IPH-03942Marine Stereo

CONFIDENTIAL This drawing and the specifications contained herein are the property of GARMIN Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. Garmin Ltd. or its subsidiaries C/O Garmin International, Inc. 1200 E. 151 st Street Olathe, Kansas 66062 USA S heet 1 of 1 Specification Control Document Drawing Number: 190-02848-90 Description: Fusion RA60 Quick Start Manual (ML) Revision: A Drawn By: MKD 03/31/21 R evision History Rev. Date Description of Change ECO No. A 03/31/21 Production Release ---- P rinting Specifications Tolerance: ±0.0787" (±2 mm) Material: 80-lb matte-finish offset. Approved equivalents allowed. Color: Black Ink Bindery: Saddle-Stitched. Approved equivalents allowed. Folds: Not applicable Trimmed Dimensions: 9.5 x 4.75 in. Finished Dimensions: 4.75 x 4.75 in. Notes: Content Management System (CMS) Details GUID: GUID-E4E0160F-92F8-4E32-BF9E-BB73C5223BD7 Version: 1 P rinted Languages EN-US, FR-FR, IT-IT, DE-DE, ES-XM, PT-BR, NL-NL, DA-DK, FI-FI, NB-NO, SV-SE, ZH-TW Notes ® F U S I O N E N T E R T A I N M E N T . C O M FUSION ® MS-RA60 Quick Start Manual 2 8 15 21 28 34 40 47 52 58 63 Quick Start Manual Manuel de démarrage rapide Manuale di avvio rapido Schnellstartanleitung Guía de inicio rápido Manual de início rápido Snelstartgids Lynstartvejledning Aloitusopas Hurtigstartveiledning Snabbstartshandbok 快速入門手冊 69 Fusion ® MS-RA60 Quick Start Manual Getting Started WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Stereo Controls Dial Turn to adjust the volume. Press to switch between zones to control the volume. Turn to move through the menus or adjust a setting. Press to select the highlighted option. Press to open a menu. Press to return to the previous screen or menu. Press to change the source. Press repeatedly to scroll through the available sources. Press to turn on the stereo. Press to mute and un-mute the stereo. Press and hold to turn off the stereo. BT source: Press to skip to the previous track or the beginning of the current track. AM or FM source: • Press to tune to the previous station or preset (preset mode with two or more presets saved). • Press and hold for faster tuning (manual mode only). DAB source: Press to return to the previous DAB station in the ensemble. When you reach the beginning of the current ensemble, the stereo automati- cally changes to the last available station in the previous ensemble. On the AUX source, select to decrease the gain for the connected source. BT source: Press to pause or resume. AM or FM source: • Press to cycle through the tuning modes (auto or manual) and presets (when two or more presets are saved). 2Quick Start Manual • Press and hold to save this station as a preset. DAB source: press to scan for DAB stations. BT source: Press to skip to the next track. AM or FM source: • Press to tune to the next station or preset (preset mode with two or more presets saved). • Press and hold for faster tuning (manual mode only). DAB source: press to advance to the next DAB station in the ensemble. When you reach the end of the current ensemble, the stereo automatically changes to the first available station in the next ensemble. On the AUX source, press to increase the gain for the connected source. Using the Dial to Select Items You can use the dial to highlight and select items on the screen. • Turn the dial to highlight an item on the screen. • Press the dial to select the highlighted option. Adjusting the Volume 1Turn the dial to adjust the volume for a zone or all zones on the stereo. 2If necessary, press the dial to switch between zones. TIP: You can press and hold the dial to adjust the subwoofer level. Stereo Screen The information displayed on the stereo screen varies depending on the source selected. This example shows the stereo playing a track on a device connected using Bluetooth ® wireless technology. Source Play status icon Track details (if available) Elapsed time Quick Start Manual3 Current track number out of total number of tracks in the playlist (if available) Track duration (if available) Playing Media Connecting a Compatible Bluetooth Device You can play media from a compatible Bluetooth device using the Bluetooth wireless connection. 1Select the Bluetooth source. 2Select > DISCOVERABLE to make the stereo visible to your compatible Bluetooth device. 3Enable Bluetooth on your compatible Bluetooth device. 4Bring the compatible Bluetooth device within 10 m (33 ft.) of the stereo. 5On your compatible Bluetooth device, search for Bluetooth devices. 6On your compatible Bluetooth device, select the MS-RA60 stereo from the list of detected devices. 7On your compatible Bluetooth device, follow the on-screen instructions to pair and connect to the discovered stereo. When pairing, your compatible Bluetooth device may ask you to confirm a code on the stereo. The stereo does not display a code, but it does connect correctly when you confirm the message on the Bluetooth device. 8If your compatible Bluetooth device does not immediately connect to the stereo, repeat steps 1 through 7. NOTE: The DISCOVERABLE setting is automatically disabled after two minutes. Setting the Tuner Region You must select the region you are in to receive AM and FM stations properly. You must select the region you are in to receive DAB stations properly. NOTE: DAB stations are not available in all regions. 1Select > SETTINGS. 2Select TUNER REGION. 3Select the region you are in. Changing the Radio Station 1Select an applicable source, such as FM. 2Select repeatedly to move through the tuning modes, and select an option: • Select AUTO to scan and stop on the next available station. 4Quick Start Manual • Select MANUAL to select a station manually. • Select PRESET to select a saved station preset. 3Select or to tune to the station. When in MANUAL tuning mode, y…

