IPH-00447Low Power Data Transmitter

TITLE SIZE PART NO: REV: SCALE Sht. Of Front SPECIFICATION CONTROL DRAWING REVISIONS REV.DATEDESCRIPTIONECO NO. A12/01/05Initial Release– – – – CONFIDENTIAL This drawing and the specifications contained herein are the property of Garmin Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. Garmin Ltd. or its subsidiaries C/O Garmin International, Inc. 1200 E. 151st Street Olathe, Kansas 66062 U.S.A. InitialsDateEdge 205/305 Owner’s Manual Drawn By: SWL12/01/05 A190-00580-00A Checked By: Project Manager: N/A Approved By: 193 NOTES: 1. DESCRIPTION: Product Documentation, Edge Owner’s Manual 2. SIZE: Trimmed and finished: 4.75” wide and 4.75” tall 3. PAGINATION: 4 cover pages, 88 text pages 4. MATERIAL: Cover: 120-lb Coated White, Text: 100-lb 2-sided Coated. (Substitutions Allowed) 5. COLOR: Cover: 4-color process. Text pages: Black ink on white paper 6. BINDERY: Perfect bound 7. FOLDS: Not applicable 8. ELECTRONIC ARTWORK: Shall conform to Garmin Archive 190-00580-00_0A.zip The following files have been archived under the above ARCHIVE FILENAME. File NameFile Contents 190-00580-00_0A.inddInDesign CS for PC, Formatted Manual 190-00580-00_0A_spec.inddInDesign CS for PC, Master Document Specification 190-00580-00_0A.pdfPortable Document Format, Manual and Release Specification LinksGraphic files (eps, bmp, etc.) FontsFont files 4.75” Bound Dimensions (Ref.) ���� ��� ������� �������������� 4.75” 9.5” Trimmed Dimensions (Ref.) BackCover Binding 4.75” Edge ™ 205/305 owner’s manual 190-00580-00_0A.indd 112/1/2005 9:44:06 AM © Copyright 2005 Garmin Ltd. or its subsidiaries. All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without the express prior written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed and to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited. Information in this document is subject to change without notice. Garmin reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. Visit the Garmin Web site (www.garmin.com) for current updates and supplemental information concerning the use and operation of this and other Garmin products. Garmin ® , Auto Lap ® , and Auto Pause ® are registered trademarks and Edge ™ , GSC10 ™ , Virtual Partner ™ , and Garmin Training Center ™ are trademarks of Garmin Ltd. or its subsidiaries and may not be used without the express permission of Garmin. This product includes technology owned by SiRF Technology, Inc. SiRF’s technology is protected by U.S. and foreign patents pending and issued. SiRF, SiRFstar and the SiRF logo are registered trademarks of SiRF Technology, Inc. SiRFstarIII and SiRF Powered are trademarks of SiRF Technology, Inc. December 2005 Part Number 190-00580-00 Rev. A Printed in Taiwan Garmin International, Inc. 1200 East 151st Street Olathe, Kansas 66062, U.S.A. Tel. 913/397.8200 or 800/800.1020 Fax 913/397.8282 Garmin (Europe) Ltd. Unit 5, The Quadrangle Abbey Park Industrial Estate Romsey, SO51 9DL, U.K. Tel. 44/0870.8501241 Fax 44/0870.8501251 Garmin Corporation No. 68, Jangshu 2nd Road Shijr, Taipei County, Taiwan Tel. 886/2.2642.9199 Fax 886/2.2642.9099 190-00580-00_0A.indd 212/1/2005 9:44:07 AM Edge Owner’s Manual 3 INTRODUCTION Introduction .........................5 About This Manual .............5 Getting Started ....................6 Charge the Battery .............6 Position the Edge .............10 Configure the Edge .........12 Acquire Satellite Signals ..........................13 Position the Heart Rate Monitor .........................14 Position the GSC10 TM Sensor ..........................16 Installing GSC10 Sensor ..16 Set Your User Profile ........19 Set Your Bike Profile ........20 Change the Backlight and Contrast Settings ........20 Training ..............................22 Auto Pause/Lap ...............22 Alerts .................................24 Using Time and Distance Alerts ..........................24 Using Speed Alerts ..........25 Using Heart Rate Alerts ...26 Using Cadence Alerts ......27 Working Out with Virtual Partner ..........................28 Workouts: Quick, Interval, and Advanced .............29 Using Workouts ...............30 Quick Workouts ............... 30 Interval Workouts ............. 33 Advanced Workouts ......... 34 Courses .............................39 Creating Courses .............39 Using Courses .................40 History ...............................42 Viewing History ................42 Deleting History ...............45 Navigation .........................46 Navigating with the Map ..46 Marking and Finding Locations .....................47 Navigating with Routes ....49 190-00580-00_0A.indd 312/1/2005 9:44:07 AM 4 Edge Owner’s Manual INTRODUCTION Viewing GPS Information ...................51 About GPS .......................52 Customizing ......................53 Setting Up Custom Data Fields ............................53 Sample Data Field Configurations ............ 54 Changing System Settings ........................55 Updating User Profile .......59 Changing Bike Profile ......59 Setting Zones ....................59 Speed Zones ...................59 Setting Your Heart Rate Zones ...........................60 Data Recording .................62 Appendix ...........................63 Edge Data Fields ..............63 Edge Accessories .............69 Viewing Hea…

