IOU2210S01Wireless Access Point

Wireless Ethernet Client NWH2210/NWH2610 Installation Guide Rev. A1 December 2001 National Datacomm Corporation 4F, No. 24-2, Industry East 4 th Road, Science Park Hsin-Chu, Taiwan, R.O.C. Technical Support E-mail: [email protected] NDC World Wide Web www.ndc.com.tw 11Mbps Wireless Networking WEC ii InstantWave 11Mbps Wireless Ethernet Client TRADEMARKS NDC and InstantWave are trademarks of National Datacomm Corporation. All other names mentioned in this document are trademarks/registered trademarks of their respective owners. NDC provides this document “as is”, without warranty of any kind, neither expressed nor implied, including, but not limited to, the particular purpose. NDC may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time. This document could include technical inaccuracies or typographical errors. FCC WARNING This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ü Reorient or relocate the receiving antenna ü Increase the separation between the equipment and receiver ü Connect the equipment into an outlet on a circuit different from that to which the receiver is connected ü Consult the dealer or an experienced radio/TV technician for help You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation FCC RF Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. InstantWave 11Mbps Wireless Ethernet Client iii Table of Contents INTRODUCTION..............................................................................................................1 SYSTEM REQUIREMENTS..................................................................................................1 PLACEMENT GUIDELINES.................................................................................................1 HOW TO USE THIS GUIDE.................................................................................................2 TERMINOLOGY USED IN THIS GUIDE..............................................................................2 APPLICATION SCENARIOS................................................................................................3 Infrastructure Network................................................................................................3 Ad Hoc Network...........................................................................................................4 HARDWARE DESCRIPTION.......................................................................................5 LED INDICATORS..............................................................................................................5 WEC CONFIGURATION TOOL INSTALLATION..............................................6 USING THE WEC COMFIG TOOL............................................................................7 CONNECT............................................................................................................................7 PASSWORD.........................................................................................................................8 SERVICE..............................................................................................................................8 General..........................................................................................................................9 Encryption...................................................................................................................11 Ethernet.......................................................................................................................13 PERFORM WEC SELF DIAGNOSTIC TEST....................................................................14 UPGRADE WEC FIRMWARE..........................................................................................14 RESET WEC CONFIGURATION......................................................................................15 CONNECT AN ETHERNET DEVICE......................................................................15 TECHNICAL SUPPORT...............................................................................................16 NDC LIMITED WARRANTY.....................................................................................17 SPECIFICATIONS..........................................................................................................19 APPENDIX.........................................................................................................................22 INDEX.................................................................................................................................23 iv InstantWave 11Mbps Wireless Ethernet Clien…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4

R:\Customer document\\NWH2210,NWH2610\NWH2210\FCC\ Label location (1264x868x2 tiff)

NATIONAL DATACOMM CORPORATION Model No: NWH2210/NWH2610 Model No: NWH2210/NWH2610 FCC ID: IOU2210S01 FCC ID: IOU2210S01 This unit complies with Part 15 of FCC Rules. This unit complies with Part 15 of FCC Rules. Operation is subject to following two conditions: Operation is subject to following two conditions: (1) This device may not cause harmful interference. (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. (2) This device must accept any interference received, including interference that may cause undesired operation. 0560 Tested To Comply With FCC Standards

Page 5 Page 6 Page 7

Page 8 Page 9

FCC ID: IOU2210S01 ADT No.910103R02 Operational Description The transmitter of the EUT is powered by power adapter and connected with notebook through RJ45 port. The antenna is Dipole antenna. There is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: IOU2210S01 Report No.: RF910103R02 1 Issued: Feb. 19, 2002 FCC TEST REPORT REPORT NO.: RF910103R02 MODEL NO.: NWH2210, NWH2610 RECEIVED: Dec. 18, 2001 TESTED: Dec. 20, 2001 ~ Feb. 1, 2002 APPLICANT:NATIONAL DATACOMM CORPORATION ADDRESS: 4F, NO.24-2, INDUSTRY EAST 4TH ROAD, SCIENCE PARK,HSINCHU, TAIWAN, R.O.C ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 49 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: IOU2210S01 Report No.: RF910103R02 2 Issued: Feb. 19, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS ................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 27 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 27 4.3.2TEST INSTRUMENTS ......................................................................................................... 27 4.3.3TEST PROCEDURE ............................................................................................................28 4.3.4TEST SETUP ....................................................................................................................... 28 4.3.5EUT OPERATING CONDITIONS......................................................................................... 28 4.3.6TEST RESULTS ................................................................................................................... 29 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 33 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 33 4.4.2INSTRUMENTS.................................................................................................................... 33 4.4.3TEST PROCEDURES .......................................................................................................... 34 4.4.4TEST SETUP ....................................................................................................................... 34 4.4.5EUT OPERATING CONDITIONS......................................................................................... 34 4.4.6TEST RESULTS ................................................................................................................... 35 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 36 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 36 4.5.2TEST INSTRUMENTS ......................................................................................................... 36 4.5.3TEST PROCEDURE ............................................................................................................37 TEST SETUP .................................................................................................................................... 37 4.5.5EUT OPERATING CONDITION ........................................................................................... 37 4.5.6TEST RESULTS ................................................................................................................... 38 4.6BAND EDGES MEASUREMENT .........................…

Text truncated - open the document above for the full version.

