IPH-04540Portable Transceiver

IMPORTANT SAFETY AND PRODUCT INFORMATION WARNING Failure to heed the following warnings could result in an accident or medical event resulting in death or serious injury. Distraction Warning This device is intended to enhance the situational awareness when used properly. If used improperly, you could become distracted by the display, which could lead to an accident causing serious personal injury or death. Only access the information displayed on the device with a glance. Always maintain awareness of your surroundings and do not stare at the display or become distracted by the display. Focusing on the display could prevent you from avoiding obstacles or hazards. Health Warnings • Always consult your physician before beginning or modifying any exercise program. Device Warnings • Do not immerse the device or batteries in water or other liquids. • To avoid possible device damage, do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun in an unattended vehicle. Bicycle Warnings • Always use your best judgement, and operate the bicycle in a safe manner. • Make sure your bicycle and hardware are properly maintained and that all parts are correctly installed. NOTICE Failure to heed the following notices could result in personal or property damage, or negatively impact the device functionality. Legal Restrictions IT IS THE USER'S RESPONSIBILITY TO MOUNT AND OPERATE THE DEVICE IN COMPLIANCE WITH ALL APPLICABLE LAWS AND ORDINANCES. Garmin ® does not assume any responsibility for any fines, penalties, or damages that may be incurred as a result of any state or local law or ordinance relating to the use of your Garmin device. Product Environmental Programs Information about the Garmin product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at garmin.com/aboutGarmin /environment. Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: garmin .com/compliance. UK Declaration of Conformity Hereby, Garmin declares that this product is in compliance with the relevant statutory requirements. The full text of the declaration of conformity is available at the following internet address: garmin .com/compliance. Innovation, Science and Economic Development Canada Compliance This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Radio Frequency Radiation Exposure This device is a portable transmitter and receiver that uses an internal antenna to send and receive low levels of radio frequency (RF) energy for data communications. The device emits RF energy below the published limits when operating in its maximum output power mode and when used with Garmin authorized accessories. The device should not be used in other configurations. This device must not be co-located or operated in conjunction with any other transmitter or antenna. FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This product does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and void your warranty and your authority to operate this device under Part 15 regulations. Software License Agreement BY USING THE DEVICE, YOU AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THE FOLLOWING SOFTWARE LICENSE AGREEMENT. PLEASE READ THIS AGREEMENT CAREFULLY. Garmin Ltd. and its subsidiaries (“Garmin”) grant you a limited license to use the software embedded in this device (the “Software”) in binary executable form in the normal operation of the product. Title, ownership rights, and intellectual property rights in and to the Software remain in Garmin and/or its third-party providers. You acknowledge that the Software is the property of Garmin and/or its third- party providers and is protected under the United States of America copyright laws and international copyright treaties. You further acknowledge that the structure, organization, and code of the Software, for which source code is not provided, are valuable trade secrets of Garmin and/or its third-party providers and that the Software in source code form remains a valuable trade secret of Garmin and/or its third-party prov…

Text truncated - open the document above for the full version.

