IPH-F4XRGTDigital transmission System (2412-24626MHz)

F4XRGT00 WARNING See the Important Safety and Product Information guide in the GPS device product box for product warnings and other important information. Always consult your physician before you begin or modify any exercise program. Getting Started When using your device for the first time, you must complete these tasks to set up the device and learn about the basic features. 1 Charge the device (page 10). 2 Put on the optional monitor (page 11). 3 Use the device (page 3). 4 Upload to Garmin Connect™ (page 6). 5 Register your device (page 15). 6 Get more information (page 16). DRAFT Keys À Select to turn the backlight on and off. Hold to turn the device on and off. Á Select to scroll through activity profiles, menus, summary details, and settings. Hold to scroll quickly through the settings. Select to scroll through training pages during an activity. Â ENTER Select to start and stop the timer. DRAFT Ã BACK Select to mark a new lap. Select to return to the previous screen. Hold to return to the time of day screen and lock the device. Ä Select to switch between the activity screen, main menu, and timer screen. Hold to send your activity to Garmin Connect. Status Icons Icons appear at the top of the activity profile and training screens. A flashing icon means the device is searching for a signal. A solid icon means the signal was found or the sensor is connected. GPS status Transmitter technology status Transmitter technology status Sensor status Sensor status Sensor status Power status Using the device The first fitness activity you record on your device can be a any outdoor activity. The device comes partially charged. You may need to charge the device (page 10) before using. DRAFT 1 Hold to turn on the device. 2 Select and to view the activity profiles. 3 Select ENTER. The activity profile is active, and the timer page appears. 4 Go outside, and wait while the device locates satellites. It may take a few minutes to locate satellite signals. The satellite bars turn green. 5 Select to start the timer. 6 Start your activity. 7 After you complete your activity, select to stop the timer. 8 Select Save to save the activity and reset the timer. A summary appears. NOTE: You can upload your activity to Garmin Connect (page 6). Training When you participate in training, you can use the tr aining activity profile to quickly transition to each segment. 1 Select > Training. DRAFT 2 Select to start the timer. 3 Select at the beginning and end of each transition. 4 After you complete your activity, select > Save. You can record your data including distance, pace, stroke count, and stroke type. 1 Select > m. 2 Select to start the timer. 3 Select at the beginning and end of each event. 4 After you complete your activity, select > Save. DRAFT Garmin Connect You can connect with your friends on Garmin Connect. Garmin Connect gives you the tools to track, analyze, share, and encourage each other. Record the events of your device. To sign up for a free account, go to www.garminconnect.com/start. Store your activities : After you complete and save an activity with your device, you can upload that activity to Garmin Connect and keep it as long as you want. DRAFT 1 Connect the device to your computer using the USB cable. 2 Go to www.garminconnect.com /start. 3 Follow the on-screen instructions. DRAFT Your device attempts to upload your saved activity to the Garmin Connect website following each activity. You can also hold on your device to start uploading your saved activities. Charging the Device WARNING This device contains a lithium-ion battery. See the Important Safety and Product Information guide in the product box for product warnings and other important information. NOTICE To prevent corrosion, thoroughly dry the contacts and the surrounding area before charging or connecting to a computer. 1 Plug the USB cable into a USB port on your computer. 2 Align the charger posts with the contacts on the device, and connect the charging clip À securely to the device. 3 Charge the device completely. 4 Remove the charger. DRAFT History NOTE: When the device memory is full, your oldest data is overwritten. Viewing History 1 Select > History > Activities. 2 Select an activity. 3 Select an option: • Select Details to view additional information about the activity. • Select Laps to select a lap and view additional information about each lap. • Select Delete to delete the selected activity. Troubleshooting Support and Updates Garmin Express provides easy access to these services for Garmin devices. • Product registration • Product manuals • Software updates DRAFT Getting More Information • Go to www.garmin.com/intosports. • Go to www.garmin.com/learningcenter . • Go to http://buy.garmin.com, or contact your Garmin dealer for information about optional accessories and replacement parts. Getting the Owner's Manual You can get the latest owner's manual from the web. 1 Go to www.garmin.com/support. 2 Select Manuals. 3 Follow the on-screen instructions to select your product. Resetting the Device If the device stops responding, you may need to reset it. This does not erase any of your data or settings. 1 Hold for 15 seconds. The device turns off. 2 Hold for one second to turn on the device. Clearing User Data You can restore all of the device settings to the factory default values. NOTE: This deletes all user-entered information, but it does not delete your history. 1 Hold . 2 Select Yes to turn off the device. 3 While holding , hold to turn on the device. 4 Select Yes. DRAFT Temperature Specifications O perating temperature range: From -20º to 60ºC (from -4º to 140ºF) Charging temperature range: From 0º to 40ºC (from 32º to 104ºF) DRAFT Garmin ® and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. Garmin Connect™, and Garmin Express™ are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. Othe…

Text truncated - open the document above for the full version.

