IHDT6AA2TURBOPOWER 50W WIRELESS CHARGING STAND

TurboPower 50W Wireless Charging Stand read me en-US | es-US | zh-CN 25 MAY 2022 2 Wireless charging stand English ..........................................................3 Language ....................................................8 25 MAY 2022 3 Lets get started Before using your wireless charging stand, please read the safety, regulatory and legal information at the back of this guide. Use your wireless charging stand for fast charging or as a hands free stand for your phone to watch videos, make video calls and more. Charge your stand Connect the USC-B® connector to your wireless charging stand and the other end to a power supply. Tip: You can charge your phone while charging the stand. English Connect to power supply 25 MAY 2022 4 Charge your phone 1 Place the back of your compatible wireless charging phone on the wireless charging stand. You can place it in a portrait or landscape position. Tip: Make sure your phone is centered on the stand. 2 On your phone tap the Wireless Charging Stand notification. Note: You’ll only have to do this the first time you place your phone on the stand. 3 On your phone tap Settings > Battery > Wireless Charging Stand > Fast mode for high speed wireless charging. Note: If your phone has a case this may impact charging efficiency. 25 MAY 2022 5 Charging options On your phone tap Settings > Battery > Wireless Charging Stand >: • Fast mode: phone charges at high speed (cooling fan is loud). • Silent mode: phone charges at low speed (cooling fan is quiet). Stand light options On your phone tap Settings > Battery > Wireless Charging Stand >: • Glow effect: base lights up, indicating charging status. To turn off Glow effect tap the switch. • Clock mode: show da te, time and battery level when phone is placed in the stand. 25 MAY 2022 6 Stand light When the base light on the bottom of the stand is: status on/off every two secondshigh speed wireless charging on/off every four secondslow speed wireless charging always onphone fully charged on/off every secondcharging error Base (LED) light Cooling fan 25 MAY 2022 7 Help & more Legal information. This guide provides important legal, safety, and regulatory information that you should read before using your product. Disposal & recycling. For help recycling products and packaging responsibly, visit www.motorola.com/recycling. Legal disclaimers. Features, functionality, and other product specifications, as well as the information contained in this guide, are based upon the latest available information and believed to be accurate at the time of printing. Motorola reserves the right to correct or change any information without notice. Arbitration & opt-out. Except where prohibited by law, any controversy or claim arising out of or relating to any Motorola product will be resolved by binding arbitration, instead of in court, unless you opt-out. To opt-out, send a written rejection notice within 30 days of purchase that includes your name, address, phone number, and stand serial number, and tells Motorola that you are rejecting this Arbitration provision to: Motorola Mobility LLC, 222 West Merchandise Mart Plaza, Attn: Arbitration Provision Opt- Out, Chicago, IL 60654 or [email protected]. Important. This product contains magnets. Always keep products with magnets more than 20 cm (8 in.) from medical devic es, such as pacemakers, internal cardio defibrillators or other devices that can be affected by a magnetic field. Also, keep products with magnets away from credit cards, ID cards and other media that use magnetically encoded information. This product is intended for use on a desk, table or other flat surface; not suitable for use in vehicles. Warranty. This product is covered by Motorola’s limited warranty. To review the warranty visit www.motorola.com/device-legal. You may also obtain a copy of the warranty by contacting Motorola at: Motorola Mobility LLC, Attention Customer Service—Warranty Request, 222 West Merchandise Mart Plaza, Chicago, IL 60654. Use & care To care for your Motorola stand, please observe the following: Liquids. Don’t expose your stand to water, rain, extreme humidity, sweat, or other liquids. Drying. In the event your stand is exposed to water, dry your stand and ports thoroughly with a soft, clean cloth. Don’t put your stand in a microwave oven, conventional oven, or dryer. 25 MAY 2022 8 Extreme heat or cold. Don’t use your stand in temperatures below -20°C (-4°F) or above 45°C (113°F). Don’t store/transport your stand in temperatures below -20°C (-4°F) or above 60°C (140°F). Dust and dirt. Don’t expose your stand to dust, dirt, sand, food, or similar materials. Cleaning. To clean your stand, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions. Shock and vibration. Don’t drop your stand or expose it to strong vibration. European conformance (CE and UKCA). The following information is applicable to phones that carry a CE or UKCA mark. Contact point: Regulatory Compliance, Motorola Mobility UK Ltd., Redwood, Crockford Lane, Chineham Business Park, Basingstoke, RG24 8WQ, UK. Hereby, Motorola Mobility LLC declares that the radio equipment model as defined in the getting started guide (and box label) supplied with this product: • Bearing the CE mark is in compliance with Directive 2014/53/EU; • And bearing the UKCA mark is in compliance with the Radio Equipment Regulations 2017. The full DoC can be found at www.motorola.com/red. This device has been tested and meets applicable limits for radio frequency (RF) exposure. Exposure value is 0.1908 A/m at 15cm distance Supported frequencies and power (Model MW-02). This stand is capable of operation on the following frequencies, subject to location and network availability. Operating mode Frequency range MHz / Band Maximum nominal transmit power dBm WPT111kHz-145kHz <50.84dbuA/m@3m FCC and IC compliance. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device …

Text truncated - open the document above for the full version.

