IYASDA-BS100Blind Spot Detection System/ Bar Type

民＇＞！Dt=.EN ® find your road Owner ’ s Manual SDA-BS100 BLind Spot DeLection System/ Bar Type Versionl.2 IC Caution: - English: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. - French: Le présentappareilestconforme aux CNR d' Industrie Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l' appareil ne doit pas produire de brouillage, et (2) l' utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum 20cm distance between the radiator your body: Use only the supp lied antenna.

Pioneer Electronics (USA) Inc. Agent Authorization Com pany: Pioneer Electronics (USA) Inc. Ad dress: 2050 W. 190th Street, Suite 100, Torrance, CA 90504 USA Product Name: Blind Spot Detection System/ Bar Type Model Number(s): SDA-BS100 SDA-BS100D, SDA-BS101, SDA-BS1, SDA-BS100LP, ND-BS100 Product Des cription: Blind Spot Detection System/ Bar Type We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to t he regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of o ur own. Date: 2020/01/07 Signature: Name: James Ha Title: VP, Service Support Division Company: Pioneer Electronics (USA) Inc.

Pioneer Electronics (USA) Inc. O ffice of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/01/07 Subject; Request for Confidentiality FCC ID: IYASDA-BS100 T o Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. T hese documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description I n additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. I t is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. S incerely, S ignature: N ame: James Ha T itle: VP, Service Support Division

External Photos

Model: SDA-BS100 FCC ID: I YA SDA-BS100 IC: 25782-SDABS100 Label Location

Internal Photos ANT

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.245 TEST REPORT For PIONEER ELECTRONICS (USA) INC. 2050 W. 190th Street, Suite 100, Torrance, CA 90504 USA Report Type: Original Report Product Type: Blind Spot Detection System/ Bar Type Test Engineer: Stone Zhang Re port Number: PKS191120001-2 Re port Date: 2020-01-08 Reviewed B y: Oscar Ye EMC Manager Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road,Kunshan,Jiangsu province,China Tel: +86-0512-86175000 Fax: +86-0512-88934268 www.baclcorp.com.cn FCC ID: IYASDA-BS100 Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: PKS191120001-2 FCC Part 15.245 Page 2 of 14 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 JUSTIFICATION ............................................................................................................................................................. 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 5 EXTERNAL I/O CABLE .................................................................................................................................................. 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 TEST EQUIPMENT LIST ........................................................................................................................................... 8 FCC§15.205, §15.209&§15.245- RADIATED EMISSIONS& OUT OF BAND EMISSION .................................. 9 APPLICABLE STANDARD .............................................................................................................................................. 9 EUT SETUP ................................................................................................................................................................ 10 TEST EQUIPMENT SETUP ............................................................................................................................................ 10 TEST PROCEDURE ...................................................................................................................................................... 10 CORRECTED AMPLITUDE & MARGIN CALCULATION ................................................................................................. 10 TEST RESULTS SUMMARY .......................................................................................................................................... 11 TEST DATA ................................................................................................................................................................ 11 EXHIBIT A - TEST SETUP PHOTOGRAPHS ....................................................................................................... 13 RADIATED SPURIOUS EMISSIONS TEST VIEW (40-60GHZ) ........................................................................................ 13 RADIATED SPURIOUS EMISSIONS TEST VIEW (50-75GHZ) ........................................................................................ 13 RADIATED SPURIOUS EMISSIONS TEST VIEW (60-90GHZ) ........................................................................................ 14 RADIATED SPURIOUS EMISSIONS TEST VIEW (90-100GHZ) ...................................................................................... 14 Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: PKS191120001-2 FCC Part 15.245 Page 3 of 14 GENERAL INFORMATION Product Description for Equipment under Test (EUT) Applicant PIONEER ELECTRONICS (USA) INC. Tested Model SDA-BS100 Product Type Blind Spot Detection System/ Bar Type Power Supply DC 12V * All measurement and test data in this report was gathered from production sample serial number: 20191120001. (Assigned by the BACL. The EUT supplied by the applicant was received on 2019-11-20) Objective This type approval report is prepared on behalf of PIONEER ELECTRONICS (USA) INC. in accordance with …

Text truncated - open the document above for the full version.

