IKQIUFMDFM Audio Transmitter

SCOSCHE IUFMD OPERATING INSTRUCTIONS CONNECTING THE IUFMD: 1. Plug the IUFMD into a cigarette lighter or +12VDC Power/Accessory socket in your vehicle. The Blue backlit LCD screen of the IUFMD will illuminate indicating there is power to the unit. The IUFMD will also display the FM frequency the unit is currently set to. A. For all iPods (excluding Shuffle), use the iPod dock connector to mini USB cable. Plug the docking cable into the bottom of your iPod then plug the Mini USB end of the cable into the receptor on the back of the IUFMD. This cable will also charge the iPod battery when connected. B. For all other MP3 players, PDAs or other media devices, use the cable with the 3.5mm headphone plug. Insert the 3.5mm plug into the headphone jack of your device then plug the Mini USB end of the cable into the receptor on the back of the IUFMD. (Use the 3.5mm plug for iPod Shuffle. The 3.5mm plug can also be used all other iPod models, however it will not charge the battery when using the headphone plug.) TUNING THE IUFMD: 1. With the cable connected between your device and the IUFMD it is time to choose a frequency. The IUFMD allows you to tune to any frequency between 88.1Mhz and 107.9Mhz on your FM radio. HINT: Before setting the frequency, manually scan your FM band on your car stereo and note the frequencies where existing radio stations are located. Select a frequency with NO existing station or mostly static for best results. In populated or urban areas it may take a few tries to find best frequencies with NO stations on them. 2. Use the “+” or “-“ buttons to tune the IUFMD to the frequency that exactly MATCHES the frequency selected on your Car Stereo. 3. Power on your device and play an audio file. You should hear the music from your portable player through your stereo. Keep the volume on your media player low and use the volume on your car stereo as the master volume control. For future use, set the selected station to an FM radio preset station button on your car stereo. If there is excess/unwanted static during play, then select a different frequency repeating steps #1 and #2. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and: 2) This device must accept any interference received, including interference that may cause undesired operation Rev.A JE 05.16.06 FCC STATEMENT: “Modification not authorized by the manufacturer may void users authority to operate this device.” NOTE: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC ID: IKQIUFMD MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Wednesday, August 30, 2006 5:05 PM To: '[email protected]' Cc: '[email protected]' Subject: FCC ID: IKQIUFMD 8/30/2006 Mr. Ramirez: In order for processing of this permissive change application (FCC ID: IKQIUFMD) to continue, the following issue(s) will have to be addressed: 1) Please describe the method employed for making average measurements. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is IKQIUFMD-1. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Fax (714) 579-1850

Correspondence by Project Project Number: Correspondence NumberMemo IKQIUFMD-1 Mr. McCutchan, In response to your request of averaging methods I am resubmitting the test report. Please see the last paragraph of page 16 "Sample Calculations". If you have any further questions, please feel free to contact me. Best Regards, Ruby A. Hall -1401226518

FCC ID: IKQIUFMD TOP VIEW FCC ID: IKQIUFMD BOTTOM VIEW

FCC ID: IKQIUFMD LABEL LOCATION Bottom of Unit

FCC ID: IKQIUFMD COVER REMOVED FCC ID: IKQIUFMD PC BOARD SIDE 1 FCC ID: IKQIUFMD PC BOARD SIDE 2

FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 1 of 17 FCC PART 15, SUBPART C TEST REPORT for FM AUDIO TRANSMITTER M/N: IUFMD FCC ID: IKQIUFMD Prepared for SCOSCHE INDUSTRIES INC. 1550 PACIFIC AVENUE OXNARD, CA 93033 Prepared by: _____________________ REYNALD O. RAMIREZ Approved by: ____________________ RUBY A. HALL COMPATIBLE ELECTRONICS INC. 2337 TROUTDALE DRIVE AGOURA, CALIFORNIA 91301 (818) 597-0600 DATE: JULY 21, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 17 2 2 2 13 18 54 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 2 of 17 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Photograph of Test Configuration - EMI 8 4.1.2 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Conducted Emissions Test 13 7.1.2 Radiated Emissions Test 14 7.1.3 RF Emissions Test Results 15 7.1.4 Sample Calculations 16 8. TEST PROCEDURE DEVIATIONS 17 9. CONCLUSIONS 17 FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 3 of 17 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts and Photos • Test Setup Diagrams • Antenna and Amplifier Gain Factors • Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Test Site FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 4 of 17 GENERAL REPORT SUMMARY This electromagnetic emission report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form except in full, without the written permission of Compatible Electronics. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: FM Audio Transmitter Model Number: IUFMD SN: None Product Description: This is an FM Audio Transmitter. Modifications: The EUT was not modified during the testing. Manufacturer: Scosche Industries Inc. 1550 Pacific Avenue Oxnard, CA 93033 Test Date: July 13, 2006 Test Specifications: EMI requirements FCC CFR Title 47, Part 15 Subpart A, B and C sections 15.31 (e), 15.109, 15.205, 15.209 and 15.239 Test Procedure: ANSI C63.4: 2003. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz. This is a DC powered device that does not plug into AC Mains therefore this test was deemed unnecessary. 2 Radiated RF Emissions, 9 kHz – 1079 MHz. Complies with the limits of FCC CFR Title 47, Part 15 Subpart C 15.205, 15.209 and 15.239 and the requirements of 15.31(e). FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 5 of 17 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the FM Audio Transmitter Model Number: IUFMD. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 2003. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined in FCC CFR Title 47, Part 15 Subpart A (15.31e), Subpart B, 15.109 Subpart C 15.205, 15.209 and 15.239. FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 6 of 17 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 2337 Troutdale Drive, Agoura, California 91301. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personnel Scosche Industries Inc. Jack DeBiasio Project Manager Compatible Electronics Inc. Reynald O. Ramirez Sr. Test Engineer Ruby A. Hall Lab Manager 2.4 Date Test Sample was Received The test sample was received on June 28, 2006. 2.5 Disposition of the Test Sample The test sample remains at Compatible Electronics Inc. 2.6 Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. RF Radio Frequency EMI Electromagnetic Interference EUT Equipment Under Test P/N Part Number S/N Serial Number HP Hewlett Packard ITE Information Technology Equipment CML Corrected Meter Limit LISN Line Impedance Stabilization Network FCC ID: IKQIUFMD Report Number: A60713F1 2337 TROUTDALE DRIVE, AGOURA, CALIFORNIA, 91301 • PH: (818) 597-0600 FX: (818) 597-1187 Page 7…

Text truncated - open the document above for the full version.

FCC ID: IKQIUFMD FRONT VIEW FCC ID: IKQIUFMD REAR VIEW
