IOU0630S02PCI Card

High Speed 11Mbps Wireless LAN User’s Guide P/N: 85-506300-10 Rev. X1 March 2000 National Datacomm Corporation 4F, No. 24-2, Industry East 4th road Science Park, Hsin-Chu Taiwan, R.O.C. Technical Support E-mail: [email protected] NDC World Wide Web www.ndc.com.tw PCI/PC Card ii InstantWave High Speed PCI/PC Card TRADEMARKS NDC and InstantWave are trademarks of NDC Communications, Inc. All other names mentioned in this document are trademarks/registered trademarks of their respective owners. NDC provides this document “as is,” without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. NDC may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time. This document could include technical inaccuracies or typographical errors. FCC WARNING This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ü Reorient or relocate the receiving antenna ü Increase the separation between the equipment and receiver ü Connect the equipment into an outlet on a circuit different from that to which the receiver is connected ü Consult the dealer or an experienced radio/TV technician for help You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation InstantWave High Speed PCI/PC Card iii Packing List The package contents vary depending on whether you have purchased the PCI Card, or the PC Card version: The PCI Card package should contain the following items: • One PCI Card • One Antenna • One CD ROM (Windows Driver and Utility program) • One Diskette for Windows NT • This User’s Guide The PC Card package should contain the following items: • One PC Card • One CD ROM (Windows Driver and Utility program) • One Diskette for Windows NT • This User’s Guide iv InstantWave High Speed PCI/PC Card Table Of Contents 11MBPS WIRELESS LAN..............................................................................................I INTRODUCTION..............................................................................................................2 INSTANTWAVE FAMILY...................................................................................................2 SYSTEM REQUIREMENTS..................................................................................................2 Hardware Platform......................................................................................................2 Software Environment................................................................................................2 GLOSSARY..........................................................................................................................3 GETTING STARTED.......................................................................................................6 HARDWARE INSTALLATION.............................................................................................6 PCI Card Installation.................................................................................................6 PC Card Installation...................................................................................................6 LEDS...................................................................................................................................7 DRIVER INSTALLATION/UNINSTALLATION...................................................................8 Installation in Windows 95........................................................................................8 Uninstalling the Adapter from Windows 95..........................................................11 Installation in Windows 98......................................................................................12 Uninstalling the Adapter from Windows 98..........................................................13 Installation in Windows NT 4.0...............................................................................14 Uninstalling the Adapter from Windows NT 4.0..................................................15 THE INSTANTWAVE WINDOWS UTILITY PROGRAM...............................16 INSTANTWAVE UTILITY INSTALLATION.....................................................................16 UNINSTALLING THE UTILITY PROGRAM......................................................................17 SOFTWARE UPGRADE PROCEDURES...............................................................18 TROUBLESHOOTING.................................................................................................19 WINDOWS 95/98..............................................................................................................19 Installation Problems................................................................................................19 WINDOWS NT 4.0...............................................................................................…

Text truncated - open the document above for the full version.

4.2 cm 6.6 cm

Page 1 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 2 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 3 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 4 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 5 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 6 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 7 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02 Page 8 of 8 REPORT NO.:RF89042101 Issued date : April 28, 2000 FCC ID: IOU0630S02


     1. Introduction 2.4 GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the total power input to the antenna is measured by power meter. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition A software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition

  6 Test Results 6.1 Antenna Gain
            ! "#!     # 6.2 Output Power Into Antenna & RF Exposure Distance :




  $!$#%!&# '$!($#%&#( $!'$$&#&&# The distance r (4 th column) calculated from the Friis transmission formula is far more shorter than 20 cm separation requirement. So, RF exposure limit warning or SAR test are not required.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 128K*8 FLASH DRAWN DESIGNED CHECKED APPROVED DATE DATE DATE DATE 97-806900-73 IS62LV1024LL U2 AM29LV010B IS62LV1024LL U3 HFA3841

