IPH-01767Portable GMRS/FRS PTT Radio Transceiver with GPS

rino ® 600 series owner’s manual © 2011 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com for current updates and supplemental information concerning the use of this product. Garmin ® , the Garmin logo, Rino ® , BlueChart ® , and City Navigator ® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. HomePort ™ , BaseCamp ™ , ANT ™ , and ANT+ ™ are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. Windows ® is a registered trademark of Microsoft Corporation in the United States and/or other countries. Mac ® is a registered trademarks of Apple Computer, Inc. microSD ™ is a trademark of SD-3C, LLC. Other trademarks and trade names are those of their respective owners. Rino 600 Series Owner’s Manual 1 Table of Contents Table of Contents Getting Started ������������������������3 Keys3 Manual Conventions 4 Battery Information 4 Acquiring Satellite Signals 6 Registering Your Device 6 Turning On the Backlight 6 Locking the Screen 7 Radio ����������������������������������������8 About the Radio 8 Choosing a Channel 8 Radio Settings 9 About Contacts 10 Notes 10 About Peer-to-Peer Positioning  11 Using SAME Weather Alerts 12 Radio Page Status Indicators 13 Waypoints and Tracks ����������15 Waypoints 15 About Sharing Data 16 Tracks 16 Navigating a Saved Track17 Navigation �����������������������������18 Navigating to a Destination 18 Map18 Compass 19 Navigating to a Contact 20 Geocaches 21 Routes 21 Using Sight ‘N Go 23 Camera and Photos ��������������24 Taking a Photo 24 Viewing Photos 24 Customizing Your Device ����26 Customizing the Data Fields 26 Customizing the Home Screen 26 Creating a Custom Profile 26 Customizing Specific Pages 27 System Settings27 Display Settings 28 Setting the Device Tones 29 2 Rino 600 Series Owner’s Manual Table of Contents Map Settings29 Tracks Settings 30 Changing the Units of Measure 31 Time Settings 31 Position Format Settings 31 Heading Settings 31 Altimeter Settings 32 Geocache Settings 33 Routing Settings 33 Marine Map Settings34 Fitness 35 Resetting Data 35 Tools ��������������������������������������36 Trip Computer 36 Elevation Plot36 Viewing the Calendar and Almanacs 36 Calculating the Size of an Area 36 Setting an Alarm 37 Opening the Stopwatch 37 Device Information ���������������38 Updating the Software 38 Viewing Device Information 38 Specifications 38 About the Batteries 39 Caring for the Device 40 Data Management 41 Additional Maps 44 Optional Accessories 44 Data Field Options 45 Troubleshooting 50 FCC Licensing Information 52 Index ��������������������������������������54 Rino 600 Series Owner’s Manual 3 Getting Started Getting Started  WaRNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. When using your device the first time, you should complete the following tasks to set up the device and get to know the basic features. 1. Install the batteries (page 4). 2. Register the device (page 6). 3. Acquire satellites (page 6). 4. Set up the radio (page 9). 5. Mark a waypoint (page 15). 6. Record a track (page 17). 7. Navigate to a destination (page 18). 8. Calibrate the compass (page 19). Keys ➌ ➊ ➋ KeyDescription ➊ Select to send out a call tone If enabled (page 11), the call key sends your position when released 4 Rino 600 Series Owner’s Manual Getting Started ➋ Hold to turn on or off the device Select to adjust backlight, volume, squelch level, and to lock or unlock the screen ➌ Hold to talk PTT stands for push-to-talk Manual Conventions All the pages are found on the home screen. Use or to scroll through the pages. The small arrows (>) used in the text indicate that you should select a series of items in order, for example, “Select Delete > Yes.” Battery Information The device operates on the included lithium-ion battery pack or four AA batteries. For tips on maximizing battery life and other battery information, see page 39. Installing the Lithium-ion Battery note: The lithium-ion battery pack can be used only with the Rino ® 650 and 655t. 1. Locate the battery pack ➊ that came in the pr…

Text truncated - open the document above for the full version.

