IPH-01017Low Power Communications Transmitter

Garmin International Inc

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Mar 29, 2006
Application Purpose: Original Equipment
Date of Application: Mar 29, 2006
Equipment Note: Low Power Communications Transmitter
Frequency Range: 2402.00000000 - 2480.00000000
Company: Garmin International Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Owner’s Manual portable GPS with turn-by-turn routing, voice, and Bluetooth ® wireless technology BMW Motorrad Navigator III Teile und Zubehör © 2006 Copyright by: BMW Motorrad and Garmin Ltd. or its subsidiaries This product has been developed for you by BMW Motorrad together with Garmin Ltd. If you have any questions regarding this product, please contact your BMW Motorrad dealer or BMW Motorrad directly. We hope you enjoy using your BMW Motorrad Navigator III. BMW Motorrad, D-80788 München, Internet address: www.bmw-motorrad.com Garmin International, Inc., 1200 E. 151st Street, Olathe, Kansas 66062 U.S.A. Tel. 913/397.8200 or 800/800.1020 Fax. 913/397.8282 Garmin (Europe) Ltd., Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51 9DL U.K. Tel. 44/0870.8501241 Fax. 44/0870.8501251 Garmin Corporation, No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan Tel. 886/2.2642.9199 Fax. 886/2.2642.9099 All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or stored in any storage medium, for any purpose without prior written consent. We hereby grant permission to download a single copy of this manual and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed, and to print one copy of this manual or any revision hereto, provided that such electronic or printed copy of this manual must contain the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited. Information in this document is subject to change without notice. BMW Motorrad reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements. Updates and further information on the application and use of this product can be found at the BMW Motorrad web site. Garmin ® and MapSource ® are registered trademarks and City Navigator ™ is a trademark of Garmin Ltd. or its subsidiaries and may not be used without the express permission of Garmin. The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Other trademarks and trade names are those of their respective owners. February 2006 Part Number 190-00634-02 Rev. A Navigator III Owner’s Manual i PREFACE Contact Information If you encounter any difficulty while using your BMW Motorrad Navigator III, or if you have any questions, in the U.S.A. contact Garmin Product Support by phone at 913/397.8200 or 800/800.1020, Monday–Friday, 8 AM–5 PM Central Time. You can also e-mail product support at [email protected]. In Europe, contact Garmin (Europe) Ltd. at 44/0870.8501241. Serial Number Record the serial number (8-digit number located on the back of the unit) in case your Navigator III needs service or you would like to buy additional maps. Serial Number: ___ ___ ___ ___ ___ ___ ___ ___ Manual Conventions When you are instructed to “touch” something, use your finger to touch an item on the screen. When you are instructed to “press” something, press a key on the front of the unit or on the remote control. You will see small arrows (>) used in the text. They indicate that you should touch a series of items. For example, if you see “touch Tools > GPS Info > GPS Settings” you should touch the Tools button, then touch GPS Info, and then touch GPS Settings. Quick Links PREFACE • Finding an address: page 7 • Viewing the map page: page 12 • Using Bluetooth ® technology: pages 21 through 24 • Turning off the GPS to use indoors: page 27 • Adjusting the volume: page 27 • Adjusting the brightness: page 32 • Cleaning and storing your unit: page vi ii Navigator III Owner’s Manual PREFACE TABLE OF CONTENTS Preface ..................................................................................i Contact Information .................................................................i Serial Number ...........................................................................i Manual Conventions ................................................................i Quick Links ...............................................................................i Warning ...................................................................................iv Attention ...................................................................................v Caring for Your Navigator III ..................................................vi Getting Ready ......................................................................1 Looking at the Navigator III ....................................................1 Using the Navigator III Keys ...................................................2 Using the Navigator III Interface ............................................2 Find It and Go! .....................................................................3 Finding a Restaurant ...............................................................3 Following Your Route ..............................................................4 Where To? ............................................................................5 Using the Where To? Menu ....................................................5 Understanding the Search Results ........................................5 Finding Recently Found Locations ......................................6 Understanding the Information Page ....................................6 Finding an Address .................................................................7 My Locations ........................................................................8 Saving Locations .....................................................................8 Saving Your Current Location ................................................8 Setting a Home Location ...................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

March 29, 2006 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Office of Engineering and Technology Federal Communications Commission Columbia, MD 21046 Equipment Approval Services Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-01017 PRODUCT: FM Transmitter operated under part 15.249. Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Operational Description, block diagram, and parts list be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459 (1998), following grant of the application. In support of this request, Garmin International, Inc. submits the following: 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-01017 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. This equipment is designed for commercial, industrial, and governmental applications. As such, unlike most consumer equipment, this equipment could be used for more than a decade in some cases. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Cover Letter(s)