5 5 4 4 3 3 2 2 1 1 DD CC BB AA HFA3861 97-806900-73

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 97-806900-73 HFA3783

5 5 4 4 3 3 2 2 1 1 DD CC BB AA 97-806900-73 HFA3683A

1162 FCC ID: IOU0630S02 Page 1 of 62 REPORT NO.:F88022501Issued date : Feb.25,2000REPORT NO.: RF89042101Issue date : April 28, 2000 REPORT NO:RF89042101 PRODUCT:Wireless LAN PCI Card MODEL NO:NWH630, NCP130, WL102 SERIAL NO:N/A CLIENT:NATIONAL DATACOMM CORPORATION. ADDRESS:4F, No 24-2, INDUSTRY EAST 4 th ROAD, Science Park Hsinchu, Taiwan, R.O.C. ISSUED BY:ADVANCE DATA TECHNOLOGY CORPORATION (ADT CORP.) OFFICE ADDRESS:11F, NO. 1, SEC. 4, NAN-KING EAST RD., TAIPEI, TAIWAN, R.O.C. LABORATORY ADDRESS:NO. 47, 14 LING, CHIA PAU TSUEN, LIN KOU HSIANG, TAIPEI HSIEN, TAIWAN, R.O.C. TEST STANDARD:47CFR Part 15, Subpart B & C TEST DATE:March 31, 2000 TEST RESULT:Pass This test report consists of 63 pages in total. This test report is the property of ADT Corp. and shall not be reproduced, except in full without the written consent of ADT. ADT hereby returns all rights in data to the client for legal use by the client. The test results contained in this report apply only to the samples tested. Accredited Laboratory 2262 FCC ID: IOU0630S02 Page 2 of 62 REPORT NO.:F88022501Issued date : Feb.25,2000REPORT NO.: RF89042101Issue date : April 28, 2000 CONTENTS 1. CERTIFICATION......................................................................................................................4 2. SUMMARY OF TEST RESULTS & GENERAL STATEMENT OF CERTIFICATION...5 3. GENERAL INFORMATION....................................................................................................6 3.1General Description of EUT..........................................................................................6 3.2 Description of Test mode...............................................................................................7 3.3 Test Methodology............................................................................................................7 3.4 Support Units...................................................................................................................8 3.5 Configuration of Tested System...................................................................................9 4. GENERAL INFORMATION OF TEST FACILITY..............................................................10 4.1 Test Lab.:........................................................................................................................10 4.2 Calibration Interval :......................................................................................................10 5. TEST PROCEDURES AND TEST RESULTS..................................................................11 5.1 Conducted Emission Measurement...........................................................................11 5.1.1 Test Instruments..................................................................................................11 5.1.2 Test Procedure.....................................................................................................11 5.1.3 Test Setup............................................................................................................12 5.1.4 Photograph of Test Setup....................................................................................13 5.1.6 Climate Condition...............................................................................................14 5.1.7 Test Results.........................................................................................................14 5.2 6 dB Bandwidth Measurement....................................................................................17 5.2.1 Test Instruments..................................................................................................17 5.2.2 Test Procedure.....................................................................................................17 5.2.3 Test Setup............................................................................................................17 5.2.4 EUT Operating condition....................................................................................17 5.2.5 Climate Condition...............................................................................................17 5.2.6 Test Results.........................................................................................................18 5.3 Maximum Peak Output Power and RF Exposure Limit Measurement.................22 5.3.1 Test Instruments..................................................................................................22 5.6.2 Test Procedure.....................................................................................................22 5.6.2.1 Maximum Peak Output Power.........................................................................22 5.6.2.2 RF Exposure Limit...........................................................................................22 5.6.3 Test Setup............................................................................................................23 5.6.4 EUT Operating condition....................................................................................23 5.6.5 Climate Condition...............................................................................................23 5.6.6 Test Results.........................................................................................................24 3362 FCC ID: IOU0630S02 Page 3 of 62 REPORT NO.:F88022501Issued date : Feb.25,2000REPORT NO.: RF89042101Issue date : April 28, 2000 5.6.6.1 Output Power Into Antenna:.............................................................................24 5.6.6.2 RF Exposure Distance Limits :........................................................................24 5.4 Radiated Emission Measurement...............................................................................28 5.4.1 Test instruments..................................................................................................28 5.4.2 Test Procedure.......................................…
