IKQIPRFCiJET Wireless RF Remote Control

VOLUME UP:Press and HOLD thisbutton to scroll volume up REWIND:Press and releasethis button to movetrack BACKWARDS.Press and HOLD thisbutton to rewindthrough the trackVOLUME DOWN:Press and HOLD thisbutton to scroll volume down PAUSE/PLAY/SLEEP:Press and release to toggle between Pause and Play.* Press andHOLD for 2 full seconds to put the iPOD into sleep mode.*If you press and hold this button for longer than 1 second but lessthan 2 seconds the iJET will ignore your request. FORWARD:Press and releasethis button to movetrack FORWARD.Press and HOLD thisbutton to forwardthrough the track. CONGRATULATIONS ON YOUR PURCHASE OF THE iJET WIRELESS RF REMOTE CONTROL The iJET was designed to provide maximum control of your iPOD fromanywhere you choose to place it regardless of whether it is in yourbackpack at school or hundreds of feet away in a different room connected to your home stereo.OPERATION:Plug the iJET into the top of your iPOD and WAIT 30 seconds. A selfdiagnostic will automatically run and your wireless remote will beready for operation within 30 seconds. Plug in your ear buds, speakersor connect to your home stereo through a set of RCA jacks (supplied insome iJET kits). The connection of ear buds, RCA jacks or stereo wire isimperative for optimum performance since the iJET uses this pluggedin wire as an antenna (Patent Pending) for maximum range. OPTIONAL iJET ACCESSORIES:iJET Remote:Program up to 10 iJET remotes into any receiver. Place an iJET remotein each bedroom, out by the pool or anywhere you choose to controlyour music. Part Number iJET-Remote. Belt Clip:The optional Belt clip is perfect for the mobile iPOD user. It easily clipsto your belt, Backpack strap, purse or anywhere you desire to keeptrack of your iJET remote control. The remote easily snaps into the beltclip for maximum flexibility. Part Number iJET-Belt Optional Color Remote Faces:For iPOD personalization you can purchase optional matching colorremote and receiver cases. Simply snap off the top cover of the iJETremote and the receiver’s face plate. Snap on a new metallic remoteface on both the remote and receiver (Packaged together). The package comes complete with all iPOD mini color configurations. Part Number: iJET-Pink, iJET- Blue, iJET-Silver, iJET-Gold,iJET-Green. ADVANCED LOW POWER MODE (ALPM):The iJET uses an advanced power down mode which minimizes currentdraw on your iPOD battery if you are not connected to a constantpower source. After 20 minutes of sensing no music playing or noremote commands being sent, the iJET goes into an advanced batterysave mode. The iJET receiver will automatically re-power itself when itdetects music playing (If there was none before) or it sees a remotebutton being pressed for more than .6 seconds. Toll Free 888-869-4737 1185 Park Center Drive • Vista, CA 92081 www.abtech2.com OPTIONAL iJET ACCESSORIES continued : iPOD Stand:This dual function stand is the perfect option for your iPOD because itis both fully functional and decorative. It props the iPOD upright onyour stereo system, television or wherever you choose to place it mak-ing viewing of the LCD screen easy as well as keeping the IJET uprightfor maximum reception of the remote. The top section can be removedif you are not using the iPOD charger or place it in the base to hidethe charger plug, ear buds or any other small iPOD accessory. Part Number iJET-Stand. OPERATION continued : VOLUME UP:Press and HOLD thisbutton to scroll volume up REWIND:Press and releasethis button to movetrack BACKWARDS.Press and HOLD thisbutton to rewindthrough the trackVOLUME DOWN:Press and HOLD thisbutton to scroll volume down PAUSE/PLAY/SLEEP:Press and release to toggle between Pause and Play.* Press andHOLD for 2 full seconds to put the iPOD into sleep mode.*If you press and hold this button for longer than 1 second but lessthan 2 seconds the iJET will ignore your request. FORWARD:Press and releasethis button to movetrack FORWARD.Press and HOLD thisbutton to forwardthrough the track. CONGRATULATIONS ON YOUR PURCHASE OF THE iJET WIRELESS RF REMOTE CONTROL The iJET was designed to provide maximum control of your iPOD fromanywhere you choose to place it regardless of whether it is in yourbackpack at school or hundreds of feet away in a different room connected to your home stereo.OPERATION:Plug the iJET into the top of your iPOD and WAIT 30 seconds. A selfdiagnostic will automatically run and your wireless remote will beready for operation within 30 seconds. Plug in your ear buds, speakersor connect to your home stereo through a set of RCA jacks (supplied insome iJET kits). The connection of ear buds, RCA jacks or stereo wire isimperative for optimum performance since the iJET uses this pluggedin wire as an antenna (Patent Pending) for maximum range. OPTIONAL iJET ACCESSORIES:iJET Remote:Program up to 10 iJET remotes into any receiver. Place an iJET remotein each bedroom, out by the pool or anywhere you choose to controlyour music. Part Number iJET-Remote. Belt Clip:The optional Belt clip is perfect for the mobile iPOD user. It easily clipsto your belt, Backpack strap, purse or anywhere you desire to keeptrack of your iJET remote control. The remote easily snaps into the beltclip for maximum flexibility. Part Number iJET-Belt Optional Color Remote Faces:For iPOD personalization you can purchase optional matching colorremote and receiver cases. Simply snap off the top cover of the iJETremote and the receiver’s face plate. Snap on a new metallic remoteface on both the remote and receiver (Packaged together). The package comes complete with all iPOD mini color configurations. Part Number: iJET-Pink, iJET- Blue, iJET-Silver, iJET-Gold,iJET-Green. ADVANCED LOW POWER MODE (ALPM):The iJET uses an advanced power down mode which minimizes currentdraw on your iPOD battery if you are not connected to a constantpower source. After 20 minutes of sensing no music playing or noremote commands being sent, the iJET goes into an advanced batterysave mode. The iJ…