March 30, 2006 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Federal Communications Commission Equipment Approval Services P.O. Box 35815 Pittsburgh, PA 15251-3315 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 CORES number: 0005-0885-88 Equipment: FCC ID: IPH-01017 FCC Rules: Part 2 and 15.249 Gentlemen: The 731 form and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. It is requested that the information contained in the operational description, block diagram, parts list, and schematics of the application be held confidential per Section 0.459. A statement of confidentiality will be attached with the application at the time of submittal. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

External Photos

ID Label/Location Info

Internal Photos

Parts List/Tune Up Info

RF Exposure Info

ROGERS LABS, INC. Garmin International, Inc. 4405 West 259 th Terrace MODEL: 011-01326-0x SN: Eng 1 Louisburg, KS 66053 Test #:060208 FCC ID#: IPH-01017 IC:1792A-01017 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS-210 Page 1 of 1 IPH 01017 Tx MPE.Doc 3/29/2006 MPE Calculation page for 011-01326-0x. MPE CalculatorGarmin IPH-01017Test 060208 MPE uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^2Antenna Gain (dBi)1 Output PowerdBd + 2.17 = dBidBi to dBd2.17 Tx Frequency (MHz)2457(Watts)0.0005Antenna Gain (dBd)-1.17 Cable Loss (dB)0.0(dBm)-3.01Antenna minus cable (dBi)1.00 Calculated ERP (mw) 0.382EIRP = Po(dBM) + Gain (dB) Calculated EIRP (mw) 0.629Radiated (EIRP) dBm-2.010 ERP = EIRP - 2.17 dB Occupational Limit Radiated (ERP) dBm-4.180 5.00000 mW/cm 2 General Public Limit 1.00000 mW/cm 2 Frequency (MHz)Occupational Limit Public Limit 300-1,500f/300f/1500 1,500-10,00051 Frequency (MHz) Occupational Limit @ Tx Freq (mW/cm^2) Public Limit @ Tx Freq (mW/cm^2) 300-1,5008.191.638 1,500-10,00051 EIRPDistanceDistanceS milliwattscminches mW/cm 2 0.62950.0019.690.00002 0.62940.0015.750.00003 0.62930.0011.810.00006 0.62925.009.840.00008 0.62920.007.870.00013 0.62915.005.910.00022 0.62914.005.510.00026 0.62913.005.120.00030 0.62912.004.720.00035 0.62911.004.330.00041 0.62910.003.940.00050 0.6299.003.540.00062 0.6298.003.150.00078 0.6297.002.760.00102 0.6296.002.360.00139 0.6295.001.970.00200 0.6294.001.570.00313 0.6293.001.180.00557 0.6292.000.790.01252 0.6291.750.690.01636 0.6291.500.590.02226 0.6291.250.490.03206 0.6291.000.390.05009 0.6290.750.300.08905 0.6290.500.200.20036 FCC radio frequency radiation exposure limits per 1.1310 FCC radio frequency radiation exposure limits per 1.1310 Power density (S) EIRP ------- = mW/cm^2 4 π r^2 r (cm) EIRP (mW)

