ecoRoute ESP Instructions ..................................................................2 ecoRoute ESP Instructions in French .................................................4 190-01132-91_0A.indd 19/14/2009 12:18:24 PM  ecoRoute ESP Instructions The ecoRoute ™ ESP device connects to your vehicle’s OBD II (On-Board Diagnostics) connector. The ecoRoute ESP device sends data wirelessly to a compatible Garmin GPS device. OBD II Connector Location The location of the OBD II connector varies for each vehicle. For the best view of the connector, open the driver door and kneel. The following are common locations in which to look for the OBD II connector: The OBD II connector is often below the steering column, between the center console and the driver’s door. The OBD II connector might be under a labeled cover. Remove or open the cover to access the connector. The OBD II connector might be under or behind the ash tray or near the power outlet in the center console. Installing the ecoRoute ESP Device  WaRnIng When installing the device in a vehicle, install the device securely so it does not interfere with the vehicle operating controls, such as the foot pedals. Interfering with the vehicle operating controls can result in an accident, which could result in injury or death. Before installing the ecoRoute ESP device, you must find the OBD II connector in your vehicle. 1. Connect the ecoRoute ESP connector to the OBD II connector in the vehicle. ecoRoute ESP connector Vehicle OBD II connector 2. Use the cable ties to secure the ecoRoute ESP device and cable to the vehicle. • • • ecoRoute ESP device RESET key Cable ties LED Customizing the Cable angle If the vehicle requires the cable to be at an angle from the connector, you can use the cable ties to customize the cable for the installation. 1. Bend the cable around the connector to suit the installation. 2. Use a cable tie to secure the cable to the connector to fit a variety of installation situations. Wirelessly Connecting with a garmin gPS Device Before wirelessly connecting to a GPS device, you must install the ecoRoute ESP device. 1. Start the vehicle. The LED turns green when the ecoRoute ESP device is communicating with your vehicle. 2. Turn on the GPS device. 3. Bring the GPS device within 10 meters (33 feet) of the ecoRoute ESP device. 4. From the Tools menu, touch ecoRoute > ESP Connection. The LED turns blue when the ecoRoute ESP device is connected to your GPS device. about the Wireless Connection to the gPS Device The ecoRoute ESP device and the GPS device automatically connect when they are turned on and are within 10 meters (33 feet) of each other. When it is not connected to a GPS device, the ecoRoute ESP device records the vehicle information and sends the data to the GPS device the next time they connect. OBD II ConnectorOBD II Connector Cable Secured to the Connector Cable Secured to the Connector 190-01132-91_0A.indd 29/14/2009 12:18:26 PM  Viewing ecoRoute ESP Data On your GPS device, touch Tools > ecoRoute. about the LEDs The LED on the top of the ecoRoute ESP device indicates the connection status: LEDMeaning Green flashingConnecting to the vehicle. Green solidCommunicating with the vehicle. Blue solidCommunicating with the vehicle and a GPS device. Resetting the ecoRoute Device Reset the ecoRoute device if it stops functioning. Press and release the Reset key to rest the device. Press and hold the Reset key for 3 seconds to restore the factory settings. NoTE: When restoring the factory settings, the wireless connection information and recorded vehicle information will be deleted. FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet that is on a • • • • • different circuit from the GPS unit. Consult the dealer or an experienced radio/TV technician for help. This product does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and void your warranty and your authority to operate this device under Part 15 regulations. Industry Canada Compliance Category I radiocommunication devices comply with Industry Canada Standard RSS-210. Category II radiocommunication devices comply with Industry Canada Standard RSS-310. Declaration of Conformity Hereby, Garmin, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. To view the full Declaration of Conformity, go to www.garmin.com /declaration-of-conformity. California notices The California Electronic Waste Recycling Act of 2003 requires the recycling of certain electronics. For more information on the applicability to this product, see www.erecycle.org.  WaRnIng This product, its packaging, and its components contain chemi…

Text truncated - open the document above for the full version.

