zumo ® 200 series quick start manual for use with the zūmo 220 January 2009 190-01144-01 Rev. A Printed in Taiwan Your zūmo Serial number under the battery Mini-USB connector under the weather cap microSD ™ card slot under the battery Release key: Slide up to open the battery cover. Battery contacts Power button: Press and hold to turn on/off the zūmo. Press quickly to adjust the backlight brightness. Speaker GPS antenna Battery cover Important Information ‹ Warning See the Important Safety and Product Information guide in the product box for product warnings and other important information. ‹ Warning This product contains a lithium-ion battery. To prevent personal injury or device damage, remove the device from the vehicle when exiting or store it out of direct sunlight. ‹ Warning Before mounting the zūmo, see the Important Safety and Product Information guide for information about laws pertaining to windshield mounting. Getting Started Install the zūmo Battery 1. Locate the lithium-ion battery that came in the product box. 2. Slide the release key up to open the battery cover on the back of the zūmo. 3. Locate the metal contacts on the end of the lithium-ion battery. 4. Insert the battery so that the metal contacts on the battery match up with the metal contacts inside the battery compartment. 5. Press the battery into place. 6. Slide the battery cover back on until it clicks into place. Mount Your zūmo in an Automobile 1. Pull back the weather cap from the mini- USB connector located on the back of your zūmo. 2. Plug the vehicle power cable into the mini-USB connector. 3. Snap the cradle onto the suction cup arm. Cradle Lever Suction cup arm 4. Remove the clear plastic from the suction cup. Clean and dry your windshield and the suction cup with a lint-free cloth. 5. Place the suction cup on the windshield. 6. Flip the lever back, toward the windshield. 7. Fit the bottom of your zūmo into the cradle. 8. Tilt the zūmo back until it snaps into place. 9. Plug the other end of the vehicle power cable into a power outlet in your vehicle. Your zūmo should turn on automatically if it is plugged in and the vehicle is running. Mount Your zūmo on the Motorcyle ‹ Warning Incorrectly wiring the power cable with bare wire leads can result in damage to the vehicle or the battery and can cause bodily injury. Garmin strongly recommends having an experienced installer with the proper knowledge of electrical systems install the unit. Step 1: Connect Power to the zūmo Select a suitable and secure location to mount the zūmo on your motorcycle, based on available power sources and safe cable routing. Step 2: Install the Handlebar Base The zūmo includes parts for two handlebar installation solutions. Custom mounts can require additional hardware (www.ram- mount.com). A) To install the U-bolt and handlebar base: 1. Place the U-bolt around the handlebar, and thread the ends through the handlebar base. 2. Tighten the nuts to secure the base. Do not overtighten. NOTE: The recommended torque is 50 lbf- in. Do not exceed torque of 80 lbf-in. Handlebar base Handlebar U-bolt B) To install the handlebar base to the clutch/brake clamp bracket: NOTE: Both 1/4 in. standard and M6 bolts are included. Match the size of the factory bolts on your clutch/brake clamp bracket. 1. Remove the two factory bolts on your clutch/brake clamp bracket. 2. Thread the new bolts through the handlebar base, spacers, and clamp bracket. 3. Tighten the bolts to secure the base. Clutch/brake clamp bracket Handlebar base Spacers Base plate Cradle Panhead screws Washers Spacers Nuts Step 3: Attach the Base Plate to the zūmo Mount 1. Thread the M4 × 40 mm panhead screws through the washers, cradle, spacers, and base plate. 2. Tighten the nuts to secure the base plate. Step 4: Attach the Base Plate to the Handlebar Base 1. Align the ball of the handlebar base and the ball of the base plate with the double- socket arm. 2. Tighten the knob slightly. 3. Adjust for better viewing and operation. 4. Tighten the knob to secure the mount. Cradle Base plate Double-socket arm Knob Handlebar base Step 5: Install Your zūmo in the Mount 1. Fit the bottom of your zūmo into the cradle. 2. Tilt the zūmo back until it snaps into place. Cradle Release button Remove Your zūmo from Either Mount 1. Press the release tab on the top of the mount to release the zūmo. 2. Lift out the zūmo. 3. Place the weather cap on the cradle (motorcycle mount only). Configure the zūmo To turn on your zūmo, press and hold . Follow the on-screen instructions. Acquire Satellites Go outdoors to an open area, out of garages, and away from tall buildings. Stop your vehicle, and turn on the zūmo. Acquiring satellite signals may take a few minutes. The bars indicate satellite strength. When the bars are green, the zūmo has acquired satellites signals. Now you can select a destination and navigate to it. Resetting the zūmo If the zūmo stops functioning, turn the zūmo off and on again. If this does not help, press and hold for 10 seconds. The zūmo should operate normally. You can also remove the battery, and then reinstall it. Using the Menu Page ➊ ➋➌ ➍ ➎ ➏➐ ➑ ➒ ➊ GPS satellite strength. ➋ Bluetooth headset status. NOTE: Pages appear differently based on your usage mode and settings. ➌ Touch to change usage mode. ➍ Battery status. ➎ Current time. Touch to change time settings. ➏ Touch to find a destination. ➐ Touch to view the map. ➑ Touch to adjust the volume. ➒ Touch to use the tools such as settings, Where Am I?, Help, and routes. Finding Points of Interest 1. Touch Where To? > Points of Interest. 2. Select a category. 3. Select a destination, and touch go!. To search by name, touch Where To? > Points of Interest > Spell Name. To search in a different area, touch Where To? > Near. Using the Go! Page ➊ ➋ ➌ ➍ ➊ Touch to view the route on the map. ➋ Touch to start navigating the route. ➌ Touch to view this location and surrounding areas on the map. ➍ Touch to save this location to…
Text truncated - open the document above for the full version.
