IHDT56CA1Portable Cellular/PCS Transceiver (AMPS/TDMA)

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 PRELIMINARY Motorola V120t (Tarpon) TDMA R1.3 Mobile Phone User’s Guide Technical Review Draft February 8, 2002 Changes to TDMA R1.3 Files: • “Menu Map” chapter. Changed “Message” menu option order. • “Menu Map” chapter. Added “Ring Styles” to main menu, removed “Ring/Vibrate” from Settings menu. • “Menu Map” chapter. Added “Location” feature to the Settings menu for Tarpon V120x phones. • “Menu Map” chapter. Added “TTY Setup” to the Initial Setup menu. • “Getting Started”/“Charging the Battery” section. Rewrote first paragraph as required (new boilerplate text). • “About Your Phone” chapter. Changed ring or vibrate alert references to “ring styles.” 2 PRELIMINARY • “About Your Phone”/“Battery Use” section. Added new intro paragraph (new boilerplate text), and the “Extending Battery Life” section. • “Sending and Receiving Calls”/“Dialing With One- Touch Dial” section. Rewrote voicemail description. • “Entering Text”/“Tap Method”/“General Text Entry Rules” section. Rewrote text entry callouts (Phoenix and Tarpon phones) to document cursor left/right movement in numeric mode. • “Menu Feature Descriptions” chapter. Moved “Ring/ Vibrate” up to a top-level menu feature, renamed it to “Ring Styles.” • “Menu Feature Descriptions”/“Settings Menu”/“Phone Status” section. Added “Active Line” feature description. • “Menu Feature Descriptions” chapter. Added “TTY Setup” feature description to the “Initial Setup” section. • “Phonebook”/“Storing a Phonebook Entry” section. Added procedural steps that describe how to turn on/ off distinctive ringer ID tones (TDMA phones). • “Phonebook”/“Storing a Phonebook Entry” section. Added procedural steps that describe how to create multiple phonebook entries for a single name. • “Messages - Voicemail”/“Storing Your Voicemail Number” section and “Listening to a Voicemail Message” section. Rewrote text related to storing the voicemail number as phonebook entry number 1. 3 PRELIMINARY • “Messages-Voicemail”/“Receiving a New Voicemail Message” section. Second paragraph, rewrote reminders interval description, eliminated reference to “every five minutes.” • “Messages - Text”/”Setting Up the Text Message Inbox” section. Added procedural steps that describe how to turn on/off SMS Alerts during a voice call (TDMA phones). • “Messages-Text”/“Receiving a Text Message” section. Second paragraph, changed reminders interval description, eliminated reference to “every five minutes.” • “Messages-Text”/“Reading, Locking, or Deleting a Text Message” section. Added new indicators to first procedure step. Moved the “Create Message” option to the top of the Text Msg Menu table. • “Messages - Text” chapter. Added new section “Storing Sounds From a Text Message” (TDMA phones). • Added new “Ring Styles” chapter. • “Ring Styles”/“Setting Reminders” section. Changed reminders interval description, eliminated reference to “every five minutes.” • “Ring Styles”/“Customizing a Ring Style”/“Activate and Deactivate Ringer IDs” section added (TDMA phones). • “Browser” chapter. Added new section “Downloading Sounds” (TDMA phones). 4 PRELIMINARY • “Games” chapter. Rewrote existing descriptions for “BlackJack,” “MindBlaster,” and “Paddleball.” Added new descriptions for “Falling Numbers,” “Reversal,” and “Video Poker.” (New descriptions added as appropriate for specific CDMA and TDMA phones.) • “Adjusting Your Settings” chapter. Removed “Ring/ Vibrate” and “Reminders” sections, created new “Ring Styles” chapter for those topics. • “Adjusting Your Settings”/“Use the My Tones Feature” section. Added new “Downloading Tones” section (TDMA phones). • “Adjusting Your Settings” chapter. Added new “TTY Operation” section. • “Troubleshooting” chapter. Added new “TTY” note. • “Troubleshooting” chapter. Added new text about the backlight affecting battery life. • “Troubleshooting” chapter. Updated references to “Ring Styles” feature. • “Programming Instructions” chapter. Rewrote instructions to support dual NAM programming. 1 PRELIMINARY Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola V120t wireless phone. Antenna Display Headset Jack Insert headset accessory. End Key End phone calls, exit menu system. Left Soft Key Perform functions identified by left display prompt. Earpiece Menu Key Voice Key Record voice notes, phonebook and shortcut names. Right Soft Key Perform functions identified by right display prompt. Send Key Send and answer calls, view recent dialed calls list. Accessory Connector Port Insert charger and phone accessories. Microphone Power Key Volume Keys Adjust earpiece and ringer volume. Scroll Keys Move through menus and lists. 