IPH-03754Low Power Transmitter

Garmin International Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 12, 2020
Application Purpose: Original Equipment
Date of Application: Mar 12, 2020
Equipment Note: Low Power Transmitter
Frequency Range: 2402.00000000 - 2480.00000000
Company: Garmin International Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Important Safety and Product Information2 Informations importantes sur le produit et la sécurité5 guida Informazioni importanti sulla sicurezza e sul prodotto7 Wichtige Sicherheits- und Produktinformationen10 Información importante sobre el producto y tu seguridad12 Informações importantes sobre segurança e sobre o produto15 Belangrijke veiligheids- en productinformatie17 Vigtige produkt- og sikkerhedinformationer19 Tärkeitä turvallisuus- ja tuotetietoja21 Viktig sikkerhets- og produktinformasjon23 Guiden Viktig säkerhets- och produktinformation25 Правила техники безопасности и сведения об изделии27 Important Safety and Product Information WARNING Failure to heed the following warnings could result in death or serious injury. Battery Warnings A lithium-ion battery is used in this device. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury. • Do not disassemble, modify, remanufacture, puncture or damage the device or batteries. • Do not expose the device or batteries to fire, explosion, or other hazard. Device Warnings • Do not leave the device exposed to a heat source or in a high- temperature location, such as in the sun in an unattended vehicle. To prevent the possibility of damage, remove the device from the vehicle or store it out of direct sunlight, such as in the glove box. • Do not operate the device outside of the following temperature range: from -20° to 55°C (from -4° to 131°F). • When storing the device for an extended time period, store within the following temperature range: from 0° to 25°C (from 32° to 77°F). • Do not use a power cable, data cable and/or power adapter that is not approved or supplied by Garmin ® . CAUTION Failure to heed the following cautions could result in minor or moderate injury. Casting To avoid injury, always be cautious of your surroundings when casting the device. NOTICE Failure to heed the following notice could result in personal or property damage, or negatively impact the device functionality. Battery Notice Contact your local waste disposal department to dispose of the device/batteries in accordance with applicable local laws and regulations. GPS Notice The navigation device may experience degraded performance if you use it in proximity to any device that uses a terrestrial broadband network operating close to the frequencies used by any Global Navigation Satellite System (GNSS), such as the Global Positioning Service (GPS). Use of such devices may impair reception of GNSS signals. Lost Devices Garmin is not responsible for lost devices. Product Environmental Programs Information about the Garmin product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at www.garmin.com/aboutGarmin/environment. Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.garmin.com/compliance. FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This product does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and void your warranty and your authority to operate this device under Part 15 regulations. 2 EN Innovation, Science and Economic Development Canada Compliance This device complies with Innovation, Science and Economic Development Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Radio Frequency Radiation Exposure This device is a mobile transmitter and receiver that uses an internal antenna to send and receive low levels of radio frequency (RF) energy for data communications. The device emits RF energy below the published limits when operating in its maximum output power mode and when used with Garmin authorized accessories. To comply with RF exposure compliance requirements, the device should be used as described in the manual. The device should not be used in other configurations. This device must not be co-located or operated in conjunction with any other transmitter or antenna. Software License Agreement BY USING THE DEVICE, YOU AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THE FOLLOWING SOFTWARE LICENSE AGREEMENT. PLEASE READ THIS AGREEMENT CAREFULLY. Garmin Ltd. and its subsidiaries (“Garmin”) …

Text truncated - open the document above for the full version.

