IPH-A2758Low Power Transmitter 2402-2480 MHz

Quick Start Manual DRAFT Introduction WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. Always consult your physician before you begin or modify any exercise program. Keys À Hold to turn the device on and off. Select to turn the backlight on and off. Á Select to unlock the device. Select to start and stop the timer. Select to choose an option or to acknowledge a message. Â Select to mark a new lap. Select to return to the previous screen. Ã Select to scroll through the widgets, data screens, options, and settings. Hold to view the shortcut menu options. 2Introduction DRAFT Locking and Unlocking the Device Keys You can lock the device keys to avoid accidental key presses during an activity. 1 Hold to view the shortcut menu. 2 Select Clock Options > Lock Device. 3 Hold to unlock the device keys. Status Icons Icons appear at the top of the home screen. A flashing icon means the device is searching for a signal. A solid icon means the signal was found or the sensor is connected. GPS status Bluetooth ® technology status Heart rate status Going for a Run The first fitness activity you record on your device can be a run, ride, or any outdoor activity. The device comes partially charged. You may need to charge the device (page 9) before starting the activity. 1 Select to unlock the screen. 2 Select an activity profile. 3 Go outside, and wait while the device locates satellites. 4 Select to start the timer. 5 Go for a run. Introduction3 DRAFT 6 After you complete your run, select to stop the timer. 7 Select an option: • Select Resume to restart the timer. • Select Save to save the run and reset the timer. You can select the run to view a summary. • Select Discard > Yes to delete the run. Smart Features Pairing Your Smartphone You should connect your device to a smartphone to complete the setup and access the full features of the device. 4Smart Features DRAFT TIP: You can also complete the setup on your computer using the Garmin Express ™ application. 1 Go to www.garmin.com/intosports/apps, and download the Garmin Connect ™ Mobile app to your smartphone. 2 From the device, select Menu > Settings > Bluetooth > Pair Mobile Device. 3 Open the Garmin Connect Mobile app, and follow the on-screen instructions to connect a device. The instructions are provided during the initial setup, or can be found in the Garmin Connect Mobile app help. Widgets Your device comes preloaded with widgets that provide at- a-glance information. Some widgets require a Bluetooth connection to a compatible smartphone. Notifications: Alerts you to incoming calls and texts based on your smartphone notification settings. Calendar: Displays upcoming meetings from your smartphone calendar. Music controls: Provides music player controls for your smartphone. Weather: Displays the current temperature and weather forecast. Activity Tracking: Tracks your daily step count, step goal, distance traveled, calories burned, and sleep statistics. Sensor Information: Displays information from an internal sensor or a connected ANT+ ® sensor. Viewing Widgets From the time of day screen, select or . Smart Features5 DRAFT Downloadable Features You can download Connect IQ ™ features such as apps, widgets, and watch faces from Garmin ® and other providers using the Garmin Connect Mobile app. Bluetooth Connected Features The device has several Bluetooth connected features for your compatible smartphone or mobile device using the Garmin Connect Mobile app. For more information, go to www.garmin.com/intosports/apps. LiveTrack: Allows friends and family to follow your races and training activities in real time. You can invite followers using email or social media, allowing them to view your live data on a Garmin Connect tracking page. Activity uploads: Automatically sends your activity to Garmin Connect Mobile as soon as you finish recording the activity. Social media interactions: Allows you to post an update to your favorite social media website when you upload an activity to Garmin Connect Mobile. Physiological Measurements The following physiological measurements require a compatible heart rate monitor. These estimates can help you track and understand your training runs and race performances. NOTE: The estimates may seem inaccurate at first. The device requires a few runs to learn about your running performance. For more information, see your owner's manual. VO2 max.: VO2 max. is the maximum volume of oxygen (in milliliters) you can consume per minute per kilogram of body weight at your maximum performance. 6Physiological Measurements DRAFT Predicted race times: Your device uses the VO2 max. estimate and published data sources to provide a target race time based on your current state of fitness. This projection also presumes you have completed the proper training for the race. Recovery advisor: The recovery advisor displays how much time remains before you are fully recovered and ready for the next hard workout. History History includes time, distance, calories, average pace or speed, lap data, and optional ANT+ sensor information. NOTE: When the device memory is full, your oldest data is overwritten. Viewing History 1 Select Menu > History > Activities. 2 Select or to view your saved activities. 3 Select an activity. 4 Select an option: • Select Details to view additional information about the activity. • Select Laps to select a lap and view additional information about each lap. • Select Delete to delete the selected activity. Using Garmin Connect You can upload all of your activity data to Garmin Connect for comprehensive analysis. With Garmin Connect, you can view a map of your activity, and share your activities with friends. 1 Connect the device to your computer using the USB cable. History7 DRAFT 2 Go to www.garminconnect.com/start. 3 Follow the on-screen instructions. Garmin Connect You can connect with your friends on Garmin Connect. Garmin Connect gives …

Text truncated - open the document above for the full version.

