IHDT56MV1WCDMA/GSM TRANSCEIVER WITH BT & WLAN

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 1 Let’s Golet’s get you up and runningAssemble & Charge 1. Cover off 2. SIM in 3. Battery in 4. Cover on 5. Charge up 6. Power up, log in Set Up & GoSet up & goNote: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. For details, contact your service provider. 1. To turn on your phone, press and hold Power on top of your phone. 2. Select a language. 3. Create or log into a Google™ account that lets you download apps from Android Market™, back up your Contacts , and more. You can also add your email or social networking accounts.Later, you can add or remove accounts by touching > Accounts . 4. When your phone shows your home screen, import your SIM contacts: Touch Dialer > Contacts , then touch Menu > Manage contacts > 2 Import contacts from: SIM card . To u c h OK to confirm. Touchscreen & Keysa few essentialsQuick Start : To u c h s c r e e n • To u c h items to select them. Try it: In the home screen, touch Dialer > Contacts . • Touch & hold items to open options. Try it: In the home screen, touch 3 Dialer > Contacts , then touch and hold a contact to open options. • Drag a list, or the home screen, to see more. Try it: In the home screen, touch Dialer > Contacts then drag your list up or down.When you drag or flick a list, a scroll button appears on the right. Drag the scroll button to move faster. • Flick (drag quickly and release) a list to move quickly. When you flick a long list, touch the screen to stop it from scrolling. • To make the screen sleep or wake up, press Power . Note: Your touchscreen might stay dark if the sensor just above it is covered. Don't use covers or screen protectors (even clear ones) that cover this sensor. Tips & tricks: Touchscreen & keys• To s h o w options for list items (like Contacts ), touch and hold them. To show options for your current display, touch Menu . • To s e t a security lock that you need to enter whenever you wake up your phone, touch Menu > Settings > Location & security > Set up screen lock . • In many apps, the touchscreen switches from portrait to landscape when you rotate your phone. To turn this on or off, touch Menu > Settings > Display > Auto-rotate screen . Power & Sleep KeyPress and hold Power to open a menu where you can turn off sound ( Silent mode ), network and wireless 4 Touchscreen & Keys connections ( Airplane mode ), or the phone ( Power off ). To save your battery, prevent accidental touches, or when you want to wipe smudges off your touchscreen, put the touchscreen to sleep by pressing Power . To wake up the touchscreen, just press Power again. To change how long your phone waits before the screen goes to sleep automatically, touch Menu > Settings > Display > Screen timeout . Ti p : To make the screen lock when it goes to sleep, use . Volume KeysPress the volume keys on the side of the phone to change the ring volume (in the home screen), or the earpiece volume (during a call). Menu, Home, Search, & Back KeysTouch Menu to open menu options in your home screen, lists, and other places.Touch Home to close any menu or app and return to the home screen. Touch and hold Home to show the last few apps you used, then touch an app to open it. In the home screen, touch Home to open or close the app menu.Touch Back to go to the previous screen. 5 Touchscreen & Keys Safety, Regulatory & LegalBattery Use & SafetyBattery Use & SafetyThe following battery use and safety information applies to all Motorola mobile devices. If your mobile device uses a non-removable main battery (as stated in your product information), details related to handling and replacing your battery should be disregarded—the battery should only be replaced by a Motorola-approved service facility, and any attempt to remove or replace your battery may damage the product.Important: Handle and store batteries properly to avoid injury or damage. Most battery issues arise from improper handling of batteries, and particularly from the continued use of damaged batteries.DON’Ts• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the form of your battery. • Don’t let the mobile device or battery come in contact with liquids.* Liquids can get into the mobile device’s circuits, leading to corrosion. • Don’t allow the battery to touch metal objects. If metal objects, such as jewelry, stay in prolonged contact with the battery contact points, the battery could become very hot. • Don’t place your mobile device or battery near a heat source.* High temperatures can cause the battery to swell, leak, or malfunction. • Don’t dry a wet or damp battery with an appliance or heat source, such as a hair dryer or microwave oven. DOs• Do avoid leaving your mobile device in your car in high temperatures.* • Do avoid dropping the mobile device or battery.* Dropping these items, especially on a hard surface, can potentially cause damage.* • Do contact your service provider or Motorola if your mobile device or battery has been damaged by dropping, liquids or high temperatures. * Note: Always make sure that the battery compartment and any connector covers are closed and secure to avoid direct exposure of the battery to any of these conditions, even if your product information states that your mobile device can resist damage from these conditions.Important: Motorola recommends you always use Motorola-branded batteries and chargers for quality assurance and safeguards. Motorola’s warranty does not cover damage to the mobile device caused by non-Motorola batteries and/or chargers. To help you identify authentic Motorola batteries from non-original or counterfeit batteries (that may not have adequate safety protection), Motorola provides holograms on its batteries. You 6 Touchscreen & Keys should confirm that any battery you purchase has a “Motorola Original” hologram.If you see a mes…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein (IHDT56MV1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Jonghwa Lee TITLE: Engineering Manager Motorola Mobility Mobile Devices Business Date: Jul, 4, 2011 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56MV1) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE 19 July 2011 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Jonghwa Lee TITLE: Engineering Manager Motorola Mobility Mobile Devices Business Date: Jul, 4, 2011 2.4. Attestation Statement (Equipment Class PCE – WCDMA/GSM 850/1900 MHz Hearing Aid Compatibility) Motorola Mobility hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. NAME: Jonghwa Lee TITLE: Engineering Manager Motorola Mobility Mobile Devices Business Date: Jul, 4, 2011