Text truncated - open the document above for the full version.

Ipod tx Block diagram LED MCU TX CH-1~CH-5 T r ansmitter

Compliance Certification Services Inc. Report No.: 50727209 Date of Issue: August 24, 2005 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 50727209 Date of Issue: August 24, 2005 Page Compliance Certification Services Inc. Report No.: 50727209 Date of Issue: August 24, 2005 Page

FCC ID LABEL FORMAT AND LOCATION Applicant: Scosche Industries Inc. FCC ID: IKQIPRFC FCC ID: IKQIPRFC This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No.: 50727209 Date of Issue: August 24, 2005 Page PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No.: 50727209 Date of Issue: August 24, 2005 Page

iJet Operational Description The iJet is a low powered, which is installed in micro controller integrated with transmitter function for wireless play iPod . See the function descriptions in attached. The transmitter is powered by two 3 volt batterys. It is designed to operate on a single fixed frequency at 433.92 MHz. See the attached block diagram and schematic. There are 5 switches trigger the integrated circuit (U1) which produces the digital control signals and will modulate the carrier signal (ASK). The carrier signal is generated by a I C oscillator/amplifier circuit comprised of a 433.92 MHz SAW(X1) . The modulated output of the RF stage is coupled to the loop antenna. The antenna is on-board track, around 80mm. The iJet is operated by the triggered momentarily within 0.2 second and will automatically deactivate send signal to receiver. This feature is incorporated by the U1 internally. All tuning and verification are performed by the manufacturer and there are no adjustments can be made by users.

