Monterra ™ Quick Start Manual May 2013190-01601-01_0APrinted in Taiwan DRAFT Introduction WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Device Overview  Camera  Microphone  Power key  LED flash  Volume keys  Battery cover D-ring  Waterproof speaker  Headphone port (under weather cap)  Mini-USB port (under weather cap) Battery Information WARNING The temperature rating for the device may exceed the usable range of some batteries. Alkaline batteries can rupture at high temperatures. Do not use a sharp object to remove batteries. CAUTION Contact your local waste disposal department to properly recycle the batteries. NOTICE Alkaline batteries lose a significant amount of their capacity as the temperature decreases. Therefore, use lithium batteries when operating the device in below freezing conditions. 2 DRAFT Installing the Battery Pack WARNING This product contains a lithium-ion battery. To prevent the possibility of personal injury or product damage caused by battery exposure to extreme heat, store the device out of direct sunlight. 1 Turn the D-ring counter-clockwise, and pull up to remove the cover. 2 Locate the metal contacts on the end of the lithium-ion battery. 3 Insert the battery into the compartment, contacts first. 4 Press the battery into place. 5 Replace the battery cover, and turn the D-ring clockwise. Charging the Battery Pack WARNING This product contains a lithium-ion battery. To prevent the possibility of personal injury or product damage caused by battery exposure to extreme heat, store the device out of direct sunlight. NOTICE To prevent corrosion, thoroughly dry the mini-USB port, the weather cap, and the surrounding area before charging or connecting to a computer. Do not attempt to use the device to charge a battery that was not provided by Garmin ® . Attempting to charge a battery that was not provided by Garmin can damage the device and void the warranty. Before you can connect the straight connector of the USB cable to your device, you may have to remove optional mount accessories. NOTE: The battery will not charge when outside the temperature range of 32 to 122°F (0 to 50°C). 3 DRAFT You can charge the battery using a standard wall outlet or a USB port on your computer. 1 Pull up the weather cap  from the mini-USB port  . 2 Plug the small end of the USB cable into the mini-USB port. 3 Plug the USB end of the cable into the AC adapter or a computer USB port. 4 Plug the AC adapter into a standard wall outlet. When you connect the device to a power source, the device turns on. 5 Charge the battery completely. Removing the Battery Pack WARNING Do not use a sharp object to remove batteries. 1 Turn the D-ring counter-clockwise, and pull up to remove the cover. 2 Pull up on the side of the battery pack closest to the power button. Installing AA Batteries Instead of the battery pack (page 3), you can use alkaline, NiMH, or lithium AA batteries. This is useful when you are on the trail and cannot charge the battery pack. Use NiMH or lithium batteries for best results. NOTE: Standard alkaline batteries are not recommended when using the camera feature. 1 Turn the D-ring counter-clockwise, and pull up to remove the cover. 2 Insert three AA batteries, observing polarity. 4 DRAFT 3 Replace the battery cover, and turn the D-ring clockwise. Turning On the Device Select . Setting Up the Device The first time you turn on the device, you must set up basic device settings. You can also set up accounts. 1 Turn on the device. 2 Follow the on-screen instructions. Using the Touchscreen • Drag or swipe your finger across the screen to pan or scroll the screen. • Pinch two fingers together to zoom out. •Spread two fingers to zoom in. • Make each touchscreen selection a separate action. • Select to return to the previous page. • Select to return to the home screen. • Select to view additional options for the page you are viewing. Home Screen  Swipe down to view notifications.  Enter text to start a search.  Swipe left and right to switch pages. Hold to customize shortcuts, widgets, or wallpaper. 5 DRAFT  Hold to drag shortcuts in or out of the dock.  Touch to view all installed apps. Viewing Notifications 1 Swipe down from the top of the screen. The list of notifications appears. 2 Select an option: • To launch the action or app mentioned in the notification, select the notification. • To dismiss a notification, swipe the notification to the right. Enabling GPS For more information about GPS, go to www.garmin.com/aboutGPS. Select Settings > Location services > GPS satellites. Connecting to a Wireless Network 1 Select Settings > Wi-Fi. 2 If necessary, select the toggle switch to turn on Wi-Fi. 3 If necessary, select Scan to scan for available networks. 4 Select a wireless network. 5 If necessary, enter the encryption key. The device connects to the wireless network. The device remembers the network information and connects automatically when you return to this location in the future. Updating the Device Software Before you can update the device software, you must be connected to a wireless network. The device checks for software updates periodically when it is connected to a wireless network. A notification appears when a software update is available. You can also check for updates manually. 1 Select an option: • When a software update notification appears, swipe down from the top of the screen, and select New software update available . • To check for an update manually, select Settings > About Monterra > System updates. 6 DRAFT The device checks for available updates. This may take several minutes. 2 Select Download, and follow the on- screen instructions. Locking and Unlocking the Touchscreen You can lock the screen to prevent inadvertent screen touches. 1 Hold the power key. 2 Select Touch Lock to toggle the screen lock on or off. Waypoints Waypoints are locations you record and st…
