A02557 Quick Start Manual DRAFT Getting Started WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Keys À LIGHT Select to turn the backlight on and off. Hold to turn the device on and off. Á START STOP Select to start or stop an activity. Select to choose an option in a menu. 2 DRAFT Â BACK Select to return to the previous page. Select to record during an activity. Ã DOWN Select to scroll through the data pages, options, messages, and settings. Select to read a long message or notification. Ä UP MENU Select to scroll through the data pages, options, messages, and settings. Select to dismiss a short message or notification. Hold to view the main menu. Charging the Device NOTICE To prevent corrosion, thoroughly dry the contacts and the surrounding area before charging or connecting to a computer. Getting Started3 DRAFT The device is powered by a built-in lithium-ion battery that you can charge using a standard wall outlet or a USB port on your computer. 1 Plug the USB end of the cable into the AC adapter or a computer USB port. 2 Plug the AC adapter into a standard wall outlet. 3 Use the sides of the charging cradle 4 With the contacts aligned, place the device into the cradle hold the device in place. When you connect the device to a power source, the device turns on, and 4 DRAFT the battery charge level appears on the screen. 5 Charge the device completely. Pairing with Your Device To access the full features of your device, you must connect it to your device. 1 Go to www.garmin.com /apps. . 2 Bring your device within 10 m (33 ft.) of your device. 3 On the device, hold MENU. 4 Select Settings > . 5 Select an action: • If this is the first time you have paired with your device, select OK. • If you have already paired with your device, select Pair Device. 6 Open the Garmin Connect Mobile app. Getting Started5 DRAFT 7 Select an option to add your device to your Garmin Connect account: • If this is the first device you have paired with the Garmin app, follow the on-screen instructions. • If you have already paired another device with the Garmin app, select > , and follow the on-screen instructions. Sensors Your device can be used with wireless sensors. For more information about compatibility and purchasing optional sensors, go to http://buy.garmin.com. 6 DRAFT . Getting the Owner's Manual You can get the latest owner's manual from the web. 1 Go to www.garmin.com /manuals. 2 View or download the full owner's manual in your preferred format. Downloadable Features You can download features such as apps and widgets from Garmin ® and other providers using the Garmin app. Widgets Your device comes preloaded with widgets that provide at-a- glance information. Some require connection to a compatible device. Notifications: Alerts you according to your notification settings. Calendar: Displays c alendar. Downloadable Features7 DRAFT Tracking: Tracks Sensor Information: Displays information from an internal sensor or a connected sensor. Compass: Displays an electronic compass. Viewing Widgets From the display, select UP or DOWN. Activities Your device can be used for activities. When you start an activity, the device displays and records sensor data. You can save activities and share them with the Garmin Connect community. Starting an Activity When you start an activity, sensors turn on automatically (if required). When you stop the activity, the device returns to normal mode. 1 Select START. 2 Select an activity. 8 DRAFT 3 If necessary, follow the on-screen instructions to enter additional information. 4 If necessary, wait while the device connects to your sensors. 5 If the activity requires go outside, and wait . 6 Select START to start the timer. NOTE: The device does not record your activity data until you start the timer. Stopping an Activity NOTE: Some options are not available for some activities. 1 Select STOP. 2 Select an option: • To reset your activity, select Reset . This resets the timer and clears all recorded data since you started the activity. • To record select . • To follow your track back to the starting Activities9 DRAFT point of your activity, select TracBack. • To resume your activity, select Resume. • To save the activity and return to low- power mode, select Save. • To discard the activity and return to low- power mode, select Discard . • To suspend your activity and resume at a later time, select Resume Later. Temperature Specifications operating temperature range: From -20º to 60ºC (from -4º to 140ºF) charging temperature range: From 5º to 40ºC (from 41º to 104ºF) sensor operating temperature range: From -5° to 50°C (from 23° to 122°F) 10 DRAFT DRAFT Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. ANT+ ® , BaseCamp™, fēnix™ , Garmin Connect ™, and TracBack ® are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. The Bluetooth ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Other trademarks and trade names are those of their respective owners. © 2014 Garmin Ltd. or its subsidiaries Printed in Taiwan www.garmin.com/support October 2014 190-01840-01_0A DRAFT