Users Manual

STRIKER ™ CAST Quick Start Manual Getting Started Getting the Owner's Manual Go to garmin.com/manuals /STRIKERcast. Charging the Device WARNING This device contains a lithium-ion battery. See the Important Safety and Product Information guide in the product box for product warnings and other important information. NOTICE To prevent corrosion, thoroughly clean and dry the contacts and the surrounding area before charging or connecting to a computer. Refer to the cleaning instructions (page 7). 1 Plug the small end of the USB cable into the charging port on your device. 2 Plug the large end of the USB cable into a USB charging port. The status LED flashes red when the device is charging. 3 Charge the device completely. The status LED and the device turn off when the device is fully charged. Automatic On and Off The device turns on automatically when you put it in the water. The device also turns on automatically when you connect it to USB power. The device stays on as long as it is in the water, which can be helpful for finding lost devices. The device also stays on as long as the app is connected. 2Quick Start Manual The STRIKER Cast app disconnects from the device after about one minute of inactivity (being in the background). The device turns off automatically after 2 minutes of being disconnected from the app and out of the water. Connecting a Mobile Device You must connect the STRIKER Cast device to the STRIKER Cast app on your mobile device to see sonar data. TIP: The status LED flashes green and red when the device is ready to connect to the STRIKER Cast app. 1 From the app store on your mobile device, install and open the STRIKER Cast app. 2 Sign in to your Garmin ® account. TIP: If you do not have an account, select Create One. 3 Put the device in water, with the two pins in contact with the water, to turn on the STRIKER Cast device and prepare it to connect. TIP: You can also connect the device to USB power and then immediately disconnect it to turn on the device and prepare it to connect. The status LED flashes green and red when the device is ready to connect to the STRIKER Cast app. 4 Select Connect > Start. 5 Select your device from the list. The serial number is printed on the bottom of the device. After you connect successfully, a message appears, and you can see sonar data when the device is in the water. Attaching a Fishing Line or Tether You can use the included nylon tether or attach the device to a fishing line on a fishing rod. Quick Start Manual3 • Attach the included nylon tether to the device. • Attach a 20-lb. test or higher fishing line to the device using a #3 barrel swivel with a snap, on a medium- action or heavier fishing rod. Fishing with the STRIKER Cast Device CAUTION To avoid injury, always be cautious of your surroundings when casting the device. NOTICE Garmin is not responsible for lost devices. Only tow the device behind a vessel moving at a slow trolling speed moving slower than 8 km/h (5 mph). To prevent corrosion, do not store the device in water, and thoroughly dry the device after use. You can fish with the device in various ways. • Cast and leave the device on a dedicated fishing rod so that you can continually change the device location. NOTE: Repeatedly casting the device as you fish provides a clearer picture of what is below the surface. This is the recommended mode of use. • Cast and tie off the device using the included tether. • Tether the device behind a small vessel, such as a kayak. 4Quick Start Manual Sonar Screen Depth Water temperature Water surface Fish Depth indicator as the sonar data screen scrolls from right to left Structure Mapping a Body of Water Using the Garmin Quickdraw ™ Contours Feature Before you can generate a map using the Garmin Quickdraw Contours feature, you must have sonar depth and GPS position data. You can only record Garmin Quickdraw Contours mapping only using models that have GPS. If your device does not have GPS, you cannot record contours, but you can download community contours. 1 From the STRIKER Cast app, select Chart. 2 Select > Record. As you fish with the STRIKER Cast device, a map is generated. A green circle indicates good depth, GPS position, and a good speed. A yellow circle indicates good depth and GPS position, but the speed is a little too fast. A red circle indicates poor depth information, poor GPS position, or a speed that is too fast. When recording is complete, select > Record to stop recording. Downloading Garmin Quickdraw Community Maps You can download Garmin Quickdraw Contours maps that other users have created and shared with the Garmin Quickdraw Community. 1 From the STRIKER Cast app on your mobile device, select Chart > > Quick Start Manual5 Quickdraw > Download from Community. 2 Use the map and search features to locate an area to download. The red dots represent Garmin Quickdraw Contours maps that have been shared for that area. 3 Tap the map to select an area. 4 Drag the box to move the download area, if necessary. 5 Drag the corners to change the download area, if necessary. 6 Select Download Area. You can now view depth information in the downloaded area on the Chart page. Marking a Waypoint on the Chart 1 Select a location on the chart. 2 From the Radial menu, select to save the location as a waypoint. Device Information Specifications Battery typeRechargeable, built-in lithium-ion battery Battery life10 hr. typical use Battery charge timeApproximately 1.5 hr. Power adapter (not included in the box, recommended) 5.5 V, 1.0 A. Standard USB wall outlet, computer port, or vehicle charger. Included tether length 5 m (16 ft.) Water ratingFloatable, IEC 60529 IPX7 1 Weight70 g (2.5 oz.) Operating temperature range From -20° to 60°C (from -4° to 140°F) Charging temperature range From 0° to 45°C (from 32° to 113°F) Compass-safe distance 2.54 cm (1 in.) Wireless frequency2.4 GHz @ 9.65 dBm Wireless range60 m (200 ft.) 2 Sonar frequency260/455 kHz Sonar depth rangeFrom less than 0.6 m …

Text truncated - open the document above for the full version.