821-0037-03 1.0 IPOD TX A 1 1 Tuesday, March 15, 2005 D : \ W OR K\ C L PAN -N EW \ 線路 圖 \F CC\I P O D T X F C C . DS N TitleSize Document Number Rev Date: Sheet of VCC VCC VCC VCC VCC VCC VCC TX CH-3CH-4 CH-1 RED SAW CH-5 CH-2 SW1SW ITCH 1 2 R51K 1 2 X1 433.92MHZ/±75KHz 1 2 Q13 3 5 6 2 3 1 C37.5P 1 2 R2100K 1 2 C1390P 1 2 R1100 1 2 C20.5P 1 2 L147nH 1 2 BT12025*2 1 2 R3100K 1 2 SW4SWITCH 1 2 R4100K 1 2 SW3SWITCH 1 2 U1PIC 16C505 1 2 3 4 5 6 7 8 9 10 11 12 13 14 VDDRB5/OSC1RB4/OSC2RB3/MCLRRC5/T0CK1RC4RC3 RC2 RC1RC0 RB2RB1RB0VSS D1DAP202K 2 1 3 C40.1uF 1 2 R8100K 1 2 SW5SWITCH 1 2 D2RED LED 1 2 J1 Prog Pads 1 2 3 4 5 R71K 1 2 SW2SW ITCH 1 2 ANT 821-0038-03 1.0 IPOD RECEIVER A 11 Friday, February 25, 2005 D:\WORK\CLPAN-NEW\IPOD\003803_01A1.DSN TitleSize Document Number Rev Date: Sheet of VCC VCC RFIN 3V VCC VCC VCC VCC DISABLE VCC RFIN 3V VIN DATA R2 2.2K 1 2 Q1 MMST2222A 2 3 1 C15104 1 2 D14148 1 2 JP2 HEADER 3 123 JP1 PHONEJACK STEREO 2 1 3 C73.3P 1 2 C8470 1 2 C17 7.5P 1 2 L12.5T 1 2 C6100P 1 2 C13100P 1 2 R5100K 1 2 C12103 1 2 L310nH 1 2 C3470P 1 2 R6 1K 1 2 C232P 1 2 C4 560P 1 2 C51uF 1 2 R4100K 1 2 U2 RX3310A 1 2 3 4 5 6 7 8 9 18 17 16 15 14 13 12 20 19 10 11 OSC2FOCPACPBCPOVSSVSSDATADISABLE VCC2MIXIN VORF VEE VIRF LFBLFA OSC1VCC1 CPC LIN C11103 1 2 C14 22UF 1 2 L2 39nH 1 2 C968P 1 2 CON1HEADER 3 123 R12.2K C11uF R3 1K L5 33nH 1 2 U1 PIC 12F675 7 6 5 2 4 8 3 1 GP0GP1GP2 GP5GP3 VSS GP4VDD C2 104 1 2 P1 ICSP PADS 1 2 3 4 5 C21 3.9P 1 2 L4 33nH 1 2 C20 3.9P 1 2 L6 33nH 1 2 C22 3.9P 1 2 R8 0 1 2 R710 1 2 C10103 1 2 C19 104 1 2 C18 104 1 2 C26 nc 1 2 C25 nc 1 2 C24 nc 1 2 GND DATA

Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 1 of 29 Rev. 00 FCC ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR of iJET WIRELESS RF REMOTE CONTROL FCC ID Number : IKQIPRFC Trade Name : Evolution Model Number : IPRFC Agency Series : N/A Report Number : 50727209-RP1 Date : August 24, 2005 Prepared to Scosche Industries Inc. 1550 Pacific Ave Oxnard CA 93033 Prepared by Compliance Certification Services Inc. No. 165, Chung Sheng Road, Hsin Tien City, Taipei Hsien, Taiwan, R. O. C. TEL: (02)2217-0894 FAX: (02)2217-1029 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 2 Rev. 00 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE................................................3 2. PRODUCT DESCRIPTION.................................................................4 3. TEST FACILITY...................................................................................4 4. MEASUREMENT STANDARDS.........................................................4 5. TEST METHODOLOGY.....................................................................4 6. MEASUREMENT EQUIPMENT USED.............................................5 7. POWERLINE RFI LIMIT....................................................................5 8. RADIATED EMISSION LIMITS.........................................................6 9. SYSTEM TEST CONFIGURATION...................................................6 10. TEST PROCEDURE..........................................................................7 11. Equipment Modifications.....................................................................8 12. TEST RESULT....................................................................................9 12.1 Maximum Modulation Percentage (M%)..........................................9 12.2 The Emissions Bandwidth.................................................................9 APPENDIX I............................................................................................10 Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 3 Rev. 00 1. VERIFICATION OF COMPLIANCE COMPANY NAME : Scosche Industries Inc. 1550 Pacific Ave Oxnard CA 93033 CONTACT PERSON : Jessica Chang TELEPHONE NO. : (886-6) 228-5663 EUT DESCRIPTION : iJET WIRELESS RF REMOTE CONTROL MODEL NAME/NUMBER : IPRFC FCC ID : IKQIPRFC DATE TESTED : July 29, 2005~August 2, 2005 REPORT NUMBER : 50727209-RP1 TYPE OF EQUIPMENT SECURITY EQUIPMENT (INTENTIONAL RADIATOR) EQUIPMENT TYPE iJET WIRELESS RF REMOTE CONTROL MEASUREMENT PROCEDURE ANSI 63.4 / 2003 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 The above equipment was tested by Compliance Certification Services Inc. for compliance with the requirements set forth in the FCC CFR 47, PART 15. The results of testing in this report apply to the product/system which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services Inc. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services Inc. will constitute fraud and shall nullify the document. Approved by: Reviewed by: Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 4 Rev. 00 2. PRODUCT DESCRIPTION Fundamental Frequency 433.92MHz Power Source 3V Battery Transmitting Time Periodic < 5 seconds Associated Receiver iJet mini RX (DoC) 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at No. 165, Chung Sheng Road, Hsin Tien City, Taipei, Taiwan R.O.C. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/2003. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 5 Rev. 00 6. MEASUREMENT EQUIPMENT USED Open Area Test Site # K Name of Equipment Manufacturer Model Serial Number Calibration Due SITE NSA CCS K Site N/A 09/04/2005 MEASURE RECEIVER R&S ESVS30 828488/004 09/24/2005 SPECTRUM ANALYZER ADVANTEST R3132 120900029 No Calibration Required ANTENNA SCHAFFNER CBL 6112B 2846 05/27/2006 PRE- AMPLIFIER SCHAFFNER CPA9231A 3639 10/08/2005 CABLE SUHNER RG 214 N-TYPE #K2 02/18/2006 THERMO- HYGRO METER TFA N/A NO.4 02/17/2006 Above 1GHz Used EMC ANALYZER (100Hz-22GHz) HP 8566B 2937A06102 06/30/2006 ANTENNA (1-18GHz) EMCO 3115 5761 01/17/2006 AMPLIFIER (1-18GHz) HP 8449B 3008A01266 02/16/2006 CABLE (1-18GHz) JYEBAO LL142 SMA#RS1&2 02/16/2006 CABLE (1-18GHz) JYEBAO LL142 SMA#C1 04/28/2006 Remark: Each piece of equipment is scheduled for calibration once a year. 7. POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 CARRIER CURRENT SYSTEM IN THE FREQUENCY RANGE OF 450 KHz TO 30 MHz SECTION 15.205 AND SECTION 15.209, 15.221, 15.223, 15.225 OR 15.227, AS APPROPRIATE. BATTERY POWER NO REQUIRED. Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID:…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No.: 50727209-RP1 FCC ID: IKQIPRFC Date of Issue: August 24, 2005 Page 6 Rev. 00 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209 RESTRICTED BANDS OF OPERATION SECTION 15.205 PERIODIC OPERATION IN THE BAND 40.66 -40.70 MHz AND ABOVE 70 MHz. SECTION 15.231 9. SYSTEM TEST CONFIGURATION Use a block of foam and combined it with EUT wrapping rubber band around it. This way it can test X, Y and Z axis. To activate continuous transmitting & receiving, place a small plastic block between rubber band and EUT push button. Radiated Open Site Test Set-up