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com August 8, 2011 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56MV1, PCS Handsets, with Wi-Fi and Bluetooth. Gentlemen; Motorola Mobility, Inc.; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56MV1. The primary transceiver in this composite device operates in the 850 MHz and 1900 MHz bands as a WCDMA/GSM portable transceiver. It employs HSPA data transmission capabilities. This device also operates in other non-FCC regulated bands outside of the US territory. This radio product is also equipped with a Wi-Fi (802.11b/g/n) transceiver. The Wi-Fi Band of operation is 2.412 - 2.462 GHz, with channels up to 17 MHz in bandwidth for 802.11g operation. The Wi-Fi device complies 15.247 (c), 15.205, and 15.209 (b). This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.4 - 2.4835 GHz (1 MHz channel bandwidth). The BT device also complies with the requirements of FCC Rule Parts 15.247 (c), 15.205 and 15.209 (b). All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 723-6272 if you require any additional information. Page 13a - 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected] Page 13a - 2

FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 8 Auguest 2011 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56MV1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56MV1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56MV1_Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. IHDT56MV1_Ex_10 (Parts List and Tune Up).pdf Transmitter Characteristics. IHDT56MV1_Ex_12 (TX Characteristics).pdf Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56MV1_Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56MV1_Ex_07b (SAR Test Set- up_Details).pdf IHDT56MV1_Ex_07c (Part 15 Test Set- up_Details).pdf IHDT56MV1_Ex_07d (HAC Test Set- up_Details).pdf User’s Manual. IHDT56MV1_Ex_08 (User Guide).pdf Internal product photographs. IHDT56MV1_Ex_09 (Internal Photos).pdf Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Page 13b - 2

FCC ID: IHDT56MV1 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITHOUT BATTERY DOOR 1 EXHIBIT 3 APPLICANT: MOTOROLA MOBILITY INC . TOP OF PHONE BOTTOM OF PHONE RIGHT OF PHONE LEFT OF PHONE FCC ID: IHDT56MV1 APPLICANT: MOTOROLA MOBILITY INC . 2 EXHIBIT 3

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11) 1.1 Location On the rear (back) side of the radio product chassis, beneath the battery (see also Exhibit 3). 1.2 Type The label is of a white polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. This label will be placed on the equipment (within the Battery Compartment) as shown below. Other information may also be included on this label, and other labels may also be present. FCC ID: IHDT56MV1 Page 1 - 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Interior Battery Compartment FCC Label Back of Device Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. Further, at the time of purchase, batteries are shipped in a separate section or compartment of the radio packaging, and are not attached to the radio. In some instances they may be shipped in separate boxes. So, the end user needs to physically install the battery by removing the battery cover, if any, or attach the battery before using the radio. Further, the placement of the label in the battery compartment is done because space is limited on the exterior of the device. The battery compartment also helps to protect the label from getting obliterated or made unreadable through regular handling and use. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. Exhibit 1A: General Information 1A.1 Production Plans Quantity production is planned. 1A.2 Data Submittal Procedure Performance data located in Exhibit 6 are supplied in accordance with the Commission’s rules: 47 CFR Part 2, Subpart J. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 15, Subparts A, B, and C; Part 24 Subparts B and D; and Part 90, Subparts I and S. Page 1 - 2 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MV1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 3 1A.3 Additional Considerations In addition to the radio receivers associated with the services authorized within this application, this device integrates a receiver designed to process signals from Global Positioning System satellites. Compliance with FCC requirements was done via the Verification process (47 CFR 2.902). This device may be considered to be a digital device, per 47 CFR 15.3(k), and can function as a computer peripheral device when functioning as an RF modem, as described in 47 CFR 15.3(r). For this reason, a Part 15B test report is included with this application.

FCC ID: IHDT56MV1 FRONT OF MAIN PCB FRONT OF MAIN PCB WITH RUBBERS 1 EXHIBIT 9 APPLICANT: MOTOROLA MOBILITY INC . FCC ID: IHDT56MV1 BACK OF MAIN PCB WITH SHIELD CAN BACK OF MAIN PCB WITH RUBBERS BACK OF MAIN PCB WITHOUT SHIELD CAN APPLICANT: MOTOROLA MOBILITY INC . 2 EXHIBIT 9 FCC ID: IHDT56MV1 FRONT OF ASSY VGA-EARPIECE FLEX BACK OF DAUGHTER PCB FRONT OF DAUGHTER PCB FRONT OF ASSY 8M CAMERA MODULE BACK OF ASSY VGA-EARPIECE FLEX BACK OF ASSY 8M CAMERA MODULE APPLICANT: MOTOROLA MOBILITY INC . 3 EXHIBIT 9 FCC ID: IHDT56MV1 FRONT VIEW OF ASSEMBLY APPLICANT: MOTOROLA MOBILITY INC . 4 EXHIBIT 9 FCC ID: IHDT56MV1 BACK VIEW OF ASSEMBLY APPLICANT: MOTOROLA MOBILITY INC . 5 EXHIBIT 9