FCC ID: IOU2210S01 Report No.: RF910103R02 27 Issued: Feb. 19, 2002 4.3 6dB BANDWIDTH MEASUREMENT 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT The minimum of 6dB Bandwidth Measurement is 0.5 MHz. 4.3.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Jan. 27, 2003 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTES: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: IOU2210S01 Report No.: RF910103R02 28 Issued: Feb. 19, 2002 4.3.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator. The bandwidth of the fundamental frequency was measured by spectrum analyzer with 100 kHz RBW and 100 kHz VBW. The 6 dB bandwidth is defined as the total spectrum the power of which is higher than peak power minus 6 dB. 4.3.4 TEST SETUP 4.3.5 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Attenuator FCC ID: IOU2210S01 Report No.: RF910103R02 29 Issued: Feb. 19, 2002 4.3.6 TEST RESULTS EUT 11Mbps Wireless Ethernet Client MODEL NWH2210, NWH2610 INPUT POWER (SYSTEM) 120Vac, 60Hz ENVIRONMENTAL CONDITIONS 14 deg. C, 65%RH, 1005 hPa TESTED BY: Bunny Yao CHANNEL CHANNEL FREQUENCY (MHz) 6 dB BANDWIDTH (MHz) MINIMUM LIMIT (MHz) PASS/FAIL 1241210.020.5PASS 6243711.110.5PASS 11246211.060.5PASS FCC ID: IOU2210S01 Report No.: RF910103R02 30 Issued: Feb. 19, 2002 CH1 FCC ID: IOU2210S01 Report No.: RF910103R02 31 Issued: Feb. 19, 2002 CH6 FCC ID: IOU2210S01 Report No.: RF910103R02 32 Issued: Feb. 19, 2002 CH11 FCC ID: IOU2210S01 Report No.: RF910103R02 33 Issued: Feb. 19, 2002 4.4 MAXIMUM PEAK OUTPUT POWER 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT The Maximum Peak Output Power Measurement is 30dBm. 4.4.2 INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Jan. 27, 2003 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: IOU2210S01 Report No.: RF910103R02 34 Issued: Feb. 19, 2002 4.4.3 TEST PROCEDURES 1. The transmitter output was connected to the peak power meter. 4.4.4 TEST SETUP 4.4.5 EUT OPERATING CONDITIONS Same as Item 3.4.5 EUT SPECTRUM ANALYZER Attenuator FCC ID: IOU2210S01 Report No.: RF910103R02 35 Issued: Feb. 19, 2002 4.4.6 TEST RESULTS EUT 11Mbps Wireless Ethernet Client MODEL NWH2210, NWH2610 INPUT POWER (SYSTEM) 120Vac, 60Hz ENVIRONMENTAL CONDITIONS 14 deg. C, 65%RH, 1005 hPa TESTED BY: Bunny Yao CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) PASS/FAIL 1241215.9030PASS 6243715.6030PASS 11246215.4930PASS

FCC ID: IOU2210S01 Report No.: RF910103R02 36 Issued: Feb. 19, 2002 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until ROHDE & SCHWARZ TEST RECEIVER ESMI839379/002Jan. 27, 2003 HP ATTENUATOR8496B3247A18505 Cal. on use HP PLOTTER7475A2641V27755 N/A NOTE: 1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: IOU2210S01 Report No.: RF910103R02 37 Issued: Feb. 19, 2002 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time = span/3 kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3 kHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP 4.5.5 EUT OPERATING CONDITION Same as Item 3.4.5 EUT SPECTRUM ANALYZER Attenuator FCC ID: IOU2210S01 Report No.: RF910103R02 38 Issued: Feb. 19, 2002 4.5.6 TEST RESULTS EUT 11Mbps Wireless Ethernet Client MODEL NWH2210, NWH2610 INPUT POWER (SYSTEM) 120Vac, 60Hz ENVIRONMENTAL CONDITIONS 14 deg. C, 65%RH, 1005 hPa TESTED BY: Bunny Yao CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-10.248PASS 62437-11.368PASS 112462-11.038PASS FCC ID: IOU2210S01 Report No.: RF910103R02 39 Issued: Feb. 19, 2002 CH1 FCC ID: IOU2210S01 Report No.: RF910103R02 40 Issued: Feb. 19, 2002 CH6 FCC ID: IOU2210S01 Report No.: RF910103R02 41 Issued: Feb. 19, 2002 CH11

FCC ID: IOU2210S01 Report No.: RF910103R02 42 Issued: Feb. 19, 2002 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049July 17, 2002 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: IOU2210S01 Report No.: RF910103R02 43 Issued: Feb. 19, 2002 4.6.4 EUT OPERATING CONDITION Same as Item 3.4.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 52.39dB delta between carrier maximum power and local maximum emission in restrict band (2.4835GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 26) is 89.4dBuV/m, so the maximum field strength in restrict band is 89.4-52.39=37.01dBuV/m which is under 54 dBuV/m limit. FCC ID: IOU2210S01 Report No.: RF910103R02 44 Issued: Feb. 19, 2002 FCC ID: IOU2210S01 Report No.: RF910103R02 45 Issued: Feb. 19, 2002 FCC ID: IOU2210S01 Report No.: RF910103R02 46 Issued: Feb. 19, 2002 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is Dipole Antenna. There is no antenna connector. And the maximum Gain of this antenna is only 0dBi. FCC ID: IOU2210S01 Report No.: RF910103R02 47 Issued: Feb. 19, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU2210S01 Report No.: RF910103R02 48 Issued: Feb. 19, 2002 RADIATED EMISSION TEST FCC ID: IOU2210S01 Report No.: RF910103R02 49 Issued: Feb. 19, 2002 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USAFCC, NVLAP, UL GermanyTUV Rheinland JapanVCCI New ZealandMoC NorwayNEMKO R.O.C.BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: IOU2210S01 Report No.: RF910103R02 47 Issued: Feb. 19, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU2210S01 Report No.: RF910103R02 48 Issued: Feb. 19, 2002 RADIATED EMISSION TEST