September 5, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-A2758 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 FCC Rules: Parts 2 and 15C To Whom It May Concern: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. Permanent Garmin International, Inc. requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics AA2758 Conf Schem.pdf Block diagram AA2758 Conf BlkDia.pdf Operational Description AA2758 Conf OpDes.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

September 5, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Short-term Confidentiality request for submittal information regarding FCC ID: IPH-A2758 FCC Rules: Parts 2 and 15C Dear Sirs: Garmin International, Inc. requests that the following information be withheld from public disclosure pursuant to CFR47 paragraphs 0.457 and 0.459, and KDB 726920 until 45 days after the Grant of Equipment Authorization. Disclosure of information would offer competitors additional unwarranted insight into the state of the product development. Short-term confidential files Exhibit File External Photos AA2758 Short Term Conf ExtPho.pdf Internal Photos AA2758 Short Term Conf IntPho.pdf Test Setup Photos AA2758 Short Term Conf TSup.pdf User Manual AA2758 Short Term Conf UserMan.pdf User Manual AA2758 Short Term Conf UserMan 1.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 +1 913 837-3214

Page 1 of 2 September 5, 2015 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-A2758 PRODUCT: Transmitter operated under 47CFR Section 15C Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES AA2758 Conf BlkDia.pdf AA2758 Conf OpDes.pdf AA2758 Conf Schem.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID: IPH-A2758 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 (15C), RSS-210 Date: September 5, 2015 Revision 1 File: AA2758 Short Term Conf ExtPho Page 1 of 1 External photographs of equipment under test

E-Label Description User manual information is as follows: Viewing Device Information You can view the unit ID, software version, regulatory information, and license agreement. 1. From the clock, hold UP. 2. Select Settings > System > About. From the “About” page, perform the following steps: Step #1: Press the down key Step #2: Press the down key The following information will be displayed:

Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 (15C), RSS-210 Date: September 5, 2015 Revision 1 File: AA2758 Short Term Conf IntPho Page 1 of 1

Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 (15C), RSS-210 Date: September 5, 2015 Revision 1 File:AA2758 TunPro Page 1 of 1 Tune-up Procedure Each unit is tested during unit production by measuring the output strength. The unit is then given pass/fail status based on the measured output strength. The pass/fail threshold is determined by engineering during product development. Compliant samples continue through production and non-compliant units are removed.

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 15C Date: September 8, 2015 Revision 1 File: Garmin AA2758 FCC TstRpt 150715 Page 1 of 42 Application For Grant of Certification FOR FOR Model: AA2758 2402-2480 MHz Low Power Transmitter FCC ID: IPH-A2758 IC: 1792A-A2758 FOR Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Test Report Number: 150715 IC Test Site Registration: 3041A-1 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 15C Date: September 8, 2015 Revision 1 File: Garmin AA2758 FCC TstRpt 150715 Page 2 of 42 Engineering Test Report For Grant of Certification Application FOR 47 CFR, PART 15C - Intentional Radiators 47 CFR Paragraph 15.249 License Exempt Intentional Radiator For Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Model: AA2758 Low Power Transmitter Frequency Range 2402-2480 MHz FCC ID#: IPH-A2758 IC: 1792A-A2758 Test Date: July 15, 2015 Certifying Engineer: Scot D. Rogers Rogers Labs, Inc. 4405 West 259 th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. SN: 63494 4405 W. 259th Terrace Model: AA2758 FCC ID#: IPH-A2758 Louisburg, KS 66053 Test #: 150715 IC: 1792A-A2758 Phone/Fax: (913) 837-3214 Test to: CFR47 15C Date: September 8, 2015 Revision 1 File: Garmin AA2758 FCC TstRpt 150715 Page 3 of 42 Table Of Contents TABLE OF CONTENTS ....................................................................................................... 3 REVISIONS .......................................................................................................................... 4 FORWARD .......................................................................................................................... 5 OPINION / INTERPRETATION OF RESULTS .................................................................... 5 EQUIPMENT TESTED ......................................................................................................... 5 EQUIPMENT FUNCTION AND CONFIGURATION............................................................. 6 Equipment Configuration........................................................................................................................................... 7 APPLICATION FOR CERTIFICATION ................................................................................ 8 APPLICABLE STANDARDS & TEST PROCEDURES ....................................................... 9 EQUIPMENT TESTING PROCEDURES ............................................................................. 9 AC Line Conducted Emission Test Procedure ......................................................................................................... 9 Radiated Emission Test Procedure ............................................................................................................................ 9 Diagram 1 Test arrangement for Conducted emissions ............................................................................................ 10 Diagram 2 Test arrangement for radiated emissions of tabletop equipment ............................................................. 11 Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) .................................. 12 TEST SITE LOCATIONS ................................................................................................... 12 LIST OF TEST EQUIPMENT ............................................................................................. 13 UNITS OF MEASUREMENTS ........................................................................................... 14 ENVIRONMENTAL CONDITIONS..................................................................................... 14 INTENTIONAL RADIATORS ............................................................................................. 14 Antenna Requirements ............................................................................................................................................. 14 Restricted Bands of Operation ................................................................................................................................. 14 Table 1 Radiated Emissions in Restricted Frequency Bands Data ........................................................................... 15 Summary of Results for Radiated Emissions in Restricted Bands ....................................................................... 15 AC Line Conducted EMI Procedure ....................................................................................................................... 16 Figure 1 AC Line Conducted emissions of EUT line 1 (EUT-USB-CPU AC Adapter) .......................................... 17 Figure 2 AC Line Conducted emissions of EUT line 2 (EUT-USB-CPU AC Adapter) .......................................... 17 Figure 3 AC Line Conducted emissions of EUT line 1 (EUT AC Adapter SCB055600P) ...................................... 18 Figure 4 AC Line Conducted emissions of EUT line 2 (EUT AC Adapter SCB055600P) ...................................... 18 Figure 5 AC Line Conducted emissions of EUT line 1 (EUT AC Adapter 326-00072-00) ..................................... …
