IHDT5EL1Portable Cellular Transceiver (AMPS/TDMA)

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 DIGITAL WIRELESS TELEPHONE Model C340 User’s Guide > Version 1.4 03/28/2004 2 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C340 wireless phone. Right Soft Key Perform functions identified by right display prompt. Navigation Key Scroll through lists, set volume. Press and hold for continuous scrolling. Power / End key Press & hold to power phone on & off, end phone calls, exit menus. Left Soft Key Perform functions identified by left display prompt. Key Pad Send Key Send and answer calls, view recent dialed calls list. Micro Phone Accessory Connector Port Insert charger, headset and phone accessories. Ear Piece 3 Menu Map Main Menu z Phonebook „ New „ Edit „ Delete „ Delete Name „ Send Msg „ Ph Book Capacity „ Delete All „ Sort By z Recent Calls „ Missed Calls „ Received Calls „ Dialed Calls „ Notepad „ Call Times „ Delete All Call Log z Messages „ Create Message „ Voicemail „ Inbox „ Quick Notes „ Outbox „ Drafts „ Memory Meter „ Message Setup z Ring Styles „ Style „ Style Details „ My Tones z Games „ Tower of Hanoi „ Shopping Mall Settings Menu z Personalize „ Home Screen „ Greeting Text „ Color Styles „ WallPaper „ Screen Saver „ Shortcuts z In Call Setup „ In Call Timer „ Answer Settings „ Speaker Phone „ Easy Prefix z Initial Setup „ Time and Date „ Backlight „ Display Timeout „ TTY „ Language „ Contrast „ DTMF „ Master Reset „ Master Clear z Phone Status „ My Phone Number „ Active Line (*This is carrier dependent.) „ Battery Meter „ Other Information (*This is carrier dependent.) z Headset „ Auto Answer z Car Settings 4 „ Bubble Shooter „ Blackjack z Office Tools „ Datebook „ Calculator „ Unit Converter „ Currency Converter z Alarm „ Enable or Disable „ New „ Edit „ Delete „ Delete All z Media Center „ My Tones „ Picture Viewer z Settings (See next column) „ Auto Answer „ Auto Hands Free z Network Setup „ Current Network „ Service Tone „ Call Drop Tone „ Network Scan (*This is carrier dependent.) „ Network Services (*This is carrier dependent.) z Security „ Phone Lock „ Talk Secure „ Restrict Calls „ New Passwords 5 Contents Welcome............................................................................................................ 2 Menu Map.......................................................................................................... 3 Contents............................................................................................................ 5 Safety and General Information .................................................................... 10 Getting Started ............................................................................................... 16 What’s in the Box? ................................................................................... 16 About This Guide ..................................................................................... 16 Installing the Battery ................................................................................ 16 Charging the Battery ................................................................................ 17 Battery Use ............................................................................................... 18 1. The Basics About Your Phone......................................................... 19 1.1 Turning Your Phone On.................................................................... 19 1.2 Turning Your Phone Off ................................................................... 20 1.3 Using the Idle Display....................................................................... 20 1.4 Using the MENU (RSK) ..................................................................... 21 1.5 Using the Speaker Phone (LSK) ...................................................... 23 1.6 Making a Call ..................................................................................... 23 1.7 Other Functions During In-Call........................................................ 24 1.7.1 MUTE...................................................................................... 24 1.7.2 Other Options........................................................................ 24 1.8 Answering a Call ............................................................................... 25 1.9 How to Enter Information in Your Phone ........................................ 26 1.9.1 How to Enter Text.................................................................. 26 1.9.2 Character Chart..................................................................... 26 1.9.3 Deleting Letters and Words ................................................. 27 1.9.4 How to Enter Punctuation and Special Characters............ 27 1.9.5 How to Enter Numbers ......................................................... 27 1.10 Adjusting Volume ............................................................................. 28 2. Phonebook ........................................................................................ 29 2.1 Phonebook Option Menus................................................................ 29 2.2 Creating a Phonebook Entry............................................................ 30 2.2.1 Entering Information............................................................. 30 2.2.2 Complete Phonebook Entry ................................................. 31 2.3 Dialing a Phonebook Entry .............................................................. 31 6 2.4 Editing a Phonebook Entry .............................................................. 32 2.5 Deleting a Phonebook Entry ............................................................ 33 2.6 Deleting selected Name of Phonebook Entry................................. 33 2.7 Deleting All Phonebook Entries...................................................…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission We hereby certify that this transmit and receive equipment (FCC ID: IHDT5EL1) for dual-Mode mobile station cellular use is capable of compliance with the TIA/EIA-95-B Mobile Station-Base Station Compatibility Standards for Dual-Mode Spread Spectrum Systems, December 1998. Furthermore, we certify compliance to ANSI/TIA/EIA-553-A-1999, Mobile Station-Land Station Compatibility Specification. (Signed – J. Ramon Chaidez) Jose Ramon Chaidez Engineering Manager Cellular Subscriber Equipment EXHIBIT 2A APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. (Signed – J. Ramon Chaidez) Jose Ramon Chaidez Engineering Manager Cellular Subscriber Equipment EXHIBIT 2B APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 911 Call Processing Method Compliance Statement Method Used Pursuant to 47 CFR Sec. 22.921, this Motorola CDMA phone at the time of commercial distribution will use a call completion method for 911 calls that is approved or endorsed by the FCC. At this time Motorola intends that this phone will incorporate either the Automatic A/B- Intelligent Retry method or the Automatic A/B-Intelligent Retry, Version 2 method for providing 911 emergency calling support. Exhibit 2C

