IHDT6ZR2READY FOR AIR REMOTE

遥控器说明书/Manual of remote control Instrucciones para el mando a distancia 设备名/The device name/Nombre del dispositivo：MR-01 遥控器配对 步骤 操作 1 打开手机蓝牙功能 2 打开遥控器蓝牙功能：同时按下“OK”和“返回”键，遥控器指示灯亮一下后 熄灭，3 秒后红灯慢速闪烁，遥控器进入蓝牙配对模式（进入后才可松开按键）。 3 在手机端选择蓝牙设备 MR-01 进行连接 4 1）连接成功后，遥控器指示红灯长亮 2 秒，然后退出配对模式，指示灯熄灭。 2）如果连接不成功，红灯持续闪烁，超时 30 秒退出配对模式，红灯熄灭。 step operation 1 Turn on Bluetooth function of mobile phone 2 At the same time, press the "OK" and "return" keys of the remote control. The indicator light will be lit and then extinguished. After 3 seconds, the red light will flash slowly, and the remote control will enter the broadcast scanning mode (you can release the button after entering). 3 Select the Bluetooth device mr-01 on the mobile phone to connect 4 1） After the connection is successful, the red light of the remote control will stay on for 2 seconds, and then exit the pairing mode and the indicator light will go off. 2）2) If the connection is not successful, the red light will continue to blink. After 30 seconds, the red light will be off when the matching mode is out. Los pasos La operación 1 Activar la función bluetooth del teléfono móvil 2 Activar la función bluetooth del mando a distancia: presione las teclas "OK" y "return" al mismo tiempo, el indicador del mando a distancia se enciende una vez y se apaga, después de 3 segundos la luz roja se deslumbra lentamente y el mando a distancia entra en el modo de emparejamiento de bluetooth (solo después de entrar puede soltar la tecla). 3 Seleccione el dispositivo bluetooth mr-01 en el lado del teléfono móvil para conectarse 4 1) después de la conexión, el mando a distancia indica que la luz roja est á encendida durante 2 segundos, luego sale del modo de emparejamiento y el indicador se apaga. 2) si la conexión no funciona, la luz roja sigue parpadeando, el tiempo de espera es de 30 segundos para salir del modo de emparejamiento y la luz roja se apaga. 按键说明 序号 按键名称 按键丝印 操作及功能 1 首页 单击：首页 2 chooser 单击：主机待机 3 静音 单击：静音 4 菜单 单击：挂电话 5 Circle 单击：接电话 6 上 单击：方向上 7 下 单击：方向下 8 左 单击：方向左 9 右 单击：方向右 10 OK 单击：确认 11 返回 单击：返回 12 鼠标 单击：空鼠开启/关闭 13 音量- 单击：音量- 14 音量+ 单击：音量+ Key description er Key name Key Icon Operation and function Home page click：Home page 2 chooser click：host standby 3 Mute click： Mute 4 menu click：Hang up 5 Circle click：answer the phone Instrucciones para pulsar las teclas 6 up click：Up 7 down click：Down 8 left click：Left 9 right click：Right 0 OK click：Confirm 1 return click：Return 2 mouse click：Mouse On/Off 3 Volu me down click： Volume down 4 Volu me up click： Volume up ombre de tecla Iconos de teclas Funcionamiento y funciones n la rimera pá na Haga clic en ： En la primera página hooser Haga clic en：Espera para host 空鼠使用 空鼠开启 有蓝牙已连接的情况下，遥控器单击空鼠键开启 空鼠关闭 单击鼠标键，关闭空鼠 鼠标左键 OK 键响应鼠标左键功能 enciar Haga clic en： silenciar menú Haga clic en ： Tel é fono colgado rcle Haga clic en：Responder al teléfono scendent Haga clic en：方向上 acia bajo Haga clic en：方向下 quierda Haga clic en：方向左 a derecha Haga clic en：方向右 K Haga clic