Important Safety and Product Information........................ 2 Informations importantes sur le produit et la sécurité ....... 6 Información importante sobre el producto y tu seguridad........................................................................ 11 DRAFT Important Safety and Product Information WARNING Failure to avoid the following potentially hazardous situations could result in an accident or collision resulting in death or serious injury. Health Warnings • Always consult your physician before beginning or modifying any exercise program. If you have a pacemaker or other implanted electronic device, consult your physician before using a heart rate monitor. • The device, the heart rate monitor, and other Garmin ® accessories are consumer devices, not medical devices, and could suffer from interference from external electrical sources. The heart rate readings are for reference only, and no responsibility is accepted for the consequences of any erroneous readings. Off-Road Navigation Warnings If your Garmin device is able to suggest off-road routes for various outdoor activities, such as biking, hiking, and all-terrain vehicles, follow these guidelines to ensure safe off-road navigation. • Always use your best judgment and exercise common sense when making off-road navigational decisions. The Garmin device is designed to provide route suggestions only. It is not a replacement for attentiveness and proper preparation for outdoor activities. Do not follow the route suggestions if they suggest an illegal course or would put you in an unsafe situation. • Always carefully compare information displayed on the device to all available navigation sources, including trail signs, trail conditions, weather conditions, and other factors that may affect safety while navigating. For safety, always resolve any discrepancies before continuing navigation, and defer to posted signs and conditions. • Always be mindful of the effects of the environment and the inherent risks of the activity before embarking on off-road activities, especially the impact that weather and weather- related trail conditions can have on the safety of your activity. Ensure that you have the proper gear and supplies for your activity before navigating along unfamiliar paths and trails. Battery Warnings A lithium-ion battery can be used in this device. Coin cell batteries can be used in the accessory. If these guidelines are not followed, batteries may experience a shortened life span or may present a risk of damage to the device, fire, chemical burn, electrolyte leak, and/or injury. 2 DRAFT • Do not leave the device exposed to a heat source or in a high-temperature location, such as in the sun in an unattended vehicle. To prevent the possibility of damage, remove the device from the vehicle or store it out of direct sunlight, such as in the glove box. • Do not disassemble, modify, remanufacture, puncture or damage the device or batteries. • Do not immerse or expose the device or batteries to water or other liquids, fire, explosion, or other hazard. • Never put batteries in mouth. If swallowed, contact a physician or poison control center. • Replaceable coin cell batteries may contain perchlorate material. Special handling may apply. See www.dtsc.ca.gov /hazardouswaste/perchlorate. • Do not use a power and/or data cable that is not approved or supplied by Garmin. • Do not operate the device outside of the temperature ranges specified in the printed manual in the product packaging. • When storing the device for an extended time period, store within the temperature ranges specified in the printed manual in the product packaging. • Do not remove or attempt to remove the non-user- replaceable battery. • Contact your local waste disposal department to dispose of the device/batteries in accordance with applicable local laws and regulations. Product Environmental Programs Information about the Garmin product recycling program and WEEE, RoHS, REACH, and other compliance programs can be found at www.garmin.com/aboutGarmin/environment. Industry Canada Compliance Category I radiocommunication devices comply with Industry Canada Standard RSS-210. Category II radiocommunication devices comply with Industry Canada Standard RSS-Gen. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. FCC Compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate 3 DRAFT radio frequency energy and may cause harmful interference to radio communications if not installed and used in accordance with the instructions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet that is on a different circuit from the GPS device. • Consult the dealer or an experienced radio/TV technician for help. This product does not contain any user-serviceable parts. Repairs should only be made by an …

Text truncated - open the document above for the full version.

