IPH-O2AWGDLOW POWER TRANSMITTER (2400-2483.5 MHz)

TITLE SIZE PART NO: REV : SCALE Sht. Of Dimensions and drawings for reference only. Drawings are not to scale. Trimmed and bound dimensions Cover 5.15" 2.4" Specifications 1. Description Product documentation: Fenix Quick Start Manual (EN-US) 2. Size Trimmed and bound: Width = 2.4”, Height = 5.15”. 3. Tolerance ±0.0787” (±2 mm) 4. Pagination 16 pages 5. Material 120-lb matte-finish of fset. Approved Equivalents Allowed. 6. Finish Matte 7. Color 4-color process 8. Bindery Saddle-stitched. 9. Folds N/A 10. Electronic Artwork Shall conform to Garmin Archive 190-01507-01_01.zip 1 1. Languages EN-US 12. Notes This part shall comply with Garmin Banned & Restricted Substances (GPN 001-00211-00). Files The following files have been archived under the above ARCHIVE FILENAME. File NameFile Contents 190-01507_01_01_Spec.inddInDesign CS4 for PC, document specification sheet 190-01507_01_01.pdfPortable Document Format, manual and specification sheet fenix_QSM_WEB_EN.pdfPortable Document Format, for online SPECIFICATION CONTROL DRAWING Revisions Rev. DateDescriptionECO No. 16/12/12Experimental Release– – – – CONFIDENTIAL This drawing and the specifications contained herein are the property of Garmin Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. Garmin Ltd. or its subsidiaries C/O Garmin International, Inc. 1200 E. 151st Street Olathe, Kansas 66062 U.S.A. InitialsDateFenix Quick Start Manual (EN-US) Drawn By: SMW6/12/12 A190-01507-011 Checked By: Project Manager: N/A Approved By: 117 fēnix™ Quick Start Manual WARNING See the Important Safety and Product Information guide in the product box for product warnings and other important information. WARNING Always consult your physician before you begin or modify any exercise program. Getting Started When using your device the first time, you should complete these tasks to set up the device and get to know the basic features. 1 Charge the device (page 2). 2 Register the device ( page 13). 3 Learn about the sensor data and modes (page 4). 4 Acquire satellites (page 7). 5 Go for a hike (page 8). 6 Create a waypoint (page 9). 7 Get the owner's manual (page 12). Charging the Device NOTICE To prevent corrosion, thoroughly dry the contacts and the surrounding area before charging or connecting to a computer. The device is powered by a built-in lithium-ion battery that you can charge using a standard wall outlet or a USB port on your computer. 1 Plug the USB end of the cable into the AC adapter or a computer USB port. 2 Plug the AC adapter into a standard wall outlet. 3 Align the left side of the charging cradle  with the groove on the left side of the device. 4 Align the hinged side of the charger  with the contacts on the back of the device. When you connect the device to a power source, the device turns on. 2 5 Charge the device completely. Keys  Select to turn the backlight on and off. Hold to turn the device on and off.  Select to scroll through the data pages, options, and settings. On the map, select to zoom out.  Select to scroll through the data pages, options, and settings. On the map, select to zoom in.  Select to return to the previous screen.  Orange key Select to open the menu for the current screen. Select to choose an option and to acknowledge a message. Hold to mark a waypoint. 3 Viewing the Status Page You can quickly switch to this page to view the time of day, battery life, and GPS status information from any other page. Hold . After five seconds the display automatically switches back to the previous page. Viewing the Sensor Data You can quickly access real-time data for the compass, altimeter, barometer, and temperature sensors. NOTE: These data pages automatically time out to low-power mode. NOTE: This data is not recorded to the device (page 7). 1 From the time of day page, select or . 4 2 Select . 3 Select . 4 Select . 5 NOTE: Your body temperature affects the temperature sensor. To get the most accurate temperature reading, remove the device from your wrist and wait 20–30 minutes. TIP: To purchase a tempe™ wireless temperature sensor, go to www.garmin.com. See the owner's manual for more information. Turning On a Sensor Mode You can put the device in compass, altimeter, barometer, or temperature mode to display continuous sensor data. For example, you can put the device in altimeter mode and continuously monitor elevation data. NOTE: If you have an optional heart rate or cadence sensor paired with the device, the list will include those data modes. 1 Select the Orange key. 2 Select Compass, Altimeter, Barometer, or Temp.. 6 Acquiring Satellite Signals and Recording a Track Before you can use the GPS navigation features, such as recording a track, you must acquire satellite signals. The device may need a clear view of the sky to acquire satellite signals. The time and date are set automatically based on the GPS position. 1 Hold to turn on the device. 2 Select your language (first time only). 3 Select the Orange key. 4 Select GPS. 5 Wait while the device locates satellites. The device displays your coordinates when it has located satellites. 6 Select Start. 7 Walk around to record a track. Your distance and time appear. 8 Select to view the loop of data pages including compass data, altimeter data, ascent and speed, and the status page. You can customize some data pages. See the owner's manual (page 12). 9 Select to pause tracking. 10 Select an option: • Select Resume to continue tracking. • Select Save to save your track. • Select Clear to erase the track without saving. 7 Tracks A track is a recording of your path. The track log contains information about points along the recorded path, including time, location, and elevation for each point. Going for a Hike Before you go for a hike, you should charge the device completely ( page 2). NOTE: The device turns on automatically while charging. If you do not charge the device befor…