Text truncated - open the document above for the full version.

CONFIDENTIAL This drawing and the specifications contained herein are the property of GARMIN Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. Garmin Ltd. or its subsidiaries C/O Garmin International, Inc. 1200 E. 151 st Street Olathe, Kansas 66062 USA Sheet 1 of 1 Specification Control Document Drawing Number: 190-00720-5G Description: ISPI Marine Fusion FCC-SAR Taiwan 1-year 4.75x4.75 (ML) Revision: A Drawn By: MKD 03/31/21 Revision History Rev. Date Description of Change ECO No. A 03/31/21 Production Release ---- Printing Specifications Tolerance: ±0.0787" (±2 mm) Material: 60-lb woodfree. Approved equivalents allowed. Color: Black ink. Bindery: Saddle-stitched. Approved equivalents allowed. Folds: Not applicable. Trimmed Dimensions: 9.5 x 4.75 in. Finished Dimensions: 4.75 x 4.75 in. Notes: Content Management System (CMS) Details GUID: GUID-190CB356-DF6F-49C3-A1BC-FA2AB740BF24 Version: 5 Printed Languages EN-US, FR-FR, IT-IT, DE-DE, ES-XM, PT-BR, DA-DK, NL-NL, FI-FI, NB-NO, SV-SE, ZH-CN Notes IMPORTANT SAFETY AND PRODUCT INFORMATION Important Safety and Product Information3 Informations importantes sur le produit et la sécurité6 guida Informazioni importanti sulla sicurezza e sul prodotto8 Wichtige Sicherheits- und Produktinformationen10 Información importante sobre el producto y tu seguridad12 Informações importantes sobre segurança e sobre o produto14 Vigtige produkt- og sikkerhedinformationer15 Belangrijke veiligheids- en productinformatie17 Tärkeitä turvallisuus- ja tuotetietoja18 Viktig sikkerhets- og produktinformasjon20 Guiden Viktig säkerhets- och produktinformation21 重要安全和产品信息23 Important Safety and Product Information WARNING Failure to heed the following warnings could result in an accident resulting in death or serious injury. Device Warnings • Do not immerse the device or batteries in water or other liquids. • Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun in an unattended vessel. To prevent the possibility of damage, remove the device from the vessel or store it out of direct sunlight. Marine Operation Warnings •You are responsible for the safe and prudent operation of your vessel. This device does not relieve you from the responsibility of safely operating your vessel. Avoid navigational hazards and never leave the helm unattended. • Always be prepared to promptly regain control of the vessel. Use caution near hazards in the water, such as docks, pilings and other vessels. Hearing Damage Warning Listening to the stereo at high volume can cause damage to your hearing. Product Environmental Programs Information about the Garmin ® product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at www.garmin.com/aboutGarmin/environment. Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.fusionentertainment.com. UK Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the relevant statutory requirements. The full text of the declaration of conformity is available at the following internet address: www.fusionentertainment.com. Innovation, Science and Economic Development Canada Compliance This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Radio Frequency Radiation Exposure This device is a mobile transmitter and receiver that uses an internal antenna to send and receive low levels of radio frequency (RF) energy for data communications. The device emits RF energy below the published limits when operating in its maximum output power mode and when used with Garmin authorized accessories. To comply with RF exposure compliance requirements, the device should be installed and operated with a minimum of 20 cm (7.87 in.) between the device and your body. The device should not be used in other configurations. This device must not be co-located or operated in conjunction with any other transmitter or antenna. FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This product does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service center. Unauthorized r…

