IOU4010S01Wireless USB Adapter

1 Your Installation Guide to IEEE 802.11b USB Wireless LAN Version: 2.01 — March 2001 1 Table of Contents REGULATORY INFORMATION...........................................................................2 STEP BY STEP INSTALLATION GUIDE...........................................................3 1 Install the IEEE802.11b USB WLAN Utility / Driver..........................................4 2 Install the USB Adapter......................................................................................7 3 IEEE802.11B USB WLAN UTILITY......................................................................8 4 Remove your USB Adapter...............................................................................16 5 Uninstall the IEEE802.11b USB WLAN Utility / Driver...................................17 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows 95/98 and Windows 2000 are trademarks of Microsoft Corp. Pentium is trademark of Intel. All copyright is reserved. 2 Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance, (example - use only shielded interface cables when connecting to computer or peripheral devices) any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 3 Step by step Installation Guide This section will lead you through the installation of USB Adapter and IEEE802.11b USB WLAN software in through details. You may wish to skip to quick start guide to wireless networking. To establish your wireless network connection, the following steps should be executed. 1. Install the software using the installation CD. 2. Install the USB Wireless LAN Adapter. 3. Install the required network protocols to communicate with your network. Most likely, you will need the TCP / IP protocol. The product is designed to operate in Windows 98, Windows Me, and Windows 2000. And the installation procedure is about the same. Please follow up the installation wizard that provided by your system to install the software. The example here is based on the Windows 98SE. 4 1 Install the IEEE802.11b USB WLAN Utility / Driver Please install the IEEE802.11b USB WLAN Utility / Driver first before inserting the IEEE802.11b USB Wireless LAN. 1. Insert the IEEE802.11b USB Wireless LAN installation CD into your CD-ROM drive. The setup program will then automatically start. 2. The setup program will start and the setup screen will appear on your monitor. Select “ Next “ to go to the next screen. 3. Please select the applications you would like to install, and click “ Next “. If you select “ Browse User Manual “, system will prompt a message to suggest you installing the Acrobat Reader. 5 4. The default destination folder is displayed in the setup dialog column. To change the default folder you can click “ Browse “ to set the destination folder. Click “ Next “ to go to the next screen. 5. Select the Program Folder for IEEE802.11b USB WLAN Utility and click “ Next “. 6 6. You will be asked if you want to add an IEEE802.11b USB WLAN Utility shortcut to your desktop. Click “ Yes “. 7. The user manual is published in Portable Document Format (PDF). If Acrobat Reader doesn’t exist in your system, the following message will be prompted and automatically enter Acrobat Reader installation screen. Please follow the instructions to complete the Acrobat Reader 4.05 installation. 8. The Driver and Help files will be copied to the system. Wait the setup program to finish the IEEE802.11b USB WLAN installation. Then select “ Yes “ and click “ Finish “ to complete the installation. It’s recommended to close other applications before rebooting your system. 9. Regards to install the IEEE802.11b USB Adapter, please refer to the next chapter 3.2 “ Install the USB Adapter. “ 7 2 Install the USB Adapter The IEEE802.11b USB WLAN driver and utility are included on the accompanying installation CD. Please follow the installation procedures in Section 3.1. (Your USB Adapter will not work properly if the dri…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Label & label location for NEH4010 Back side view

Page 3 Page 4

FCC ID: IOU4010S01 ADT No.90031608A Operational Description The transmitter of the EUT is powered by host equipment from USB port. The antenna is Inverted F Antenna, and there is no antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: IOU4010S01 Report No.: RF90031608A 1 Issued: March 11, 2002 FCC TEST REPORT REPORT NO.: RF90031608A MODEL NO.: NWH4010 RECEIVED: NA TESTED: Feb. 20, 2002 APPLICANT:NATIONAL DATACOMM CORPORATION ADDRESS:4F, No. 24-2, Industrial East 4 th Road, Science Park, Hsin Chu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: IOU4010S01 Report No.: RF90031608A 2 Issued: March 11, 2002 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................................... 9 4.1.2TEST INSTRUMENTS ...........................................................................................................9 4.1.3TEST PROCEDURES .......................................................................................................... 10 4.1.4TEST SETUP ....................................................................................................................... 10 4.1.5EUT OPERATING CONDITIONS......................................................................................... 11 4.1.6TEST RESULTS ................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................................... 18 4.2.2TEST INSTRUMENTS ......................................................................................................... 19 4.2.3TEST PROCEDURES .......................................................................................................... 20 4.2.4TEST SETUP ....................................................................................................................... 21 4.2.5EUT OPERATING CONDITIONS......................................................................................... 21 4.2.6TEST RESULTS ................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................ 26 4.3.2TEST INSTRUMENTS ......................................................................................................... 26 4.3.3TEST PROCEDURE ............................................................................................................27 4.3.4TEST SETUP ....................................................................................................................... 27 4.3.5EUT OPERATING CONDITIONS......................................................................................... 27 4.3.6TEST RESULTS ................................................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ................................... 32 4.4.2INSTRUMENTS.................................................................................................................... 32 4.4.3TEST PROCEDURES .......................................................................................................... 33 4.4.4TEST SETUP ....................................................................................................................... 33 4.4.5EUT OPERATING CONDITIONS......................................................................................... 33 4.4.6TEST RESULTS ................................................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ........................................... 35 4.5.2TEST INSTRUMENTS ......................................................................................................... 35 4.5.3TEST PROCEDURE ............................................................................................................36 4.5.4TEST SETUP ....................................................................................................................... 36 4.5.5EUT OPERATING CONDITION ........................................................................................... 36 4.5.6TEST RESULTS ................................................................................................................... 37 4.6BAND EDGES MEASUREMENT .............................................................…

Text truncated - open the document above for the full version.

