IHDT56ZD1Mobile Cellular Phone

1 en-US Legal, safety, and regulatory Legal information. This guide provides important legal, safety, and regulatory information that you should read before using your product. For the complete legal information, from the home screen swipe up and tap Settings > , then type Legal information, or visit www.motorola.com/device-legal. Water repellent. Your phone is not waterproof. For more about your phone’s water-repellent design and care, see the user guide. Regulatory information (e-label). To view regulatory information for this phone, from the home screen swipe up and tap Settings > , then type Regulatory, or visit www.motorola.com/device-legal. Battery safety. Your phone uses a removable battery. Don’t use tools, sharp objects, or excessive force to insert or remove the battery. This may damage the battery and could cause burning and injury. Battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service center or similar skilled personnel. If your phone becomes unresponsive, press and hold the Power button until the screen goes dark and your phone restarts. Charge your phone using a compatible Motorola charger. Use of other chargers is not recommended. Don’t charge your phone in temperatures below -20°C (-4°F) or above 45°C (113°F). For more, see the “Legal information” section of this guide, or visit www. motorola.com/device-legal. Driving precautions. Responsible and safe driving is your primary responsibility when driving a vehicle. Always obey local laws and regulations. For more, see the “Legal information” section of this guide to find the complete legal information, or visit www.motorola. com/device-legal. Seizures, blackouts, eyestrain & discomfort. This device may display flashing images or loud sounds. For more, see the “Legal information” section of this guide to find the complete legal information, or visit www.motorola.com/device-legal. Medical devices. This device may interfere with pacemakers and other medical devices. For more, see the “Legal information” section of this guide to find the complete legal information, or visit www. motorola.com/device-legal. Class 1 Laser. This device is classified as a Class 1 Laser product, which is safe in normal use per IEC60825-1:2007 and IEC60825-1:2014. This device complies with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice 50, dated June 24, 2007. Do not attempt to modify or disassemble. Extreme heat or cold. Don’t use your phone in temperatures below CLASS 1 LASER PRODUCT 2 en-US -20°C (-4°F) or above 45°C (113°F). Don’t store/transport your phone in temperatures below -20°C (-4°F) or above 60°C (140°F). Operational warnings. Obey all local restrictions when using mobile devices in public areas, such as hospitals, airplanes, or schools. • Potentially explosive areas: Potentially explosive areas are often, but not always, posted and can include blasting areas, fueling stations, fueling areas (such as below decks on boats), fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain dust, or metal powders. Turn off your phone before entering such an area, and do not charge batteries. In such areas, sparks can occur and cause an explosion or fire. • Symbol key: Your charger, phone, battery (if user-removable), phone display, user’s guide, or packaging may contain symbols, defined as follows: 032374o Important safety information follows. The package and paper products that came with your phone can be recycled. Don’t dispose of your battery or phone with your household waste. See “Disposal & recycling” for more information. 032376o Don’t dispose of your battery or phone in a fire. For indoor use only. Listening at high volume to music or voice through a headset or headphone may damage your hearing. Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. Disposal & recycling. For help recycling products and packaging responsibly, go to www.motorola.com/recycling. Usage. This phone supports apps and services that could use 3 en-US a lot of data, so make sure your data plan meets your needs. Contact your service provider for details. Certain apps and features may not be available in all countries. Warranty. This product is covered by Motorola’s limited warranty. To review the warranty on your phone, swipe up and tap Settings > , then type Legal information, or visit www.motorola.com/ device-legal. You may also obtain a copy of the warranty by contacting Motorola at: Motorola Mobility LLC, Attention Customer Service—Warranty Request, 222 West Merchandise Mart Plaza, Suite 1800, Chicago, IL 60654. Arbitration & opt-out. Except where prohibited by law, any controversy or claim arising out of or relating to any Motorola product will be resolved by binding arbitration, instead of in court, unless you opt-out. To opt-out, send a written rejection notice within 30 days of purchase that includes your name, address, phone number, phone, and phone serial number, and tells Motorola that you are rejecting this Arbitration provision to: Motorola Mobility LLC, 222 West Merchandise Mart Plaza, Suite 1800, Attn: Arbitration Provision Opt-Out, Chicago, IL 60654 or [email protected]. To locate your phone’s serial (IMEI) number, from the home screen swipe up and tap Settings > , then type IMEI. For more information on this arbitration provision, on your phone, swipe up and tap Settings > , then type Legal information, or visit www.motorola.com/ device-legal. Legal disclaimers. Features, services and applications are network dependent and may not be available in all areas; additional terms/ charges may apply. Features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola res…