Text truncated - open the document above for the full version.

TITLE SIZE PART NO: REV: SCALE Sht. Of Dimensions and drawings for reference only. Drawings are not to scale. Trimmed and bound dimensions Cover ISPI 5.15" 2.4" Specifications 1. Description Product documentation: ISPI, Fitness Small (ML 12) 2. Size Trimmed and bound: Width = 2.4”, Height = 5.15”. 3. Tolerance ±0.0787” (±2 mm) 4. Pagination 56 pages 5. Material White 80-lb wood-free, white 6. Finish None 7. Color black and white 8. Bindery Saddle-stitched. 9. Folds N/A 10. Electronic Artwork Shall conform to Garmin Archive 190-01450-92_0A.zip 11. Languages EN, FR, IT, DE, ES, PT, NL, DA, FI, NO, SV, PL 12. Notes This part shall comply with Garmin Banned & Restricted Substances (GPN 001-00211-00). Files The following files have been archived under the above ARCHIVE FILENAME. File NameFile Contents 190-00720-43_0A.inddInDesign CS4 for PC, formatted manual 190-00720-43_0A_Spec.inddInDesign CS4 for PC, document specification sheet 190-00720-43_0A.pdfPortable Document Format, manual and specification sheet ISPI_fitness_small_ML12.pdfPortable Document Format, for online LinksGraphic files (eps, bmp, etc.) FontsFont files SPECIFICATION CONTROL DRAWING Revisions Rev.DateDescriptionECO No. A5/18/12Initial Release– – – – CONFIDENTIAL This drawing and the specifications contained herein are the property of Garmin Ltd. or its subsidiaries and may not be reproduced or used in whole or in part as the basis for manufacture or sale of products without written permission. Garmin Ltd. or its subsidiaries C/O Garmin International, Inc. 1200 E. 151st Street Olathe, Kansas 66062 U.S.A. InitialsDateISPI, Fitness, small (ML 12) Drawn By: SMW5/18/12 A190-00720-43A Checked By: Project Manager: N/A Approved By: 157 Important Safety and Product Information ..........................2 Informations importantes relatives au produit et à la sécurité ......................7 Informazioni importanti sulla sicurezza e sul prodotto..................12 Wichtige Sicherheits- und Produktinformationen .....................17 Información importante sobre el producto y tu seguridad ..................22 Informações importantes de segurança e do produto..................26 Belangrijke veiligheids- en productinformatie ............................31 Vigtige produkt- og sikkerhedsinformationer .................35 Tärkeitä turvallisuus- ja tuotetietoja ......................................39 Viktig sikkerhets- og produktinformasjon .........................43 Viktig säkerhets- och produktinformation ..........................47 Ważne informacje dotyczące bezpieczeństwa i produktu .............51 ISPI_small.INDD 15/18/2012 10:41:01 AM 2 Important Safety and Product Information  WARNING Failuretoavoidthefollowingpotentiallyhazardous situationscouldresultindeathorseriousinjury. Off-Road