Text truncated - open the document above for the full version.

Date: March 29, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: IPH-03942 To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 1-May 2021. ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Applicant’s company name : International Certification Corp. Applicant’s company address : No.3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., Tao Yuan City 333, Taiwan (R.O.C.) Signature : Job Title and Dept. : Manager E-mail : [email protected] Tel. : 886-3-271-8628

Project No.: 0O2701 Page No. : 1 of 18 Photographs of EUT Project No.: 0O2701 Page No. : 2 of 18 Project No.: 0O2701 Page No. : 3 of 18 Project No.: 0O2701 Page No. : 4 of 18 Project No.: 0O2701 Page No. : 5 of 18 Project No.: 0O2701 Page No. : 6 of 18 Project No.: 0O2701 Page No. : 7 of 18 Project No.: 0O2701 Page No. : 8 of 18

FCC ID: IPH-03942 IC: 1792A-03942

Project No.: 0O2701 Page No. : 9 of 18 Project No.: 0O2701 Page No. : 10 of 18 Project No.: 0O2701 Page No. : 11 of 18 Project No.: 0O2701 Page No. : 12 of 18 Project No.: 0O2701 Page No. : 13 of 18 Project No.: 0O2701 Page No. : 14 of 18 Project No.: 0O2701 Page No. : 15 of 18 Project No.: 0O2701 Page No. : 16 of 18 Project No.: 0O2701 Page No. : 17 of 18 Project No.: 0O2701 Page No. : 18 of 18

Report No.: FA0O2701 Page : 1 of 6 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : IPH-03942 Equipment : Marine Stereo Model No. : A03942 Brand Name : FUSION Applicant : Garmin International, Inc. Address : 1200 E. 151st Street Olathe, KS 66062 United States Standard : 47 CFR FCC Part 2.1091 Received Date : Oct. 27, 2020 Tested Date : Nov. 04 ~ Nov. 12, 2020 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA0O2701 Page : 2 of 6 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 4 1.5 MPE EVALUATION RESULTS .............................................................................................................. 5 2 TEST LABORATORY INFORMATION ................................................................................................. 6 Report No.: FA0O2701 Page : 3 of 6 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA0O2701 Rev. 01 Initial issue Mar. 17, 2021 Report No.: FA0O2701 Page : 4 of 6 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 * * 4 R Pi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2) Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA0O2701 Page : 5 of 6 Report Version: Rev. 01 1.5 MPE EVALUATION RESULTS Frequency Range (MHz) Maximum Conducte d Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Ratio* Pass / Fail 2402~2480 10.82 11 1.72 20 0.004 1 0.004 Pass *Ratio = Power density / Limit. Report No.: FA0O2701 Page : 6 of 6 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corporation (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No.30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan (R.O.C.) No.3-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 33381, Taiwan (R.O.C.) No.14-1, Lane 19, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 333, Taiwan (R.O.C.) If you have any suggestion, please feel free to contact us as below information Tel: 886-3-271-8666 Fax: 886-3-318-0155 Email: [email protected] ══END══