Front of Rino 650 Back of Rino 650 with battery removed Back of Rino 650 with Lithium Ion Battery Side of Rino 650 with Lithium Ion Battery Back of Rino 650 w/ Alkaline battery pack Side of Rino 650 w/ Alkaline battery pack Back of DUT with Lithium Ion battery and Belt-Clip accessory Side of DUT with Lithium Ion battery and Belt-Clip accessory Back of DUT with Lithium Ion battery and Carabiner Clip acc. Side of DUT with Lithium Ion battery and Carabiner Clip acc. Back of DUT with Lithium Ion battery, Belt-Clip accessory, and Ear Receiver audio accessory Back of DUT with Lithium Ion battery, Belt-Clip accessory, and Earbud w/ PTT audio accessory Back of DUT with Lithium Ion battery, Belt-Clip accessory, and Headset-Mic audio accessory Lithium Ion Battery P/N: 011-02526-30 AA Battery Pack P/N: 011-02526-40 Swivel Belt-Clip accessory P/N: 013-00063-00 (with spine mount) Carabiner Clip accessory P/N: 011-01750-20 Flexible Ear Receiver audio accessory P/N: 013-00071-00 Earbud w/ PTT Mic audio accessory P/N: 013-00072-00 Headset w/ Mic audio accessory P/N: 013-00392-00

Rino 650 FCC ID LABEL LOCATION (SEE NEXT PAGE) MGR. PROJ. RELEASED BY UNLESS NOTED OTHERWISE ANGLES +/- 0 DEG./30 MIN. HOLES +/-.003”, .08 mm .XXX +/-.005”, .13 mm .XX +/-.010”, .25 mm TOLERANCE CHKD. DRAWN DATE OFSHT. REV. DWG. NO. SCALE SIZE TITLE CONFIDENTIAL This drawing and the specifications contained herein are the property of Garmin Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. 161-01582-01 A A 1 1 1X Aries W. 04/25/11 PRODUCTION RELEASE REMOVE NOM, ADD “MODEL” 04/25/11 3/24/11 80004 A B REV. DATE DESCRIPTION APPRVD. REVISIONS ---- SPECIFICATION CONTROL DRAWING c/o Garmin International, Inc. Garmin Ltd. or its subsidiaries 1200 E. 151st Street Olathe, Kansas 66062 U.S.A. 3. MAIN TAG AND ADDITIONAL TAG ARE SUPPLIED ON ONE ROLL WITH EQUIVALENT SERIAL NO.S ADJACENT TO EACH OTHER. ALL TAGS ARE "KISS CUT" ON ROLL. 4. PARTS TO BE FABRICATED USING DIGITAL CORELDRAW FILE. 5. THIS PART SHALL COMPLY WITH GARMIN BANNED & RESTRICTED SUBSTANCES DOCUMENT GPN 001-00211-00 NOTES: 1. MATERIAL: VINYL LAMINATE, SECOND SURFACE PRINTED. BACKGROUND - BLACK. NOMENCLATURE (SEE CHART), SERIAL NUMBERS TO BE BLACK. ACRYLIC PERMANENT ADHESIVE ON BACK SIDE WITH PEEL OFF RELEASE LINER. TOTAL PACKAGE THICKNESS EXCLUDING RELEASE LINER IS .002-.005 (0.05-0.13). SCALE: 1X 29V000000 2. 9 DIGIT SERIAL NUMBER TO BE PRINTED SEQUENTIALLY IN FIELDS AS SHOWN (2D, CODE 39 W/HUMAN READABLE OR HUMAN READABLE ONLY WHEN APPLICABLE). PRINT ADDITIONAL TAGS (30 X 7.5) IN QTY INDICATED (BARCODE 39 WITH HUMAN READABLE ONLY). ALL TAGS PRINTED WITH INDELIBLE BLACK INK. S/N RANGE FOR THIS ITEM: 29V000000-29V999999 AS INDICATED ON GARMIN PURCHASE ORDER. Pantone Cool Grey 6C Tag,S/N,Rino 650,US M/N: Rino 650 Made in Taiwan FCC ID:IPH-01767 29V000000 18.0 mm 22.5 mm M/N: Rino 650 Made in Taiwan FCC ID:IPH-01767