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E Test Report FCC-ID: IYASDA-BS100 Product Name: Blind Spot Detection System/ Bar Type Trademark: Pioneer Model Name : SDA-BS100 SDA-BS100D, SDA-BS101, SDA-BS1, SDA-BS100LP, ND-BS100 Prepared For : Pioneer Electronics (USA) Inc. Address : 2050 W. 190th Street, Suite 100, Torrance, CA 90504 USA Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Nov. 13, 2019 - Dec. 03, 2019 Date of Report : Dec. 03, 2019 Report No.: BCTC1911000890E IC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com.cn Page 1 of 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E CERTIFICATION Applicant’s name ................. : Pioneer Electronics (USA) Inc. Address .................................. : 2050 W. 190th Street, Suite 100, Torrance, CA 90504 USA Manufacture's Name ............ : Pioneer Electronics (USA) Inc. Address .................................. : 2050 W. 190th Street, Suite 100, Torrance, CA 90504 USA Product description Product name ............................ : Blind Spot Detection System/ Bar Type Trademark: Pioneer Model Name: SDA-BS100 SDA-BS100D, SDA-BS101, SDA-BS1, SDA-BS100LP, ND-BS100 Test Standards: FCC 47 CFR Part 15, Section 15.245 ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Prepared by(Engineer): Cai Fangzhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou IC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com.cn Page 2 of 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED MEASUREMENT. 12 3.2.1 TEST PROCEDURE 12 3.2.2 DEVIATION FROM TEST STANDARD 13 3.2.3 TEST SETUP 13 3.2.4 EUT OPERATING CONDITIONS 14 3.2.5 TEST RESULTS 15 4 . BANDWIDTH TEST 21 4.1 APPLIED PROCEDURES / LIMIT 21 4.1.1 TEST PROCEDURE 21 4.1.2 DEVIATION FROM STANDARD 21 4.1.3 TEST SETUP 21 4.1.4 EUT OPERATION CONDITIONS 21 4.1.5 TEST RESULTS 22 5 . ANTENNA REQUIREMENT 23 5.1 STANDARD REQUIREMENT 23 5.2 EUT ANTENNA 23 IC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com.cn Page 3 of 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E Table of Contents Page 6 . EUT TEST PHOTO 24 7 . PHOTOS OF THE EUT 26 IC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com.cn Page 4 of 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC 47 CFR Part 15,Subpart C, Section 15.245 Standard Section Test Item Judgment Remark 15.245 (b) Fundamental Radiated PASS 15.245 (b) Spurious Emission Measurement PASS 15.215 (c) Bandwidth PASS 15.205 (a) Band Edge Emission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Testing Co., Ltd. Add. : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China FCC Te s t Firm Registration Number: 712850 IC Registered No.: 23583 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% IC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com.cn Page 5 of 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTCFY11911000890E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment ADD-ON BLIND SPOT DETECTION SYSTEM LICENSE PLATE BAR TYPE FOR UNIVERSAL APPLICATION Trade Name Pioneer Model Name SDA-BS100 Serial Model SDA-BS100D, SDA-BS101, SDA-BS1, SDA-BS100LP, ND-BS100 Model Difference Consecutive Model Years and sales territories Product Description Operation Frequency: 24089MHz Bit Rate of Transmitter 1Mbps Number Of Channel 1CH Max. RF Output Power: 106.23 dBuV/m Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Power Supply DC 12V 0.4A Connecting I/O Port(s) Please refer to the User's Manual Hardware Version: SB236A18 Software Version: SB236A07-V9-test1 Power level set 10dBm Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MH…

Text truncated - open the document above for the full version.

Radiated Measurement Photos 30-1GHz 1-18GHz 18-40GHz