Page 1 of 2 September 3, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-F4XRGT Product: Unlicensed Transmitter operated under paragraph 15C Dear Sirs: Garmin International, Inc. requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES Conf BlkDia F4XRGT00.pdf Conf OpDes F4XRGT00.pdf Conf Schem F4XRGT00.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-F4XRGT 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

September 11, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Short-term Confidentiality request for submittal information regarding FCC ID: IPH-F4XRGT FCC Rules: Parts 2 and 15C Dear Sirs: Garmin International, Inc. requests that the following information be withheld from public disclosure pursuant to CFR47 paragraphs 0.457 and 0.459, and KDB 726920 until 45 days after the Grant of Equipment Authorization. Disclosure of information would offer competitors additional unwarranted insight into the state of the product development. Short-term confidential files Exhibit File External Photos Short Term Conf ExtPho F4XRGT00.pdf External Photos Short Term Conf Garmin 1300 SAR Report FCC-IC R1.0 Part 2 of 3 Photos Internal Photos Short Term Conf IntPho F4ACGQ0 Test Setup Photos Short Term Conf TSup F4XRGT00.pdf User Manual Short Term Conf UserMan F4XRGT00 1.pdf User Manual Short Term Conf UserMan F4XRGT00 2.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 +1 913 837-3214

September 3, 2014 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-F4XRGT 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 FCC Rules: Parts 2 and 15C To Whom It May Concern: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. Permanent Garmin International, Inc. requests that the material in the Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics Conf Schem F4XRGT00.pdf Block diagram Conf BlkDia F4XRGT00.pdf Operational Description Conf OpDes F4XRGT00.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Garmin International, Inc. SN: 3885910507bw 4405 W. 259th Terrace Model: F4XRGT00 FCC ID#: IPH-F4XRGT Louisburg, KS 66053 Test #: 140716 IC: 1792A-F4XRGT Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247), RSS-210 Date: September 3, 2014 Revision 1 File: Short Term Conf ExtPho F4XRGT00 Page 1 of 3 External photographs of equipment under test Rogers Labs, Inc. Garmin International, Inc. SN: 3885910507bw 4405 W. 259th Terrace Model: F4XRGT00 FCC ID#: IPH-F4XRGT Louisburg, KS 66053 Test #: 140716 IC: 1792A-F4XRGT Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247), RSS-210 Date: September 3, 2014 Revision 1 File: Short Term Conf ExtPho F4XRGT00 Page 2 of 3 Rogers Labs, Inc. Garmin International, Inc. SN: 3885910507bw 4405 W. 259th Terrace Model: F4XRGT00 FCC ID#: IPH-F4XRGT Louisburg, KS 66053 Test #: 140716 IC: 1792A-F4XRGT Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247), RSS-210 Date: September 3, 2014 Revision 1 File: Short Term Conf ExtPho F4XRGT00 Page 3 of 3

Label Diagram and Placement Label is located on outer back surface of device. Text is 4 point font or larger.

Rogers Labs, Inc. Garmin International, Inc. SN: 3885910507bw 4405 W. 259th Terrace Model: F4XRGT00 FCC ID#: IPH-F4XRGT Louisburg, KS 66053 Test #: 140716 IC: 1792A-F4XRGT Phone/Fax: (913) 837-3214 Test to: CFR47 (15.247), RSS-210 Date: September 16, 2014 Revision 1 File: Short Term Conf IntPho F4XRGT00 Page 1 of 1 Internal Photographs