Text truncated - open the document above for the full version.

12 Edge Owner’s Manual GETTING STARTED Configure the Edge When you first turn on your Edge, the following setup screens appear. Follow the on-screen instructions: Screens 4 and 5 apply to Edge 305 only. 1 2 3 4 5 190-00580-00_0A.indd 1212/1/2005 9:44:13 AM Edge Owner’s Manual 13 GETTING STARTED Acquire Satellite Signals Before you begin using the Edge, you must acquire GPS satellite signals. It may take 30-60 seconds to acquire signals. To acquire satellite signals: Go outdoors to an open area away from tall buildings and trees. Then press and hold the Power button. On the Satellite page, the available satellites are flashing while the Edge searches for satellite signals. Acquired satellites and each corresponding bar below change to solid. The GPS accuracy appears at the top of the page. NOTE: You can turn off the GPS receiver and use the Edge indoors. See page 55. 190-00580-00_0A.indd 1312/1/2005 9:44:14 AM 14 Edge Owner’s Manual GETTING STARTED Position the Heart Rate Monitor NOTE: The heart rate monitor is an accessory for the Edge 305 only. Wear the heart rate (HR) monitor directly on your skin, just below the breastplate. It should be snug enough to stay in place during your workout. To view heart rate information on your Edge during a workout, you must add it to the data fi elds on one of the data pages. See page 53 for more information on customizing the data fi elds on your Edge. To use the heart rate monitor: 1. Push one tab on the elastic strap through the slot in the heart rate monitor. 2. Wet both sensors on the back of the heart rate monitor to create a strong connection between your pulse and the transmitter. sensors 190-00580-00_0A.indd 1412/1/2005 9:44:15 AM Edge Owner’s Manual 15 GETTING STARTED 3. Attach the strap to the other side of the heart rate monitor around your chest. NOTE: If you have trouble with erratic heart rate readings, position the transmitter on your back instead of your chest, or try applying electrode gel. 4. Tighten or loosen the strap as necessary so that it fits snugly against your body. 5. Turn on the Edge. 6. Bring it within range (3 meters) of the heart rate monitor. The heart rate monitor automatically transmits your heart rate to the Edge, and the heart rate icon changes from flashing to constant. TIP: Be sure to move away from other heart rate monitors while the Edge is trying to “pair” with your heart rate monitor and begin receiving heart rate data. Once the Edge pairs with your heart rate monitor, you can go near other heart rate monitors. For more information on pairing, training, and troubleshooting, see pages 70-74. 