IOU0640S01USB Wireless LAN Adapter

High Speed 11Mbps Wireless LAN User’s Guide P/N: 85-506300-00 Rev. X1 August 2001 National Datacomm Corporation 4F, No. 24-2, Industry East 4th road Science Park, Hsin-Chu Taiwan, R.O.C. Technical Support E-mail: [email protected] NDC World Wide Web www.ndc.com.tw USB Adapter ii InstantWave High Speed USB Adapter TRADEMARKS NDC and InstantWave are trademarks of NDC Communications, Inc. All other names mentioned in this document are trademarks/registered trademarks of their respective owners. NDC provides this document “as is,” without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. NDC may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time. This document could include technical inaccuracies or typographical errors. FCC WARNING This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation InstantWave High Speed USB Adapter iii FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. iv InstantWave High Speed USB Adapter PackingList The package contents vary depending on whether you have purchased the PnP USB Adapter: The USB Adapter package should contain the following items: • One USB Adapter • One Diskette for Windows driver • Two Diskettes for Windows Utility Program • This User’s Guide InstantWave High Speed USB Adapter v TableOfContents Introduction Congratulations on choosing an InstantWave High Speed wireless networking family product. InstantWave High Speed was designed with a “Maximizing the convenience of networking” philosophy in mind. You will find InstantWave High Speed very easy to configure and use. This User’s Guide gives comprehensive instructions on installing and using the InstantWave High Speed USB Adapters, and also explains how to install and use the InstantWave High Speed Utility Program. InstantWave High Speed Family The InstantWave High Speed USB Adapters are part of the InstantWave High Speed family of easy to use high performance wireless communication products. The family products include: • InstantWave High Speed PC Card (NWH610) • InstantWave High Speed PCI Card (NWH630) • InstantWave High Speed Access Point (NWH660, NWH650) • InstantWave High Speed USB Adapter (NWH640) System Requirements Hardware Platform A station must be an x86 compatible PC with a USB interface. The minimum system configuration is the same as that required to run MS Windows (Windows 95OSR2, 98, NT 4.0, 2000). Software Environment The stations operate in conjunction with most of the MS Windows (Windows 95OSR2, 98, NT 4.0, 2000). 2 InstantWave High Speed USB Adapter Glossary Wireless Network In the IEEE 802.11 definition, a wireless network is classified as an Ad-Hoc network or an Infrastructure network. Ad-Hoc Network An Ad-Hoc network is formed by a number of wireless stations (without an Access Point) communicating via radio waves. For the users, the shared resources on the wireless network appear exactly as they would on a regular wired network. The wireless operation of the network is totally transparent. Figure 1 depicts a typical Ad-Hoc network scenario. Figure 1. An Ad-Hoc Network Infrastructure Network An Infrastructure network is formed by several stations and one Access Point (AP), with the stations within range of the AP. Figure 2 depicts a typical Infrastructure network topology. Figure 2. An Infrastructure Network Server Wired Computers Access Point Wireless Computers (USB Adapter) Wireless Stations InstantWave High Speed USB Adapter 3 Group ID / BSSID A Group ID (the 802.11 standard uses the term BSSID ) is the ID of a wireless cell. A wireless cell is usually made up of stations in an area that the radio signal can comfortably cover. In other words, any wireless station in the cell can communicate with any other within reach of the radio signal (Figure 3). Figure 3. A Wireless Cell (Group) Domain Name / ESSID A domain is usually defined by the network administrator as a segment/subnet of a large network and may be made up of overlapping wireless cells. Wireless nodes can roam freely within the same domain without disconnecting from the network. Figure 4 depicts a common wireless network setup. Figure 4. Roaming in the Same Domain Roaming The convenience of a mobile PC is the ability to move freely. The concept is si…

Text truncated - open the document above for the full version.