Motorola Mobility LLC 222 W. Merchandize Mart Plaza, Chicago Il US www.motorola.com Date: May 24, 2022 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: IHDT6AA2 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting confidentiality for exhibits filed with the commission supporting the application of equipment authorization for those items referenced above. Motorola Mobility respectfully requests the Commission to withhold indefinitely from public disclosure the following attachments under Long-Term Confidentiality. ⚫ Schematic Diagrams ⚫ Block Diagrams ⚫ Part List ⚫ Operational Description The above listed documents contain detailed system and equipment descriptions that are proprietary and confidential information under Motorola trade secret protection. Public disclosure of above documents would be harmful to our company and would provide competitors an unfair advantage. This information is not made publicly available even after commercial release of the device. In additional to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We request the commission to grant short-term confidentiality request on the following attachments for 180 days after the grant as outlined in Public Notice DA 04-1705. ⚫ External Photos ⚫ Internal Photos ⚫ Test Setup Photos ⚫ User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Sincerely, Jeff Narducci Director, Global Regulatory Compliance [email protected]

Motorola Mobility LLC Wireless charger approval FCC ID: IHDT6AA2 Data: 2022/5/9 There’s a wireless charger that would like to have your authorization as an inductive wireless power transfer applications approval. The specific product as below, wireless quick charger, with its designed features and specified description, meets special requirement for KDB 680106 D01 v03 section 5 (b) requirements. Company: Motorola Mobility LLC Product Name: TURBOPOWER 50W WIRELESS CHARGING STAND Model Number: MW-02 FCC ID: IHDT6AA2 KDB 680106 D01 v03r01 section 5 (b) requirement: Product Technical Specification: Result: Power transfer frequency is less than 1 MHz. 111K-142KHz Complied Output power from each primary coil is less than or equal to 15 watts Max 50W No Complied The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. only one source primary coils is working when charging. Complied Client device is placed directly in contact with the transmitter Placed directly Complied Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only Complied The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. the detailed data please refer to RF exposure report Complied

External Photos

05/12/22 TBD 39380A- Yufei Tong S. Gioia V1 A Original created by Susan using Draft sent from vendor via Yufeil Tong. Layout approved by Jingjia Li. Sent for RC approvals. 05/17/22 Mike Roper S. Gioia V2 B Additions requested by Mike Roper. 05/19/22 Dan Cox S. Gioia V3 C FCC ID IHDT6AA2 requested added in by Dan Cox ARTWORK NUMBER DATE PART NUMBER TITLE/DESCRIPTION: FILE NAME: REQUESTERSTATUS 39380A-C REVDETAILS/CHANGE SUMMARY/CXD SUBMITTALITC GRAPHICS 2022 MOTOROLA & LENOVO CONFIDENTIAL RESTRICTED ARTWORK INTENT COMPOSITE TEXT AND RC ICONS Laser Etched Graphics ARTWORK RECIEVED FROM VENDOR Composite With Information Needed DO NOT USE AS ARTWORK ‘FOR GUIDE AND INFO REQUIREMENTS ONLY H-28112 RAMATEL H-28112 RAMATEL H-28112 RAMATEL

