A04223 DOG DEVICE Quick Start Manual..................2 Manuel de démarrage rapide.........9 Manuale di avvio rapido............17 Schnellstartanleitung...............25 Guía de inicio rápido...............34 Manual de Início Rápido............42 Snelstartgids......................50 Aloitusopas.......................58 Hurtigstartveiledning...............65 Snabbstartshandbok...............72 Kezdő lépések.....................80 Ръководство за бърз старт........88 A04223 Dog Device Quick Start Manual Getting Started WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Dog Device NOTE: Your dog device may look different than the device pictured. VHF antenna GPS antenna Power button Contact points Status LED Flashing beacon LEDs Turning On the Device • On the dog device, hold the power button until the status LED flashes and the collar beeps. Turning Off the Device Hold the power button until the status LED turns solid red. The dog device beeps and turns off. Charging the Dog Device NOTICE To prevent corrosion, thoroughly dry the contacts on the dog device and the surrounding area before connecting the charging clip. NOTE: Your dog device may look different than the device pictured. You should fully charge the battery before you use the dog device for the first 2Quick Start Manual EN time. Charging a fully depleted battery takes about five hours. 1Snap the charging clip onto the dog device . 2Plug the small end of the power cable into the USB port on the charging clip. 3Plug the power cable into a power source. The status LED is solid red when the collar is charging. 4After the status LED turns solid green, remove the charging clip from the collar. Acquiring Satellite Signals Both the dog device and navigator must acquire satellite signals before you put the dog device on your dog. Acquiring satellites can take a few minutes. 1 Go outdoors to an open area. 2 Turn on both devices. in the status bar shows the GPS signal strength. When the dog device has acquired satellite signals, the status LED flashes green. Adding a Dog to the Navigator Using Wireless Pairing To pair wirelessly, the dog device must be within range of the navigator. 1 Hold the power button on the dog device until the device emits two series of beeps (about 2 seconds), and then release the power button. The status LED flashes blue. The dog device is now ready to be paired with a navigator. 2On the navigator, select Dog List > Add Dog. 3Select Pair Collar, and follow the on- screen instructions. Quick Start Manual3 EN 4After successfully adding the dog device, enter the name of the dog, and select . 5Select a beacon color for this dog device, and select . Selecting and Installing the Contact Points CAUTION To prevent irritation from the contact points, remove the collar for at least eight hours out of every 24-hour period. Do not spray the device with harsh chemicals including but not limited to flea or tick spray. Always ensure that any flea or tick spray that is applied to the dog is completely dry before placing the collar on the dog. Small amounts of harsh chemicals can damage the plastic components and collar strap. For best results, select the correct contact points based on your dog's coat. 1Select the correct contact point length for your dog's coat type: • For dogs with thicker coats, use the longer contact points. • For dogs with shorter coats, use the shorter contact points. 2If necessary, use the included wrench to remove the contact points. 3Twist the contact points into the collar. 4Tighten with the included wrench, but do not overtighten. When you put the collar on the dog, make sure the contact points are tight against the neck. Fitting the Collar on Your Dog CAUTION To prevent irritation from the contact points, remove the collar for at least eight hours out of every 24-hour period. This device is not intended for human use. Do not attempt to use on any person. Do not spray the device with harsh chemicals including but not limited to flea or tick spray. Always ensure that any flea or tick spray that is applied to the dog is completely dry before placing the collar on the dog. Small amounts of harsh chemicals can damage the plastic components and collar strap. 4Quick Start Manual EN Before you can put the collar on the dog, you must pair the navigator and dog device (page 3 ), and acquire satellite signals (page 3). In order to effectively train the dog, the collar must fit the dog properly. If the collar is too loose or positioned incorrectly, stimulation may be inconsistent. This can delay or prevent successful training. 1 Position the collar with the communication antenna pointing up, the GPS antenna facing up, the LEDs facing forward, and the contact points against the neck. 2Place the collar around the middle of the dog's neck. 3Tighten the strap so that it is snug around the dog's neck, and fasten the buckle. NOTE: The collar should fit tightly and should not be able to rotate or slide on the dog's neck. The dog must be able to swallow food and water normally. You should observe your dog's behavior to verify that the collar is not too tight. 4Wiggle the device to work the contact points through the dog's coat. NOTE: The contact points must have contact with the dog's skin to be effective. 5If the strap is too long, cut off the excess, leaving at least 7.62 cm (3 in.) to spare. TIP: You can mark the hole used to fasten the buckle for future reference. Dog Tracking and Training One navigator can track multiple dog devices and other navigators. Dog Tracking The navigator allows you to track your dog or multiple dogs, using the tracking compass or map. The map displays your Quick Start Manual5 EN location and your dog's location and tracks. The compass pointer indicates the direction of the dog's current location. Dog Training NOTICE You should research and investigate the training methods best suited for you, your dog, and …