IOU0640S01

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 September 2, 2001 RE: National Datacom Corporation FCC ID: IOU0640S01 All of these comments are procedural and should be fairly quick to resolve. 1.) Please submit new Form 731 showing the RF output rated in terms of conducted power. 2.) The External Photos folder shows a single 0 byte file. Please resubmit. 3.) All cover letters are 0 byte files. Please resubmit 4.) The following Internal photos are 0 byte files: IntPho-1; IntPho-2. Please resubmit. William H. Graff Examining Engineer President and Director of Engineering mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5

Page 6 Page 7

FCC ID: IOU0640S01 Report No.: RF900809R02 1 Issued: August 27, 2001 FCC TEST REPORT REPORT NO.: RF900809R02 MODEL NO.: NCP140, NWH640 RECEIVED: August 9, 2001 TESTED: August 13 ~ August 22, 2001 APPLICANT: NATIONAL DATACOMM CORPORATION ADDRESS: 4F, No.24-2, Industry East 4 th Road, Science Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 Lab Code: 200102-0 FCC ID: IOU0640S01 Report No.: RF900809R02 2 Issued: August 27, 2001 Table of Contents 1CERTIFICATION ...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION ...........................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...............................7 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT ................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT.................................................... 9 4.1.2TEST INSTRUMENTS....................................................................................................... 9 4.1.3TEST PROCEDURES..................................................................................................... 10 4.1.4TEST SETUP .................................................................................................................. 10 4.1.5EUT OPERATING CONDITIONS..................................................................................... 11 4.1.6TEST RESULTS ..............................................................................................................12 4.2RADIATED EMISSION MEASUREMENT ...................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ...................................................... 18 4.2.2TEST INSTRUMENTS..................................................................................................... 19 4.2.3TEST PROCEDURES..................................................................................................... 20 4.2.4TEST SETUP .................................................................................................................. 21 4.2.5EUT OPERATING CONDITIONS..................................................................................... 21 4.2.6TEST RESULTS ..............................................................................................................22 4.36DB BANDWIDTH MEASUREMENT ..........................................................27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT.............................................................. 27 4.3.2TEST INSTRUMENTS..................................................................................................... 27 4.3.3TEST PROCEDURE........................................................................................................ 28 4.3.4TEST SETUP .................................................................................................................. 28 4.3.5EUT OPERATING CONDITIONS..................................................................................... 28 4.3.6TEST RESULTS ..............................................................................................................29 4.4MAXIMUM PEAK OUTPUT POWER ..........................................................33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................. 33 4.4.2INSTRUMENTS...............................................................................................................33 4.4.3TEST PROCEDURES..................................................................................................... 34 4.4.4TEST SETUP .................................................................................................................. 34 4.4.5EUT OPERATING CONDITIONS..................................................................................... 34 4.4.6TEST RESULTS ..............................................................................................................35 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ......................................... 36 4.5.2TEST INSTRUMENTS..................................................................................................... 36 4.5.3TEST PROCEDURE........................................................................................................ 37 4.5.4TEST SETUP .................................................................................................................. 37 4.5.5EUT OPERATING CONDITION ....................................................................................... 37 4.5.6TEST RESULTS ..............................................................................................................38 4.6BAND EDGES MEASUREMENT ................................................................42 FCC ID: IOU0640S01 Report No.: RF900809R02 3 Issued: August 27, 2001 4.6.1LIMITS OF BAND EDGES MEASUREMENT ........…

Text truncated - open the document above for the full version.

FCC ID: IOU0640S01 Report No.: RF900809R02 42 Issued: August 27, 2001 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI 848926/005 846839/018 Dec 28, 2001 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: IOU0640S01 Report No.: RF900809R02 43 Issued: August 27, 2001 4.6.4 EUT OPERATING CONDITION Same as Item 3.4.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 51.27dB delta between carrier maximum power and local maximum emission in restrict band (2522.3GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 26) is 83.8dBuV/m, so the maximum field strength in restrict band is 83.8-51.27=32.53dBuV/m which is under 54 dBuV/m limit. FCC ID: IOU0640S01 Report No.: RF900809R02 44 Issued: August 27, 2001 FCC ID: IOU0640S01 Report No.: RF900809R02 45 Issued: August 27, 2001 FCC ID: IOU0640S01 Report No.: RF900809R02 46 Issued: August 27, 2001 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is dipole antenna. There is no antenna connector. The maximum Gain of the antenna is 1dBi only. FCC ID: IOU0640S01 Report No.: RF900809R02 47 Issued: August 27, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU0640S01 Report No.: RF900809R02 48 Issued: August 27, 2001 RADIATED EMISSION TEST FCC ID: IOU0640S01 Report No.: RF900809R02 49 Issued: August 27, 2001 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USA FCC, NVLAP, UL Germany TUV Rheinland Japan VCCI New Zealand MoC Norway NEMKO R.O.C. BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: IOU0640S01 Report No.: RF900809R02 47 Issued: August 27, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU0640S01 Report No.: RF900809R02 48 Issued: August 27, 2001 RADIATED EMISSION TEST