2 PRELIMINARY Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. TrueSync, Sidekick, Starfish, and the Stylized Starfish Logo are registered trademarks of Starfish Software, Inc., a wholly owned independent subsidiary of Motorola, Inc. All other product or service names are the property of their respective owners. © 2002 Motorola, Inc. All rights reserved. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC.FCC ID: IHDT56CA1 EXHIBIT 8A INSTRUCTION MANUAL An updated Users Manual follows: DIGITAL WIRELESS TELEPHONE User's Guide > 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola 120t wireless phone. Antenna Display Headset Jack Insert headset accessory. End Key End phone calls, exit menu system. Left Soft Key Perform functions identified by left display prompt. Earpiece Menu Key Voice Key Record voice notes, phonebook and shortcut names. Right Soft Key Perform functions identified by right display prompt. Send Key Send and answer calls, view recent dialed calls list. Accessory Connector Port Insert charger and phone accessories. Microphone Power Key Volume Keys Adjust earpiece and ringer volume. Scroll Keys Move through menus and lists. 2 Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. TrueSync, Sidekick, Starfish, and the Stylized Starfish Logo are registered trademarks of Starfish Software, Inc., a wholly owned independent subsidiary of Motorola, Inc. All other product or service names are the property of their respective owners. © 2002 Motorola, Inc. All rights reserved. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Manual number: 6809438A79-O Cover number:8988485L49-O " 3 Menu Map Main Menu • Recent Calls • Received Calls • Dialed Calls • Notepad • Call Times • Phonebook • Datebook • Quick Dial • Radio • Messages • Create Msg • Voicemail • Text Msgs • Quick Notes • Outbox • Drafts • Ring Styles • Style • Style Detail • My Tones • Shortcuts • Voice Notes • Browser • Calculator • Games • Settings (see next page) Shortcuts Change display zoom: Press M, then press and hold M Lock/unlock keypad: Press M * Display my phone number: Press M # Go to dialed calls list: Press N Exit menu system: Press O Note: This is the standard phone menu layout. You or your service provider may have changed the menu layout or changed some feature names. Not all features may be available for all users. For example, the Radio feature on the main menu (left) is displayed only when the optional FM Stereo Radio Headset accessory is plugged into the accessory connector port on your phone (see phone illustration, page 1). " 4 Settings Menu • Phone Status • My Tel. Number • Active Line • Battery Meter • Other Information • Connection • Incoming Call • In-Call Setup • In-Call Timer • Answer Options • Security • Phone Lock • Lock Keypad • Lock Application • Talk Secure • Restrict Calls • New Passwords • Other Settings • Personalize • Main Menu •Keys • Greeting • Quick Dial • Initial Setup • Time and Date • Backlight • Zoom • TTY Setup • Scroll • Animation • Language • Battery Save • Contrast • DTMF • Master Reset • Master Clear • Network • Car Settings • Headset 5 Contents Contents Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Safety and General Information . . . . . . . . . . . . . . . . . . 11 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . 19 Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . 21 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Seeing Your Phone Number . . . . . . . . . . . . . . . . . . . . 22 About Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Making and Answering Calls . . . . . . . . . . . . . . . . . . . . 28 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Using Talk Secure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Returning an Unanswered Call . . . . . . . . . . . . . . . . . 29 Calling an Emergency Number . . . . . . . . . . . . . . . . . 29 Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . 30 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . 30 Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The following is a statement of my qualifications: MSEE 1992 Drexel University, PA 10 years Cellular Design Experience Signature: (signed) Tom Daniel Name: Tom Daniel Date: March 14, 2002 Position: Lead Section Manager I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct. Signature: (signed) Thomas Urschel Name: Thomas Urschel Date: March 14, 2002

