329021/4 Oct. 13, 2022 Oct. 12, 2023 Vector signal generator R&S SMJ100A 100498 Feb. 13, 2022 Feb. 12, 2023 Splitter (1X2) WOKEN 2WAYDIV 12101200003 Oct. 13, 2022 Oct. 12, 2023 Splitter (1X4) WOKEN 4WAYDIV 0120…

Text truncated - open the document above for the full version.

Report No.: FZ282601 Page : 1 of 98 Report Version: Rev. 01 FCC DFS Test Report FCC ID : I88WX3310-1 Equipment : AX5400 Gigabit Wireless Extender Model No. : WX3310-B1 Brand Name : ZYXEL Applicant : Zyxel Communications Corporation Address : No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Standard : 47 CFR FCC Part 15.407 Received Date : Aug. 26, 2022 Tested Date : Oct. 14 ~ Oct. 18, 2022 Operating Mode : Master We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FZ282601 Page : 2 of 98 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Support Equipment List .......................................................................................................................... 6 1.3 The Equipment List ................................................................................................................................ 6 1.4 Testing Condition ................................................................................................................................... 7 1.5 Testing Facility ....................................................................................................................................... 7 1.6 Test Standards ....................................................................................................................................... 7 1.7 Deviation from Test Standard and Measurement Procedure ................................................................. 7 1.8 Measurement Uncertainty ...................................................................................................................... 7 2 TECHNICAL REQUIREMENTS FOR DFS ............................................................................................ 8 2.1 Applicability of DFS Requirements ......................................................................................................... 8 2.2 DFS Detection Thresholds and Response Requirement ....................................................................... 9 2.3 Radar Test Waveforms ........................................................................................................................ 10 3 DFS TEST RESULTS .......................................................................................................................... 16 3.1 DFS Detection Threshold levels ........................................................................................................... 16 3.2 UNII Detection Bandwidth .................................................................................................................... 18 3.3 Channel Availability Check (CAC) ........................................................................................................ 26 3.4 In-Service Monitoring ........................................................................................................................... 30 3.5 Statistical Performance Check ............................................................................................................. 35 4 TEST LABORATORY INFORMATION ............................................................................................... 98 Report No.: FZ282601 Page : 3 of 98 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FZ282601 Rev. 01 Initial issue Oct. 26, 2022 Report No.: FZ282601 Page : 4 of 98 Report Version: Rev. 01 Summary of Test Results FCC Rules Description of Test Result FCC 15.407 KDB 905462 D02 Non-Occupancy Period Pass FCC 15.407 KDB 905462 D02 DFS Detection Threshold Pass FCC 15.407 KDB 905462 D02 Channel Availability Check Time Pass FCC 15.407 KDB 905462 D02 U-NII Detection Bandwidth Pass FCC 15.407 KDB 905462 D02 Channel Closing Transmission Time Pass FCC 15.407 KDB 905462 D02 Channel Move Time Pass Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FZ282601 Page : 5 of 98 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) Frequency Range (GHz) 5.15~5.25, 5.25~5.35, 5.47~5.725, 5.725~5.85 Wireless Function 11a / HT20 / HT40 / VHT20 / VHT40 / VHT80 / VHT160 / HE20 / HE40 / HE80 / HE160 TDWR band(5600-5650MHz) Supported Not Supported Opeartion Function AP / Repeater Operating Mode at DFS Band Master Firmware / Software Version V1.00(ABSF.5)b2_20221017 Note: All tests are performed under AP mode and repeater mode is validated. 1.1.2 Antenna Details Ant. No. Type Connector Operating Frequencies (MHz) / Antenna Gain (dBi) 5250~5350 5470~5725 1 PIFA I-pex 2.99 4.08 2 PIFA I-pex 1.18 1.51 3 PIFA I-pex 4.1 3.76 4 PIFA I-pex 3.32 2.64 Note: Lowest gain antenna is selected for DFS test. 1.1.3 Highest and Possible Lowest Power Level Non-beamforming mode Highest Power Level and Possible Lowest Power Level Frequency Band Highest RF Output Power (dBm) Highest EIRP (dBm) Lowest RF Output Power (dBm) Lowest EIRP (dBm) 5.3G 23.90 28.00 17.90 22.00 5.6G 23.88 27.96 17.88 21.9…

Text truncated - open the document above for the full version.

Report No. : AP292111 Antenna Composite Gain Test Report TEL : 886-3-327-3456 Page No. : 1 of 12 FAX : 886-3-327-0973 Issued Date : Oct. 24, 2022 Report Template No.: HE1-U3 Ver1.0 Report Version : 01 Antenna Composite Gain Test Report Equipment AX5400 Gigabit Wireless Extender Brand Name ZYXEL Model Name WX3310-B1 Applicant Zyxel Communications Corporation No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Manufacturer Zyxel Communications Corporation No.2 Industry East RD. IX, Hsinchu Science Park, Hsinchu 30075, Taiwan, R.O.C Sample Received Sep. 21, 2022 Start Test Date Sep. 27, 2022 Final Test Date Sep. 27, 2022 ___________________________________________ Approved by: Jackson Tsai SPORTON INTERNATIONAL INC. Hsinhua Laboratory No.52, Huaya 1st Rd., Guishan Dist., Taoyuan City 333411, Taiwan (R.O.C.) Report No. : AP292111 Antenna Composite Gain Test Report TEL : 886-3-327-3456 Page No. : 2 of 12 FAX : 886-3-327-0973 Issued Date : Oct. 24, 2022 Report Template No.: HE1-U3 Ver1.0 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 1. Operation Mode and Antenna Information ........................................................................................ 4 2. Test Frequency ..................................................................................................................................... 4 3. Testing Location ................................................................................................................................... 5 4. Test Facilit…