Cover Letter(s)

Page 1 of 2 February 26, 2020 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID: IPH-03754 Product: Transmitter operated under 47CFR Section 15C Dear Sirs: Garmin International, Inc. requests that the material in the Block Diagram, Operational Description, Schematics, and Tune up Procedure be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES A03754 Conf BlkDia.pdf A03754 Conf OpDes.pdf A03754 Conf Schem.pdf A03754 Conf TunPro.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Block Diagram, Operational Description, Schematics, and Tune up Procedure which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID: IPH-03754 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed Block Diagram, Operational Description, Schematics, and Tune up Procedure. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry the protection sought is narrowly drawn as provided in regulations. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Cover Letter(s)

March 5, 2020 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Short-term Confidentiality request for submittal information regarding FCC ID: IPH-03754 FCC Rules: Parts 2 and 15C Dear Sirs: Garmin International, Inc. requests that the following information be withheld from public disclosure pursuant to CFR47 paragraphs 0.457 and 0.459, and KDB 726920 until 180 days after the Grant of Equipment Authorization. Disclosure of information would offer competitors additional unwarranted insight into the state of the product development. Short-term confidential files File A03754 Short Term Conf ExtPho.pdf A03754 Short Term Conf IntPho.pdf A03754 Short Term Conf TSup.pdf A03754 Short Term Conf UsrMan.pdf A03754 Short Term Conf UsrMan 1.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 +1 913 837-3214

External Photos

ID Label/Location Info

M/N: 03754 FCC ID: IPH-03754 SN: XXXXXXXXX Bottom of unit: IC: 1792A-03754

Internal Photos

RF Exposure Info

Rogers Labs, Inc. Garmin International, Inc. SN’s: 3986442368 / 3986442344 4405 West 259 th Terrace Model: 03754 FCC ID: IPH-03754 Louisburg, KS 66053 Test: 190318 IC: 1792A-03754 Phone/Fax: (913) 837-3214 Test to: CFR47 15C, RSS-Gen RSS-247 Date: March 4, 2020 Revision 1 File: 03754 RF Exemption Page 1 of 1 Model: 03754 Test Number: 190318 MPE Calculator RF Exposure uses EIRP for calculation. EIRP is based on TX power added to the antenna gain in dBi. dBi = dB gain compared to an isotropic radiator. S = power density in mW/cm^2 Transmitter Output power (dBm) 7.60 Transmitter Output power (mW) 5.75 Transmitter maximum Output power operating at 100% (Watts) 0.006 Antenna Gain (dBi) 1 Output Power for 100% duty Cycle operation (Watts) 0.006 Antenna Gain (Numeric) 1.26 Tx Frequency (MHz) 2442 Calcualtion power (Watts) 0.006 dBd + 2.17 = dBi dBi to dBd 2.2 Antenna Gain (dBd) -1.17 Cable Loss (dB) 0.0 Adjusted Power (dBm) 7.6 Antenna minus cable (dBi) 1.00 Calculated ERP (mw) 4.395 EIRP = Po(dBM) + Gain (dB) Calculated EIRP (mw) 7.244 Radiated (EIRP) dBm 8.600 ERP = EIRP - 2.17 dB Radiated (ERP) dBm 6.430 Occupational Limit f/300 mW/cm 2 Frequency (MHz) Occupational Limit (mW/cm 2 ) Public Limit (mW/cm 2 ) 81.4 W/m 2 30-300 1 0.2 General Public Limit 300-1,500 f/300 f/1500 f/1500 mW/cm 2 1,500-10,000 5 1 16.3 W/m 2 Occupational Limit 0.6455ƒ 0.5 W/m 2 39.7 W/m 2 Frequency (MHz) Occupational Limit (W/m 2 ) Public Limit (W/m 2 ) General Public Limit 100-6,000 0.6455ƒ 0.5 0.02619ƒ 0.6834 W/m 2 6,000-15,000 50 5.4 W/m 2 48-300 1.291 300-6,000 0.02619ƒ 0.6834 6,000-15,000 50 10 f = Transmit Frequecny (MHz) f (MHz) = 2442 P T = Power Input to Antenna (mW) P T (mW) = 5.7544 Duty cycle (percentage of operation) % = 100 P A = Adjusted Power due to Duty cycle or Cable Loss (mW) P A (mW) = 5.75 G N = Numeric Gain of the Antenna GN (numeric) = 1.26 S 20 = Power Density of device at 20cm (mW/m 2 ) S 20 =(P A G N )/(4πR 20 ) 2 S 20 (mW/m 2 ) = 0.00 S 20 = Power Density of device at 20cm (W/m 2 ) S 20 =(P A G N )/(4πR 20 ) 2 S 20 (W/m 2 ) = 0.01 S L = Power Density Limit (W/m 2 ) S L (W/m 2 )= 5.412 R C = Minimum distance to the Radiating Element for Compliance (cm) R C =√ (P A G N /4π S L ) R C (cm) = 1.0 S C = Power Density of the device at the Compliance Distance R C (W/m 2 ) S C =(P A G N )/(4πR C ) 2 S C (W/m 2 ) = 5.41 R 20 = 20cm R20= 20 For Complaince with Canada General Population Limits, User Manual must indicate a minimum seperation distance of 1.0 cm Or in Meters for Complaince with Canada General Population Limits, a minimum seperation distance of 0.010 Meters FCC radio frequency radiation exposure limits per 1.1310 IC radio frequency radiation exposure limits per RSS-102 EIRP Power density (S) mW/cm 2 = ------- 4 p r^2 r (cm) EIRP (mW)