Cars detected within 140 m Voitures détectées dans les 140 m Automobile rilevate entro 140 m Coches detectados hasta a 140 m Carros detectados em até 140 m Moves up as the car approaches Monte à mesure que la voiture s’approche Si sposta verso l’alto appena l’automobile si avvicina Se mueve hacia arriba a medida que el vehículo se acerca Move-se para cima conforme o carro se aproxima Changes color based on level of threat Change de couleur selon le niveau de danger Cambia colore in base al potenziale livello di pericolo Cambia de color según el nivel de amenaza Muda de cor com base no nível de ameaça ggarmin.com/manuals/varmin.com/manuals/  WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. The device can improve situational awareness. It is not a replacement for cyclist attentiveness and good judgement. Always use your best judgment, and operate the bicycle in a safe manner. Select a secure location to mount the device where it does not interfere with the safe operation of your bike.  AVERTISSEMENT Consultez le guide Informations importantes sur le produit et la sécurité inclus dans l’emballage du produit pour prendre connaissance des avertissements et autres informations sur le produit. L’appareil peut faciliter le repérage. Il ne vous dispense pas de faire preuve de vigilance et de bon sens. Faites preuve de bon sens et roulez toujours de la manière la plus sûre possible. Pour installer l’appareil, choisissez un endroit sûr qui n’entrave pas le bon fonctionnement de votre vélo.  AVVERTENZA Per avvisi sul prodotto e altre informazioni importanti, vedere la guida Informazioni importanti sulla sicurezza e sul prodotto inclusa nella confezione. Il dispositivo può migliorare il rilevamento della posizione, ma non esonera il ciclista dal prestare la massima attenzione e usare il buon senso. Seguire sempre il buon senso e utilizzare la bici con prudenza. Scegliere una posizione stabile, che non ostacoli i movimenti sulla bicicletta.  ADVERTENCIA Consulta la guía Información importante sobre el producto y tu seguridad que se incluye en la caja del producto y en la que encontrarás avisos e información importante sobre el producto. El dispositivo puede ayudar a conocer mejor las condiciones actuales de la ruta. No es un sustituto de la atención ni del criterio del ciclista. Usa siempre tu mejor criterio y conduce el vehículo de forma segura. Selecciona una ubicación segura para instalar la unidad donde no interfiera con el funcionamiento seguro de la bicicleta.  ATENÇÃO Consulte o guia Informações importantes de segurança e do produto na caixa do produto para obter mais detalhes sobre avisos e outras informações importantes. O dispositivo pode melhorar a perceção situacional. Não substitui a atenção e o bom senso do ciclista. Tenha sempre bom senso e utilize a bicicleta de forma segura. Selecione um local seguro para posicionar o dispositivo de modo que não interfira com a operação segura da sua bicicleta. 190-03000-90_0AFebruary 2023Printed in T aiwan support.garmin.com © 2023 Garmin Ltd. or its subsidiaries Garmin ® , the Garmin logo, ANT+ ® , and Edge ® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. ™ is a trademark of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. The BLUETOOTH ® word mark and logos are owned by Bluetooth SIG Inc. and any use of such marks by Garmin is under license. 2.4 GHz @ 8 dBm maximum; 24 GHz @ 10 dBm maximum Operating temperaure range: From -20° to 60°C (from -4° to 140°F) DC 1.6 W @ 12 V El número de registro COFETEL/IFETEL puede ser revisado en el manual a través de la siguiente página de internet. 190-03000-90_0A.indd 1190-03000-90_0A.indd 12/13/2023 1:59:27 PM2/13/2023 1:59:27 PM 190-03000-90_0A.indd 2190-03000-90_0A.indd 22/13/2023 1:59:29 PM2/13/2023 1:59:29 PM