APPLICANT: MOTOROLAFCC ID: IHDT56CA1 Exhibit 13 March 15, 2002 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56CA1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the conventional Analog Cellular standard in the 800 MHz band and the Digital TDMA standard in both the cellular and PCS bands, as outlined in EIA/TIA IS136 "Dual- Mode Mobile Station Compatibility Standard", dated December 1995. Technical details for this alternate cellular technology (permitted under the cellular service option provisions in Section 22.933 of the Commission's rules) related to Type Acceptance of this equipment, as noted in paragraphs 31 and 32 of the Report and Order in FCC GEN. Docket No. 87-390, are detailed in Exhibit 12. Contact Information: Please contact me by telephone at (847) 523-6167,or by e-mail ([email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLAFCC ID: IHDT56CA1 Exhibit 13A May 10, 2002 RESPONSE TO QUESTIONS Reference: Correspondence Reference Number: 4093 731 Confirmation Number: TC555372 Date of Original Email: 05/07/2002 EMC 1) Letter stating compliance with ESN and 911 calling requirements of 22.919 and 22.921. RESPONSE: In the original submission, both the ESN and 911 statements were located in Operational Description (Exhibit 12) to facilitate exhibit confidentiality. However, this exhibit had a collation error and the statements were not located as described in the table of contents. A revised exhibit 12 is attached. 2) Measurement data showing compliance with 22.917(f) while in the 800 MHZ CDMA mode. RESPONSE: Refer to the following plot. 3) A statement detailing how the burst nature of the TDMA modes was addressed during power/emission measurements. Response: The burst nature of the TDMA mode was addressed during power measurements with the use of a Gigatronic 8652 power meter and 80701 power sensor. The power meter was configured for Burst Average Power (BAP). APPLICANT: MOTOROLAFCC ID: IHDT56CA1 Exhibit 13A The burst nature of the TDMA mode was addressed during emissions measurements using a spectrum analyzer in peak detect mode with the ‘Max Hold’ function selected for the active trace. 4) Justification for necessary BW for each mode according to 2.202 ( c). RESPONSE: Refer to the bandwidth calculations in revised Exhibit 12A. 5) Complete parts lists. RESPONSE: Refer to revised exhibit 10A. 6) Please revise the tune range stated on the grant. The 800 MHZ values appear to be incorrect. They appears to be block range as oppose to tuning range. RESPONSE: 824.04 MHz – 848.97 MHz SAR RESPONSE: A new users manual is included in response to question 2. Refer to the supplemental SAR report for the other SAR issues. 1) Statement detailing "extrapolation" performed on SAR values reported in the summary tables. Please justify the power levels used for testing. SAR testing at or above EMC testing power levels is recommended by Supplement C. 2) Updated users manual. SAR values included did not agree with those in the SAR report. 3) Statement of compliance with FCC RF exposure requirements. Such a statement could not be located. 4) Justification for the body-worn test configurations used. It appears that the leather case was only tested at 1900 MHZ while the clip was only tested at 800 MHZ. Also, please describe the testing performed for the "rubber" phone cover pictured on page 19. No results or test photographs were located. Please provide all appropriate data/details. 5) Discussion of how the EUT was operated/controlled during the test to assure the testing of all appropriate modes, maximum power, and any duty factor driven parameters. Supplement C Appendix B part I 2. 6) Additional description of the SAR measurement system. Please describe the main components of the system and how the SAR measurements are actually performed once setup: include coarse scan, determination of peak SAR location, scans to measure points in 1 gram volume, and procedure to determine SAR value from the measurement points. Per Supplement C Appendix B part II 7 and 8. Please include additional description/photographs of the phantom. 7) Justification for use of 6.5 as the conversion factor for 835 MHZ head liquid. Calibration certificates suggest 6.4 should have been used. 8) Additional SAR test plots. Plots for at least for the highest SAR point for each band in each test configuration should be provided.