January 12, 2010 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-01364 PRODUCT: Low power Transmitters operated under part 15.249. Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Operational Description, Block diagram, and parts list be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459, following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES 01102393 Conf BlkDia.pdf 01102393 Conf OpDes.pdf 01102393 Conf Schem.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-01364 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers
January 12, 2010 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-01364 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 FCC Rules: Parts 2 and 15.249 Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. Permanent Garmin International, Inc. requests that the material in the Parts List, Schematics, block diagram, and Operational Description be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459, following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics 01102393 Conf Schem.pdf Block diagram 01102393 Conf BlkDia.pdf Operational Description 01102393 Conf OpDes.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214
Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 01102393 GPN: 011-02393-xx FCC ID#: IPH-01364 Louisburg, KS 66053 Test #: 091211 SN: 3696480058 IC: 1792A-01364 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01102393 ExtPho Date: January 12, 2010 External photographs of equipment under test
zūmo 220 unit label Label will be placed underneath the battery, inside the battery door.
Back side of PCB Front side of PCB (BT antenna is in lower left corner) Inside front side of unit Inside rear case and rear of PCB
Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 01102393 GPN: 011-02393-xx FCC ID#: IPH-01364 Louisburg, KS 66053 Test #: 091211 SN: 3696480058 IC: 1792A-01364 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01102393 TunPro Date: January 12, 2010 Tune-up Procedure The 26 MHz crystal used by the Bluetooth transceiver does not have any adjustment. Transceiver functional performance is measured at the board level and final testing in production on a pass fail basis.
Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 01102393 GPN: 011-02393-xx FCC ID#: IPH-01364 Louisburg, KS 66053 Test #: 091211 SN: 3696480058 IC: 1792A-01364 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01102393 RFExp Date: January 12, 2010 MPE Calculation page MPE CalculatorGarminTest Number091211 MPE uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^ 2Antenna Gain (dBi)1 Output Power dBd + 2.17 = dBidBi to dBd2.17 Tx Frequency (MHz)2441(Watts)0.001000- 1.17 Antenna minus cable (dBi)1.00 Cable Loss (dB)0.0(dBm)0.00 Calculated ERP (mw) 0.764Radiated (EIRP) dBm1.000 Calculated EIRP (mw) 1.259 Radiated (ERP) dBm-1.170 Occupational Limit 5.00000mW/cm 2 Ge ne ral Public Limit 1.00000mW/cm 2 Frequency (MHz)Occupational LimitPublic Limit 300-1,500f/300f/1500 1,500-10,00051 Frequency (MHz) Occupational Limit @ Tx Freq (mW/cm^2) Public Limit @ Tx Freq (mW/cm^2) 300-1,5008.1366666671.627333333 1,500-10,00051 EIRPDistanceDistanceS milliwattscminchesmW/cm 2 1.25950.0019.690.00004 1.25940.0015.750.00006 1.25930.0011.810.00011 1.25920.007.870.00025 1.25910.003.940.00100 1.2595.001.970.00401 1.2594.001.570.00626 1.2593.001.180.01113 1.2592.000.790.02505 1.2591.000.390.10018 1.2590.500.200.40073 1.2590.320.130.97834 1.2590.200.082.50455 1.2590.150.064.45254 1.2590.100.0410.01821 Frequency (MHz) O c c up a tio na l Limit minimum Distance (cm / in) P ub lic Limit minimum distance (cm / in) 300-1,500N/AN/A 1,500-10,0000.15 / 0.060.32 / 0.13 FCC radio frequency radiation exposure limits per 1.1310 FCC radio frequency radiation exposure limits per 1.1310 Power d ensity (S) = EIRP -------= mW/cm^2 4 p r^2 [ r (cm), EIRP (mW)]