™ Owner’s Manual © 2023 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements. Go to www.garmin.com for current updates and supplemental information concerning the use of this product. Garmin ® , the Garmin logo, ANT+ ® , ® , fēnix ® , Forerunner ® , Venu ® , and vívoactive ® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Garmin Connect ™ , Garmin Express ™ , and ™ are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. The BLUETOOTH ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin is under license. M/N: A04540 Country restrictions apply. 010-02790-00 is approved for operation in France and the United Kingdom. 010-02789-00 is approved for operation in Germany. Introduction WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. The device can improve situational awareness. It is not a replacement for cyclist attentiveness and good judgement. Always maintain awareness of your surroundings, and operate the bicycle in a safe manner. Failure to do so could result in serious injury or death. Always consult your physician before you begin or modify any exercise program. Getting Started You can use the with your compatible Garmin ® device or a phone. This list provides an overview of the installation and setup tasks. • • Install the tail light mount (page 2). If you are using an ® series bike computer, pair the devices (page 5). • If you are using your phone, download the Garmin app to your phone, and pair the devices (page 10). • If you are using another Garmin device, pair the devices (page 15). Tips for Installing the Device The includes a tail light and micro radar that can detect approaching vehicles up to 140 meters away. • Select a secure location to mount the device where it does not interfere with the safe operation of your bike. • Mount the device as high as possible for optimal Introduction1 light visibility and radar detection. NOTE: The mount surface should be vertical. The devices are designed to accommodate most bike rack angles. • Mount the device 250 mm to 1200 mm above the road. • Mount the parallel to the longitudinal axis of the vehicle. • Ensure the device faces backward and is perpendicular to the road. • Make sure there are no obstructions in front of the light. • Go for a test ride during the day in a safe environment. Installing the Device on a Rear Rack Before you can install the , you need 3 mm and 4 mm hex keys and a cable to connect your device. 1 Complete the required steps based on the configuration of your rear rack: • If the rear rack can accommodate the friction flange adapter, complete steps 2 through 6. • If the device can be attached directly to the rear rack, complete steps 7 through 10. 2Attach the friction flange adapter to your using two M4 screws. 2Introduction 3Using a 3 mm hex key, tighten the two M4 screws to 1 N-m (9 lbf-in.). 4Align the hole in the friction flange adapter or extender with the hole in the rear rack of your bike. 5Using a 4 mm hex key, tighten the M5 screw to 3 N-m (27 lbf-in.). 6If you are not using a friction flange adapter, align the holes in the rear rack of your bike with the holes on the back of your . 7Using a 3 mm hex key, tighten the two M4 screws to 1 N-m (9 lbf-in.). 8Connect the cable to your bike. Consult the owner's manual for your bike for additional information on connecting devices. 9Secure the cable so that it does not interfere with any moving parts of the bike. Device Overview Introduction3 Device button Hold for 1 second to turn the device on and enter active mode. Hold for 4 seconds to enter pairing mode (page 10). When the device is in sleep mode, hold for 2 seconds to wake the device. Hold for 2 seconds to turn the tail light off. Hold for 10 seconds to reset the device. Device status LED Changes color based on the pairing status and device mode status. Status LED LED State Status Flashing purple The device is in active pairing mode. Flashing blue The device is in smart mode and can be controlled by a paired compat‐ ible Garmin device. Flashing yellow The device is in demo mode. Solid red An error occurred. You may need to restart the device. Tail Light Modes and Intensity You can switch the tail light modes by 4Introduction pressing the device button (page 3). Mode Light Intensity Function Solid (default) High The tail light is on, and the device detects vehicles. Standby Off The tail light is off, and the device continues to detect vehicles. Turning Off the Tail Light Hold the device button for 2 seconds (page 3). The radar continues to function while the tail light is off. The and Your You can remotely control your radar device and customize settings using your compatible bike computer. This section contains instructions for the . Other compatible bike computers contain similar settings and controls (page 15). Pairing the with Your The first time you connect the to your , you must pair both devices using ANT+ ® technology. After the initial pairing, the device automatically connects to the radar device when you start your activity and the radar The and Your 5 device is active and within range. NOTE: The radar device is compatible with other Garmin devices (page 15). 1 Bring the within range (3 m) of the sensor. NOTE: Stay 10 m away from other wireless sensors while pairing. 2 Turn on the . 3 Select > Sensors > Add Sensor > Search All. 4 While the is turned off, hold the device button for 4 seconds to enter pairing mode. The status LED flashes purple, and the ta…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 17, 2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: IPH- 04540 Garmin International, Inc., (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Ben Karsak

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 30, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: IPH-04540 Garmin International, Inc., Garmin certifies that, as of the date of the filing of the application, Garmin International, Inc.. is our designated U.S. agent for service of process for the above referenced FCC ID. Garmin International, Inc., accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Garmin International, Inc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: FRN: 0005088588 Name: Garmin International, Inc. Address: 1200 E. 151st , Olathe, Kansas, 66062, United States Contact Person: Ben Karsak Tel.: 913-440-1946 Email: [email protected] Sincerely, Garmin International, Inc. Ben Karsak

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 17, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: IPH- 04540 Garmin International, Inc., (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Ben Karsak

Page 1 of 1 Request for Confidentiality Date: February 14, 2023 Subject: Confidentiality Request for: FCC ID: IPH-04540 IC: 1792A-04540 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent ☐ Not Provided Block Diagrams ☒ Short Term ☐ Not Provided External Photos ☒ Short Term ☐ Permanent ☐ Not Provided Internal Photos ☐ Short Term ☒ Permanent ☐ Not Provided Operation Description/Theory of Operation ☐ Short Term ☐ Permanent ☒ Not Provided Parts List & Placement/BOM ☐ Short Term ☐ Permanent ☒ Not Provided Tune-Up Procedure ☐ Short Term ☒ Permanent ☐ Not Provided Schematics ☒ Short Term ☐ Not Provided Test Setup Photos ☒ Short Term ☐ Permanent ☐ Not Provided User’s Manual The above-mentioned company has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality (if applicable): The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify Timco in the event information regarding the product or the product is made available to the public before the requested period has expired. Timco will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered Provided to IC applications Sincerely, By: __________________________ Nic Johnson, Technical Manager, NCEE Labs

