GROUP RIDE RADIO Quick Start Manual Installing the Antenna on the Group Ride Radio Mount NOTE: The mounted antenna must be at least 4 cm (1.57 in.) away from the nearest roll bar or metal surface to avoid radio interference. You can mount the antenna directly onto the Group Ride Radio mount. For the best results, use this method only in vehicles that do not have a roll cage. Screw down and tighten the antenna onto the Group Ride Radio mount. Relocating the Antenna NOTE: The mounted antenna must be at least 4 cm (1.57 in.) away from the nearest roll bar or metal surface to avoid radio interference. You can use the antenna relocation kit to mount your antenna in a more suitable location for your vehicle, such as a roll bar at the rear of your vehicle, to receive better radio reception. For the best results, use this method for vehicles that have a roll cage. 1 Screw down and tighten the antenna cable onto the Group Ride Radio mount . 2 Find a suitable location for the antenna. 3 Using a flat head screwdriver or 5 / 16 in. (8 mm) nut driver, loosen the bolt on the antenna relocation mount until the ring separates. 4 Place the mount around the roll bar. 5 Tighten the bolt on the mount until the ring is secure. 6 Screw down and tighten the antenna onto the antenna relocation plate. 7 Route the antenna cable along a suitable path in your vehicle, and secure it using the included zip ties. 2Quick Start Manual Installing the Fist Microphone and Mount Before you can attach the fist microphone mount to your dashboard, you must select a suitable location on the dashboard. WARNING It is your responsibility to ensure the mounting location complies with all applicable laws and ordinances, and does not block your view of the road during the safe operation of your vehicle. NOTICE Avoid wires, gauges, air bags, air bag covers, HVAC, and other items when drilling pilot holes and attaching the mount to the vehicle. Garmin ® is not responsible for any damages or consequences arising from the installation. 1 Align and insert the connector on the fist microphone onto the Group Ride Radio mount. 2 Tighten the collar around the connected cable. 3 Place the mount on the selected location. 4 Using the mount as a template, mark the three screw locations. 5 Drill pilot holes (optional). For some types of mounting material, drilling pilot holes is necessary. 6 Securely fasten the mount to the surface using the supplied screws . 7 Slide the fist microphone onto the mount. Group Ride Radio Specifications Water resistance IEC 60529 IPX7 1 Operating temperature range From -20° to 55°C (from -4° to 131°F) Charging temperature range From 0° to 45°C (from 32° to 113°F) 1 The device withstands incidental exposure to water of up to 1 m for up to 30 min. For more information, go to www.garmin.com/waterrating. Quick Start Manual3 Power input (vehicle power cable, motorcycle, or external power) From 12 to 24 Vdc Battery typeLithium-ion battery Battery voltage range From 3.5 to 4.1 V Wireless frequencies (United States) From 151.82 to 154.6 MHz @ 31.7 dBm Wireless frequencies (EMEA) From 169.4125 to 169.4625 MHz @ 29.5 dBm Wireless frequencies (New Zealand) From 160.175 to 160.5750 MHz @ 22 dBm Wireless frequencies (Australia) From 151.15 to 152.15 MHz @ 17.3 dBm 4Quick Start Manual support.garmin.com © 2020 Garmin Ltd. or its subsidiaries Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used without the express permission of Garmin. The BLUETOOTH ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. Wi‑Fi ® is a registered mark of Wi-Fi Alliance Corporation. Printed in Taiwan October 2020 190-02649-92_01