190-00580-00_0A.indd 1512/1/2005 9:44:15 AM 16 Edge Owner’s Manual GETTING STARTED Position the GSC10 TM Sensor NOTE: The GSC10 is an accessory for the Edge 305 only. Installing GSC10 Sensor The Edge 305 CAD includes a wireless speed and cadence sensor. Both magnets must be aligned with their respective indication line for the Edge to receive data. To install the GSC10: 1. Place the GSC10 on the rear chain stay. Loosely attach the GSC10 using two cable ties. reset button cable ties indication line GSC10 on rear chain stay 1 190-00580-00_0A.indd 1612/1/2005 9:44:15 AM Edge Owner’s Manual 17 GETTING STARTED 2. Attach the pedal magnet to the crank arm using the adhesive mount and a cable tie. Make sure the pedal magnet is within 5 mm of the GSC10 and the indication line on the pedal magnet lines up with the indication line on the GSC10. 3. Attach the spoke magnet by unscrewing the magnet from the plastic piece. Then place the spoke in the groove of the plastic piece and tighten slightly. The magnet can face away from GSC10 if there is not enough room between sensor arm and spoke. Make sure the magnet is aligned with the sensor arm indication line. 4. Unscrew and move the sensor arm to within 5 mm of the spoke magnet. You can also tilt the GSC10 closer to either magnet for improved alignment. cable tie pedal magnet on crank arm indication line 2 190-00580-00_0A.indd 1712/1/2005 9:44:16 AM 18 Edge Owner’s Manual GETTING STARTED 5. Press the Reset button on the GSC10. The LED light turns red, then green. Pedal to test the sensor alignment. The red LED blinks each time the crank arm passes the sensor, and the green LED blinks each time the wheel magnet passes the sensor arm. NOTE: This will test the fi rst 60 passes. Press Reset again if you require additional passes. 6. When everything is aligned and working correctly, tighten the cable ties, sensor arm, and spoke magnet. sensor arm indication line spoke magnet on wheel spoke magnet 3 pedal magnet 190-00580-00_0A.indd 1812/1/2005 9:44:17 AM Edge Owner’s Manual 19 GETTING STARTED Set Your User Profile The Edge uses information that you enter about yourself to calculate calorie consumption. Set your user profile before you begin using the Edge to ensure it is recording accurate workout data. To set your user profile: 1. Press mode to access the Main Menu. 2. Select Settings > User Profile. 3. Enter your Gender, Birth Date, and Weight. TIP: When finished selecting options or entering values on your Edge, press the mode button to exit the field or page. If you are setting your user profile for the first time (Edge 305 with heart rate monitor), a Max HR message appears. Select Yes to adjust your maximum heart rate calculation based on your user profile. 190-00580-00_0A.indd 1912/1/2005 9:44:17 AM 20 Edge Owner’s Manual GETTING STARTED Set Your Bike Profile You can set up to three profiles. To set your bike profile: 1. Press mode to access the Main Menu. 2. Select Settings > Bike Profile. 3. Select the bike profile you wish to use. 4. Enter the Bike Weight. 5. If you have an Edge 305 with the GSC10 speed and cadence sensor on your bike, select the Sensor Mounted check box. 6. In the Wheel Size field, select Auto to have the GSC10 automatically detect your tire size using GPS data or select Custom to enter your tire size. Change the Backlight and Contrast Settings To change the Edge dis…

Text truncated - open the document above for the full version.