Text truncated - open the document above for the full version.

read me Let’s get started Before using your phone, please read the legal, safety, and regulatory information provided with your product. Main Camera Depth Camera Flash Front Camera SIM & microSD Card Tray Headset Jack Google Assistant Button* Pro ximity Sensor Volume Buttons Power Button Micro USB/Charger Speaker Microphone Fingerprint Sensor Earpiece es-US Put in the cards & power on Nano SIM 1 Insert the SIM tool into the tray hole to pop out the tray. Make sure you use the correct size SIM card and don’t cut the SIM card. One SIM model Two SIM model or SIM2 SIM1 SIM 2 Insert the SIM card(s) with the gold contacts down, then gently push the tray into the slot. Add a microSD card for additional storage*. 3 Press and hold the Power button, then follow the prompts to get started. *microSD card is optional, sold separately. Press: Open the Google Assistant. Press & hold: Say a command or question. Note: This feature may not be available in all languages. * motorola.com Help & more Get answers, updates, and info: • Help is here: From the home screen, swipe up and tap Settings > Help to learn how to use your phone and get support. • Get more: Get software, user guides, and more at www.motorola.com/mymotoe. • Get apps: Tap Play Store to browse and download apps. Legal information. This guide provides important legal, safety, and regulatory information that you should read before using your product. For the complete legal information, from the home screen swipe up and tap Settings > , then type Legal information, or visit www.motorola.com/ device-legal. Water repellent. Your phone is not waterproof. For more about your phone’s water-repellent design and care, see the user guide. Battery safety. To prevent possible burning and injury, the battery in your phone should only be removed by a Motorola-approved service center or similar skilled personnel. If your phone becomes unresponsive, press and hold the Power button until the screen goes dark and your phone restarts. Charge your phone using a compatible Motorola charger. Use of other chargers is not recommended. Don’t charge your phone in temperatures below -20°C (-4°F) or above 45°C (113°F). For more, see the “Legal information” section of this guide, or visit www.motorola.com/device-legal. Warning about high volume usage. To prevent possible hearing damage, do not listen at high volume levels for long periods. Disposal & recycling. For help recycling products and packaging responsibly, visit www.motorola.com/recycling. Class 1 Laser. This device is classified as a Class 1 Laser product, which is safe in normal use per IEC60825-1:2007 and IEC60825-1:2014. This device complies with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice 50, dated June 24, 2007. Do not attempt to modify or disassemble. Extreme heat or cold. Don’t use your phone in temperatures below -20°C (-4°F) or above 45°C (113°F). Don’t store/transport your phone in temperatures below -20°C (-4°F) or above 60°C (140°F). Legal disclaimers. Features, services and applications are network dependent and may not be available in all areas; additional terms/charges may apply. Features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to correct or change any information without notice. Arbitration. Your purchase is governed by a binding arbitration clause. For more information and how to opt-out, see the legal guide that came with your phone. Specific Absorption Rate (SAR)(ICNIRP). YOUR PHONE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES. The highest SAR values under the ICNIRP guidelines for your phone model are: CLASS 1 LASER PRODUCT Head SAR ____W/kg Body-worn SAR ____W/kg SAR information (on e-label). To view specific absorption rate (SAR) values for this phone, from the home screen swipe up and tap Settings > , then type Regulatory, or visit www.motorola.com/sar. Electrical Requirements. Battery: Adapter: Entrance: Exit: Car Charger: Entrance: Exit: Copyright & trademarks. MOTOROLA, the stylized M logo, MOTO, and the MOTO family of marks are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. Google, Android, Google Play and other related marks and logos are trademarks of Google LLC. microSD Logo is a trademark of SD-3C, LLC. All other product or service names are the property of their respective owners. © 2020 Motorola Mobility LLC. All rights reserved. Product ID: moto e7 plus (Model XT2081-1) Manual Number:

Motorola Mobility LLC 222 W. Merchandize Mart Plaza, Chicago Il US www.motorola.com Federal Communications Commission Date: July 31, 2020 Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: (IHDT56ZD1) To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting confidentiality for exhibits filed with the commission supporting the application of equipment authorization for those items referenced above. Motorola Mobility respectfully requests the Commission to withhold indefinitely from public disclosure the following attachments under Long-Term Confidentiality. ⚫ Schematic Diagrams ⚫ Block Diagrams ⚫ Part List ⚫ Operational Description ⚫ Tune-up Procedure The above listed documents contain detailed system and equipment descriptions that are proprietary and confidential information under Motorola trade secret protection. Public disclosure of above documents would be harmful to our company and would provide competitors an unfair advantage. This information is not made publicly available even after commercial release of the device. In additional to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We request the commission to grant short-term confidentiality request on the following attachments for 180 days after the grant as outlined in Public Notice DA 04-1705. ⚫ External Photos ⚫ Internal Photos ⚫ Test Setup Photos ⚫ User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Sincerely, Jeff Narducci Director, Global Regulatory Compliance [email protected]

Motorola Mobility LLC 222 W. Merchandize Mart Plaza, Chicago Il US www.motorola.com Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: July 31, 2020 SUBJECT: FCC Application for (IHDT56ZD1) To Whom It May Concern: We, the undersigned, hereby authorize Jim Huang at SGS-CSTC Standards Technical Services Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SGS-CSTC Standards Technical Services Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. This authorization is limited to the following product, and shall remain in place until completion of the certification, or until revoked, whichever is earlier: FCC ID: IHDT56ZD1 Regards, Jeff Narducci Director, Global Regulatory Compliance [email protected]

Amendment Letter TIMCO Engineering, Inc. This is to request report update for FCC ID: IHDT56ZD1, The Major change filed under this application and the relevant report numbers are as below: Original report number New report number Revise content ZR/2020/5000901 ZR/2020/5000901-01 1.Add test site Information in section 2, 3.2 and 3.3. 2. Update equipment list in section 5. 3. Update the report NO. of appendix B in header with “-01 4. Add antenna height and angle for ‘Field Strength of Spurious Radiation’ ZR/2020/5000902 ZR/2020/5000902-01 1. Revise test site Information in section 4.5, 4.6. 2. Modify data conversion error of antenna height in radiated emission. 3. Update equipment list in section 5. 4. Update Support Units. ZR/2020/5000903 ZR/2020/5000903-01 1.Add test site Information in section 2, 3.2 and 3.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 6. ZR/2020/5000904 ZR/2020/5000904-01 1.Add test site Information in section 2, 3.2 and 3.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 6. ZR/2020/5000905 ZR/2020/5000905-01 1.Add test site Information in section 2, 3.2 and 3.3 2.Modify data conversion error of antenna height in radiated spurious emission and Radiated band- edge. 3.Update equipment list in section 6. Setup photo Add test location. Sincerely, (signature) (printed name) Derek Yang