Applicant: Garmin International Inc. FCC ID: IPH-F4XRGT IC: 1792A-F4XRGT Model: DUT Type: Wireless GPS Device 2014 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 34 Date(s) of Evaluation July 29-31, 2014 Test Report Serial No. 071114IPH-1300-SNA Test Report Revision No. Rev. 1.1 (2 nd Release) Test Report Issue Date September 15, 2014 Description of Test(s) Specific Absorption Rate RF Exposure Category Gen. Pop. / Uncontrolled Test Lab Certificate No. 2470.01 . DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION - FCC / IC Original Filing Name CELLTECH LABS INC. TEST LAB INFORMATION Address 21-364 Lougheed Road, Kelowna, B.C. V1X 7R8 Canada TEST LAB ACCREDITATION Type ISO / IEC 17025 Accreditation A2LA Test Lab Certificate No. 2470.01 Name GARMIN INTERNATIONAL INC. APPLICANT INFORMATION Address 1200, East 151 st Street, Olathe, KS, 66062 USA STANDARDS APPLIED FCC 47 CFR §2.1093 IC Health Canada Safety Code 6 FCC KDB 447498 D01v05r02, KDB 865664 D01v01r03 IC RSS102 Issue 4 FCC KDB 865664 D02v01r01, KDB 643646 D01v01r01 IEC 62209-1:2005 PROCEDURES APPLIED IEEE IEEE 1528-2013 IEC 62209-2:2010 FCC Digital Transmission System (DTS) - §15 Subpart C FCC Unlicensed National Information Infrastructure TX (NII) - §15 Subpart E DEVICE CLASSIFICATION IC Low Power License-Exempt Radiocommunication Device (RSS-210 Issue 8) DEVICE DESCRIPTION Wireless GPS Device APPLICATION TYPE Original Filing DATE(S) OF EVALUATION July 29-31, 2014 SAMPLES RECEIVED July 11, 2014 DEVICE IDENTIFIERS FCC ID IPH- F4XRGT IC ID 1792A- F4XRGT TEST SAMPLE S/N 3885910496bw Devices Tested Model Internal Transmitters Data Rates Frequency Range Manufacturer's Rated Output Power 802.11b/g 1Mbps 2412-2462 MHz dBm 802.15 2400-2483 MHz Antennas Tested Batteries Tested Internal Li-ion EVALUATION RESULTS Maximum SAR Level Evaluated FCC Body 0.003 FCC/IC SAR Limit Maximum SAR Level Evaluated IC Body 0.003 W/kg 1g 1.6 W/kg General Public / Uncontrolled Celltech Labs Inc. declares under its sole responsibility that this wireless portable device has demonstrated compliance with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada Safety Code 6 for the General Population / Uncontrolled Exposure environment. The device was tested in accordance with the measurement procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 4, IEEE Standard 1528-2013 and International Standard IEC 62209-2:2010. All measurements were performed in accordance with the SAR system manufacturer recommendations. ***** This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. ***** The results and statements contained in this report pertain only to the device(s) evaluated I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Test Report Approved By Art Voss, P.Eng. Senior Engineer Celltech Labs Inc. Applicant: Garmin International Inc. FCC ID: IPH-F4XRGT IC: 1792A-F4XRGT Model: DUT Type: Wireless GPS Device 2014 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 34 Date(s) of Evaluation July 29-31, 2014 Test Report Serial No. 071114IPH-1300-SNA Test Report Revision No. Rev. 1.1 (2 nd Release) Test Report Issue Date September 15, 2014 Description of Test(s) Specific Absorption Rate RF Exposure Category Gen. Pop. / Uncontrolled Test Lab Certificate No. 2470.01 TABLE OF CONTENTS 1.0 INTRODUCTION ______________________________________________ 4 2.0 SAR MEASUREMENT SYSTEM _________________________________ 4 3.0 CONDUCTED OUTPUT POWER MEASUREMENTS _________________ 5 4.0 DUTY CYCLE MEASUREMENT__________________________________ 6 5.0 FLUID DIELECTRIC PARAMETERS ______________________________ 7 6.0 SAR MEASUREMENT SUMMARY________________________________ 8 7.0 SAR SCALING FOR TUNE-UP TOLERANCE _______________________ 9 8.0 SIMULTANEOUS TRANSMISSION ASSESSMENT __________________ 9 9.0 DETAILS OF SAR EVALUATION________________________________ 10 10.0 SAR EVALUATION PROCEDURES_____________________________ 10 11.0 SYSTEM VERIFICATION _____________________________________ 11 12.0 SIMULATED EQUIVALENT TISSUES ___________________________ 12 13.0 SAR LIMITS________________________________________________ 12 14.0 ROBOT SYSTEM SPECIFICATIONS ____________________________ 13 15.0 PROBE SPECIFICATION (EX3DV4) ____________________________ 14 16.0 SAM TWIN PHANTOM V4.0C _________________________________ 14 17.0 DEVICE HOLDER ___________________________________________ 14 18.0 TEST EQUIPMENT LIST _____________________________________ 15 19.0 MEASUREMENT UNCERTAINTY (IEC 62209-2) __________________ 16 20.0 REFERENCES _____________________________________________ 17 APPENDIX A - SAR MEASUREMENT PLOTS _________________________ 18 APPENDIX B - SYSTEM PERFORMANCE CHECK PLOTS ______________ 23 APPENDIX C - MEASURED FLUID DIELECTRIC PARAMETERS _________ 26 APPENDIX D - SAR TEST SETUP & DUT PHOTOGRAPHS______________ 27 APPENDIX E - DIPOLE CALIBRATION ______________________________ 32 APPENDIX F - PROBE CALIBRATION_______________________________ 33 APPENDIX G - SAM PHANTOM CERTIFICATE OF CONFORMITY ________ 34 Applicant: Garmin International Inc. FCC ID: IPH-F4XRGT IC: 1792A-F4XRGT Model: DUT Type: Wireless GPS Device 2014 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 3 of 34 Date(s) of Evaluation July 29-31, 2014 Test Report Serial No. 071114IPH-1300-SNA Test Report Revision No. Rev. 1.1 (2 nd Release) Test Report Is…

Text truncated - open the document above for the full version.