Edge Owner’s Manual 23 TRAINING 4. In the Auto Lap Trigger field, select By Distance to enter a value or By Position to choose an option: • Lap Press only–triggers the lap counter each time you press the lap button and every time you pass that location again. • Start And Lap–triggers the lap counter at the GPS location where you press the start button and at any locations during the ride where you press the lap button. • Mark And Lap–triggers the lap counter at a specific GPS location marked before the ride and at any locations during the ride where you press the lap button. 5. Press mode repeatedly to exit. 190-00580-00_0A.indd 2312/1/2005 9:44:17 AM 24 Edge Owner’s Manual TRAINING Alerts Use Edge alerts to train toward certain time, distance, speed, heart rate, and cadence goals. Using Time and Distance Alerts Time and distance alerts are useful for long workouts when you want to train for a certain amount of time or distance. When you reach your goal, the Edge beeps and displays a message. To set a time or distance alert: 1. Press mode to access the Main Menu. Select Training. 2. Select Alerts > Time/Dist Alert. 3. In the Time Alert field, select Once or Repeat. 4. Enter a time in the Alert At field. 190-00580-00_0A.indd 2412/1/2005 9:44:17 AM Edge Owner’s Manual 25 TRAINING 5. In the Distance Alert field, select Once or Repeat. 6. Enter a distance in the Alert At field. 7. Press mode repeatedly to exit. Using Speed Alerts Speed alerts notify you if you exceed or drop below a custom speed setting during your ride. The speed alert takes advantage of Speed Zones, which are ranges of speed that you can store in the Edge. For more information, or to set your Speed Zones, see page 59. To set a speed alert: 1. Press mode to access the Main Menu. Select Training. 2. Select Alerts > Speed Alert. 3. In the Fast Speed Alert field, select a Speed Zone from the menu or select Custom to enter your own alert value. 4. Repeat for the Slow Speed Alert. 5. Press mode repeatedly to exit. 190-00580-00_0A.indd 2512/1/2005 9:44:17 AM 26 Edge Owner’s Manual TRAINING Using Heart Rate Alerts NOTE: Heart rate alerts are a feature of the Edge 305 only. Similar to speed alerts, the heart rate alert notifies you if your heart rate exceeds or drops below a specific number of beats per minute (bpm). Heart rate alerts can also notify you if your heart rate exceeds or drops below a certain heart rate zone—a range of beats per minute. The five commonly accepted heart rate zones can help you determine the intensity of your workout. For more about setting your heart rate zones, see page 60. For more information about training with heart rate zones, see page 70. To set a heart rate alert: 1. Press mode to access the Main Menu. Select Training. 2. Select Alerts > HR Alert. 3. In the Min HR Alert field, select a zone from the menu or select Custom to specify your own alert value. 4. Repeat for the Max HR Alert. The maximum value allowed is 235 bpm. 190-00580-00_0A.indd 2612/1/2005 9:44:17 AM Edge Owner’s Manual 27 TRAINING 5. Press mode repeatedly to exit. NOTE: When entering custom heart rate values, you must set your minimum and maximum alerts at least 5 bpm apart. Using Cadence Alerts NOTE: Cadence alerts are a feature of the Edge 305 only. Similar to speed alerts, the cadence alert notifies you if your cadence exceeds or drops below a specific number of revolutions of the crank arm per minute (rpm). For more information about training with cadence, see page 75. To set a cadence alert: 1. Press mode to access the Main Menu. Select Training. 2. Select Alerts > Cadence Alert. 3. In the Fast Cadence Alert field, select On. 4. Enter a value in the Alert Above field. The maximum cadence value allowed is 255. 5. Repeat for the Slow Cadence Alert. 6. Press mode repeatedly to exit. 190-00580-00_0A.indd 2712/1/2005 9:44:18 AM 28 Edge Owner’s Manual TRAINING Working Out with Virtual Partner Your Virtual Partner is a unique tool designed to help you meet your training goals. The Virtual Partner competes with you during quick workouts and courses. The Virtual Partner “rides” alongside (top bike graphic) of you. Your current time, speed, distance, and distance from the Virtual Partner appears on the Workout page. If you are ahead of the Virtual Partner, the bottom field background is white. If you are behind, the background is black (as shown). To see Virtual Partner data: 1. Set up a quick workout or course. 2. Press mode to see the Workout or Course page. 3. Press start. 4. Press enter to scroll through the workout or course data pages. Virtual Partner You 190-00580-00_0A.indd 2812/1/2005 9:44:18 AM Edge Owner’s Manual 29 TRAINING To turn off Virtual Partner: 1. Press mode to access the Main Menu. 2. Select Training > Virtual Partner. 3. In the Virtual Partner field, select Off. Workouts: Quick, Interval, and Advanced From the Main Menu, select Training > Workouts to choose the type of workout right for you. Quick and interval workouts are replaced each time you create a workout of the same type. Advanced workouts can be saved, edited, and transferred between Training Center TM and your Edge. 190-00580-00_0A.indd 2912/1/2005 9:44:18 AM 30 Edge Owner’s Manual TRAINING Using Workouts During your workout, press mode to see the Workout data page. When you complete all steps in your workout, the “Workout Finished!” message appears. To end a workout early: 1. Press mode to access the Main Menu. 2. Select Training > Stop Workout. To end a workout step early: Press the lap/reset button. Quick Workouts It is easy to set up a challenging workout with your Edge based on the following criteria: • Distance and time • Time and speed • Distance and speed 190-00580-00_0A.indd 3012/1/2005 9:44:18 AM Edge Owner’s Manual 31 TRAINING To set up a quick workout by distance and time: 1. Press mode to access the Main Menu. Select Training. 2. Select Workouts > Quick Workouts > Dist & Time. 3. Enter values in the Distance and Time fields. 4. Check the Sp…