Date: June 7, 2004 Subject: Request for additional information regarding FCC ID: IHDT5EL1 (Portable AMPS/TDMA Cellular Transceiver) Reference: Application Received: 5/5/2004 Correspondence Reference Number: 240607A.IHD Confirmation Number: TC4159 Date of Original Email: 06/07/04 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Please provide the modulation characteristics plots for AMPS operation required by Section 2.1047. Response: Please refer to the following plots: Tx Audio Response – AMPS Mode Tx AUDIO RESPONSE-AMPS MODE -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000100000 Frequency(Hz) Mo du l a ti o n (d B ) Modulation(dB) USL LSL 1 Frequency Deviation with Compander On Frequency Deviation characteristic with Compandor On 0 2 4 6 8 10 12 -50 -48 -46 -44 -42 -40 -38 -36 -34 -32 -30 -28 -26 -24 -22 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20 Audio Level (dB) D e viatio n(KH z) 300Hz 1KHz 3KHz Frequency Deviation with Compander Off Frequency Deviation characteristic with Compandor Off 0 2 4 6 8 10 12 -50 -48 -46 -44 -42 -40 -38 -36 -34 -32 -30 -28 -26 -24 -22 -20 -18 -16 -14 -12 -10 -8 -6 -4 -2 0 2 4 6 8 10 12 14 16 18 20 Audio Level (dB) D e via t io n( K H z) 300Hz 1KHz 3KHz 2. Please provide an occupied bandwidth plot for TDMA operation (used to determine the emission designator). Response: Please refer to the following plot: 2 TDMA 800 – Channel 384 (836.52 MHz) – Occupied Bandwidth 3. Several items in the EMC report are listed as being past their cal due date. Please address. Response:. The updated (corrected) equipment list follows: ETSDRG Horn Antenna31156222 9/29/2004 A.H. Systems Inc.DRG Horn AntennaSAS-2--/57136512/17/2004 ETSLog-Periodic Antenna314811883/5/2005 ETSBiconical Antenna3110B337011/14/2004 AttenuatorWeinschelAS-6667510/14/2004 AttenuatorWeinschelAS-6667711/4/2004 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett-PackardSignal Generator83623B3844A011956/20/2004 ThermotronEnvironmental ChamberS-4315801/5/2005 Hewlett-PackardPre-Amplifier8347A3307A0200111/4/2004 AgilentPower MeterEE4418BGB4020638812/5/2004 AgilentPower SensorE4412BUS3848632111/23/2004 Hewlett-PackardPre-Amplifier8447F2805A034195/19/2005 4. Two places in the application list "CDMA" instead of "TDMA" - p.18 of the EMC report, and Exhibit 2C (911 calls). Please confirm that these are typos. Response: Page 18 of the EMC test report should indicate “TDMA” and not “CDMA”. A replacement exhibit 2C is submitted for E911 compliance. 3