Antenna

Report Number: 68.950.22.0569.01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China RF exposure evaluation 1. Introduction Model : MW-02 Product Type : TURBOPOWER 50W WIRELESS CHARGING STAND Brand name : MOTO Applicant : Motorola Mobility LLC Address : 222 W. Merchandise Mart Plaza, Chicago Illinois 60654 USA Manufacturer : Motorola Mobility LLC Address : 222 W. Merchandise Mart Plaza, Chicago Illinois 60654 USA This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 and KDB 680106 D01 v03r01 of the FCC Rules and Regulations. Report Number: 68.950.22.0569.01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China 2. Product information Product: TURBOPOWER 50W WIRELESS CHARGING STAND Model no.: MW-02 FCC ID: IHDT6AA2 Rating: 5-20Vdc 3.5A Max supplied by an external adapter RF Transmission Frequency: 111-145KHz Max magnetic field strength distance 3m: 102.06dBuV/m Antenna Type: Litz Wire Coil Antenna gain: 0dBi Description of the EUT: The Equipment Under Test (EUT) is a wireless charger which operated at 111-145KHz. Report Number: 68.950.22.0569.01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China 3. Limit and Guidelines on RF Exposure (1) According to KDB 680106 D01 v03r01 3(c) For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of 15 cm. E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63 A/m. Below 100 kHz, applicable reference levels for maximum instantaneous exposure field strengths are defined in clause 3.a). (2)According to §1.1310 system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 ≤6 3.0-30 1842/f 4.89/f *900/f 2 <6 30-300 61.4 0.163 1.0 <6 300-1,500 f/300 <6 1,500-100,000 5 <6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 <30 1.34-30 824/f 2.19/f *180/f 2 <30 30-300 27.5 0.073 0.2 <30 300-1,500 f/1500 <30 1,500-100,000 1.0 <30 f = frequency in MHz * = Plane-wave equivalent power density Per the guidance of KDB 680106, the E-field and H-field limits shown in the table above are extended down to 100kHz. 4. Test setup Report Number: 68.950.22.0569.01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Report Number: 68.950.22.0569.01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China 5. Measurement procedure a) The RF exposure test was performed on the table in anechoic chamber. b) The measurement was investigated between the edge of the charger and center of the field probe in the closest state. c) Maximum E-field and H-field measurements were made on each of five sides of the EUT that could come in contact with a user. Five sides are defined as follows: Right (P2), Top, Left (P4), Rear (P1) and Front (P3). Refer to the test position diagram above. d) According to the guidance of KDB 680106 D01 v03r01 test distance was 15 cm on the surrounding sides from the EUT. e) Equipment approval considerations item 5.b) of KDB 680106 D01 v03r01 (1) Power transfer frequency is less than 1 MHz - Yes, The device operates at a frequency of 111 KHz to 145 KHz. (2) Output power from each primary coil is less than or equal to 15 watts. - No; the maximum output power of the primary coil is 50 W. so we have Submitted an Inquiry to FCC official (KDB Inquiry Number 476529). (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. -Yes, only one source primary coils is working when charging. (4) Client device is placed directly in contact with the transmitter. - Yes (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). - Yes, Mobile exposure conditions only (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. - Refer to following worst test result (For more detail, please refer to section 7) 1) The worst E-Field Strength levels at 15 cm < 50 % of the MPE E-Field Strength limit 614 V/m Quickly charging test mode: 1.6931V/m < 307 V/m 2) The worst H-Field Strength levels at 15 cm < 50 % of the MPE H-Field Strength limit 1.63 A/m Quickly charging test mode 0.3649A/m < 0.815 A/m 3) The top surface E-Field Strength levels at 20 cm < 50 % of the MPE E-Field Strength…

Text truncated - open the document above for the full version.

Report Number: 68.950.22.0502.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 1 of 26 FCC - TEST REPORT Report Number : 68.950.22.0502.01 Date of Issue: 2022-06-23 Model : MW-02 Product Type : TURBOPOWER 50W WIRELESS CHARGING STAND Brand name : MOTO Applicant : Motorola Mobility LLC Address : 222 W. Merchandise Mart Plaza, Chicago Illinois 60654 USA Manufacturer : Motorola Mobility LLC Address : 222 W. Merchandise Mart Plaza, Chicago Illinois 60654 USA Test Result : ◼ Positive  Negative Total pages including Appendices : 26 TÜV SÜD Certification and Testing (China) Co., Ltd. – Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. – Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. – Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. – Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 68.950.22.0502.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 2 of 26 1 Table of Contents 1 Table of Contents .......................................................................................................................................... 2 2 Details about the Test Laboratory ................................................................................................................. 3 3 Description of the Equipment Under Test ..................................................................................................... 4 4 Summary of Test Standards ......................................................................................................................... 5 5 Summary of Test Results .............................................................................................................................. 6 6 General Remarks .......................................................................................................................................... 7 7 Test Setups ................................................................................................................................................... 8 8 Systems test configuration ............................................................................................................................ 9 9 Technical Requirement ............................................................................................................................... 10 9.1 Conducted Emission Test ................................................................................................................... 10 9.2 20 dB Bandwidth ................................................................................................................................. 15 9.3 Radiated Emission Test ...................................................................................................................... 16 10 Test Equipment List ................................................................................................................................. 25 11 System Measurement Uncertainty .......................................................................................................... 26 Report Number: 68.950.22.0502.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 3 of 26 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12 & 13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District Shenzhen 518052 P.R. China Telephone: 86 755 8828 6998 Fax: 86 755 828 5299 FCC Registration No.: 514049 Report Number: 68.950.22.0502.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755 8828 5299 Page 4 of 26 3 Description of the Equipment Under Test Product: TURBOPOWER 50W WIRELESS CHARGING STAND Model no.: MW-02 FCC ID: IHDT6AA2 Rating: Input: 5-20VDC 3.5A Max Output: 50W Max RF Transmission Frequency: 111-145KHz Antenna Type: Integrated coil antenna Description of the EUT: The Equipment Under Test (EUT) is a Wireless Charger which operated at 111-145kHz. Report Number: 68.950.22.0502.01 EMC_SZ_FR_23.03 FCC Release 2017-06-20 TÜV SÜD Certification and Testing (China) Co., Ltd. Sh…

Text truncated - open the document above for the full version.

Conducted Emission Radiated Emission 9KHz to 30MHz Test Setup Photos Radiated Emission 30MHz to 1GHz 15cm EMF Top 20cm EMF