Text truncated - open the document above for the full version.

November 10, 2005 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Equipment Approval Services Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-00447 PRODUCT: FM Transmitter operated under part 15.249. Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Operational Description, block diagram, and parts list be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459 (1998), following grant of the application. In support of this request, Garmin International, Inc. submits the following: 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-00447 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. This equipment is designed for commercial, industrial, and governmental applications. As such, unlike most consumer equipment, this equipment could be used for more than a decade in some cases. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

November 10, 2005 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 CORES number: 0005-0885-88 Equipment: FCC ID: IPH-00447 FCC Rules: Part 2 and 15.249 Gentlemen: The 731 form and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. It is requested that the information contained in the operational description, block diagram, parts list, and schematics of the application be held confidential per Section 0.459. A statement of confidentiality will be attached with the application at the time of submittal. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 1 of 2 GSC10 Tx Ext Photos.Doc 12/8/2005 External photographs of equipment under test. ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 2 of 2 GSC10 Tx Ext Photos.Doc 12/8/2005

ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 1 of 1 GSC10 Tx ID Label location.Doc 12/8/2005 FCC/IC ID label and location.

ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 1 of 2 GSC10 Tx Int Phot.Doc 12/8/2005 Internal photographs of transmitter section of equipment under test. ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 2 of 2 GSC10 Tx Int Phot.Doc 12/8/2005

ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter SN: 1 Louisburg, KS 66053 Test #:051026 FCC ID#: IPH-00447 IC:1792A-00447 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 1 of 1 GSC10 Tx Tune.Doc 12/8/2005 The unit has no provisions for tuning. It is produced and tested with a pass on pass operation.