Test Report Serial No.: 041511–T1095-E249U Report Issue Date: July 15, 2011 Measurement Date(s): June 6 -10 , 2011 Report Revision No.: Revision 1.0 FCC Rule Part(s): 47 CFR §15.249 FCC Test Firm Reg. No.: 714830 IC Standard(s): RSS-210 RSS-Gen IC Test Site No.: IC 3874A-1 Test Lab Certificate No. 2470.01 Applicant: Garmin International Model: Rino 650, Rino 655t FCC ID: IPH-01767 IC:1792A-01767 DUT Type: Portable 5W UHF FRS/GMRS PTT Radio Transceiver w/ GPS 2010 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 16 DECLARATION OF COMPLIANCE - ELECTROMAGNETIC COMPATIBILITY (FCC/IC) FCC PART 15.249 & IC RSS-210 (Issue 8) Name CELLTECH LABS INCORPORATED Test Lab Information Address 21-364 Lougheed Road, Kelowna, British Columbia V1X 7R8 Canada FCC 714830 Test Lab Registration No.(s) IC 3874A-1 Name GARMIN INTERNATIONAL INC. Applicant Information Address 1200, East 151 st Street, Olathe, KS, 66062 USA FCC 47 CFR Part 15.249 IC RSS-210 Issue 8; RSS-Gen Issue 3 Standard(s) & Procedure(s) ANSI C63.4-2003 FCC Low Power Communication Device (DXX) Device Classification(s) IC Low-power Licence-exempt Radiocommunication Device (Category 1) FCC TCB Certification Application Type(s) IC CB Certification FCC ID: IPH-01767 Device Identifier(s) IC: 1792A-01767 Device Model(s) Tested Rino 650, Rino 655t (with camera) Test Sample Serial No. 1766382247995203 (Identical Prototype) - Rino 655t Transmit Frequency Band 2400 – 2483.5 MHz Transmit Frequency Range 2402 - 2479 MHz Max. RF Output Power Tested 94.3 dBuV/m (Peak) 46.8 dBuV/m (Avg) Modulation Type(s) Pulsed GFSK Transmitter Duty Cycle(s) Normal Operation = 0.210 ms(on) T= 50 ms ~ 0.5% on air time Antenna Type(s) Tested Printed inverted F-antenna Power Source(s) Tested Li-Ion 7.8V (nominal) 2300mAh P/N: 011-02526-30 This wireless device has demonstrated compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC 47 CFR Part 15.249; Industry Canada RSS-210 Issue 8 and RSS-Gen Issue 3; and ANSI C63.4-2003. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results and statements contained in this report pertain only to the device(s) evaluated. This report shall not be reproduced partially or in full without the prior written approval of Celltech Labs Inc. Test Report Approved By Sean Johnston Laboratory Manager Celltech Labs Inc. Test Report Serial No.: 041511–T1095-E249U Report Issue Date: July 15, 2011 Measurement Date(s): June 6 -10 , 2011 Report Revision No.: Revision 1.0 FCC Rule Part(s): 47 CFR §15.249 FCC Test Firm Reg. No.: 714830 IC Standard(s): RSS-210 RSS-Gen IC Test Site No.: IC 3874A-1 Test Lab Certificate No. 2470.01 Applicant: Garmin International Model: Rino 650, Rino 655t FCC ID: IPH-01767 IC:1792A-01767 DUT Type: Portable 5W UHF FRS/GMRS PTT Radio Transceiver w/ GPS 2010 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 16 TABLE OF CONTENTS 1.0 SCOPE ................................................................................................................................................................ 4 2.0 REFERENCES .................................................................................................................................................... 4 2.1 Normative References ......................................................................................................................................... 4 3.0 PASS/FAIL CRITERIA......................................................................................................................................... 4 4.0 FACILITIES AND ACCREDITATIONS ................................................................................................................ 5 5.0 GENERAL INFORMATION ................................................................................................................................. 5 5.1 Applicant Information ........................................................................................................................................... 5 5.2 DUT Description .................................................................................................................................................. 5 5.3 Mode(s) of Operation Tested............................................................................................................................... 5 5.4 Modification(s) ..................................................................................................................................................... 5 Appendix A – Duty Cycle .................................................................................................................................... 6 Appendix B – Occupied Bandwidth and Band Edge........................................................................................... 7 Appendix C - Radiated Spurious Emissions (TX) .............................................................................................10 Appendix D - Radiated Spurious Emissions (RX) .............................................................................................14 Appendix E - Antenna Requirement §15.203 ...................................................................................................16 FIGURES Figure E.6-1 - Setup Drawing – Radiated TX Spurious Emissions (> 1 GHz) .......................................................... 7 Figure E.6-1 - Setup Drawing – Radiated TX Spurious Emissions (> 1 GHz) ................................…

Text truncated - open the document above for the full version.

Test Report Serial No.: 041511IPH-T1094-E95U Test Report Issue Date: July 15, 2011 Measurement Dates: May 18, June 01-10 , 2011 Test Report Revision: Rev. 1.0 FCC 47 CFR §2, §95A, §95B FCC Accredited Site Rule Part(s) Applied: IC RSS-210 (8), RSS-Gen (3) Test Site Registration: IC Site File #: 3874A-1 Test Lab Certificate No. 2470.01 Applicant: Garmin International Inc. FCC ID: IPH-01767 IC: 1792A-01767 DUT Type: Portable 5W UHF FRS/GMRS PTT Radio Transceiver w/ GPS DUT Model(s):Rino 650, Rino 655t 2011 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 32 of 39 F.10 TEST SETUP PHOTOGRAPH