February 07, 2023 Federal Communications Commission Equip Approval Services Post Office Box 358315 Pittsburgh, Pennsylvania 15215-5315 To Whom It May Concern: Pursuant to 47 CFR 2.911, Garmin International, Inc. (Garmin) has authorized Nic Johnson of the Nebraska Center for Excellence in Electronics to act on Garmin’s behalf for the sole and express purpose of processing applications to the Federal Communication Commission (FCC) for equipment FCC authorization. This authorization is limited to FCC ID: IPH-04540. Consistent with the foregoing, Nic Johnson is authorized to: 1) Sign Form 731, 2) Sign letters of application, 3) Request confidentiality, and 4) Exchange data and information with the FCC, and authorized TCBs on behalf of Garmin. This authorization is not assignable to other beyond Nic Johnson. No party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 862. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. This authorization expires February 11, 2024 Sincerely, Kiran Kumar Compliance Engineer nothing follows

May 6, 2022 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Innovation, Science and Economic Development Canada Certification and Engineering Bureau 3701 Carling Avenue PO Box 11490, Station H Ottawa, Ontario, Canada K2H 8S2 To Whom It May Concern: Pursuant to 47 CFR 2.911, Garmin International, Inc. (Garmin) has authorized the following Garmin International Associates to act on Garmin's behalf for the sole and express purpose of processing applications to the Federal Communication Commission (FCC) and Innovation, Science and Economic Development Canada (ISED) for equipment authorization or certification. Mr. Chris Strauss, Compliance Engineering Team Lead Mr. William Pertner, Compliance Engineering Team Lead Mr. Jay Everett, Compliance Engineering Team Lead Mr. Mike Moranha, Compliance Engineer Ms. Poojita Bhattu, Compliance Engineer Mr. Doug Burroughs, Compliance Engineer Mr. Jeffrey Hailey, Compliance Engineer Mr. Dan Irish, Compliance Engineer Mr. Kiran Kumar, Compliance Engineer Mr. Tim Olson, Compliance Engineer Mr. Carlos Ortega, Compliance Engineer Mr. Cody Riggle, Compliance Engineer Mr. David Utt, Staff Compliance Engineer Mr. Jonathan Shafer, Design Certification Engineer Ms. Sara Jones, Design Certification Engineer As such, the Garmin Associates listed above are authorized to: 1) sign Form 731, 2) sign letters of application, 3) request confidentiality, and 4) exchange data and information with the FCC, IC and/or authorized TCBs on behalf of Garmin. In addition, these individuals shall be considered "authorized individuals" to act on Garmin's behalf where an "authorized individual's" attestation is necessary or preferred. This authorization remains in effect until notified to the contrary by Garmin. Sincerely, Ben Karsak Manager Compliance Engineering Garmin International, Inc.

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: February 07, 2023 SUBJECT: FCC Application for FCC ID: IPH-04540 To Whom It May Concern: Garmin will continue to apply processes and procedures to ensure compliance with 47 CFR 2 requirements regarding products produced under Supplier’s Declaration of Conformity procedure for class B computer peripheral portion as applicable to this composite filing. Sincerely, Kiran Kumar Compliance Engineer