Main Antenna DIV Antenna WIFI Antenna

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 835 MHz Head System Performance Check 1750 MHz Head System Performance Check 1900 MHz Head System Performance Check 2450 MHz Head System Performance Check 2600 MHz Head Date: 2020/6/28 Test Laboratory: SGS-SAR Lab System Performance Check 835 MHz Head DUT: D835V2; Type: D835V2; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.904 S/m; ε r = 42.233; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 7; Type: SAM; Serial: 1027 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Body/d=15mm, Pin=250mW/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.06 W/kg Body/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.68 V/m; Power Drift = 0.00 dB Peak SAR (extrapolated) = 3.86 W/kg SAR(1 g) = 2.53 W/kg; SAR(10 g) = 1.65 W/kg Maximum value of SAR (measured) = 3.24 W/kg 0 dB = 3.24 W/kg = 5.11 dBW/kg Date: 2020/7/18 Test Laboratory: SGS-SAR Lab System Performance Check 835 MHz Head DUT: D835V2; Type: D835V2; Serial: 4d105 Communication System: UID 0, CW (0); Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL835;Medium parameters used: f = 835 MHz; σ = 0.901 S/m; ε r = 41.299; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3962; ConvF(9.85, 9.85, 9.85); Calibrated: 2020/4/1; Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE3 Sn414; Calibrated: 2019/12/17 Phantom: SAM6; Type: SAM; Serial: 1824 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Body/d=15mm, Pin=250mW/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 3.06 W/kg Body/d=15mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 53.82 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 3.83 W/kg SAR(1 g) = 2.5 W/kg; SAR(10 g) = 1.63 W/kg Maximum value of SAR (measured) = 3.19 W/kg 0 dB = 3.19 W/kg = 5.04 dBW/kg Date: 2020/7/5 Test Laboratory: SGS-SAR Lab System Performance Check 1750 MHz Head DUT: D1750V2; Type: D1750V2; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.345 S/m; ε r = 40.419; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.81, 7.81, 7.81); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 8; Type: SAM; Serial: 1063 DASY52 4.7.80(0); SEMCAD X 14.6.10(7373) Body/d=10mm, Pin=250mW/Area Scan (6x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 9.41 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 83.52 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 16.0 W/kg SAR(1 g) = 8.63 W/kg; SAR(10 g) = 4.65 W/kg Maximum value of SAR (measured) = 13.3 W/kg 0 dB = 13.3 W/kg = 11.24 dBW/kg Date: 2020/7/10 Test Laboratory: SGS-SAR Lab System Performance Check 1750 MHz Head DUT: D1750V2; Type: D1750V2; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.36 S/m; ε r = 39.139; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3962; ConvF(8.5, 8.5, 8.5); Calibrated: 2020/4/1; Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE3 Sn414; Calibrated: 2019/12/17 Phantom: SAM6; Type: SAM; Serial: 1824 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Body/d=10mm, Pin=250mW/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 14.1 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 85.63 V/m; Power Drift = 0.03 dB Peak SAR (extrapolated) = 17.5 W/kg SAR(1 g) = 9.45 W/kg; SAR(10 g) = 5.03 W/kg Maximum value of SAR (measured) = 14.5 W/kg 0 dB = 14.5 W/kg = 11.61 dBW/kg Date: 2020/7/14 Test Laboratory: SGS-SAR Lab System Performance Check 1750 MHz Head DUT: D1750V2; Type: D1750V2; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.331 S/m; ε r = 40.591; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3789; ConvF(7.61, 7.61, 7.61); Calibrated: 2020/6/16; Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE4 Sn1374; Calibrated: 2019/9/24 Phantom: SAM5; Type: SAM; Serial: 1481 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Body/d=10mm, Pin=250mW/Area Scan (7x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 13.9 W/kg Body/d=10mm, Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 85.83 V/m; Power Drift = 0.05 dB Peak SAR (extrapolated) = 17.2 W/kg SAR(1 g) = 9.26 W/kg; SAR(10 g) = 4.93 W/kg Maximum value of SAR (measured) = 14.2 W/kg 0 dB = 14.2 W/kg = 11.52 dBW/kg Date: 2020/7/16 Test Laboratory: SGS-SAR Lab System Performance Check 1750 MHz Head DUT: D1750V2; Type: D1750V2; Serial: 1149 Communication System: UID 0, CW (0); Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL1750;Medium parameters used: f = 1750 MHz; σ = 1.33 S/m; ε r = 40.794; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3962; ConvF(8.5, 8.5, 8.5); Calibrated: 2020/4/1; Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE3 Sn414; Calibrated: 2019/12/17…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Appendix B Detailed Test Results 1. GSM GSM850 for Head & Body GSM1900 for Head & Body 2. WCDMA WCDMA Band II for Head & Body WCDMA Band IV for Head & Body WCDMA Band V for Head & Body 3.LTE LTE Band 2 for Head & Body LTE Band 4 for Head & Body LTE Band 5 for Head & Body LTE Band 7 for Head & Body LTE Band 66 for Head & Body 4.WIFI WIFI 2.4G