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 EXHIBIT 2C 911 CALL PROCESSING METHOD COMPLIANCE STATEMENT Method Used The Motorola TDMA phone uses the “Automatic A/B Roaming-IR” method for providing Enhanced 911 Emergency Calling support in compliance with the FCC mandate. User Interface While in the process of attempting to complete a 911 call the Motorola TDMA phone provides visual feedback to the caller. The display of the phone will show the text “Emergency” while the phone is attempting to find a carrier system to complete the call. The display will continue to read “Emergency” through the duration of the call. System Description When a 911 call is initiated, the Motorola TDMA phone ignores all programmed restrictions with regard to which systems; both analog and digital are useable for completing the call. If the Motorola TDMA phone has acquired service on a system at the time the 911 call is initiated it will attempt to complete the call using that system. If the phone is not in service on a system it will initially attempt to complete the call using any available system it can find, which may exist on any frequency band or mode, supported by the handset. The phone will continue attempting to complete the ‘911’ call until the call is completed, the user has ended the call, or the battery is exhausted.

APPLICANT: MOTOROLA FCC ID: IHDT5EL1 May 6, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT5EL1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in both the conventional Analog Cellular and the Digital TDMA standards in the 800 MHz band. Contact Information: Please contact me by telephone at (847) 523-6167,or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

Exhibit 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT5EL1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT5EL1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

FRONT VIEW REAR VIEW Applicant: Motorola, Inc.FCC ID: IHDT5EL1 1Exhibit 9 REAR VIEW Applicant: Motorola, Inc.FCC ID: IHDT5EL1 2Exhibit 9 INTERNAL VIEW OF THE HOUSING Front internal view Rear internal view Applicant: Motorola, Inc.FCC ID: IHDT5EL1 3Exhibit 9

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission We hereby certify that this transmit and receive equipment (FCC ID: IHDT5EL1) for dual-Mode mobile station cellular use is capable of compliance with the TIA/EIA-95-B Mobile Station-Base Station Compatibility Standards for Dual-Mode Spread Spectrum Systems, December 1998. Furthermore, we certify compliance to ANSI/TIA/EIA-553-A-1999, Mobile Station-Land Station Compatibility Specification. (Signed – J. Ramon Chaidez) Jose Ramon Chaidez Engineering Manager Cellular Subscriber Equipment EXHIBIT 2A APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. (Signed – J. Ramon Chaidez) Jose Ramon Chaidez Engineering Manager Cellular Subscriber Equipment EXHIBIT 2B APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 911 Call Processing Method Compliance Statement Method Used Pursuant to 47 CFR Sec. 22.921, this Motorola CDMA phone at the time of commercial distribution will use a call completion method for 911 calls that is approved or endorsed by the FCC. At this time Motorola intends that this phone will incorporate either the Automatic A/B- Intelligent Retry method or the Automatic A/B-Intelligent Retry, Version 2 method for providing 911 emergency calling support. Exhibit 2C