Applicant: Garmin International Inc. FCC ID: IPH-F4XRGT IC: 1792A-F4XRGT Model: DUT Type: Wireless GPS Device 2014 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 32 of 34 Date(s) of Evaluation July 29-31, 2014 Test Report Serial No. 071114IPH-1300-SNA Test Report Revision No. Rev. 1.1 (2 nd Release) Test Report Issue Date September 15, 2014 Description of Test(s) Specific Absorption Rate RF Exposure Category Gen. Pop. / Uncontrolled Test Lab Certificate No. 2470.01 APPENDIX E - DIPOLE CALIBRATION Date: May 2, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Dipole: D2450V2 Serial Number: 825 Last Calibrated: Apr. 25, 2012 Antenna Parameters with Head TSL Impedance Real (ohms) Deviation from cal Impedance Imaginary (ohms) Deviation from cal Return Loss (dB) Deviation from Cal Last Calibration 53.0 - +5.5 - -24.3 - Extended Cal Jul 10, 2013 53.0 0 +7.5 2.0 -22.3 8.2% Extended Cal Jun 12, 2014 53.4 0.4 +6.3 0.8 -23.2 -4.5% Antenna Parameters with Body TSL Impedance Real (ohms) Deviation from cal (ohms) Impedance Imaginary (ohms) Deviation from cal (ohms) Return Loss (dB) Deviation from Cal (%) Last Calibration 50.4 - +6.1 - -24.3 - Extended Cal Jun 17, 2013 49.0 1.4 +7.9 1.8 -21.3 12.3% Extended Cal May 2, 2014 49.3 1.1 +7.5 1.4 -22.3 -8.2% Date: May 2, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Head TSL Date: May 2, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Body TSL Date: May 2, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Head TSL Date: Jun 12, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Dipole: D2450V2 Serial Number: 825 Last Calibrated: Apr. 25, 2012 Antenna Parameters with Head TSL Impedance Real (ohms) Deviation from cal Impedance Imaginary (ohms) Deviation from cal Return Loss (dB) Deviation from Cal Last Calibration 53.0 - +5.5 - -24.3 - Extended Cal Jul 10, 2013 53.0 0 +7.5 2.0 -22.3 8.2% Extended Cal Jun 12, 2014 53.4 0.4 +6.3 0.8 -23.2 -4.5% Antenna Parameters with Body TSL Impedance Real (ohms) Deviation from cal (ohms) Impedance Imaginary (ohms) Deviation from cal (ohms) Return Loss (dB) Deviation from Cal (%) Last Calibration 50.4 - +6.1 - -24.3 - Extended Cal Jun 17, 2013 49.0 1.4 +7.9 1.8 -21.3 12.3% Date: Jun 12, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Head TSL Date: Jun 12, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Body TSL Date: Jun 12, 2014 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Antenna VSWR with Head TSL Date: Jul 17, 2013 Revision No. Rev. 1.1 2450 MHz Dipole Extended Calibration Test Lab Certificate No. 2470.01 Dipole: D2450V2 Serial Number: 825 Last Calibrated: Apr. 25, 2012 Antenna Parameters with Head TSL Impedance Real (ohms) Deviation from cal Impedance Imaginary (ohms) Deviation from cal Return Loss (dB) Deviation from Cal Last Calibration 53.0 - +5.5 - -24.3 - Extended Cal Jul 10, 2013 53.0 0 +7.5 2.0 -22.3 8.2% Antenna Parameters with Body TSL Impedance Real (ohms) Deviation from cal (ohms) Impedance Imaginary (ohms) Deviation from cal (ohms) Return Loss (dB) Deviation from Cal (%) Last Calibration 50.4 - +6.1 - -24.3 - Extended Cal Jun 17, 2013 49.0 1.4 +7.9 1.8 -21.3 12.3% Applicant: Garmin International Inc. FCC ID: IPH-F4XRGT IC: 1792A-F4XRGT Model: DUT Type: Wireless GPS Device 2014 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior w…