Test Report

APPLICATION For GRANT OF CERTIFICATION FOR MODEL: 011-01326-0X Low Power Transmitter P/N 011-01326-0x FCC ID: IPH-01017 IC: 1792A-01017 FOR GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Test Report number 060208 TEST REPORT For APPLICATION of CERTIFICATION For GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Phone: (913) 397-8200 Mr. Van Ruggles Director of Quality Assurance MODEL: 011-01326-0X GPN 011-01326-0x Low Power Transmitter FREQUENCY: 2,400-2,483.5 MHz FCC ID: IPH-01017 IC: 1792A-01017 Test Report Number: 060208 Test Date: February 8, 2006 Certifying Engineer: Scot D. Rogers ROGERS LABS, INC. 4405 West 259th Terrace Louisburg, KS 66053 Telephone: (913) 837-3214 FAX: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-01017 4405 West 259 th Terrace MODEL: 011-01326-0x IC:1792A-01017 Louisburg, KS 66053 Test #:060208 SN: ENG 1 GPN: 011-01326-0x Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 3 of 37 IPH 01017 Transmitter FCC IC Test Report.Doc 3/28/2006 TABLE OF CONTENTS TABLE OF CONTENTS 3 FORWARD 4 APPLICABLE STANDARDS & TEST PROCEDURES 4 EQUIPMENT TESTED 5 LIST OF TEST EQUIPMENT 5 2.1033(B) APPLICATION FOR CERTIFICATION 6 EQUIPMENT AND CABLE CONFIGURATION 7 Test Setup 7 EQUIPMENT FUNCTION AND TESTING PROCEDURES 7 Configuration options for the EUT 8 AC Line Conducted Emission Test Procedure 9 Radiated Emission Test Procedure 9 Units of Measurements 9 Test Site Locations 10 SUBPART C - INTENTIONAL RADIATORS 10 15.203 ANTENNA REQUIREMENTS 10 15.205 RESTRICTED BANDS OF OPERATION 11 Data 15.205 12 Summary of Results for Radiated Emissions in Restricted Bands 15.205 12 15.207 CONDUCTED EMISSIONS LIMITS; GENERAL REQUIREMENTS 12 AC Line Conducted EMI 15.207 12 Data Conducted Emissions (7 Highest Emissions) (320-00171-12) 18 Data Conducted Emissions (7 Highest Emissions) (320-00171-11) 18 Data Conducted Emissions (7 Highest Emissions) (320-00171-13) 18 Data Conducted Emissions (7 Highest Emissions) (320-00171-14) 19 Summary of Results for AC Line Conducted General Emissions 15.207 19 15.209 RADIATED EMISSIONS LIMITS; GENERAL REQUIREMENTS 19 General Radiated EMI 15.209 19 General Radiated Emissions Data 15.209 23 Summary of Results for General Radiated Emissions 15.209 23 15.249 OPERATION IN THE BAND 2,400-2,483.5 MHZ 24 Transmitter Radiated Emissions 29 Power from Antenna Substitution Method for 15.249 30 Transmitter Antenna Conducted Emissions 30 TRANSMITTER EMISSIONS SUMMARY OF RESULTS 30 Summary of Results for Transmitter Radiated Emissions 15.249 30 FREQUENCY STABILITY 31 Measurements Required 31 Test Arrangement 31 Results 32 Summary of Results for Frequency Stability 33 Statement of Modifications and Deviations 33 APPENDIX 34 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-01017 4405 West 259 th Terrace MODEL: 011-01326-0x IC:1792A-01017 Louisburg, KS 66053 Test #:060208 SN: ENG 1 GPN: 011-01326-0x Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 4 of 37 IPH 01017 Transmitter FCC IC Test Report.Doc 3/28/2006 FORWARD The following information is submitted for consideration in obtaining a Grant of Certification for low power intentional radiator per CFR Paragraph 15.249 operation in the 2400 – 2483.5 MHz band. Name of Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Model: 011-01326-0x, GPN 011-01326-0x FCC ID: IPH-01017 Industry Canada ID: 1792A-01017 Frequency Range: 2400-2483.5 MHz. Operating Power: Less than 1 mW (as design specification, measured 94.9 dBμV/m @ 3 meters). Applicable Standards & Test Procedures a) In accordance with the Federal Communications Code of Federal Regulations, dated October 1, 2004, Part 2, Subpart J, Paragraphs 2.907, 2.911, 2.913, 2.925, 2.926, 2.1031 through 2.1057, applicable parts of paragraph 15, Part 15C paragraph 15.249, and Industry Canada RSS-210, the following information is submitted. b) Test procedures used are the established Methods of Measurement of Radio-Noise Emissions as described in the ANSI 63.4-2003 Document, and FCC documents DA00-1407 and DA00-705. NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Garmin International, Inc. FCC ID:IPH-01017 4405 West 259 th Terrace MODEL: 011-01326-0x IC:1792A-01017 Louisburg, KS 66053 Test #:060208 SN: ENG 1 GPN: 011-01326-0x Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249, RSS 210 Page 5 of 37 IPH 01017 Transmitter FCC IC Test Report.Doc 3/28/2006 Equipment Tested Equipment Serial Number FCC I.D.# 011-01326-0X ENG 1 IPH-01017 GA 27 GA27-1 N/A GXM 30 YHZHEOWL N/A GTM 10 GTM10-1 N/A Dell Computer 2574199639 DoC Printer B94C2121X N/A List of Test Equipment A Hewlett Packard 8591EM and or 8562A Spectrum Analyzer was used as the measuring device for the emissions testing. The analyzer settings used are described in the following table. Refer to the Appendix for a complete list of Test Equipment. HP 8591EM SPECTRUM ANALYZER SETTINGS CONDUCTED EMISSIONS: RBW AVG. BW DETECTOR FUNCTION 9 kHz 30 kHz Peak/Quasi Peak RADIATED EMISSIONS (30 – 1000 MHz): RBW AVG. BW DETECTOR FUNCTION 120 kHz 300 kHz Peak/Quasi Peak HP 8562A SPECTRUM ANALYZER SETTINGS RADIATED EMISSIONS (1 – 40 GHz): RBW AVG. BW DETECTOR FUNCTION 1 MHz 1 MHz Peak/Average ANTENNA CONDUCTED EMISSIONS: RBW AVG. BW DETECTOR FUNCTION 120 kHz 300 kHz Peak EQUIPMENT MFG. MODEL CAL. DATE DUE. LISN Comp. Design FCC-LISN-2-MOD.CD 10/05 10/06 LISN FCC FCC-LISN-50-16-2-08 6/05 6/06 LISN Comp. Design 1762 2/05 2/06 Antenna ARA BCD-235-B 10/05 10/06 Antenna EMCO 3147 10/05 10/06…

Text truncated - open the document above for the full version.

Test Setup Photos