Navigation Warnings SomeGarminrecreationalproductsareabletosuggest off-roadroutesforvariousoutdooractivities,suchas biking,hiking,andall-terrainvehicles.Followthese guidelinestoensuresafeoff-roadnavigation. •Alwaysuseyourbestjudgmentandexercise commonsensewhenmakingoff-roadnavigational decisions.TheGarmindeviceisdesignedtoprovide routesuggestionsonly.Itisnotareplacementfor attentivenessandproperpreparationforoutdoor activities.Do not follow the route suggestions if they suggest an illegal course or would put you in an unsafe situation. •Alwayscarefullycompareinformationdisplayedonthe devicetoallavailablenavigationsources,including trailsigns,trailconditions,weatherconditions,and otherfactorsthatmayaffectsafetywhilenavigating. Forsafety,alwaysresolveanydiscrepanciesbefore continuingnavigation,anddefertopostedsignsand conditions. •Alwaysbe mindfulof the effectsof the environmentand theinherentrisksoftheactivitybeforeembarkingon off-roadactivities,especiallytheimpactthatweather andweather-relatedtrailconditionscanhaveonthe safetyofyouractivity.Ensurethatyouhavetheproper gearandsuppliesforyouractivitybeforenavigating alongunfamiliarpathsandtrails. Health Warnings •Alwaysconsultyourphysicianbeforebeginning ormodifyinganyexerciseprogram.Ifyouhavea pacemakerorotherimplantedelectronicdevice, consultyourphysicianbeforeusingaheartrate monitor. •Thedevice,theheartratemonitor,andotherGarmin accessoriesareconsumerdevices,notmedical devices,andcouldsufferfrominterferencefrom externalelectricalsources.Theheartratereadingsare ISPI_small.INDD 25/18/2012 10:41:01 AM 3 forreferenceonly,andnoresponsibilityisacceptedfor theconsequencesofanyerroneousreadings. Battery Warnings Iftheseguidelinesarenotfollowed,theinternallithium- ionbatterymayexperienceashortenedlifespanor maypresentariskofdamagetotheGPSdevice,fire, chemicalburn,electrolyteleak,and/orinjury. •Donotleavethedeviceexposedtoaheatsourceorin ahigh-temperaturelocation,suchasinthesuninan unattendedvehicle.Topreventdamage,removethe devicefromthevehicleorstoreitoutofdirectsunlight, suchasintheglovebox. •Donotpunctureorincineratethedeviceorbattery. •Whenstoringthedeviceforanextendedtime,store withinthefollowingtemperaturerange:from32°Fto 77°F(from0°Cto25°C). •Donotoperatethedeviceoutsideofthefollowing temperaturerange:from-4°Fto122°F(from-20°C to50°C). •Contactyourlocalwastedisposaldepartmentto disposeofthedevice/batteryinaccordancewith applicablelocallawsandregulations. Additional User-Replaceable Battery Warnings: •Donotuseasharpobjecttoremovethebattery. •Keepthebatteryawayfromchildren. •Donotdisassemble,puncture,ordamagethebattery. •Ifusinganexternalbatterycharger,onlyusethe Garminaccessoryapprovedforyourproduct. •Onlyreplacethebatterywiththecorrectreplacement batter…

Text truncated - open the document above for the full version.