Report No.: FR0O2701AD Page : 1 of 63 Report Version: Rev. 01 FCC Test Report FCC ID : IPH-03942 Equipment : Marine Stereo Model No. : A03942 Brand Name : FUSION Applicant : Garmin International, Inc. Address : 1200 E. 151st Street Olathe, KS 66062 United States Standard : 47 CFR FCC Part 15.247 Received Date : Oct. 27, 2020 Tested Date : Nov. 04 ~ Nov. 12, 2020 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FR0O2701AD Page : 2 of 63 Report Version: Rev. 01 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Local Support Equipment List ................................................................................................................ 8 1.3 Test Setup Chart .................................................................................................................................... 9 1.4 The Equipment List .............................................................................................................................. 10 1.5 Test Standards ..................................................................................................................................... 11 1.6 Reference Guidance ............................................................................................................................ 11 1.7 Deviation from Test Standard and Measurement Procedure ............................................................... 11 1.8 Measurement Uncertainty .................................................................................................................... 11 2 TEST CONFIGURATION ..................................................................................................................... 12 2.1 Testing Facility ..................................................................................................................................... 12 2.2 The Worst Test Modes and Channel Details ....................................................................................... 12 3 TRANSMITTER TEST RESULTS ....................................................................................................... 13 3.1 Unwanted Emissions into Restricted Frequency Bands ...................................................................... 13 3.2 Unwanted Emissions into Non-Restricted Frequency Bands .............................................................. 30 3.3 Conducted Output Power ..................................................................................................................... 38 3.4 Number of Hopping Frequency ............................................................................................................ 41 3.5 20dB and Occupied Bandwidth ............................................................................................................ 45 3.6 Channel Separation .............................................................................................................................. 52 3.7 Number of Dwell Time .......................................................................................................................... 57 4 TEST LABORATORY INFORMATION ............................................................................................... 63 Report No.: FR0O2701AD Page : 3 of 63 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FR0O2701AD Rev. 01 Initial issue Mar. 17, 2021 Report No.: FR0O2701AD Page : 4 of 63 Report Version: Rev. 01 Summary of Test Results FCC Rules Test Items Measured Result 15.207 Conducted Emissions Note 1 N/A 15.247(d) 15.209 Radiated Emissions [dBuV/m at 3m]: 45.25MHz 38.99 (Margin -1.01dB) - QP Pass 15.247(d) Band Edge Meet the requirement of limit Pass 15.247(b)(1) Conducted Output Power Power [dBm]: 10.87 Pass 15.247(a)(1)(iii) Number of Hopping Channels Meet the requirement of limit Pass 15.247(a)(1) Hopping Channel Separation Meet the requirement of limit Pass 15.247(a)(1)(iii) Dwell Time Meet the requirement of limit Pass 15.203 Antenna Requirement Meet the requirement of limit Pass N/A means Not Applicable. Note 1 : The EUT consumes DC power, so the test is not required. Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FR0O2701AD Page : 5 of 63 Report Version: Rev. 01 1 General Description 1.1 Information 1.1.1 Specification of the Equipment under Test (EUT) RF General Information Frequency Range (MHz) Bluetooth Mode Ch. Frequency (MHz) Channel Number Data Rate 2400-2483.5 BR V4.2 2402-2480 0-78 [79] 1 Mbps 2400-2483.5 EDR V4.2 2402-2480 0-78 [79] 2 Mbps 2400-2483.5 EDR V4.2 2402-2480 0-78 [79] 3 Mbps Note 1: RF output power specifies that Maximum Peak Conducted Output Power. Note 2: Bluetooth BR uses a GFSK. Note 3: Bluetooth EDR uses a combination of π/4-DQPSK and 8DPSK. 1.1.2 Antenna Details Ant. No. Type Connector Gain (dBi) Remarks 1 PIFA N/A 1.72 --- 1.1.3 Power Supply Type of Equipment under T…

Text truncated - open the document above for the full version.

Report No.: FR0O2701 Page: : 1 of 4 Report Version: Rev. 01 Photographs of the Test Configuration Radiated Emission Below 1GHz Test Report No.: FR0O2701 Page: : 2 of 4 Report Version: Rev. 01 Radiated Emission Below 1GHz Test Report No.: FR0O2701 Page: : 3 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test Report No.: FR0O2701 Page: : 4 of 4 Report Version: Rev. 01 Radiated Emission Above 1GHz Test
