IPH-04281Mobile mounted digital recording device

IMPORTANT SAFETY AND PRODUCT INFORMATION WARNING Failure to heed the following warnings could result in an accident or collision resulting in death or serious injury. Battery Warnings A lithium-ion battery is used in this device. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury. • Do not expose the device or batteries to fire, explosion, or other hazard. • Do not disassemble, modify, remanufacture, puncture or damage the device or batteries. • Do not remove or attempt to remove the non-user-replaceable battery. Distraction Warning This device is intended to enhance the situational awareness when used properly. If used improperly, you could become distracted by the display, which could lead to an accident causing serious personal injury or death. Only access the information displayed on the device with a glance. Always maintain awareness of your surroundings and do not stare at the display or become distracted by the display. Focusing on the display could prevent you from avoiding obstacles or hazards. Driver Assistance Warning If your device has Forward Collision Warning System (FCWS) and Lane Departure Warning System (LDWS) features, be advised that these features are for information only and do not replace your responsibility to observe all road and driving conditions, abide by all traffic regulations, and use safe driving judgment at all times. The FCWS and LDWS features rely on the camera to provide warnings of upcoming vehicles and lane markers and, as a result, may have limited functionality in low visibility conditions. Certain conditions may impair the warning function. Go to garmin.com/warnings for details. Choking Hazard This product contains small parts. This product is not for children under 3 years. Vehicle Installation Warnings • When installing the device in a vehicle, do not place the device where it obstructs the driver’s view of the road or interferes with vehicle operating controls, such as the steering wheel, foot pedals, or transmission levers. Do not place unsecured on the vehicle dashboard . Do not place the device in front of or above any airbag . Incident Messaging Warning The incident messaging feature is not available in all areas. If you have an active LTE subscription for your device, you are within an LTE network coverage area, and incident messaging is enabled, your device can contact your emergency contacts if an incident is detected. This is a supplemental feature that should not be relied upon as a primary method to obtain emergency assistance. Neither this device nor the Garmin Drive ™ app will contact emergency services on your behalf. Magnet Warning Both the device and its mount may contain magnets. Under certain circumstances, magnets may cause interference with some internal medical devices, including pacemakers and insulin pumps. Devices and mounts that contain magnets should be kept away from such medical devices. CAUTION Failure to heed the following cautions could result in minor or moderate injury, or property damage. LTE Services The LTE connected features on this device are supplemental and should not be relied upon as a primary method to monitor your vehicle. The functionality, reliability, and timeliness of messages and notifications depend on a number of factors that are beyond the control of Garmin ® , including but not limited to cellular connectivity, reception, and device power. NOTICE Failure to heed the following notices could result in personal or property damage, or negatively impact the device functionality. Battery Notices • Contact your local waste disposal department to dispose of the device/ batteries in accordance with applicable local laws and regulations. Windshield Mounting Legal Restrictions Before using the device on your windshield, check the state and local laws and ordinances where you drive. Some state laws prohibit or restrict the placement of objects on the windshield of a motor vehicle. IT IS THE USER'S RESPONSIBILITY TO MOUNT THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Always mount your Garmin device in a location that does not obstruct the driver's view of the road. Garmin does not assume any responsibility for any fines, penalties, or damages that may be incurred as a result of any state or local law or ordinance relating to the use of your Garmin device. Magnet Notice Both the device and its mount may contain magnets. Under certain circumstances, magnets may cause damage to some electronic devices, including hard drives in laptop computers. Use caution when devices and mounts that contain magnets are near electronic devices. Camera Legal Notice Some jurisdictions may prohibit or regulate recording audio and video, or taking photographs. Jurisdictions may require that all parties have knowledge of the recording and provide consent before you record audio and video or take photographs. It is your responsibility to know and comply with all laws, regulations, and any other restrictions in your jurisdiction. Product Environmental Programs Information about the Garmin product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at garmin.com /aboutGarmin/environment. Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: garmin.com/compliance. UK Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the relevant statutory requirements. The full text of the declaration of conformity is available at the following internet address: garmin.com/compliance. Innovation, Science and Economic Development Canada Compliance This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Can…

Text truncated - open the document above for the full version.

Letter of Authorization and Anti- Drug Statement Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Product Name: Model Number: A04281 FCC ID:IPH-04281 We authorize: CETECOM Inc., to act on our behalf on all matters concerning the above named equipment. We declare that CETECOM Inc. is allowed to forward all information related to the approval project to the Federal Communications Commission and discuss any issues concerning the approval application. The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? ☒ Yes I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. Signature of Authorized Person Filing: Title: Senior Compliance Engineer Date: 8/23/22

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: August 23, 2022 Subject: Request for Permanent Confidentiality FCC ID: IPH-04281 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, Garmin International, Inc. hereby requests permanent confidentiality for documents filed under the following exhibit types: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description These items contain detailed system and equipment description and related information about the product which Garmin International, Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Garmin International, Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards, Tim Olson Senior Compliance Engineer Garmin International Inc. 1200 East 151 st Olathe KS, 66062

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: August 23, 2022 Subject: Request for Short Term Confidentiality FCC-ID: IPH-04281 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, Garmin International, Inc. hereby requests short term confidentiality for documents filed under the following exhibit types: 1. External Photographs 2. Internal Photographs 3. User / Instruction Manual 4. Test Set-up Photographs until the product will be publicly announced. Short term confidentiality release date / period: 180 days These items contain detailed system and equipment description and related information about the product which Garmin International, Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Garmin International, Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are informed and aware of our obligation that we have to inform the involved TCB in written and in due time if we intend to market the product prior to the above specified confidentiality release date so that the short term confidentiality classification can be reset prior to product launch. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards, Tim Olson Senior Compliance Engineer Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062