December 28, 2009 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-01633 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 RE: Request Certification Issue date January 6, 2010 Hello We request the application for this (IPH-01633) project be reviewed and processed for grant of certification. We respectfully request issuance of the grant of certification be January 6, 2010 as this is the date for product marketing. This request removes need for typical short term confidential exhibit status. We continue requesting holding eligible exhibits confidential for long term. Please review and let me know if you have any questions or concerns. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

September 28, 2009 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-01633 PRODUCT: Low power Transmitters operated under part 15.249. Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Operational Description, Block diagram, and parts list be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459, following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES 01633 Conf BlkDia.pdf 01633 Conf OpDes.pdf 01633 Conf Schem.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-01633 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

December 28, 2009 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-01633 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 FCC Rules: Parts 2 and 15.249 Gentlemen: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site to be used in obtaining a grant of certification. Confidentiality is requested as outlined below. Permanent Garmin International, Inc. requests that the material in the Parts List, Schematics, block diagram, and Operational Description be withheld from public disclosure in accordance with Section 0.459 of the Commissions Rules, 47 C.F.R. 0.459, following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics 01633 Conf Schem.pdf Block diagram 01633 Conf BlkDia.pdf Operational Description 01633 Conf OpDes.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 011-02327-00 GPN: 011-02327-00 FCC ID#: IPH-01633 Louisburg, KS 66053 Test #: 090916 SN: FCC #2 IC: 1792A-01633 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01633 ExtPho Date: December 28, 2009 External photographs of equipment under test

Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 011-02327-00 GPN: 011-02327-00 FCC ID#: IPH-01633 Louisburg, KS 66053 Test #: 090916 SN: FCC #2 IC: 1792A-01633 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01633 LabelSmpl Date: September 25, 2009 FCC/IC ID label and location Label Location Label Placement Company Name Location on Front of Equipment

Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 011-02327-00 GPN: 011-02327-00 FCC ID#: IPH-01633 Louisburg, KS 66053 Test #: 090916 SN: FCC #2 IC: 1792A-01633 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01633 IntPho Date: December 28, 2009 External photographs of equipment under test

Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 011-02327-00 GPN: 011-02327-00 FCC ID#: IPH-01633 Louisburg, KS 66053 Test #: 090916 SN: FCC #2 IC: 1792A-01633 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01633 TunPro Date: September 25, 2009 Tune-up Procedure The 16.0MHz crystal used by the Bluetooth transceiver does not have any adjustment. Transceiver functional performance is measured at the board level and final testing in production on a pass fail basis.

Rogers Labs, Inc. Garmin International, Inc. 4405 West 259 th Terrace Model: 011-02327-00 GPN: 011-02327-00 FCC ID#: IPH-01633 Louisburg, KS 66053 Test #: 090916 SN: FCC #2 IC: 1792A-01633 Phone/Fax: (913) 837-3214 Test to: CFR47 Parts 2 and 15.249, RSS-210 Page 1 of 1 Revision 1 File: 01633 RFExp Date: September 25, 2009 MPE Calculation page GarminTest Number:090916 MPE CalculatorMPE uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^2 Antenna Gain (dBi)1 Output PowerdBd + 2.17 = dBi dBi to dBd2.2 Tx Frequency (MHz)2441Maximum (Watts)0.0004Antenna Gain (dBd)-1.17 C able Loss (dB)0.0(dBm)- 3.73Antenna minus cable (dBi)1.00 Calculated ERP (mw) 0.324EIRP = Po(dBM) + Gain (dB) Calculated EIRP (mw) 0.533Radiated (EIRP) dBm-2.729 ERP = EIRP - 2.17 dB Occupational Limit Radiated (ERP) dBm-4.899 5.00000mW/cm 2 Ge ne ral Public Limit 1.00000mW/cm 2 Frequency (MHz)Occupational LimitPublic Limit 300-1,500f/300f/1500 1,500-10,00051 Frequency (MHz) Occupational Limit @ Tx Freq (mW/cm^2) Public Limit @ Tx Freq (mW/cm^2) 300-1,5008.1366666671.627333333 1,500-10,00051 EIRPDistanceDistanceS milliwa ttsc minc he smW /c m 2 0.533100.0039.370.00000 0.53375.0029.530.00001 0.53350.0019.690.00002 0.53340.0015.750.00003 0.53330.0011.810.00005 0.53320.007.870.00011 0.53310.003.940.00042 0.5335.001.970.00170 0.5332.000.790.01061 0.5331.000.390.04245 0.5330.750.300.07547 0.5330.500.200.16981 0.5330.250.100.67925 0.5330.200.081.06133 0.5330.150.061.88681 Frequency (MHz) Occupational Limit minimum Distance (cm / inches) P ublic Limit minimum distance (cm / inches) 300-1,500N/AN/A 1,500-10,000N/A0.20 / 0.10 FCC radio frequency radiation exposure limits per 1.1310 FCC radio frequency radiation exposure limits per 1.1310 Power density (S) = EIRP -------= mW/cm^2 4 p r^2 [ r (cm), EIRP (mW)]