Test Report

Testing NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN’s: 3986442368 / 3986442344 4405 West 259 th Terrace Model: 03754 FCC ID: IPH-03754 Louisburg, KS 66053 Test: 190318 IC: 1792A-03754 Phone/Fax: (913) 837-3214 Test to: CFR47 15C, RSS-Gen RSS-247 Date: March 3, 2020 Revision 2 File: 03754 DTS TstRpt 190318 r2 Page 1 of 40 Application For Grant of Certification FOR Model: 03754 2402-2480 MHz (DTS) Broadband Digital Transmission System FCC ID: IPH-03754 IC: 1792A-03754 FOR Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 FCC Designation: US5305 IC Test Site Registration: US0096 Test Report Number: 190318 Authorized Signatory: Scot D. Rogers Testing NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN’s: 3986442368 / 3986442344 4405 West 259 th Terrace Model: 03754 FCC ID: IPH-03754 Louisburg, KS 66053 Test: 190318 IC: 1792A-03754 Phone/Fax: (913) 837-3214 Test to: CFR47 15C, RSS-Gen RSS-247 Date: March 3, 2020 Revision 2 File: 03754 DTS TstRpt 190318 r2 Page 2 of 40 Engineering Test Report For Grant of Certification Application FOR 47 CFR, PART 15C - Intentional Radiators 47 CFR Paragraph 15.247 and Industry Canada RSS-GEN and RSS-247 License Exempt Intentional Radiator For Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Digital Transmission System Model: 03754 Frequency Range 2402-2480 MHz FCC ID: IPH-03754 IC: 1792A-03754 Test Date: March 18, 2019 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 Testing NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN’s: 3986442368 / 3986442344 4405 West 259 th Terrace Model: 03754 FCC ID: IPH-03754 Louisburg, KS 66053 Test: 190318 IC: 1792A-03754 Phone/Fax: (913) 837-3214 Test to: CFR47 15C, RSS-Gen RSS-247 Date: March 3, 2020 Revision 2 File: 03754 DTS TstRpt 190318 r2 Page 3 of 40 Tabl e of Cont ents TABLE OF CONTENTS .................................................................................................. 3 REVISIONS ..................................................................................................................... 5 FOREWORD ................................................................................................................... 6 OPINION / INTERPRETATION OF RESULTS ............................................................... 6 EQUIPMENT TESTED .................................................................................................... 9 Equipment Function and Configuration .......................................................................................................... 10 Equipment Configuration.................................................................................................................................. 11 APPLICATION FOR CERTIFICATION ......................................................................... 12 APPLICABLE STANDARDS & TEST PROCEDURES ................................................ 13 TESTING PROCEDURES ............................................................................................ 13 AC Line Conducted Emission Test Procedure ................................................................................................ 13 Radiated Emission Test Procedure ................................................................................................................... 13 Antenna Port Conducted Emission Test Procedure ........................................................................................ 14 Diagram 1 Test arrangement for Conducted emissions ..................................................................................... 15 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 16 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 17 Diagram 4 Test arrangement for Antenna Port Conducted emissions ............................................................... 18 TEST SITE LOCATIONS .............................................................................................. 18 LIST OF TEST EQUIPMENT ........................................................................................ 19 UNITS OF MEASUREMENTS ...................................................................................... 20 ENVIRONMENTAL CONDITIONS................................................................................ 20 STATEMENT OF MODIFICATIONS AND DEVIATIONS ............................................. 20 INTENTIONAL RADIATORS ........................................................................................ 20 Antenna Requirements ...................................................................................................................................... 20 Testing NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN’s: 3986442368 / 3986442344 4405 West 259 th Terrace Model: 03754 FCC ID: IPH-03754 Louisburg, KS 66053 Test: 190318 IC: 1792A-03754 Phone/Fax: (913) 837-3214 Test to: CFR47 15C, RSS-Gen RSS-247 Date: March 3, 2020 Revision 2 File: 03754 DTS TstRpt 190318 r2 Page 4 of 40 Restricted Bands of Operation .......................................................................................................................... 21 Table 1 Harmonic Radiated Emissions in Restricted Bands Data ..................................................................... 21 Summary of Results for Radiated Emissions in Restricted Bands .......…