APPLICATION For GRANT OF CERTIFICATION FOR MODEL: GSC10 Data Transmitter P/N 011-01227-xx FCC ID: IPH-01227 IC: 1792A-00447 FOR GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 TEST REPORT For APPLICATION of CERTIFICATION For GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Phone: (913) 397-8200 Mr. Van Ruggles Director of Quality Assurance MODEL: GSC10 PN 011-01227-xx Data Transmitter FREQUENCY: 2,400-2,483.5 MHz FCC ID: IPH-00447 IC: 1792A-00447 Test Date: October 26, 2005 Certifying Engineer: Scot D. Rogers ROGERS LABS, INC. 4405 West 259th Terrace Louisburg, KS 66053 Phone: (913) 837-3214 FAX: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-00447 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter IC:1792A-00447 Louisburg, KS 66053 Test #:051026 SN: 1 GPN: 011-01227-xx Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 3 of 26 GSC10 Transmitter Test Report.Doc 12/19/2005 TABLE OF CONTENTS TABLE OF CONTENTS 3 APPLICABLE STANDARDS & TEST PROCEDURES 4 EQUIPMENT TESTED 4 LIST OF TEST EQUIPMENT 5 2.1033(B) APPLICATION FOR CERTIFICATION 6 EQUIPMENT AND CABLE CONFIGURATION 7 Test Setup 7 EQUIPMENT FUNCTION AND TESTING PROCEDURES 7 Configuration options for the EUT 8 AC Line Conducted Emission Test Procedure 8 Radiated Emission Test Procedure 8 Units of Measurements 8 Test Site Locations 9 SUBPART C - INTENTIONAL RADIATORS 9 15.203 ANTENNA REQUIREMENTS 9 15.205 RESTRICTED BANDS OF OPERATION 9 Data 15.205 10 Summary of Results for Radiated Emissions in Restricted Bands 15.205 10 15.207 CONDUCTED EMISSIONS LIMITS; GENERAL REQUIREMENTS 11 AC Line Conducted EMI 15.207 11 Summary of Results for AC Line Conducted General Emissions 15.207 11 15.209 RADIATED EMISSIONS LIMITS; GENERAL REQUIREMENTS 12 General Radiated EMI 15.209 12 General Radiated Emissions Data 15.209 15 Summary of Results for General Radiated Emissions 15.209 16 15.249 OPERATION IN THE BAND 2,400-2,483.5 MHZ 16 Data: Transmitter Radiated Emissions from EUT 19 Data: Antenna Substitution Method for 15.249 19 TRANSMITTER EMISSIONS SUMMARY OF RESULTS 20 Summary of Results for Transmitter Radiated Emissions 15.249 20 FREQUENCY STABILITY 20 Measurements Required 20 Test Arrangement 21 Results 22 Summary of Results for Frequency Stability 22 Statement of Modifications and Deviations 22 APPENDIX 23 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-00447 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter IC:1792A-00447 Louisburg, KS 66053 Test #:051026 SN: 1 GPN: 011-01227-xx Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 4 of 26 GSC10 Transmitter Test Report.Doc 12/19/2005 Applicable Standards & Test Procedures a) In accordance with the Federal Communications Code of Federal Regulations, dated October 1, 2004, Part 2, Subpart J, Paragraphs 2.907, 2.911, 2.913, 2.925, 2.926, 2.1031 through 2.1057, applicable parts of paragraph 15, Part 15C paragraph 15.249, and Industry Canada RSS-210, the following information is submitted. b) Test procedures used are the established Methods of Measurement of Radio-Noise Emissions as described in the ANSI 63.4-2003 Document FCC and documents DA00-1407 and DA00-705. Equipment Tested Equipment Serial Number FCC I.D.# GSC10 1 IPH-00447 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-00447 4405 West 259 th Terrace MODEL: GSC10 Data Transmitter IC:1792A-00447 Louisburg, KS 66053 Test #:051026 SN: 1 GPN: 011-01227-xx Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 5 of 26 GSC10 Transmitter Test Report.Doc 12/19/2005 List of Test Equipment A Hewlett Packard 8591EM and or 8562A Spectrum Analyzer was used as the measuring device for the emissions testing. The analyzer settings used are described in the following table. Refer to the Appendix for a complete list of Test Equipment. HP 8591EM SPECTRUM ANALYZER SETTINGS CONDUCTED EMISSIONS: RBW AVG. BW DETECTOR FUNCTION 9 kHz 30 kHz Peak/Quasi Peak RADIATED EMISSIONS (30 – 1000 MHz): RBW AVG. BW DETECTOR FUNCTION 120 kHz 300 kHz Peak/Quasi Peak HP 8562A SPECTRUM ANALYZER SET…
