IYZGK1Lotus keyfob

Technical Description GK1 Originator : Xun Gong Department : SDYE-A-SH Tel. : 86 21 58973302- 9412 Fax. : Email : [email protected] Initial version : 31.03.2023 Revision : Version: 1.0 Technical Description MU1 2 / 6 1. Functional description The GK1, as a passive entry vehicle key, is part of a driving authorisation system, which further consists of a Body Control Unit and up to 8 UWB vehicle modules. The Body Control Unit in the vehicle initiates the communication to the GK1 over Bluetooth LE. After successful identification, a time-of-flight measurement is triggered bidirectionally between the UWB vehicle module and the GK1. The distance is measured between the UWB vehicle module and the GK1 by means of the time of flight based on speed of light. The components exchange encrypted data for car access, to start the engine and to locate the key. 2. User manual The GK1 has one button. On each button press, it initiates the communication to the Body Control Module over Bluetooth LE and the vehicle either unlocks, locks, or opens the trunk. The distance measurement is a bidirectional communication between key and GU1. The key is called verifier and sends first to the GU1. The GU1 is called prover and sends back, after receiving the verifier signal. The key then computes the distance from the time of flight. The Body Control Unit in the vehicle can automatically operate functions such as unlocking measurements depending on the distance of the key 3. Technical Data Temperature range Working temperature -40°- +85° C Data of RF-Part(UWB) Transmission mode bidirectional RF 2 channels Receiver Channel frequencies Channel 5: 6489.6 MHz Channel 9: 7987.2 MHz 10 dB bandwidth ＞500 MHz per channel Frequency tolerance (production, aging, temperature) +/-20 ppm Technical Description MU1 3 / 6 Sensitivity -90 dBm Modulation: PM Frequency deviation +/- 125 MHz Antenna: integrated PCB antenna, combined for Rx / Tx Transmitter: Center frequency see Rx Frequency tolerance (production, aging, temperature) +/-20 ppm Transmitter power EIRP with PCB antenna ＜-41.3 dBm/MHz Modulation: PM Antenna: integrated PCB antenna, combined for Rx / Tx Data of RF-Part(BLE) Transmission mode BLE 5.0 40 channels Receiver Channel frequencies 2402MHz ~ 2480MHz Bandwidth 2MHz per channel Frequency offset +/-150kHz Frequency drift +/-50kHz Sensitivity ＜-90 dBm Modulation: GFSK Antenna: integrated PCB antenna, combined for Rx / Tx Transmitter: Center frequency see Rx Bandwidth 2MHz per channel Frequency offset +/-150kHz Technical Description MU1 4 / 6 Frequency drift +/-50kHz Transmitter power EIRP ＜10dBm Modulation: GFSK Antenna: integrated PCB antenna, combined for Rx / Tx Rough mechanical dimensions 63.2 X 47 X 12.6 mm Weight: 45 g WARNING Do not ingest the battery, Chemical Burn Hazard (The remote control supplied with) This product contains a coin/button cell battery. If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children. If the battery compartment does not close securely, stop using the product and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. FCC Regulations: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against Technical Description MU1 5 / 6 harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ⚫ Reorient or relocate the receiving antenna. ⚫ Increase the separation between the equipment and receiver. ⚫ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ⚫ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: ➢ Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Radiation Exposure Statement: The product is a low power device and its output power is lower than FCC SAR exemption level. ISED Notice  This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device.  Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: 1) l'appareil ne doit pas produire de brouillage, et 2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.  This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter, except tested built-in radios.  Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction avec une autre antenne ou un autre émetteur, exception faites des radios intégrées qui ont été testées. …

Text truncated - open the document above for the full version.

