IOL-1356-AV1033Reader

Confidential Page 1 3/8/2007 AVID Identification Systems RFID Classroom Desktop Reader Model #1033 Confidential Page 2 3/8/2007 FCC NOTICE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction's manual, may cause interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • It is strongly recommended that the TV be plugged into a separate wall outlet. In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Confidential Page 3 3/8/2007 A 3.5” color LCD is used to provide users with a nice screen that is clearly viewable in a variety of lighting conditions. This LCD screen includes a touch screen to allow user data entry into the RFID final product. Standard storage (Flash) and program/data (SDRAM) memory has been specified to store the LEOs embedded OS, custom application programs, and RFID records. 1. Applications for the Classroom RFID Reader This is the Main Menu after booting up the PDA: 1. The “Calibrate” program is used to calibrate the touch screen. 2. The “Clock” program is for displaying the current date and time. 3. The “AVID” program will load the next main menu screen, which will allow the user to enter one of the following five applications: Confidential Page 4 3/8/2007 1) RFID final product “Vendors Program” 2) RFID final product “Classrooms program” (password required to sign in/out) 3) RFID final product “Setup Program” (password required to sign in) 4) RFID final product “File Utilities Program” (password required to delete files) 5) RFID final product “Import / Export Data Program” to SD Card or USB Flash Disk (password protection required) 6) If the User clicks the “Exit” button it will go back to the previous Main Menu screen: Confidential Page 5 3/8/2007 2. Classrooms Program Sample Sceen: This function is only for use by the event Administrator and requires the use of a password. Purpose: This program is for collecting the attendees’ information in a training session or similar event. Attendees will bring the RFID badge to the Reader and the Reader will scan the badge and retrieve the data in the badge. If the User clicks “Exit” and re-enters the correct password, the program will go back to previous screen. Notes: The Operator of the Reader should have the Classroom schedule setup before scanning attendees’ badge. Refer to the “Setup program” section for details. The Attendee will see the screen below when their badge is scanned. This screen will remain for two seconds before it returns back to the Scan screen as pictured above. Confidential Page 6 3/8/2007 In the “Clock-in only” scenario; the “Clocked In Already!” warning message will appear on the screen if the attendee tries to scan in more than once. Confidential Page 7 3/8/2007 In the “Clock-in/Clock-out” scenario: 1. The “Good Bye” message will appear on the screen when the Attendee scans his/her RFID Badge during the “Clock Out” period. It means that the attendee has clocked out successfully. 2. The “Clocked Out Already!” warning message will appear if the Attendee tries to clock out more than once. This warning message screen will stay for two seconds and then go back to the scan page screen. Confidential Page 8 3/8/2007 3. Setup Program This program is only accessible by the Event Administrator or Operator and is used for Classroom scheduling and requires a password to enter into the program. There are four submenus in Setup screen as follows: 4. File Utilities Program Confidential Page 9 3/8/2007 In File Utilities, the following functions are available. a. View/Modify File: browse the records with user selectable sorting order and edit the selected record. Confidential Page 10 3/8/2007 User can select the following sorting order. a. First Name b. Last Name c. Company d. Tag ID e. City f. State g. Phone h. URL i. Email j. Clock-in time k. Clock-out time (only required for classrooms program) l. Lecture name (only required for classrooms program) m. Lecture reference (only required for classrooms program) n. Classroom no. (only required for classrooms program) o. Speaker name (only required for classrooms program) View/Edit Classrooms program: Confidential Page 11 3/8/2007 File Deletion program (Password is required to enter into this screen): 1) User clicks “Delete Vendor’s Database” button to delete the vendor’s user database. 2) User clicks “Delete Classroom’s Database” button…

Text truncated - open the document above for the full version.

3185 Hamner Avenue, Norco, CA 92860 (951) 371-7505 May 3, 2007 CETCB 114 Olinda Drive Brea, CA 92823 Gentlemen: This is a letter of authorization to accept Compatible Electronics, Inc. as an Agent for AVID ID Systems, Inc., 3185 Hamner Avenue, Norco, CA 92860-1983 (AVID), for a period of one year, to sign applications before the certification body on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following AVID ID Systems, Inc. product: RFID Scanners under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of the FCC Rules and Regulations. Please also accept this letter as an attestation that neither AVID ID Systems, Inc. nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non-voting, have been denied federal benefits under section 5301 of the Anti-Drug Abuse act of 1988, 21 U.S.C. 853(a). In addition, AVID ID Systems, Inc. will notify the Federal Communications Commission if, at any time, the situation changes causing RF Digital Corporation to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at (951) 371-7505 Sincerely, Michael F. Cruz Director of Engineering AVID ID Systems, Inc.

3185 Hamner Avenue, Norco, CA 92860 (951) 371-7505 May 3, 2007 CETCB 114 Olinda Drive Brea, CA 92823 Subject: Request for withholding from public disclosure the schematic diagrams, block diagrams, and operational description pursuant to an application for certification. Gentlemen: We, AVID ID Systems, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with our application for certification be withheld from public disclosure per Section 0.459 of the FCC rules. This request is made under the provisions of Section 0.457 (d) of the Commissions rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any questions or need any additional information, please give me a call at (951) 371-7505. Sincerely, Michael F. Cruz Director of Engineering Avid ID Systems, Inc.

Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 18 FCC PART 15, SUBPART B and C TEST REPORT for READER MODEL: AVID1033 Prepared for AVID ID SYSTEMS, INC. 3185 HAMNER AVENUE NORCO, CALIFORNIA 92860 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MARCH 6, 2007 REPORT APPENDICES TOTAL BODY A B C D E PAGES 18 2 2 217 14 55 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 7. TEST PROCEDURES 14 7.1 RF Emissions 14 7.1.1 Conducted Emissions Test 14 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 15 7.1.3 Radiated Emissions (Spurious and Harmonics) Test (Continued) 16 7.2 Frequency Tolerance of Carrier Signal 17 8. CONCLUSIONS 18 Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 18 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Reader Model: AVID1033 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: AVID ID Systems, Inc. 3185 Hamner Avenue Norco, California 92860 Test Dates: February 21, 22, and 23, 2007 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.207, 15.209 and 15.225 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 18 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.207. 2 Radiated RF Emissions, 9 kHz – 135.6 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209 and 15.225. 3 Radiated RF Emissions, 135.6 MHz – 2000 MHz Complies with the Class A limits of CFR Title 47, Part 15, Subpart B. Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 18 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Reader, Model: AVID1033 (EUT). The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class A (above 135.6 MHz) and the Class B (135.6 MHz and below) specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209 and 15.225. Report Number: B70223D2 FCC Part 15 Subpart B and FCC Section 15.225 Test Report Reader Model: AVID1033 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 7 of 18 2. ADMINISTRATIVE DATA 2.1 Location of Testing The EMI tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2 Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST). 2.3 Cognizant Personne…

Text truncated - open the document above for the full version.