Page 1 of 2 July 21, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. 1200 East 151st Street Olathe, KS 66062 Re: Confidentiality for submittal information regarding FCC ID number IPH-O2AWGD PRODUCT: Low power Transmitters operated under paragraph 15.249. Dear Sirs: Garmin International, Inc. requests that the material in the Parts List, Schematics, Block Diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. In support of this request, Garmin International, Inc. submits the following information. CONFIDENTIAL FILES Conf BlkDia O2AWGD00.pdf Conf OpDes O2AWGD00.pdf Conf Schem O2AWGD00.pdf 1. Identification of the specific information for which confidential treatment is sought: The materials set forth in the Operational Description, block diagram, parts list, and Schematics, which are segregated, from the non-confidential exhibits of the application, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: IPH-O2AWGD 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation, circuit diagrams, and schematic. As such, this material is treated as highly confidential business information. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 913 837-3214 Page 2 of 2 4. Explanation of the degree to which the information concerns a service that is subject to competition: The material for which confidentiality is sought is employed in the design and manufacture of this transmitting equipment that is offered on a highly competitive basis. Customers for this equipment have a variety of competing sources. 5. Explanation of how disclosure of the information could result in substantial competitive harm: Disclosure would, in effect, give away the fruits of the labors of Garmin International, Inc.’s engineering personnel, who have designed the equipment and the manufacturing process. Disclosure would also offer competitors additional unwarranted insight into the state of the product development, thereby allowing competitors an advantage, not available to Garmin International, Inc. 6. Identification of any measures taken by the submitting party to prevent unauthorized disclosure: The information for which confidential treatment is sought is kept confidential by Garmin International, Inc. and not made available to third parties except pursuant to non-disclosure agreements. 7. Identification of whether the information is available to the public and the extent of any previous disclosure of the information to third parties: To the knowledge of those preparing this application, the information has not been disclosed publicly heretofore. While the general theory of operation of this equipment has been the subject of numerous disclosures in industry and standards groups as well as in rule making proceedings of the FCC, the protection sought is narrowly drawn and pertains to certain specific implementations of this radio technology. 8. Justification of the period during which the submitting party asserts that the material should not be available for public disclosure: This material should not be disclosed for at least 25 years. While improvements in design are made relatively frequently, disclosure of the design information would lead to insights into both design and manufacturing techniques that could have an adverse competitive effect for many years to come. As such, it is important that the design not be made available to unauthorized persons who might attempt to use knowledge of the design to compromise the applications for which the equipment will be employed. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers

July 21, 2012 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Applicant: Garmin International, Inc. Equipment: FCC ID: IPH-O2AWGD 1200 East 151st Street CORES number: 0005-0885-88 Olathe, KS 66062 FCC Rules: Parts 2 and 15.249 To Whom It May Concern: The form 731 and application have been electronically submitted and any attachments will be up loaded to your web site for use in obtaining a grant of certification. Confidentiality is requested as outlined below. Permanent Garmin International, Inc. requests that the material in the Parts List, Schematics, block diagram, and Operational Description be withheld from public disclosure pursuant to Sections 0.457 and 0.459 of the Commission’s Rules following grant of the application. A statement of confidentiality will be attached with the application at the time of submittal. Exhibit File Schematics Conf Schem O2AWGD00.pdf Block diagram Conf BlkDia O2AWGD00.pdf Operational Description Conf OpDes O2AWGD00.pdf Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. Enclosures ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214

Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: ExtPho O2AWGD00 Page 1 of 3 External photographs of equipment under test Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: ExtPho O2AWGD00 Page 2 of 3 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: ExtPho O2AWGD00 Page 3 of 3

Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: LabelSmpl O2AWGD00 Page 1 of 1 ID label and location Label Location Label

Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: IntPho O2AWGD00 Page 1 of 2 Internal Photographs Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: IntPho O2AWGD00 Page 2 of 2

Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 21, 2012 Revision 1 File: TunPro O2AWGD00 Page 1 of 1 Tune-up Procedure No transmitter tune-up is required for the transceiver. Transceiver functional performance is measured both at the board level and at final test during production.

NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 23, 2012 Revision 1 File: O2AWGD00 TstRpt 120627 Page 1 of 41 Application For Grant of Certification FOR Model: O2AWGD00 GPN 011-02844-xx Low Power Transmitter FCC ID: IPH-O2AWGD IC: 1792A-O2AWGD FOR GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Test Report Number 120627 Authorized Signatory: Scot D. Rogers NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 23, 2012 Revision 1 File: O2AWGD00 TstRpt 120627 Page 2 of 41 Test Report for Application of Certification For GARMIN INTERNATIONAL, INC. 1200 East 151st Street Olathe, KS 66062 Phone: (913) 397-8200 Mr. Van Ruggles Director of Quality Assurance Model: O2AWGD00 GPN 011-02844-xx Low Power Transmitter Frequency Range: 2,402-2,480 MHz FCC ID: IPH-O2AWGD IC: 1792A-O2AWGD Test Report Number: 120627 Test Date: June 27, 2012 Authorized Signatory: Scot D. Rogers Rogers Labs, Inc. 4405 West 259th Terrace Louisburg, KS 66053 Telephone/Facsimile: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP, NIST, or any agency of the Federal Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 23, 2012 Revision 1 File: O2AWGD00 TstRpt 120627 Page 3 of 41 Table of Contents TABLE OF CONTENTS .................................................................................................... 3 FORWARD ....................................................................................................................... 5 APPLICABLE STANDARDS & TEST PROCEDURES .................................................... 5 OPINION / INTERPRETATION OF RESULTS ................................................................. 5 STATEMENT OF MODIFICATIONS AND DEVIATIONS ................................................. 6 ENVIRONMENTAL CONDITIONS.................................................................................... 6 UNITS OF MEASUREMENTS .......................................................................................... 6 TEST SITE LOCATIONS .................................................................................................. 6 LIST OF TEST EQUIPMENT ............................................................................................ 7 APPLICATION FOR CERTIFICATION ............................................................................. 8 EQUIPMENT TESTED SETUP, FUNCTION AND CONFIGURATIONS .......................... 9 Equipment Function and Test Setup ....................................................................................................................... 9 EUT Configuration Options .................................................................................................................................... 10 SUBPART C - INTENTIONAL RADIATORS .................................................................... 11 AC Line Conducted Emission Test Procedure ....................................................................................................... 11 Radiated Emission Test Procedure ......................................................................................................................... 11 ANTENNA REQUIREMENTS ........................................................................................... 12 RESTRICTED BANDS OF OPERATION ......................................................................... 12 Radiated Emissions in Restricted Bands Data ....................................................................................................... 13 Summary of Results for Radiated Emissions in Restricted Bands ....................................................................... 13 AC Line Conducted EMI Procedure ....................................................................................................................... 14 Figure One AC Line Conducted emissions of EUT line 1 (EUT AC Adapter) ..................................................... 15 Figure Two AC Line Conducted emissions of EUT line 2 (EUT AC Adapter) ..................................................... 15 Figure Three AC Line Conducted emissions of EUT line 1 (EUT USB to CPU) .................................................. 16 Figure Four AC Line Conducted emissions of EUT line 2 (EUT USB to CPU) ................................................... 16 Data AC Line Conducted Emissions ...................................................................................................................... 17 Summary of Results for AC Line Conducted Emissions ....................................................................................... 18 NVLAP Lab Code 200087-0 Rogers Labs, Inc. Garmin International, Inc. FCC ID: IPH-O2AWGD 4405 West 259 th Terrace Model: O2AWGD00 IC: 1792A- O2AWGD Louisburg, KS 66053 Test #:120627 SN: 3846360698 GPN: 011-02844-xx Phone/Fax: (913) 837-3214 Test to: FCC CFR 47 15.249, RSS 210 Date: July 23, 2012 Revision 1 File: O2AWGD00 TstRpt 120627 Page 4 of 41 General Radiated EMI Testing Procedure ..................................................................…