en：OK greso Haga clic en：返回 on el rató Haga clic en：空鼠开启/关闭 olumen acia abajo Haga clic en ： Volumen hacia abajo umentar volumen Haga clic en：Aumentar el volumen 用户校准及 灵敏度调节 1：同时按住“音量加+ 和 音量-”指示灯常亮--->将遥控器放置不动 3 秒 后红灯快速闪烁（100ms 亮 100ms 灭）开始校准（校准时间 5 秒），校准 成功红灯常亮（保持 10 分钟后自动退出或者按任意按键退出），校准失败 红灯熄灭 2：鼠标+音量加 灵敏度调高 3：鼠标+有量减 灵敏度调低 4: 鼠标速度调节分为 5 档，默认在中间挡 Use the mouse Mouse On When there is a link, click the empty mouse button on the remote control Mouse Off Click the mouse button to close the empty mouse Left mouse button The OK key responds to the left mouse button function User calibration and sensitivity adjustment 1: At the same time, press and hold the "volume plus + and volume -" indicator light always on --- > put the remote control in place for 3 seconds, the red light will flash quickly (100ms on and 100ms off ) to start calibration (calibration time is 5 seconds), the red light will always be on if calibration is successful (it will exit automatically after 10 minutes or press any key to exit), and the red light will go out if calibration fails 2: Mouse + volume plus sensitivity up 3: Mouse + reduced sensitivity 4: Mouse speed adjustment is divided into five gears, the default is in the middle gear Abrir el ratón 有蓝牙已连接的情况下，遥控器单击空鼠键开启 Cierre del Haga clic en la tecla ratón para cerrar el ratón vacío ratón Botón izquierdo del ratón La tecla OK responde a la función del botón izquierdo del ratón Calibración del usuario y regulación de sensibilidad 1: al mismo tiempo mantenga pulsado el indicador "volumen más + y volumen -" siempre encendido ---> mantenga el mando a distancia parado durante 3 segundos después de que la luz roja paraliza rápidamente (100ms encendido y 100ms apagado) para iniciar la calibración (tiempo de calibración 5 segundos) 2: ratón + volumen más sensibilidad 3: ratón + con reducción de sensibilidad 4: el ajuste de la velocidad del ratón se divide en 5 marchas, por defecto en el medio 低电提示 *采用 2 节 7 号干电池供电 *低电检测和提示 1）VBAT<=2.4V 提示低电， 2）VBAT<=2.2V 以下禁止工作，重上电才能恢复，检测到禁止工作电压，红灯快速闪 烁 10 秒后进入禁止，这 10 秒内可以正常工作， Low power prompt *Two 7 dry batteries are used for power supply *Low power detection and prompt 1) Vbat < = 2.4V indicates low power, 2) When Vbat < = 2.2V, it is forbidden to work, and it can only be restored after power on again. When the forbidden working voltage is detected, the red light will flash rapidly for 10 seconds, and then it will enter the forbidden mode, which can work normally within 10 seconds, Consejos de baja potencia * alimentado por 2 pilas secas 7 * detección de baja potencia y consejos 1) VBAT<=2.4V indica baja potencia, 2) el funcionamiento está prohibido por debajo de VBAT<=2.2V, sólo se puede volver a poner la electricidad, se detecta la tensión prohibida de funcionamiento, la luz roja paraliza r á pidamente durante 10 segundos despu é s de entrar en la prohibición, estos 10 segundos pueden funcionar normalmente, 指示灯说明 没有链接蓝牙：按下遥控器指示灯闪烁 2 次 蓝牙链接成功状态：按一下指示灯闪烁一次 Indicator light description No Bluetooth link: press th…