January 7, 2003 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Attn: Martin Perrine In re: Motorola, Inc. FCC ID: IHDT56CA1 TC#: TC555372 CRN: 4472 Date: 6/21/2002 Dear Martin: This is in response to your fax dated January 6, 2003 requesting information on the above- referenced device. Please note that the above correspondence CRN 4472 dated 6/21/2002 was answered and submitted to FCC on 7/12/2002. Please find attached the list of attachments. We apologize for the confusion. Please let us know if you have any questions with the amendment(s) or response to your questions. Best regards, cc: Motorola, Inc. Mail your comments or suggestions (To: [email protected]) FCC - Federal Communications Commission - FCC OET Search Form 15 Matches Found For: FCC ID = IHDT56CA1 Query Results: View AttachmentExhibit TypeDescription of ExhibitDate Submitted to FCC Display Mode Attestation StatementsExhibit 2 Attestation Statements04/08/2002pdf Cover Letter(s)Exhibit 13 Confidentiality Letter04/08/2002pdf Cover Letter(s)Exhibit 13a Amendment Response to 409305/24/2002pdf External PhotosExhibit 3 External Photos04/08/2002pdf ID Label/Location InfoExhibit 1 ID Label Location04/08/2002pdf Internal PhotosExhibit 9 Internal Photos04/08/2002pdf Parts List/Tune Up InfoExhibit 10a Parts List05/24/2002pdf Parts List/Tune Up InfoExhibit 10 Tune Up procedure04/08/2002pdf RF Exposure InfoExhibit 11 SAR Report04/08/2002pdf RF Exposure InfoSupplemental Response to CRN 447207/12/2002pdf RF Exposure InfoSupplemental SAR Report Response to 409305/24/2002pdf RF Exposure InfoSupplemental SAR Report RESPONSE TO 22040504/09/2002pdf Test ReportExhibit 6 Test Report04/08/2002pdf Users ManualExhibit 8 Users Manual04/08/2002pdf Users ManualExhibit 08a Amendment Users Manual05/24/2002pdf End of Report. Page 1 of 1FCC OET Search Form 1/7/03https://gullfoss2.fcc.gov/cgi-bin/ws.exe/prod/oet/forms/reports/Search_Form.hts?mode=Edit&form=Exhibits&application_id=555372&fcc_

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 EXHIBIT 3 Front View Rear View, with Battery Removed to Show Equipment ID Label

APPLICANT: MOTOROLA FCC ID: IHDT56CA1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is the label that will appear on the radio when in production. It will be placed on the outside of the radio telephone. FCC ID: IHDT56CA1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 EXHIBIT 9 Front View (Shields Removed) Rear View (Shields Removed)

Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 10 Transceiver Adjustments/Tune-Up Procedure There are no user accessible adjustments or tuning in this portable cellular transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments.

Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 10A1 Transceiver Adjustments/Tune-Up Procedure There are no user accessible adjustments or tuning in this portable cellular transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments. Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 10A2 Parts List Reference SynbolPart NumberDescription C4302113928N01CAP CER CHIP 0.1UF 10% C10012113743N40CAP CHIP 39.0 PF 5% C10022113743N40CAP CHIP 39.0 PF 5% C10032113928P04CHIP CAPACITOR (CERAMIC),CHIP C10042113928P04CHIP CAPACITOR (CERAMIC),CHIP C10052113743E22CAP CHIP .10 UF 10% C10062113928N01CAP CER CHIP 0.1UF 10% C10072113928J08CAP CERAMIC CHIP 10.0UF C10082113928J08CAP CERAMIC CHIP 10.0UF C10092113928C04CAP CER CHIP 4.7UF 6.3V10% C1012113743N03 CAP CHIP 1.0 PF +-.25PF COG C10102113743L31CAP CHIP 3900 PF 10% X7R C10112113743L41CAP CHIP 10000 PF 10% C10122113928K09CAP CER CHIP 10.0 UF 6.3V 10% C10132113743N40CAP CHIP 39.0 PF 5% COG C10142113743N40CAP CHIP 39.0 PF 5% COG C10152113743N38CAP CHIP 33.0 PF 5% C10162113743M24CAP CHIP 100000 PF +80-20% C10172113743M24CAP CHIP 100000 PF +80-20% C10182113928P04CHIP CAPACITOR (CERAMIC),CHIP C10192113743N50CAP CHIP 100 PF 5% C1022113743N03 CAP CHIP 1.0 PF +-.25PF COG C10212113743M24CAP CHIP 100000 PF +80-20% C10222113743N40CAP CHIP 39.0 PF 5% COG C10232113743N40CAP CHIP 39.0 PF 5% COG C10242113743N40CAP CHIP 39.0 PF 5% C10252113743M24CAP CHIP 100000 PF +80-20% C10262.11374E+16CAP CHIP .033 UF 10% C10272113743M24CAP CHIP 100000 PF +80-20% C1028 2113743L23CAP CHIP 1800 PF 10% C10362113743N40CAP CHIP 39.0 PF 5% C10372113743L05CAP CHIP 330 PF 10% C10382113928C04CAP CER CHIP 4.7UF 6.3V10% C10392113743N40CAP CHIP 39.0 PF 5% C1042113743L17CAP CHIP 1000 PF 10% X7R C10402113743M24CAP CHIP 100000 PF +80-20% C10412113743N40CAP CHIP 39.0 PF 5% COG C10432113743M24CAP CHIP 100000 PF +80-20% C10442113928P04CHIP CAPACITOR (CERAMIC),CHIP C10452113743L41CAP CHIP 10000 PF 10% C10462311049A65CAP TANT CHIP C10482113928C04CAP CER CHIP 4.7UF 6.3V10% C10492113743M24CAP CHIP 100000 PF +80-20% C1052113743N03 CAP CHIP 1.0 PF +-.25PF COG C10502113743M24CAP CHIP 100000 PF +80-20% C10512113743M24CAP CHIP 100000 PF +80-20% C10522113743M24CAP CHIP 100000 PF +80-20% Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 10A3 C10542113743M24CAP CHIP 100000 PF +80-20% C10552113928K09CAP CER CHIP 10.0 UF 6.3V C10562113928K09CAP CER CHIP 10.0 UF 6.3V C10572113928A01CAP CER CHIP 1.0 UF 10V C10582113743N38CAP CHIP 33.0 PF 5% C10592113743M24CAP CHIP 100000 PF +80-20% C1062113743N03 CAP CHIP 1.0 PF +-.25PF COG C10612113743N38CAP CHIP 33.0 PF 5% COG C10622113928C04CAP CER CHIP 4.7UF 6.3V10% C10642113928C04CAP CER CHIP 4.7UF 6.3V10% C10652113743N38CAP CHIP 33.0 PF 5% C10662113743M24CAP CHIP 100000 PF +80-20% C10672113743M24CAP CHIP 100000 PF +80-20% C10682113743N30CAP CHIP 15.0 PF 5% C10692113743N30CAP CHIP 15.0 PF 5% C10702113743M24CAP CHIP 100000 PF +80-20% C10712113743M24CAP CHIP 100000 PF +80-20% C10722113743M24CAP CHIP 100000 PF +80-20% C10732113743M24CAP CHIP 100000 PF +80-20% C10742113743M24CAP CHIP 100000 PF +80-20% C10752113743M24CAP CHIP 100000 PF +80-20% C10762113743M24CAP CHIP 100000 PF +80-20% C10782113743M24CAP CHIP 100000 PF +80-20% C10792113743M24CAP CHIP 100000 PF +80-20% C1082113743L41CAP CHIP 10000 PF 10% C10802113743M24CAP CHIP 100000 PF +80-20% C10812113743M24CAP CHIP 100000 PF +80-20% C10832113743N30CAP CHIP 15.0 PF 5% C10842113928C04CAP CER CHIP 4.7UF 6.3V10% C10852113928C04CAP CER CHIP 4.7UF 6.3V10% C10862113743N38CAP CHIP 33.0 PF 5% C10872113928P04CHIP CAPACITOR (CERAMIC),CHIP C1092113743N03 CAP CHIP 1.0 PF +-.25PF COG C10922113928P04CHIP CAPACITOR (CERAMIC),CHIP C10932113928C04CAP CER CHIP 4.7UF 6.3V10% C10942113928C04CAP CER CHIP 4.7UF 6.3V10% C10952113928C04CAP CER CHIP 4.7UF 6.3V10% C10962113928C04CAP CER CHIP 4.7UF 6.3V10% C10972113928C04CAP CER CHIP 4.7UF 6.3V10% C10982113928C04CAP CER CHIP 4.7UF 6.3V10% C10992113928C04CAP CER CHIP 4.7UF 6.3V10% C1102113743L41CAP CHIP 10000 PF 10% X7R C11002113928P04CHIP