IOL-125-AV1034MiniTracker Plus II Reader

Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Tuesday, December 18, 2007 12:17 PM To: '[email protected]' Cc: '[email protected]' Subject: FCC ID: IOL-125-AV1034 12/18/2007 Mr. Fujimoto: In order for processing of this certification application (FCC ID: IOL-125-AV1034) to continue, the following issue (s) will have to be addressed: 1) The test report indicates that the 2001 version of ANSI C63.4 was used. The 2003 edition is now required. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is IOL-125-AV1034-1. Best regards, Scott McCutchan Operations Manager Compatible Electronics TCB

Correspondence by Project Project Number: Correspondence NumberMemo 125-AV1034-1 In order for processing of this certification application (FCC ID: IOL-125-AV1034) to continue, the following issue(s) will have to be addressed: 1) The test report indicates that the 2001 version of ANSI C63.4 was used. The 2003 edition is now required. Response: ANSI C63.4: 2003 was used. The test report has been revised to correctly state that the 2003 version of ANSI C63.4 was used. 1198002836

Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 13 FCC PART 15, SUBPART B and C TEST REPORT for MINI-TRACKER PLUS II READER MODEL: 1034 RFID READER Prepared for AVID IDENTIFICATION SYSTEMS, INC. 3185 HAMNER AVENUE NORCO, CALIFORNIA 92860 Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: DECEMBER 10, 2007 REPORT APPENDICES TOTAL BODY A B C D E PAGES 13 2 2 2 11 4 34 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 13 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 EMI Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Radiated Emissions (Spurious, Fundamental, and Harmonics) Test 12 8. CONCLUSIONS 13 Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 13 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of 3 Meter Radiated Test Site 2 Plot Map and Layout of 10 Meter Radiated Test Site Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 13 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Mini-TracKer Plus II Reader Model: 1034 RFID Reader S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: AVID Identification Systems, Inc. 3185 Hamner Avenue Norco, California 92860 Test Dates: November 28 and 29, 2007 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205 and 15.209 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed, as the EUT is a battery-operated device that does not connect to the AC public mains. 2 Radiated RF Emissions, 9 kHz - 1000 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C Sections 15.205 and 15.209. Highest Reading in Relation to Spec Limit: 41.75 dBμV @ 192. 071 MHz (*U c = 2.02 dB) Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 13 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Mini-TracKer Plus II Reader, Model: 1034 RFID Reader. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205 and 15.209. Report Number: B71129D1 FCC Part 15 Subpart B and FCC Section 15.209 Test Report Mini-TracKer Plus II Reader Model: 1034 RFID Reader 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 13 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personnel AVID Identification Systems, Inc. Michael F. Cruz Director of Engineering Compatible Electronics, Inc. James Ross Test Engineer Kyle Fujimoto Test Engineer 2.4…