FCC ID: IOU4010S01 Report No.: RF90031608A 35 Issued: March 11, 2002 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until R&S SPECTRUM ANALYZER FSEK30100049Jul. 16, 2002 NOTE:1. The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2. The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: IOU4010S01 Report No.: RF90031608A 36 Issued: March 11, 2002 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3 kHz RBW and 30 kHz VBW, set sweep time = span/3 kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3 kHz for a full response of the mixer in the spectrum analyzer. 4.5.4 TEST SETUP 4.5.5 EUT OPERATING CONDITION Same as Item 3.4.5 EUT SPECTRUM ANALYZER FCC ID: IOU4010S01 Report No.: RF90031608A 37 Issued: March 11, 2002 4.5.6 TEST RESULTS EUT 11Mbps Wireless USB Adapter MODEL NWH4010 INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 20 deg. C, 55%RH, 1005 hPa TESTED BY: Bruce Shiau CHANNEL NUMBER CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-10.688PASS 62437-9.868PASS 112462-10.768PASS FCC ID: IOU4010S01 Report No.: RF90031608A 38 Issued: March 11, 2002 CH1 FCC ID: IOU4010S01 Report No.: RF90031608A 39 Issued: March 11, 2002 CH6 FCC ID: IOU4010S01 Report No.: RF90031608A 40 Issued: March 11, 2002 CH11 FCC ID: IOU4010S01 Report No.: RF90031608A 41 Issued: March 11, 2002 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until R&S SPECTRUM ANALYZER FSEK30100049Jul. 16, 2002 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.6.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. FCC ID: IOU4010S01 Report No.: RF90031608A 42 Issued: March 11, 2002 4.6.4 EUT OPERATING CONDITION Same as Item 3.4.5 4.6.5 TEST RESULTS The spectrum plots are attached on the following 2 pages. D2 line indicates the highest level, D1 line indicates the 20dB offset below D2. It shows compliance with the requirement in part 15.247(C). NOTE: The band edge emission plot on the following 2 pages shows 46.87dB delta between carrier maximum power and local maximum emission in restrict band (2.48774GHz). The emission of carrier strength list in the test result of channel 11 at the item 4.2.6 (Page 25) is 95.9dBuV/m, so the maximum field strength in restrict band is 95.9-46.87=49.03 dBuV/m which is under 54 dBuV/m limit. FCC ID: IOU4010S01 Report No.: RF90031608A 43 Issued: March 11, 2002 FCC ID: IOU4010S01 Report No.: RF90031608A 44 Issued: March 11, 2002 FCC ID: IOU4010S01 Report No.: RF90031608A 45 Issued: March 11, 2002 4.7 ANTENNA REQUIREMENT 4.7.1 STANDARD APPLICABLE For intentional device, according to FCC 47 CFR Section 15.203, an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. And according to FCC 47 CFR Section 15.247 (b), if transmitting antennas of directional gain greater than 6dBi are used, the power shall be reduced by the amount in dB that the directional gain of the antenna exceeds 6dBi. 4.7.2 ANTENNA CONNECTED CONSTRUCTION The antenna used in this product is Inverted F Antenna. There is no antenna connector. The maximum Gain of the antenna is -1dBi only. FCC ID: IOU4010S01 Report No.: RF90031608A 46 Issued: March 11, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU4010S01 Report No.: RF90031608A 47 Issued: March 11, 2002 RADIATED EMISSION TEST FCC ID: IOU4010S01 Report No.: RF90031608A 48 Issued: March 11, 2002 6 INFORMATION ON THE TESTING LABORATORIES We, ADT Corp., were founded in 1988 to provide our best service in EMC and Safety consultation. Our laboratories are accredited and approved by the following approval agencies according to ISO/IEC 17025, Guide 25 or EN 45001: USAFCC, NVLAP, UL GermanyTUV Rheinland JapanVCCI New ZealandMoC NorwayNEMKO R.O.C.BSMI, DGT, CNLA Copies of accreditation certificates of our laboratories obtained from approval agencies can be downloaded from our web site: www.adt.com.tw/index.5/phtml. If you have any comments, please feel free to contact us at the following: Lin Kou EMC Lab: Tel: 886-2-26052180 Fax: 886-2-26052943 Hsin Chu EMC Lab: Tel: 886-35-935343 Fax: 886-35-935342 Lin Kou Safety Lab: Tel: 886-2-26093195 Fax: 886-2-26093184 Lin Kou RF&Telecom Lab Tel: 886-3-3270910 Fax: 886-3-3270892 Email: [email protected] Web Site: www.adt.com.tw The address and road map of all our labs can be found in our web site also.

FCC ID: IOU4010S01 Report No.: RF90031608A 46 Issued: March 11, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: IOU4010S01 Report No.: RF90031608A 47 Issued: March 11, 2002 RADIATED EMISSION TEST