1. Rear View 2. Front View 3. Side view 4. Ports

The Nebraska Center for Excellence in Electronics (NCEE) authorizes the above named company to reproduce this report provided it is reproduced in its entirety for use by the company’s employees only. Any use that a third party makes of this report, or any reliance on or decisions made based on it, are the responsibility of such third parties. NCEE accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. RF Exposure Evaluation Report Client: Garmin International 1200 E 151st Street Olathe Kansas 66062 USA Model: A04540 FCC ID: IPH-04540 IC: 1792A-04540 Test Report No.: RFE20221213-20B ISED CAB Identifier: US0177 Approved By: __________________ Fox Lane, EMC Test Engineer Date: February 28, 2023 Total Pages: 6 NCEE Labs Report Number: RFE20221213-20B Test Report Prepared for Garmin International The Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Page 2 of 6 Revision Page Rev. No. Date Description Original 21 February 2023 Prepared by – FLane A 21 February 2023 Signed - FL B 28 February 2023 Title Change - FL NCEE Labs Report Number: RFE20221213-20B Test Report Prepared for Garmin International The Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Page 3 of 6 Regulatory Requirements: FCC Part 1.1310, 2.1091, 2.1093 KDB 447498 D01 RSS-102, Issue 5 Summary: The EUT’s EIRP and conducted output power were used to evaluate for exemption from routine SAR testing. EUT: FCC ID: IPH-04540 IC: 1792A-04540 MPE Lab Nebraska Center for Excellence in Electronics MPE Labs FCC Cab Designation: US1060 MPE Labs ISED Cab Designation: US0177 Conducted Power: 5.532 dBm / 0.003574 W Antenna gain: 2.596 dBi / 1.818 numeric EIRP: 8.128 dBm EIRP / 0.00650 W EIRP + 10% tune-up tolerance: 8.54 dBm / 0.00715 W EIRP (mW) = Conducted power (mW) x antenna gain (numeric) Antenna gain was measured by lab by comparing radiated sample to conducted sample NCEE Labs Report Number: RFE20221213-20B Test Report Prepared for Garmin International The Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Page 4 of 6 Calculations: Parameters: Test separation > 50 mm max. EIRP of channel, including tune-up tolerance, mW = 7.15 mW f(GHz) = 2.480 GHz (highest frequency of range chosen for worst-case) EIRP + 10% tolerance was used as it is higher than the conducted value. KDB 447498 D01, Section 4.3.1(a): Limit / numeric threshold = 7.5 for extremity SAR [ 7 / 5 ] x SQRT(2.480) = 2.20 ≤ 7.5 EXEMPT EIRP + power tolerance was rounded up to the nearest mW as instructed in the KDB NCEE Labs Report Number: RFE20221213-20B Test Report Prepared for Garmin International The Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Page 5 of 6 RSS 102, Issue 5, Section 2.5.1 2.5.1 Exemption Limits for Routine Evaluation — SAR Evaluation SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 50 mm, except when the device operates at or below the applicable output power level (adjusted for tune-up tolerance) for the specified separation distance defined in Table 1. f(MHz) = 2402 MHz (lowest limit frequency within range) Exemption limit = 308.5 mW (extrapolated to 2480 MHz @ 50mm) EIRP with 10% tolerance = 7.15 mW Conducted power with 10% tolerance = 3.93 mW 2.4GHz radio Limit passing % = 2.4GHz% = 2.32% 24GHz radio limit passing % = Radar% = 5.1% Total Limit % = 2.4GHz% + Radar% = 2.32 + 5.1 < 100%, therefore exempt Both EIRP and conducted power with tolerance are EXEMPT NCEE Labs Report Number: RFE20221213-20B Test Report Prepared for Garmin International The Nebraska Center for Excellence in Electronics 4740 Discovery Drive Lincoln, NE 68521 Page 6 of 6 Result: The EUT was found to be exempt from routine SAR testing and COMPLIANT with RF exposure requirements. REPORT END

Antenna Gain Information: A04540 Equipment Description: This report contains the antenna gain information for the BLE/ANT+ and Radar antennas for Garmin Model A04540. The operational frequency of these technologies is approximately 2400-2480 MHz and 24000-24250 MHz, respectively, and the maximum gain within the frequency band is reported. Reported Data: Maximum Gain for BLE/ANT+ (Antenna): 4.22 dBi @ 2402 MHz Maximum Gain for BLE/ANT+ (Antenna): 10.55 dBi @ 24125 MHz Procedure: Garmin uses an ETS-Lindgren AMS-8500 3D Fully Anechoic Automated Antenna Measurement System. The measurement chamber is fully anechoic and contains both the Equipment Under Test (EUT) and the measurement antenna. The EUT is mounted on a Multi-Axis Positioner, which can orient the antenna in all orientations relative to the measurement antenna. The measurement antenna is dual-polarized and measures both horizontal and vertical polarization simultaneously. The other equipment includes a Vector Signal Generator, a multi-channel Vector Network Analyzer, and a control PC. Data is taken and analyzed using EMQuest Data Acquisition and Analysis Software. The output includes the maximum 3D antenna gain within the frequency band. Setup: Equipment List: 3D Chamber PC interfaced to Test Equipment EMQuest Software w/ Required Drivers for Equipment Installed AMS-8500 Anechoic Wireless Test Chamber Dual Polarization Measurement Antenna (ETS 3164) Multi-Axis Positioning System (MAPS) Multi-Axis Positioning Controller (ETS EMCO Model 2090) Network Analyzer (Agilent E5017C) Automated RF Switch Controller (Agilent) Additional Information: • Photos of the antennas are provided in the separate Internal Photos exhibit. • The Confidential Operating D…