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT5EL1 Date of test: Date of Report: 04/15/2004 to 05/11/2004 05/13/2004 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT5EL1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2003 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION......................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST....................................................................................3 2.1 Antenna description.............................................................................................................................................. 3 2.2 Device description ................................................................................................................................................. 3 3. TEST EQUIPMENT USED........................................................................................................................3 3.1 Dosimetric System................................................................................................................................................. 3 3.2 Additional Equipment .......................................................................................................................................... 4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID.............................................4 5. SYSTEM ACCURACY VERIFICATION..................................................................................................5 6. TEST RESULTS........................................................................................................................................6 6.1 Head Adjacent Test Results ................................................................................................................................. 6 6.2 Body Worn Test Results ....................................................................................................................................... 8 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION....10 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE........................11 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION...........................14 APPENDIX 4: PROBE CALIBRATION CERTIFICATE...........................................................................16 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE............................................................17 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET...................................................................18 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST ....................................................................21 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EL1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT5EL1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2. Description of the Device Under Test 2.1 Antenna description Type Stubby Location Right Hand Side Length 25 mm Dimensions Width 7 mm Configuration Helix 2.2 Device description FCC ID Number IHDT5EL1 Serial number 3473E4AC & 5207595175 Mode(s) of Operation AMPS 800 TDMA 800 Modulation Mode(s) AMPS TDMA Maximum Output Power Setting 26.50dBm 27.50dBm Duty Cycle 1:1 1:3 Transmitting Frequency Rang(s) 824.04 – 848.97 MHz 824.04 – 848.97 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 3. Test Equipment Used 3.1 Dosimetric System The Motorola Personal Communications Sector Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy3™ v3.1d) manu…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 13890-1 Report Date – May 26, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Michael E. Hill Title: Senior Electrical Engineer Date : 2004-05-26____ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. EXHIBIT 6 A2LA Certificate Number: 1846-01 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Table of Contents Description Page Test Report Details 4 Applicable Standards 4 Summary of Testing 5 General and Special Conditions 5 Equipment and Cable Configurations 6 Measuring Equipment and Calibration Information 6 Measurement Procedures and Data RF Power Output 7 Radiated Power (ERP) 8 Occupied Bandwidth 9 Measurement Results 9 AMPS-Unmodulated Carrier 10 AMPS Supervisory Audio Tone 10 AMPS Voice 11 AMPS Signaling Tone 11 AMPS – 10kb/s Wideband Data 12 AMPS Lower Band Edge 12 AMPS Upper Band Edge 13 TDMA 800 Reference Level Plot 14 TDMA 800 Occupied Bandwidth Plot 14 TDMA 800 Lower Band Edge 15 TDMA 800 Upper Band Edge 15 Spurious Emissions at Antenna Terminals 16 AMPS 800 Tabular and Graphical Data 17 TDMA 1900 Tabular and Graphical Data 18 Field Strength of Spurious Emissions 19 AMPS 800 Tabular and Graphical Data 20 TDMA 800 Tabular and Graphical Data 21 Frequency Stability 22 AMPS 800 Tabular and Graphical Data 23 TDMA 800 Tabular and Graphical Data 24 Test Report Number: 13890-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Field Strength of Spurious Emissions from Unintentional Radiators 25 AMPS 800 Tabular and Graphical Data 26 TDMA 800 Tabular and Graphical Data 27 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 28 Figure A.2 – Substitution Measurement 28 Test Report Number: 13890-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: AMPS 800 and TDMA 800 Model Number: C340 Version: SJWF0211AA Serial Numbers: 3473E4A0, 3473E4AB, 3473E4AF Testing Complete Date: May 26, 2004 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 13890-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 15.0 dB 6 Field Strength of Spurious Emissions 15.3 dB 7 Frequency Stability 160 Hz 8 Field Strength of Spurious Emissions 18.3 dB from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 13890-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ETSDRG Horn Antenna31156222 A.H. Systems Inc.DRG Horn AntennaSAS-200/5712654/29/2004 ETSLog-Periodic Antenna314811894/29/2004 ETSBiconical Antenna3110B33694/29/2004 ETSBiconical Antenna3110B337011/14/2004 AttenuatorWeinschel AS-6667510/14/2004 AttenuatorWeinschel AS-6667711/4/2004 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett Packard Signal Generator 83623B 3844A01195 5/20/2004 ThermotronEnvironmental ChamberS-4315801/5/2005 Hewlett PackardPre-Amplifier8347A11/4/2004 Hewlett PackardPre-Amplifier8447F2805A034195/19/2004 AgilentPower MeterEE4418B12/5/2004 AgilentSensorE4412B11/23/2004 All equipment is on a one-year calibration cycle. Test Report Number: 13890-1 EXHIBIT 6 6 APPLICANT: MOTOROLA INC FCC ID: IHDT5EL1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a HPE4406A Vector Signal Analyzer through a 10dB passive attenuato…

Text truncated - open the document above for the full version.