Important Safety and Product Information2 Informations importantes sur le produit et la sécurité5 Información importante sobre el producto y tu seguridad8 © 2020 Garmin Ltd. or its subsidiaries Printed in Taiwan October 2020 190-00720-AV_01 Important Safety and Product Information WARNING Failure to heed the following warnings could result in death, serious injury, or property damage. Distraction Warning This device is intended to enhance the situational awareness when used properly. If used improperly, you could become distracted by the display, which could lead to an accident causing serious personal injury or death. Only access the information displayed on the device with a glance. Always maintain awareness of your surroundings and do not stare at the display or become distracted by the display. Focusing on the display could prevent you from avoiding obstacles or hazards. Vehicle Installation Warnings • When installing the device in a vehicle, do not place the device where it obstructs the driver’s view of the road or interferes with vehicle operating controls, such as the steering wheel, foot pedals, or transmission levers. Do not place unsecured on the vehicle dashboard . Do not place the device in front of or above any airbag . • The windshield mount may not stay attached to the windshield in all circumstances. Do not place the mount where it will become a distraction if it should become detached. Keep your windshield clean to help ensure that the mount stays on the windshield. Street Navigation Warnings If your Garmin ® device accepts street maps and suggests routes that follow roads, follow these guidelines to ensure safe on-road navigation. • Always use your best judgment, and operate the vehicle in a safe manner. Do not become distracted by the device while driving, and always be fully aware of all driving conditions. Minimize the amount of time spent viewing the device screen while driving. • Do not input destinations, change settings, or access any functions requiring prolonged use of the device controls while driving. Pull over in a safe and legal manner before attempting such operations. • When navigating, carefully compare information displayed on the device to all available navigation sources, including road signs, road closures, road conditions, traffic congestion, weather conditions, and other factors that may affect safety while driving. For safety, always resolve any discrepancies before continuing navigation, and defer to posted signs and conditions. • The device is designed to provide route suggestions. It is not a replacement for driver attentiveness and good judgement. Do not follow route suggestions if they suggest an illegal maneuver or would place the vehicle in an unsafe situation. Off-Road Navigation Warnings If your Garmin device is able to suggest off-road routes for various outdoor activities, such as biking, hiking, and all- terrain vehicles, follow these guidelines to ensure safe off- road navigation. • Always use your best judgment and exercise common sense when making off-road navigational decisions. The Garmin device is designed to provide route suggestions only. It is not a replacement for attentiveness and proper preparation for outdoor activities. Do not follow the route suggestions if they suggest an illegal course or would put you in an unsafe situation. • Always carefully compare information displayed on the device to all available navigation sources, including trail signs, trail conditions, weather conditions, and other factors that may affect safety while navigating. For safety, always resolve any discrepancies before continuing navigation, and defer to posted signs and conditions. • Always be mindful of the effects of the environment and the inherent risks of the activity before embarking on off-road activities, especially the impact that weather and weather-related trail conditions can have on the safety of your activity. Ensure that you have the proper gear and supplies for your activity before navigating along unfamiliar paths and trails. Battery Warnings A lithium-ion battery is used in this device. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury. • Do not disassemble, modify, remanufacture, puncture or damage the device or batteries. • Do not remove or attempt to remove the non-user- replaceable battery. • Do not expose the device or batteries to fire, explosion, or other hazard. Magnet Warning Both the device and its mount may contain magnets. Under certain circumstances, magnets may cause interference with some internal medical devices, including pacemakers and insulin pumps. Devices and mounts that contain magnets should be kept away from such medical devices. Hearing Damage Warning You can permanently damage your ears and lose hearing if you listen to the device, earbuds, or headphones at high volume. If you experience ringing in your ears or muffled speech, stop listening and have your hearing checked. FCC Warnings Exposure to Radio Frequency Signals–Your device is a radio transmitter and receiver. When it is on, it receives and also sends out radio frequency (RF) signals. Antenna Care–Use only the supplied antenna or a recommended antenna accessory. Unauthorized antennas, modifications, or attachments could damage the radio and may violate FCC regulations. Warning: Do not use any radio that has a damaged antenna, because if it comes into contact with your skin, a minor burn can result. Electronic Devices–Most modern electronic equipment is shielded from RF signals. However, certain equipment may not be shielded against the RF signals from your wireless radio. 2 EN Pacemakers–The Health Industry Manufacturers Association (HIMA) and Wireless Technology Research recommend that a minimum separation of six inches (6”) be maintained between a handheld wireless radio and a pacemaker to avoid potential in…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: July 17 , 2020 SUBJECT: FCC Application for FCC ID: IPH-04041 To Whom It May Concern: Garmin will continue to apply processes and procedures to ensure compliance with 47 CFR 2 requirements regarding products produced under Supplier’s Declaration of Conformity procedure for class B computer peripheral portion as applicable to this composite filing. Sincerely, Tim Olson Senior C ompliance Engineer

