nüvi ® 2575R/ 2575 quick start manual 2 nüvi 2575R/ 2575 Quick Start Manual Connecting the Device to Vehicle Power WARNING This product contains a lithium-ion battery. To prevent the possibility of personal injury or product damage caused by battery exposure to extreme heat, remove the device from the vehicle when exiting or store it out of direct sunlight. Charge your device before using it on battery power. 1. Fit the bottom of your device into the mount. 2. Tilt your device back until it snaps into place. 3. Plug the vehicle power cable ➊ into the mini-USB connector ❹ on the mount. ➊ ➋ ➌ ➍ 4. Plug the other end of the vehicle power cable into a power outlet in your vehicle. nüvi 2575R/ 2575 Quick Start Manual 3 5. If you are using a traffic receiver , connect the external antenna to the traffic receiver and secure it to the windshield using the suction cups. 6. There is an optional choice for video in connector ➋, connecting rear view camera and driving recorder connector ➌. After the device has been connected to vehicle power, the following occurs. • The device turns on. • The device acquires satellite signals. When at least one of the bars is green, your device has acquired satellite signals. • NOTE: The device may need a clear view of the sky to acquire satellite signals. • The device charges as you drive. in the status bar indicates the status of the internal battery. Mounting Your Device 1. Remove the clear plastic from the suction cup. 2. Clean and dry your windshield and the suction cup with a lint- free cloth. 3. Press the suction cup to the windshield. 4. While pressing, flip the lever back toward the windshield. 5. Snap the mount ➊ onto the suction cup arm ➋. ➊ ➋ 4 nüvi 2575R/ 2575 Quick Start Manual Device Overview ➊ ➋ ➊ Power key ➋ microSD ™ card slot ➌ Analogue television receiver ➍ External TV antenna connector Using the Power Key 1. Press and quickly release the Power key to view additional options. 2. Select an option: • To adjust screen brightness, touch and drag the scroll bar. • To turn off your device, touch Off. • To reset the device, hold the Power key for 10 seconds. • To exit the menu, press and release the Power key. About Points of Interest The detailed maps loaded in your device contain points of interest, such as restaurants, hotels, and auto services. Finding a Point of Interest by Category 1. From the Main menu, touch Where To? > Points of Interest. 2. Select a category. 3. If necessary, select a subcategory. 4. Select a destination. 5. Touch Go!. nüvi 2575R/ 2575 Quick Start Manual 5 Touch > Save on this page to save the location to a Favorites folder on the device. Use the Favorites folder to save the location of your workplace, home, and other common destinations. 6. If necessary, select an option: • Touch Drive to calculate a route you will navigate by driving. • Touch Walk to calculate a route you will navigate by walking. • Touch Public Transit to calculate a route that combines public transit and walking. NOTE: You must have cityXplorer ™ maps loaded to navigate using public transit. Go to www.garmin.com to purchase cityXplorer maps. Using the Main Menu ➊ ➋➌ ➍➐➑➎➏ • Touch ➊ to select a transportation mode. • Touch ➋ to find a destination. • Touch ➌ to view the map. • Touch ➍ to stop a route. • Touch ➎ to detour a route. • Touch ➏ to watch TV • Touch ➐ to adjust the volume. • Touch ➑ to open the menu of tools and settings. 6 nüvi 2575R/ 2575 Quick Start Manual Your Route on the Map NOTICE The speed limit icon feature is for information only and does not replace the driver’s responsibility to abide by all posted speed limit signs and to use safe driving judgment at all times. Garmin will not be responsible for any traffic fines or citations that you may receive for failing to follow all applicable traffic laws and signs. Your route is marked with a magenta line on the map. If you depart from the original route, your device recalculates the route. A speed limit icon could appear as you travel on major roadways. Using the Map Functions ➊➋ ➌ ➍ ➎ ➏ ➐ ➑ ➒ • Touch ➊ to view the next turn. If a view of a junction exists, the junction view appears. • Touch ➋ to view the turn list. • Touch ➌ to zoom in and out. • Touch ➍ to return to the Main menu. • Touch and hold ➍ from any screen to return to the Main menu. • Touch ➎ to change the data field. • Touch ➏ to view the Where Am I? page. nüvi 2575R/ 2575 Quick Start Manual 7 • Touch and drag ➐ to view a different area of the map. • Touch ➑ to view trip information. • Touch ➒ to change the speed limit if the speed limit shown on the map is incorrect. Portable Entertainment nuvi 2575 is not only a GPS navigator. It builds in Analogue TV function, providing you an ultimate recreational experience. You’ll never feel bored on the road. Analogue TV Touch TV at main menu to enter television mode. ➊ ➋ ➌ ➍ ➎ ➏ ➐ ➑ ➒ ➓ ➓ 1. Exit menu: back to navigation page but not stop playing TV 2. Select region: select your current location 3. Mute button: cease volume Touch 3, when showing means mute. Touch 3 again, showing means volume on. 4. Volume down: lower down volume 8 nüvi 2575R/ 2575 Quick Start Manual 5. Volume up: raise volume 6. Channel down 7. Channel up Touch and to change channel 8. TV signal: showing analogue TV signal strength 9. Battery: showing battery power remaining 10. Close TV function: close TV function and back to navigation page 11. Exit to navigation: go back to navigation page About Traffic NOTICE Garmin is not responsible for the accuracy or timeliness of the traffic information. The FM Traffic Message Channel (TMC) traffic subscription is automatically enabled and does not require an additional subscription purchase to activate. The FM TMC traffic receiver is available in retail shops For information about traffic receivers and coverage areas, go to www .garmin.com/traffic. nüvi 2575R/ 2575 Quick Start Manual 9 Manually Avoiding Traffic on Your Route 1. From the map, touch . 2. Touch Traffic On Route. 3.…