E-Label Information A.The following specific instructions are provided in the Quick Start Manual that ships with the device a.Label viewing directions are found in the user manual (outlined here for reference) and available on line at www.garmin.com b.Getting the Owner's Manual i.The owner's manual includes instructions for using device features and accessing regulatory information Go to www.garmin.com/manuals/A04281 B.The following are the specific instructions provided in the owner’s manual that is provided at www.garmin.com/manuals: a.Device Information b.Viewing Regulatory and Compliance information. c.1) From the settings menu, Scroll to the bottom of the menu d.2) Select System e.3) Select Regulatory. M/N: A04281 FCC ID: IPH-04281 IC: 1792A-04281 Contains FCC ID:XMR201909EC25AFX IC:10224A-2019EC25AFX C.The above information is programmed by Garmin in such a manner that third-parties cannot modify it. a.“No special accessories or supplemental plug-ins (e.g., installation of a SIM/USIM card) are required to access the information. Access to the information is provided without special codes, accessories, or permissions beyond the normal security protection to unlock the screen, sign-in page, or overall product access.” D.The above M/N, FCC ID, and IC numbers can be found printed on the product packaging

A2LA Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V4.0 2012-07-25 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM Radio Frequency Exposure Evaluation Report For: Garmin International, Inc. Model Name: A04281 Product Description: Mobile mounted digital recording device FCC ID: IPH-04281 ISED ID: 1792A-04281 Applied Rules and Standards: CFR Part 1.1307 & 1.1310, Part 2.1091 ISEDC RSS-102 Issue 5 Report number: EMC_GARMI-107-22001_FCC_MPE DATE: 12-05-2022 Test Report #: EMC_GARMI-107-22001_FCC_MPE Date of Report: 12-05-2022 Page 2 of 8 1. Assessment This RF Exposure evaluation report provides information about compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091), and ISEDC standard RSS-102, under given conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated, respectively, where relevant. The device meets the limits as stipulated by the above given FCC/ISEDC rule parts based on available specifications. Company Name Product Description Model # Garmin International, Inc. Mobile mounted digital recording device A04281 Responsible for Testing Laboratory: 12-05-2022 Compliance Arndt Stoecker (Director of Regulatory Services) Date Section Name Signature Responsible for the Report: 12-05-2022 Compliance Kris Lazarov (Senior EMC Engineer) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM Inc. USA. Contents Test Report #: EMC_GARMI-107-22001_FCC_MPE Date of Report: 12-05-2022 Page 3 of 8 1. Assessment ................................................................................................................................... 2 2. Administrative Data ..................................................................................................................... 4 2.1. Identification of the Testing Laboratory Issuing the Test Report ......................................... 4 2.2. Identification of the Client ..................................................................................................... 4 2.3. Identification of the Manufacturer ......................................................................................... 4 3. Equipment under Assessment ...................................................................................................... 5 4. RF Exposure Limits and FCC and ISED ..................................................................................... 6 4.1. FCC § 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. ................... 6 4.2. RSS-102, cl. 2.5.2 Exemption Limits for Routine Evaluation: ............................................. 6 4.3. RF Exposure Test Exemptions for Simultaneous Transmission Sources .............................. 6 5. Evaluations ................................................................................................................................... 7 5.1. Routine Environmental Evaluation Applicability Standalone Transmission ........................ 7 5.2. Routine Environmental Evaluation Applicability Simultaneous Transmission .................... 7 6. Revision History ........................................................................................................................... 8 Test Report #: EMC_GARMI-107-22001_FCC_MPE Date of Report: 12-05-2022 Page 4 of 8 2. Administrative Data 2.1. Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Director of Regulatory Services: Arndt Stoecker Responsible Project Leader: Sangeetha Sivaraman 2.2. Identification of the Client Applicant’s Name: Garmin International, Inc. Street Address: 1200 East 151st Street City/Zip Code Olathe, KS / 66062 Country USA 2.3. Identification of the Manufacturer Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Test Report #: EMC_GARMI-107-22001_FCC_MPE Date of Report: 12-05-2022 Page 5 of 8 3. Equipment under Assessment Model No A04281 HW Version 0 SW Version 0.42 FCC-ID : IPH-04281 IC-ID: 1792A-04281 FWIN: A04281 HVIN: A04281 PMN: A04281 Product Description: Mobile mounted digital recording device Transceiver Technology LTE Band 2, 4, 5, 12, 66 Bluetooth LE WLAN 802.11a/b/g/n/ac 2.4 GHz; UNII-1; UNII-3 Co-located Transmitters/ Antennas? Cellular and WLAN can transmit simultaneously Power Supply/ Rated Operating Voltage Range 5Vdc, 2A Operating Temperature Range -20°C to + 70°C Sample Revision Prototype  Production  Pre-Production Device Category Fixed Installation Mobile Portable Exposure Category  Occupational/ Controlled  General Population/ Uncontrolled Radio Technology Maximum Power (dBm) Peak Gain (dBi) LTE Bands 2, 4, 5, 12, 66 25 - See Note 1 0.38 – See Note 5 Bluetooth LE 2.4 GHz 2.71 – See Note 2 5.30 - See Note 5 WLAN 2.4 GHz 17.45 – See Note 3 5.30 - See Note 5 WLAN 5 GHz 18 – See Note 4 1.98 - See Note 5 Note 1: The power and tu…