Rev 1/26/2023 Marquardt GmbH Schloss-str.16,78604 Rietheim-Weilheim,Germany Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 10,2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: IYZGK1 Marquardt GmbH (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Gerd Villing Tel: 00497424991747 Fax: 00497424992122 E-mail: [email protected] Rev 1/26/2023 Marquardt GmbH Schloss-str.16,78604 Rietheim-Weilheim,Germany Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 10,2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: IYZGK1 Marquardt GmbH (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered”equipment. Sincerely, Gerd Villing Tel: 00497424991747 Fax: 00497424992122 E-mail: [email protected]

Rev 1/26/2023 Marquardt GmbH Schloss-str.16,78604 Rietheim-Weilheim,Germany Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 10,2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: IYZGK1 Marquardt GmbH (“the applicant”) certifies that, as of the date of the filing of the application, Marquardt Switches,Inc is our designated U.S. agent for service of process for the above referenced FCC ID. Marquardt GmbH accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Marquardt Switches,Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Marquardt Switches,Inc U.S. Agent FRN: The agent for service of process does no other business with the FCC and does not have an FRN. Address: 2990 Waterview Drive ,Rochester Hills,MI 48309,USA Contact Person: Michael Fera Tel.: Michael Fera Email: [email protected] Sincerely, Marquardt GmbH Marquardt Switches,Inc Gerd Villing Michael Fera Michael FeraGerd Villing Applicant FRN: 0007486251

Marquardt GmbH Schloss-str.16,78604 Rietheim-Weilheim,Germany Date: August 23, 2023 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: IYZGK1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. ⚫ Schematic Diagram ⚫ Block Diagram ⚫ Parts List ⚫ Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations. ◆ External Photos ◆ Internal Photos ◆ Test Setup Photos ◆ Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Gerd Villing Tel: 00497424991747 Fax: 00497424992122 E-mail: [email protected]

Marquardt GmbH Schloss-str.16,78604 Rietheim-Weilheim,Germany Date: August 23, 2023 Power of Attorney To whom it may concern, Please be notified that I, Gerd Villing, have designated Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co., Ltd as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co. Ltd on the matters relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.U.S.C. 862, we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act. This authorization is limited to the product of as following: FCC ID: IYZGK1 If you have any acknowledgement and response, please send it to Joey Lao of Bureau Veritas 7Layers Communications Technology (Shenzhen) Co., Ltd directly. Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, Gerd Villing Tel: 00497424991747 Fax: 00497424992122 E-mail: [email protected]

Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 1 of 3 Report Version 1 Reference No.: W7L-P230608W002FCC ID: IYZGK1 PHOTOGRAPHS OF THE EUT Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 2 of 3 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 3 of 3 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1

FCC ID：IYZGK1 IC：2701A-GK1 Label Location next the battery compartment Battery compartment Back of EUT

Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 1 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 2AGCDJACSTD191-B1122212AGCDJACSTD191-B2AGCDJACSTD191-B2AGCDJACSTD191- B2AGCDJACSTD191-B PHOTOGRAPHS OF THE EUT Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 2 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 2AGCDJACSTD191-B1122212AGCDJACSTD191-B2AGCDJACSTD191-B2AGCDJACSTD191- B2AGCDJACSTD191-B Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 3 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 2AGCDJACSTD191-B1122212AGCDJACSTD191-B2AGCDJACSTD191-B2AGCDJACSTD191- B2AGCDJACSTD191-B Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 4 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 2AGCDJACSTD191-B1122212AGCDJACSTD191-B2AGCDJACSTD191-B2AGCDJACSTD191- B2AGCDJACSTD191-B