for Head & Body 5.Bluetooth Bluetooth for Head & Body Date: 2020/6/28 Test Laboratory: SGS-SAR Lab XT2081-1 GSM850 GSM 190CH Left cheek DUT: XT2081-1; Type: Mobile Cellular Phone; Serial: N0GL250415 Communication System: UID 0, GSM Only Communication System (0); Frequency: 836.6 MHz;Duty Cycle: 1:8.30042 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.904 S/m; ε r = 42.314; ρ = 1000 kg/m 3 Phantom section: Left Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 7; Type: SAM; Serial: 1027 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Configuration/Head/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.230 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 4.286 V/m; Power Drift = -0.07 dB Peak SAR (extrapolated) = 0.249 W/kg SAR(1 g) = 0.202 W/kg; SAR(10 g) = 0.158 W/kg Maximum value of SAR (measured) = 0.229 W/kg 0 dB = 0.229 W/kg = -6.40 dBW/kg Date: 2020/7/18 Test Laboratory: SGS-SAR Lab XT2081-1 GSM 850 GSM 251CH Back side 5mm DUT: XT2081-1; Type: Mobile Cellular Phone; Serial: N0GL250171 Communication System: UID 0, GSM Only Communication System (0); Frequency: 848.8 MHz;Duty Cycle: 1:8.30042 Medium: HSL835;Medium parameters used: f = 849 MHz; σ = 0.916 S/m; ε r = 41.022; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3962; ConvF(9.85, 9.85, 9.85); Calibrated: 2020/4/1; Sensor-Surface: 1.4mm (Mechanical Surface Detection) Electronics: DAE3 Sn414; Calibrated: 2019/12/17 Phantom: SAM6; Type: SAM; Serial: 1824 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Configuration/Body/Area Scan (7x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.39 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 15.40 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 1.97 W/kg SAR(1 g) = 0.942 W/kg; SAR(10 g) = 0.531 W/kg Maximum value of SAR (measured) = 1.46 W/kg 0 dB = 1.46 W/kg = 1.64 dBW/kg Date: 2020/6/28 Test Laboratory: SGS-SAR Lab XT2081-1 GSM850 GPRS 2TS 251CH Back side 5mm DUT: XT2081-1; Type: Mobile Cellular Phone; Serial: N0GL250415 Communication System: UID 0, GPRS/EGPRS Mode(2up) Communication System (0); Frequency: 848.8 MHz;Duty Cycle: 1:4.14954 Medium: HSL835;Medium parameters used: f = 849 MHz; σ = 0.914 S/m; ε r = 42.031; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 7; Type: SAM; Serial: 1027 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.33 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 20.18 V/m; Power Drift = -0.00 dB Peak SAR (extrapolated) = 2.05 W/kg SAR(1 g) = 1.17 W/kg; SAR(10 g) = 0.706 W/kg Maximum value of SAR (measured) = 1.54 W/kg 0 dB = 1.54 W/kg = 1.88 dBW/kg Date: 2020/6/28 Test Laboratory: SGS-SAR Lab XT2081-1 GSM850 GPRS 2TS 190CH Back side 0mm DUT: XT2081-1; Type: Mobile Cellular Phone; Serial: N0GL250415 Communication System: UID 0, GPRS/EGPRS Mode(2up) Communication System (0); Frequency: 836.6 MHz;Duty Cycle: 1:4.14954 Medium: HSL835;Medium parameters used: f = 837 MHz; σ = 0.904 S/m; ε r = 42.314; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(9.05, 9.05, 9.05); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 7; Type: SAM; Serial: 1027 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Configuration/Body/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 6.76 W/kg Configuration/Body/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 22.98 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 9.72 W/kg SAR(1 g) = 3.72 W/kg; SAR(10 g) = 1.84 W/kg Maximum value of SAR (measured) = 6.13 W/kg 0 dB = 6.13 W/kg = 7.87 dBW/kg Date: 2020/7/6 Test Laboratory: SGS-SAR Lab XT2081-1 GSM1900 GSM 661CH Left cheek DUT: XT2081-1; Type: Mobile Cellular Phone; Serial: N0GL250415 Communication System: UID 0, GSM Only Communication System (0); Frequency: 1880 MHz;Duty Cycle: 1:8.30042 Medium: HSL1900;Medium parameters used: f = 1880 MHz; σ = 1.407 S/m; ε r = 40.354; ρ = 1000 kg/m 3 Phantom section: Left Section DASY 5 Configuration: Probe: EX3DV4 - SN3793; ConvF(7.61, 7.61, 7.61); Calibrated: 2020/5/9; Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn1267; Calibrated: 2019/12/17 Phantom: SAM 8; Type: SAM; Serial: 1063 DASY52 52.8.8(1258); SEMCAD X 14.6.10(7373) Configuration/Head/Area Scan (8x13x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.104 W/kg Configuration/Head/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 2.909 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.134 W/kg SAR(1 g) = 0.085 W/kg; SAR(10 g) = 0.053 W/kg Maximum value of SAR (measured) = 0.110 W/kg 0 dB = 0.110 W/kg = -9.59 dBW/kg Date: 2020/7/18 Test Laboratory: SGS-SAR Lab XT2081-1 GSM100 GSM 512CH Back side 5mm DUT:…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Report No.: SZEM180700681601 Appendix C Calibration certificate 1. Dipole D835V2- SN 4d105(2019-12-17) D1750V2-SN 1149(2019-05-21) D1900V2- SN 5d028(2019-12-17) D2450V2- SN 733(2019-12-17) D2600V2-SN 1125(2019-05-20) 2. DAE DAE4- SN 1267(2019-12-17) DAE3-SN 414(2019-12-17) DAE4-SN 1374(2019-09-24) 3. Probe EX3DV4-SN 3789(2020-06-16) EX3DV4-SN 3962(2020-04-01) EX3DV4-SN 3793(2020-05-09)