June 4, 2020 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Innovation, Science and Economic Development Canada Certification and Engineering Bureau 3701 Carling Avenue PO Box 11490, Station H Ottawa, Ontario, Canada K2H 8S2 To Whom It May Concern: Pursuant to 47 CFR 2.911, Garmin International, Inc. (Garmin) has authorized the following Garmin International Associates to act on Garmin's behalf for the sole and express purpose of processing applications to the Federal Communication Commission (FCC) and Innovation, Science and Economic Development Canada (ISED) for equipment authorization or certification. Ms. Poojita Bhattu, Compliance Engineer, Outdoor Products Mr. Doug Burroughs, Senior Compliance Engineer, Wellness & Fitness Products Mr. Jeffrey Hailey, Lead Compliance Eng ineer, Marine Products Mr. Dan Irish, Senior Compliance Engineer, Consumer Automotive Products Mr. Hadid Jones, Team Leader, Compliance Engineering Mr. Tim Olson, Senior Compliance Engineer, Consumer Automotive & Auto OEM Products Mr. William Pertner, Lead Compliance Engineer, Outdoor Products Mr. Cody Riggle, Compliance Engineer, Marine Products Mr. David Utt, Staff Compliance Engineer, Wellness & Fitness Products As such, the Garmin Associates listed above are authorized to: 1) sign Form 731, 2) sign letters of application, 3) request confidentiality, and 4) exchange data and information with the FCC, IC and/or authorized TCBs on behalf of Garmin. In addition, these individuals shall be considered "authorized individuals" to act on Garmin's behalf where an "authorized individual's" attestation is necessary or preferred. This authorization remains in effect until notified to the contrary by Garmin. Sincerely, Mr. Douglas Kealey, Manager Environmental and Regulatory Affairs

Authority To Act As Agent Date: July 17, 2020 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Ni c Johnson of th e Nebraska Center fo r Excellence i n Electronics (NCEE Labs) is authorized to act on ou r behalf, until otherwise notified, for applications t o American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: July 16, 2021 By: Tim Olson Senior Compliance Engineer Garmin International, Inc.

Page 1 of 1 Request for Confidentiality Date: February 4, 2021 Subject: Confidentiality Request for: Garmin International, Inc. FCC ID: IPH-04041 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 9.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent ☐ Not Provided Block Diagrams ☒ Short Term ☐ Not Provided External Photos ☒ Short Term ☐ Permanent ☐ Not Provided Internal Photos ☐ Short Term ☒ Permanent ☐ Not Provided Operation Description/Theory of Operation ☐ Short Term ☐ Permanent ☒ Not Provided Parts List & Placement/BOM ☐ Short Term ☒ Permanent ☐ Not Provided Tune-Up Procedure ☐ Short Term ☒ Permanent ☐ Not Provided Schematics ☒ Short Term ☐ Not Provided Test Setup Photos ☒ Short Term ☐ Permanent ☐ Not Provided User’s Manual The above-mentioned company has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality (if applicable): The applicant requests the exhibits selected above as short term confidential be withheld from public view for 30 days. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered Provided to IC applications Sincerely, By: __________________________ Nic Johnson, Technical Manager, NCEE Labs

EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS Shown with loop mount EXTERNAL PHOTOS S EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS EXTERNAL PHOTOS Optional ball mount

TAIWAN 000000000 FCC ID: IPH-04041 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation A04041 Label Placement Back of unit

INTERNAL PHOTOS INTERNAL PHOTOS INTERNAL PHOTOS INTERNAL PHOTOS Data radio Voice radio INTERNAL PHOTOS INTERNAL PHOTOS INTERNAL PHOTOS

RF Exposure Evaluation FCC Radiation Exposure Calculation This equipment should be installed and operated with minimum distance specified below Frequency P o P o P o + 10% tolerance FCC Maximum Exposure limit Field Density a 20cm Margin MHz dBm mW mW mW/cm^2 mW/cm^2 mW/cm^2 154.570 31.72 1485 1633 0.20 0.10 0.10 Controlled exp. Field Density = ( Po x G)/(4*Pi*r^2) General pop. 1 1 = yes Limit = 0.2 mW/cm^2 G = Gain = - 5dBi = 0.32 (linear) S = Field density limit at Frequency specified Po = conducted output power r = Min distance (cm) Note: EIRP measurements are made when the antenna is not easily connected directly to a spectrum analyzer and the antenna gain is not published. References FCC Part 1.1310, 2.1091 FCC OET Bulletin 65, Edition 97-01 FCC Supplement C to OET Bulletin 65, edition 01-01