Text truncated - open the document above for the full version.

RF_160, Issue 03 Declaration of Authorization We Name: Motorola Mobility LLC Address: 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA City: Chicago Country: U.S.A. Declare that: Name Representative of agent: Lisa Wang (1) Agent Company name: EMTEK (SHENZHEN) CO., LTD. Address: Bldg 69, Majialong Industry Zone, Nanshan District, City: Shenzhen Country China is authorized to apply for Certification of the following product(s): Product description: READY FOR AIR REMOTE Type designation: MR-01 Trademark: FCC ID: IHDT6ZR2 on our behalf. Date: 2021-5-30 Name: Jeff Narducci Function: Director Product Compliance Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Motorola Mobility LLC Address: 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA City: Chicago Country: U.S.A. To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: IHDT6ZR2 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: The product is not yet on the market and is for trade purposes Planned Release Date STC: 180 days (notes 2, 3, 4, 5) Date: 2021-6-10 Name and signature of applicant: Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 EUT View 3 EUT View 4 EUT View 5 EUT View 6 ----------------The end----------------

Label and label location

EUT INTERNAL PHOTOGRAPHS Solder Board-Component View 1 Solder Board-Component View 2 Solder Board-Component View 3 Solder Board-Component View 4 ----------------The end---------------- BT ANT

RF EXPOSURE EVALUATION 1. Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 2. Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] .[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 3. Test Result The max conducted power including tune-up tolerance is 1.5dBm(1.41mW). [(max.power of channel, mw)/(min. test separation distance, mm)][ √f(GHz)] =1.41/5*(√2.402)=0.44<3.0 Then SAR evaluation is not required

Report No. ES210430033W Page 1 of 42 Ver.1.0 TEST REPORT Product Name ： READY FOR AIR REMOTE Model Number ： MR-01 FCC ID ： IHDT6ZR2 Prepared for : Motorola Mobility LLC Address : 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES210430033W Date(s) of Tests : May. 1, 2021 to May. 15, 2021 Date of issue : May. 16, 2021 Report No. ES210430033W Page 2 of 42 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ......................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ....................................................................................................................... 5 3 SUMMARY OF TEST RESULT ............................................................................................................................ 6 4 TEST METHODOLOGY ....................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................................ 7 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ................................................................................................................. 9 5.1 FACILITIES .................................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................................... 9 6 TEST SYSTEM UNCERTAINTY ........................................................................................................................ 10 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2......................................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ..................................................................................................... 12 7.4 SUPPORT EQUIPMENT.............................................................................................................................. 13 8 TEST REQUIREMENTS .................................................................................................................................... 14 8.1 DTS 6DB BANDWIDTH ............................................................................................................................... 14 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ................................................................................... 17 8.3 MAXIMUM POWER SPECTRAL DENSITY ................................................................................................. 20 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ................................................. 23 8.5 RADIATED SPURIOUS EMISSION ............................................................................................................. 28 8.6 CONDUCTED EMISSIONS TEST ............................................................................................................... 40 8.7 ANTENNA APPLICATION ............................................................................................................................ 41 Report No. ES210430033W Page 3 of 42 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Motorola Mobility LLC Address： 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA Manufacturer : Motorola Mobility LLC Address： 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA EUT : READY FOR AIR REMOTE Model Name : MR-01 Trademark : Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : May. 1, 2021 to May. 15, 2021 Prepared by : Tracy Hu /Editor Reviewer : Sewen Guo /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ES210430033W Page 4 of 42 Ver.1.0 Modified History Version Report No. Revision Date Summary Ver.1.0 ES210430033W / Original Report Report No. ES210430033W Page 5 of 42 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Product: READY FOR AIR REMOTE Model Number: MR-01 Sample: 1# Device Type: Bluetooth V4.0 Data Rate : 1Mbps for GFSK modulation Modulation: GFSK Operating Frequency Range: 2402-2480MHz Number of Channels: 40 Channels for Bluetooth DTS Transmit Power Max: 1.26 dBm Antenna Type: Integral Antenna Antenna Gain: 1.5 dBi Rating: DC 3V Test voltage: DC 3V Temperature Range: -10°C ~ 55°C Date of Received: May. 1, 2021 Applicant: Motorola Mobility LLC Address: 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA Manufacturer: Motorola Mobility LLC Address: 222 W,Merchandise Mart Plaza, Chicago IL 60654 USA Factory : Linxee(Shenzhen) Technology Co.,Ltd. Address : 6nd …

Text truncated - open the document above for the full version.

Setup photos Radiated Spurious Emissions(30MHz-1GHz) Radiated Spurious Emissions(above 1GHz)