Dipole D1750V2 SN 1149 Head Liquid Date of Measurement Return Loss(dB) Δ % Impedance (Ω) ΔΩ 2019-05-21 -31.8 / 47.6 / 2020-05-20 -32.3 1.57% 48.9 1.3Ω Dipole D2600V2 SN 1125 Head Liquid Date of Measurement Return Loss(dB) Δ % Impedance (Ω) ΔΩ 2019-05-20 -25.7 / 48.9 / 2020-05-19 -26.6 3.50% 50.8 1.9Ω

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Page : 1 of 126 FCC SAR TEST REPORT Report No: ZR/2020/50009 Applicant: Motorola Mobility LLC Manufacturer: Motorola Mobility LLC Product Name: Type Name: Mobile Cellular Phone MC369 Model No.(EUT): XT2081-1 Trade Mark: Motorola FCC ID: IHDT56ZD1 Standards: FCC 47CFR §2.1093 Date of Receipt: 2020-06-11 Date of Test: 2020-06-28 to 2020-07-19 Date of Issue: 2020-07-28 Test conclusion: PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. Authorized Signature: Derek Yang Wireless Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Page : 2 of 126 REVISION HISTORY Report Number Revision Description Issue Date ZR/2020/5000906 01 Original 2020-07-28 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/5000906 Page : 3 of 126 TEST SUMMARY Frequency Band Max Reported SARg(W/kg) Head Body worn Hotspot Product specific 10g SAR GSM850 0.26 1.16 1.40 2.29 …

Text truncated - open the document above for the full version.