Important Safety and Product Information..................................................................... 2 Informations importantes sur le produit et la sécurité.................................................... 9 Información importante sobre el producto y tu seguridad........................................... 17 Informações importantes de segurança e do produto................................................. 24 Important Safety and Product Information WARNING Failure to avoid the following potentially hazardous situations could result in an accident or collision resulting in death or serious injury. Health Warnings • Always consult your physician before beginning or modifying any exercise program. If you have a pacemaker or other implanted electronic device, consult your physician before using a heart rate monitor. • The device, the heart rate monitor, and other Garmin ® accessories are consumer devices, not medical devices, and could suffer from interference from external electrical sources. The heart rate readings are for reference only, and no responsibility is accepted for the consequences of any erroneous readings. Navigation Warnings If your Garmin device uses or accepts mapping products, follow these guidelines to ensure safe navigating. • Always carefully compare information displayed on the device to all available navigation sources, including information from visual sightings, local waterway rules and restrictions, and maps. For safety, always resolve any discrepancies or questions before continuing navigation, and defer to posed signs and conditions. • Use this device only as a navigational aid. Do not attempt to use the device for any purpose requiring precise measurement of direction, distance, location, or topography. Off-Road Navigation Warnings If your Garmin device is able to suggest off-road routes for various outdoor activities, such as biking, hiking, and all- terrain vehicles, follow these guidelines to ensure safe off-road navigation. • Always use your best judgment and exercise common sense when making off-road navigational decisions. The 2 Garmin device is designed to provide route suggestions only. It is not a replacement for attentiveness and proper preparation for outdoor activities. Do not follow the route suggestions if they suggest an illegal course or would put you in an unsafe situation. • Always carefully compare information displayed on the device to all available navigation sources, including trail signs, trail conditions, weather conditions, and other factors that may affect safety while navigating. For safety, always resolve any discrepancies before continuing navigation, and defer to posted signs and conditions. • Always be mindful of the effects of the environment and the inherent risks of the activity before embarking on off- road activities, especially the impact that weather and weather-related trail conditions can have on the safety of your activity. Ensure that you have the proper gear and supplies for your activity before navigating along unfamiliar paths and trails. Battery Warnings A lithium-ion battery can be used in this device. Coin cell batteries can be used in the accessory. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury. • Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun in an unattended vehicle. To prevent the possibility of damage, remove the device from the vehicle or store it out of direct sunlight, such as in the glove box. • Do not disassemble, modify, remanufacture, puncture or damage the device or batteries. • Do not immerse or expose the device or batteries to water or other liquids, fire, explosion, or other hazard. • Do not use a sharp object to remove the removable batteries. 3 • Keep batteries away from children. • Never put batteries in mouth. If swallowed, contact a physician or poison control center. • Replaceable coin cell batteries may contain perchlorate material. Special handling may apply. See www.dtsc.ca.gov/hazardouswaste /perchlorate. • Do not use a power and/or data cable that is not approved or supplied by Garmin. • If using an external battery charger, only use the Garmin accessory approved for your product. • Only replace batteries with correct replacement batteries. Using other batteries presents a risk of fire or explosion. To purchase replacement batteries, see your Garmin dealer or the Garmin website. • Do not operate the device outside of the temperature ranges specified in the printed manual in the product packaging. • When storing the device for an extended time period, store within the temperature ranges specified in the printed manual in the product packaging. • Do not remove or attempt to remove the non-user-replaceable battery. • Contact your local waste disposal department to dispose of the device/ batteries in accordance with applicable local laws and regulations. Product Environmental Programs Information about the Garmin product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at www.garmin.com /aboutGarmin/environment. Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. To view the full Declaration of Conformity, go to www.garmin.com/compliance. Industry Canada Compliance Category I radiocommunication devices comply with Industry Canada Standard RSS-210. Category II radiocommunication devices comply with 4 Industry Canada Standard RSS-Gen. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Radio Frequenc…

Text truncated - open the document above for the full version.

Radio Frequency Radiation Exposure This device is a mobile transmitter and receiver that uses an internal antenna to send and receive low levels of radio frequency (RF) energy for data communications. The device emits RF energy below the published limits when operating in its maximum output power mode and when used with Garmin authorized accessories. To comply with RF exposure compliance requirements, the device should be used as described in the manual. The device should not be used in other configurations. This device must not be co-located or operated in conjunction with any other transmitter or antenna. Exposition aux rayonnements à fréquence radioélectrique Cet appareil est un transmetteur/récepteur mobile qui utilise une antenne interne pour envoyer et recevoir des champs de radiofréquences de faible puissance lors des communications de données. Les champs de radiofréquences émis par l’appareil lorsqu’il fonctionne au maximum de sa puissance et qu’il est utilisé avec des accessoires approuvés par Garmin ne dépassent pas les limites fixées par la réglementation. Pour être conforme aux exigences d’exposition aux radiofréquences, l’appareil doit être utilisé conformément aux instructions du manuel. L’appareil ne doit être utilisé dans aucune autre configuration. Cet appareil ne doit pas être placé ou utilisé en conjonction avec d’autres antennes ou émetteurs. SAR_Insert_not_sep.indd 19/13/2013 3:57:03 PM © 2013 Garmin Ltd. or its subsidiaries Garmin International, Inc. 1200 East 151 st Street, Olathe, Kansas 66062, USA Garmin (Europe) Ltd. Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK Garmin Corporation No. 68, Zhangshu 2 nd Road, Xizhi Dist., New Taipei City, 221, Taiwan (R.O.C.) www.garmin.com September 2013 190-01678-00_0A Printed in Taiwan SAR_Insert_not_sep.indd 29/13/2013 3:57:03 PM