CAPACITOR (CERAMIC),CHIP C11022113743M24CAP CHIP 100000 PF +80-20% C11032113743M24CAP CHIP 100000 PF +80-20% C11042113743M24CAP CHIP 100000 PF +80-20% C11052113743M24CAP CHIP 100000 PF +80-20% C11062113743M24CAP CHIP 100000 PF +80-20% C1107 2113928C03CAP CER CHIP 1.0 UF 6.3V 10% C11082113928P04CHIP CAPACITOR (CERAMIC),CHIP Applicant: Motorola, INC.FCC ID: IHDT56CA1 Exhibit 10A4 C11092113928P04CHIP CAPACITOR (CERAMIC),CHIP C1112113743N18CAP CHIP 4.7 PF +-.25PF COG C11102113928C04CAP CER CHIP 4.7UF 6.3V10% C11112113928C04CAP CER CHIP 4.7UF 6.3V10% C11122113743L41CAP CHIP 10000 PF 10% C11132113743N40CAP CHIP 39.0 PF 5% C11142113743N40CAP CHIP 39.0 PF 5% C11152113743N40CAP CHIP 39.0 PF 5% C11162113743N40CAP CHIP 39.0 PF 5% C11172113928K09CAP CER CHIP 10.0 UF 6.3V 10% C11202113928K09CAP CER CHIP 10.0 UF 6.3V C11212113928K09CAP CER CHIP 10.0 UF 6.3V C11222113743N40CAP CHIP 39.0 PF 5% C11242113743N40CAP CHIP 39.0 PF 5% COG C1132113743N03 CAP CHIP 1.0 PF +-.25PF COG C13002113743N03CAP CHIP 1.0 PF +-.25PF C14002113743N03 CAP CHIP 1.0 PF +-.25PF COG C14012113743N03 CAP CHIP 1.0 PF +-.25PF COG C15492113743K16013 1 CAP CHIP .220 UF +80-20% 16V C15502113743K16013 1 CAP CHIP .220 UF +80-20% 16V C15542113743N40CAP CHIP 39.0 PF 5% C2002113743N50CAP CHIP 100 PF 5% COG C2012113743L41CAP CHIP 10000 PF 10% X7R C2022113743N10 CAP CHIP 2.2 PF +-.25PF COG C2042113743N22CAP CHIP 6.8 PF + -.5PF COG C2052113743N28CAP CHIP 12.0 PF 5% COG C2092113743L41CAP CHIP 10000 PF 10% X7R C2102113743N50CAP CHIP 100 PF 5% COG C2112113743N28CAP CHIP 12.0 PF 5% COG C2122113743N07 CAP CHIP 1.5 PF +-.25PF COG C2132113743L41CAP CHIP 10000 PF 10% X7R C2142113743N50CAP CHIP 100 PF 5% COG C2242113743N26 CAP CHIP 10.0 PF 5% COG C2252113743N28CAP CHIP 12.0 PF 5% COG C3002113743N24CAP CHIP 8.2 PF C3012113743N07CAP CHIP 1.5 PF +-.25PF C302211374…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT56CA1 Date of test: Date of Report: 02/15/02-02/22/02 03/07/02 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 2001 N. Division Room: AS228 Harvard, Illinois 60033 Test Responsible: Firass Badaruzzaman SAR RF Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following electromagnetic exposure tests: System Validation & Interlaboratory Comparison Simulated Tissue Specifications and Procedure EME Cellular Phone Testing Procedure On the following types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT56CA1 to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2001 This test report shall not be reproduced in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1) Introduction 3 2) Description of the Device Under Test 3 Antenna description 3 Device description 3 3) Test Equipment 3 4.1 Dosimetric system 3 4.2 Additional equipment used 3 4) Electrical parameters of the tissue simulating liquid 4 5) System Accuracy Verification 5 6) Test Results 6 6.1 Head Adjacent Test Results 7 6.2 Body-Worn Test Results 9 Reference Notes Appendix 1: SAR distribution comparison for the system accuracy verification 11 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 12 Appendix 3: SAR distribution plots for Body Worn Configuration 15 Appendix 4. Probe Calibration Certificate 17 Appendix 5: Photographs of the device under test 18 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sect…

Text truncated - open the document above for the full version.