FCC RF Exposure Test Report Report Format Version 1.0.0 Issued Date : Aug. 29, 2023 Report No. : W7L-P230608W002SA01 FCC SAR Exemption Evaluation Report Report No. : W7L-P230608W002SA01 Applicant : Marquardt GmbH Address : Schloss-str.16,78604 Rietheim-Weilheim,Germany Product : Lotus keyfob FCC ID : IYZGK1 Brand : Marquardt Model No. : GK1 Standards : FCC 47 CFR Part 2 (2.1093) / Part 1 (1.1307) KDB 447498 D04 v01 Sample Received Date : Jun. 08, 2023 Date of Testing : Jun. 08, 2023 ~ Aug. 29, 2023 CERTIFICATION: The above equipment have been tested by HUARUI 7LAYERS HIGH TECHNOLOGY (SUZHOU) CO., LTD., and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA or any government agencies. Prepared By : Approved By : Chao Wu/ Engineer Peibo Sun/ Manager This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about- us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. FCC RF Exposure Test Report Report Format Version 1.0.0 Issued Date : Aug. 29, 2023 Report No. : W7L-P230608W002SA01 Table of Contents RELEASE CONTROL RECORD .................................................................................................................................................... 3 1. DESCRIPTION OF EQUIPMENT UNDER TEST .................................................................................................................... 4 2. SAR EXEMPTION EVALUATION ........................................................................................................................................... 5 2.1 MAXIMUM TUNE-UP POWER (DECLARED BY MANUFACTURER) ......................................................................... 6 2.2 SAR TEST EXCLUSION THRESHOLDS ..................................................................................................................... 7 3. INFORMATION ON THE TESTING LABORATORIES ........................................................................................................... 8 FCC RF Exposure Test Report Report Format Version 1.0.0 Issued Date : Aug. 29, 2023 Report No. : W7L-P230608W002SA01 Release Control Record Report No. Reason for Change Date Issued W7L-P230608W002SA01 Initial release Aug. 29, 2023 FCC RF Exposure Test Report Report Format Version 1.0.0 Issued Date : Aug. 29, 2023 Report No. : W7L-P230608W002SA01 1. Description of Equipment Under Test EUT Type* Lotus keyfob Brand Name* Marquardt Model Name* GK1 Tx Frequency Bands (Unit: MHz) BT-LE: 2402 ~ 2480 UWB：CH5: 6489.6MHz/ CH9: 7987.2MHz Uplink Modulations BT-LE: GFSK UWB：BPSK Maximum Tune-up Conducted Power (Unit: dBm) BT-LE: 0.95 dBm UWB：CH5:-17.30 dBm / CH9：-21.45 dBm Antenna Type* PCB Antenna EUT Stage* Production Unit NOTE: 1. *Since the above data and/or information is provided by the client relevant results or conclusions of this report are only made for these data and/or information , Test Lab is not responsible for the authenticity, integrity and results of the data and information and/or the validity of the conclusion. 2. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. 3. List of Accessory: ACCESSORIES BRAND MANUFACTURER MODEL SPECIFICATION Lithium Battery Panasonic Panasonic Corporation CR2032 Capacity:3.0 Vdc, 225mAh FCC RF Exposure Test Report Report Format Version 1.0.0 Issued Date : Aug. 29, 2023 Report No. : W7L-P230608W002SA01 2. SAR Exemption Evaluation Following FCC KDB 447498 D04 “Interim General RF Exposure Guidance” v01 SAR-based Exemption: The corresponding SAR Exclusion Threshold condition, listed below: 1) SAR-based thresholds are derived based on frequency, power, and separation distance of the RF source. The formula defines the thresholds in general for either available maximum time averaged power or maximum time-averaged ERP, whichever is greater. 2) Per § 1.1307(b)(3)(i)(B), for single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: 3) The available ma…

Text truncated - open the document above for the full version.

CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 1| BLEANTENNA SPECIFICATION X U N G O N G–15.07. 2 0 2 2 CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 2| •Antenna Manufacturer：Marquardt GmbH •Manufacturer Address：Schloss-str.16,78604 Rietheim-Weilheim,Germany •BLE Ant Model：MQBANTK •Antenna Type：PCB Antenna •Antenna size：13.2mm*5.4mm MARQUARD T2 3 .0 8 .2 0 2 3| CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 3| SIMULATION VS. MEASURMENTS MARQUARD T2 3 .0 8 .2 0 2 3| Comperableresults=> equalbehavior Measurement Simulation CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 4| •Measurementsaredoneinsidea anachonicchamber. •As referencea PCB antennaisused •The measuredparameterisS 21 (mag) => 2 Port VNA •The VNA iscalibratedon thetwofeedingpointsofthe antennas(referenceandDUT) •The antennapatternofthexy-, xz-, yz-planes is calculated •Stepsize=> 3° MEASUREMENT SETUP MARQUARD T 2 3 .0 8 .2 0 2 3| CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 5| SAMPLE ORIENTATIONS MARQUARD T2 3 .0 8 .2 0 2 3| xz-plane yz-plane xy-plane CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 6| •A path = friispathloss •S 21 = measuredwithVNA •G R = gainofreferenceantenna CALCULATIONOFTHEANTENNAGAIN MARQUARD T2 3 .0 8 .2 0 2 3| VNA Port 1 VNA Port 2 Path lossA path ford = 80 cm S 21 G T G R Calibrationpoint 퐺 푇 =푆 21 −퐺 푅 −퐴 푝푎푡ℎ CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 7| LOW –CIRCULAR(TOTAL GAIN) MARQUARD T2 3 .0 8 .2 0 2 3| xz-planeyz-planexy-plane 1.5 dBi 2.2 dBi 1.7 dBi CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 8| MID–CIRCULAR(TOTAL GAIN) MARQUARD T2 3 .0 8 .2 0 2 3| xz-planeyz-planexy-plane 1.1 dBi 1.2 dBi CONFIDENTIAL© This documentistheexclusivepropertyofMarquardt. Withoutourconsent, itmaynot bereproducedorgiventothirdparties. 9| HIGH –CIRCULAR(TOTAL GAIN) MARQUARD T2 3 .0 8 .2 0 2 3| xz-planeyz-planexy-plane Max Gain = 2.2dBi 0.4 dBi 1.1 dBi 0.5 dBi

Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 1 of 73 Report Version 1 Test Report No.: W7L-P230608W002RF01 FCC TEST REPORT (Part 15, Subpart C) Applicant: Marquardt GmbH Address: Schloss-str.16,78604 Rietheim-Weilheim,Germany Manufacturer or Supplier: Marquardt GmbH Address: Schloss-str.16,78604 Rietheim-Weilheim,Germany Product: Lotus keyfob Brand Name: Marquardt Model Name: GK1 FCC ID: IYZGK1 Date of tests: Jun. 08, 2023 ~ Aug. 19, 2023 The tests have been carried out according to the requirements of the following standard: FCC Part 15, Subpart C, Section 15.247 ANSI C63.10-2013 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Prepared by Chao Wu Engineer / Mobile Department Approved by Peibo Sun Manager / Mobile Department Date: Aug. 19, 2023 Date: Aug. 19, 2023 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 2 of 73 Report Version 1 Test Report No.: W7L-P230608W002RF01 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 5 1 SUMMARY OF TEST RESULTS .................................................................................................... 6 1.1 MEASUREMENT UNCERTAINTY ............................................................................................... 7 2 GENERAL INFORMATION ............................................................................................................ 8 2.1 GENERAL DESCRIPTION OF EUT............................................................................................. 8 2.2 DESCRIPTION OF TEST MODES............................................................................................... 9 2.2.1 CONFIGURATION OF SYSTEM UNDER TEST ................................................................ 10 2.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ..................................... 10 2.3 DUTY CYCLE OF TEST SIGNAL .............................................................................................. 13 2.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................ 14 2.5 DESCRIPTION OF SUPPORT UNITS ....................................................................................... 14 3 TEST TYPES AND RESULTS ...................................................................................................... 15 3.1 RADIATED EMISSION MEASUREMENT .................................................................................. 15 3.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT ....................................................... 15 3.1.2 TEST INSTRUMENTS ........................................................................................................ 16 3.1.3 TEST PROCEDURES ........................................................................................................ 17 3.1.4 DEVIATION FROM TEST STANDARD .............................................................................. 17 3.1.5 TEST SETUP ...................................................................................................................... 18 3.1.6 EUT OPERATING CONDITIONS ....................................................................................... 19 3.1.7 TEST RESULTS ................................................................................................................. 20 3.2 6 DB BANDWIDTH MEASUREMENT ........................................................................................ 32 3.2.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT .............................................................. 32 3.2.2 TEST INSTRUMENTS ........................................................................................................ 32 3.2.3 TEST PROCEDURE ........................................................................................................... 33 3.2.4 DEVIATION FROM TEST STANDARD .............................................................................. 33 3.2.5 TEST SETUP ..............................................................................................................…

Text truncated - open the document above for the full version.

Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 1 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 SET-UP FOR FCC 15.247 Radiated emission test: Frequency Range< 30MHz ~1GHz > Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 2 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 Radiated emission test: Frequency Range< Above 1GHz > Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 3 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 Radiated emission test: Frequency Range< 9KHz- 30MHz > Huarui 7layers High Technology (Suzhou) Co., Ltd. Tower N, Innovation Center, 88 Zhuyi Road, High-tech District, Suzhou City, Anhui Province Tel: +86 (0557) 368 1008 Page 4 of 4 Report Version 1 Reference No.: W7L-P230608W002 FCC ID: IYZGK1 SET-UP FOR FCC 15.519 Radiated emission test: Frequency Range< Below 960MHz > Radiated emission test: Frequency Range< Above 960MHz >