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-01633 4405 West 259 th Terrace Model: 011-02327-00 IC: 1792A-01633 Louisburg, KS 66053 Test #:090916 SN: FCC #2 GPN: 011-02327-00 Phone/Fax: (913) 837-3214 Test to: FCC CFR47 15.249, RSS 210 Page 1 of 30 Revision 1 File: 011-02327-00 090916 TstRpt Date: September 28, 2009 Application For Grant of Certification FOR Model: 011-02327-00 P/N 011-02327-00 Low Power Transmitter FCC ID: IPH-01633 IC: 1792A-01633 FOR GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Test Report Number 090916 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-01633 4405 West 259 th Terrace Model: 011-02327-00 IC: 1792A-01633 Louisburg, KS 66053 Test #:090916 SN: FCC #2 GPN: 011-02327-00 Phone/Fax: (913) 837-3214 Test to: FCC CFR47 15.249, RSS 210 Page 2 of 30 Revision 1 File: 011-02327-00 090916 TstRpt Date: September 28, 2009 Test Report for Application of Certification For GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Phone: (913) 397-8200 Mr. Van Ruggles Director of Quality Assurance Model: 011-02327-00 P/N 011-02327-00 Low Power Transmitter Frequency Range: 2,402-2,480 MHz FCC ID: IPH-01633 IC: 1792A-01633 Test Report Number: 090916 Test Date: September 16, 2009 Authorized Signatory: Scot D. Rogers Rogers Labs, Inc. 4405 West 259th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-01633 4405 West 259 th Terrace Model: 011-02327-00 IC: 1792A-01633 Louisburg, KS 66053 Test #:090916 SN: FCC #2 GPN: 011-02327-00 Phone/Fax: (913) 837-3214 Test to: FCC CFR47 15.249, RSS 210 Page 3 of 30 Revision 1 File: 011-02327-00 090916 TstRpt Date: September 28, 2009 Table of Contents TABLE OF CONTENTS .................................................................................................... 3 FORWARD ....................................................................................................................... 5 APPLICABLE STANDARDS & TEST PROCEDURES .................................................... 5 OPINION / INTERPRETATION OF RESULTS ................................................................. 5 ENVIRONMENTAL CONDITIONS .................................................................................... 6 STATEMENT OF MODIFICATIONS AND DEVIATIONS ................................................. 6 UNITS OF MEASUREMENTS .......................................................................................... 6 TEST SITE LOCATIONS .................................................................................................. 6 LIST OF TEST EQUIPMENT ............................................................................................ 7 APPLICATION FOR CERTIFICATION ............................................................................. 8 EQUIPMENT TESTED ...................................................................................................... 9 EQUIPMENT AND CABLE CONFIGURATION ................................................................ 9 Test Setup .................................................................................................................................................................. 9 Equipment Function and Testing Procedures ........................................................................................................ 9 Configuration options for the EUT ......................................................................................................................... 10 AC Line Conducted Emission Test Procedure ....................................................................................................... 10 Radiated Emission Test Procedure ......................................................................................................................... 10 SUBPART C - INTENTIONAL RADIATORS .................................................................... 11 ANTENNA REQUIREMENTS ........................................................................................... 11 RESTRICTED BANDS OF OPERATION ......................................................................... 11 Radiated Emissions in Restricted Bands Data ....................................................................................................... 12 Summary of Results for Radiated Emissions in Restricted Bands ....................................................................... 12 RADIATED EMISSIONS LIMITS; GENERAL REQUIREMENTS ..................................... 13 General Radiated EMI Testing Procedure ............................................................................................................. 13 Figure One Radiated Emissions Plot ...................................................................................................................... 14 Figure Two Radiated Emissions Plot ..................................................................................................................... 14 Figure Three Radiated Emissions Plot ................................................................................................................... 15 Figure Four Radiated Emissions Plot ..................................................................................................................... 15 Figure Five Radiated Emissions Plot ..................................................................................................................... 16 Figure Six Radiated Emissions Plot ....................…
