1 Table of Contents Specification-----------------------------------------------------------------------------------------------------3 Package Contents---------------------------------------------------------------------------------------------4 Hardware Connecting----------------------------------------------------------------------------------------5 LED Indicators--------------------------------------------------------------------------------------------------6 General Setting-------------------------------------------------------------------------------------------------7 Status------------------------------------------------------------------------------------------------------12 Router-----------------------------------------------------------------------------------------------12 ADSL------------------------------------------------------------------------------------------------13 PPP --------------------------------------------------------------------------------------------------14 USB Driver Procedures------------------------------------------------------------------------------------15 Installation USB Driver Procedures-------------------------------------------------------------15 Microsoft Windows 98SE---------------------------------------------------------------------15 Microsoft Windows 2000----------------------------------------------------------------------20 Microsoft Windows ME------------------------------------------------------------------------23 Microsoft Windows XP------------------------------------------------------------------------27 Uninstallation USB Driver Procedures---------------------------------------------------------30 Microsoft Windows 98SE---------------------------------------------------------------------30 Microsoft Windows 2000----------------------------------------------------------------------32 Microsoft Windows ME------------------------------------------------------------------------34 Microsoft Windows XP------------------------------------------------------------------------36 Advanced Setting--------------------------------------------------------------------------------------------38 ADMINISTRATION------------------------------------------------------------------------------------38 WAN -------------------------------------------------------------------------------------------------38 LAN/DHCP----------------------------------------------------------------------------------------42 DNS--------------------------------------------------------------------------------------------------43 NAT --------------------------------------------------------------------------------------------------44 Port Forwarding----------------------------------------------------------------------------------46 Wireless--------------------------------------------------------------------------------------------47 ADSL Configuration----------------------------------------------------------------------------48 RIP Configuration-------------------------------------------------------------------------------49 Diagnostic Test-----------------------------------------------------------------------------------50 Router Table--------------------------------------------------------------------------------------52 MAC Filtering-------------------------------------------------------------------------------------53 SECURITY-----------------------------------------------------------------------------------------------54 Admin Password--------------------------------------------------------------------------------54 2 User Password-----------------------------------------------------------------------------------55 Misc Configuration------------------------------------------------------------------------------56 System Log---------------------------------------------------------------------------------------58 Code Update--------------------------------------------------------------------------------------59 Status------------------------------------------------------------------------------------------------------60 Router-----------------------------------------------------------------------------------------------60 ADSL------------------------------------------------------------------------------------------------61 LAN --------------------------------------------------------------------------------------------------62 WAN -------------------------------------------------------------------------------------------------63 ATM--------------------------------------------------------------------------------------------------64 TCP connections--------------------------------------------------------------------------------65 Learned MAC Table----------------------------------------------------------------------------66 PPP Status----------------------------------------------------------------------------------------67 3 Specification SpecificationModel Name:1 Port ADSL Wireless Router Annex A / Annex B/UR2 Chipset ADSL Wireless Router Chip:(CX82310-14/24) ARM940T Processor Line ConnectionRJ-11(2 wires) Line/Phone ,USB, RJ-45 (4 port) , RS -232CConnection Features High speed Asymmetric Digital Subscriber Line (ADSL) connection to the telephone line Complete USB ADSL modem solution DMT modulation and demodulation Supports splitter less ADSL implementation Tone detection for low power mode ATM SAR performed in software driver Compliant with ADSL standards Full-rate ANSI T1.413 Issue 2 and ITU G.dmt (G.992.1) standards Splitter less ITU G.lite (G.992.2) specification Full-rate adaptive modem Maximum downstream rate of 8 Mbps Maximumupstream rate of 1 Mbps G.lite adaptive modem Maximum downstream rate of 1.5 Mbps Maximum upstream rate of 512 Kbps WAN Mode Support PPP over ATM (RFC 2364) PPP over Ethernet (RFC 2516) LAN Mode Support Bridged/routed Ethernet over ATM (RFC 2684/1483) Classical IP over ATM (RFC 1577) and PPP over Ethernet (RFC 2516) Bridge Mode Support Ethernet to ADSL…
Text truncated - open the document above for the full version.
Request for Confidentiality Date:10/06/2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: JCHAWR-8210 Please be advised that the following information is to be held confidential and behalf of APPLICANT NAME: • Part List • Schematics • Block diagram • Operational description The application contains technical information which Well Communication Corp. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Signatory ______________________ Vincent Hsiao
FCC Labeling Requirements and Information Date:10/06/2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: FCC Labeling Requirements FCC ID: JCHAWR-8210 The following label information is required by the FCC Rules and Regulations for certified devices. Also attached, please find marketing information required by the FCC Rules and Regulations. Thank you for your attention to these matters. Sincerely, ______________________ Vincent Hsiao Manufacturer’s Letter Date:10/06/2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: JCHAWR-8210 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Signatory ______________________ Vincent Hsiao
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 21, 2003 RE: Well Communication Corp FCC ID: JCHAWR-8210 I have a few comments on this Application. 1.) The front view of the External Photographs is very fuzzy. Kindly supply a clearer photograph. 2.) No Confidentiality Request letter was uploaded with this Application. This is so unusual that it deserves my double checking to be sure that it is okay for all Exhibits, including Schematics, Block Diagram, Operational Description and Parts List to be viewed at the FCC website. Please confirm. 3.) FYI: For all Unlicensed Part 15 devices it is not necessary to upload the Parts List with the Application. 4.) FYI: The FCC now prefers that for RF category “Mobile” devices, the power density “S” be calculated at 20cm, and not the estimated safe separation “R”. Please review your RF Exposure exhibit. 5.) FYI: The hardcopy plots of band edge emissions on pp. 39 and 40 of the Test Report do not show any RBW or VBW or sweep time information. It is helpful if this information is included on all plots. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 22, 2003 RE: Well Communication Corp FCC ID: JCHAWR-8210 I have an additional comment for this Application. 1.) Please provide data showing this device will meet the radiated restricted band requirements above 2483.5MHz and below 2490MHz. See 15.205. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
Made in Taiwan 0470 R I.T.E E199697 USC LISTED FCC ID : JCHAWR-8210 45.00 mm 29.00 mm Tested To Comply With FCC Standards For HOME OR OFFICE USE Model No. : AWR-8210 POWER : AC 12V/800mA This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions : (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.
Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Measurement of MPE 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT EUT : ADSL Wireless Router Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Model No. : AWR-8210, AWR-8210B Granted FCC ID : JCHAWR-8210 Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel: 11 Channel Modulation Skill : DBPSK, DQPSK, DCCK Power Type : By the Power adaptor M/N: MW41-1200800A I/P: 120Vac, 60Hz O/P: 12Vac, 800mA Applicant : Well Communication Corp. 11F, No. 778, Chung Cheng Rd., Chung Ho City, Taipei Hsien, Taiwan, R.O.C. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, equation for predicting RF fields, by the Friis Transmission Formula: Power density at the specific separation (portable): 2 22 /760.1 )20(4 584.1872.55 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R65.2 4 584.1872.55 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.65 cm." Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (2 / 10) = 1.584
Test Report ----------------------------------------------------------------------------- 1/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 MEASUREMENT REPORT of 2.4 GHz Wireless device Applicant : Well Communication Corp. Model No. : AWR-8210, AWR-8210B EUT : ADSL Wireless Router FCC ID : JCHAWR-8210 Report No. : W0115648 Tested by : Training Research Co., Ltd. TEL : 886-2-26461146 FAX : 886-2-26461778 No. 15, Lane 530, Pa-Lian RD., Sec. 1, Hsichih City, Taipei Hsien, Taiwan, R.O.C. Test Report ----------------------------------------------------------------------------- 3/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Tables of Contents I. GENERAL ....................................................................................................................... 5 1.1 Introduction ................................................................................................................ 5 1.2 Description of EUT .................................................................................................... 5 1.3 Description of Support Equipment ............................................................................ 6 1.4 Configuration of System Under Test ......................................................................... 9 1.5 Verify the Frequency and Channel ........................................................................... 12 1.6 Test Procedure .......................................................................................................... 13 1.7 Location of the Test Site ........................................................................................... 13 1.8 General Test Condition ............................................................................................. 13 II. Section 15.101(a) : Equipment Authorization of Unintentional Radiators................ 14 III. Section 15.203 : Antenna Requirement.......................................................................... 14 IV. Section 15.207 : Power Line Conducted Emissions for AC Powered Units .............. 15 4.1 Test Condition & Setup ............................................................................................ 15 4.2 List of Test Instruments ............................................................................................ 15 4.3 Test Configuration .................................................................................................... 16 4.4 Test Result of Conducted Emissions ........................................................................ 18 V. Section 15.247(a) : Technical Description of the EUT.................................................. 22 VI. Section 15.247(a)(2) : Bandwidth for Direct Sequence System .................................. 23 6.1 Test Condition & Setup ............................................................................................ 23 6.2 Test Instruments Configuration ................................................................................ 23 6.3 List of Test Instruments ............................................................................................ 23 6.4 Test Result of Bandwidth ........................................................................................... 24 VII. Section 15.247(b) : Power Output ................................................................................. 28 7.1 Test Condition & Setup ............................................................................................ 28 7.2 List of Test Instruments ............................................................................................ 29 7.3 Test Result ................................................................................................................ 29 Test Report ----------------------------------------------------------------------------- 4/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 VIII. Section 15.247(c) : Spurious Emissions (Radiated) .................................................. 30 8.1 Test Condition & Setup ............................................................................................ 30 8.2 List of Test Instruments ............................................................................................ 31 8.3 Test Instruments Configuration ................................................................................ 32 8.4 Test Result of Spurious Radiated Emissions ............................................................ 34 8.5 Test Result of Bandedge ............................................................................................. 38 IX. Section 15.247(d) : Power Spectral Density .................................................................. 41 9.1 Test Condition & Setup ............................................................................................ 41 9.2 Test Instruments Configuration ................................................................................ 41 9.3 List of Test Instruments .............................................................................................. 41 9.4 Test Result of Power Spectral Density ..................................................................... 42 Appendix A: Set Up Procedure ............................................................................................ 46 Appendix B: Antenna Specification .................................................................................... 47 Test Report ----------------------------------------------------------------------------- 5/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of applicant in support that the cable gateway certification in accordance with Part 2 Subpart J and Part 15 Subpart A/B/C of th…
Text truncated - open the document above for the full version.
Test Report ----------------------------------------------------------------------------- 39/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Channel 1 This is the hard copy of our bandedge measurement generated by our bandedge testing program. The picture shown above is the bandedge of channel 1. 1. The lobe right by the fundamental side is already 20dB below the highest emission level. 2. The emissions recorded in the restricted band (<2400MHz) is do comply with the Part 15.209(a) – under the limited line marked in red color. 3. The equipment setting was RBW=100K, VBW=100K, Sweep time=100ms. Test Report ----------------------------------------------------------------------------- 40/47 Report No.: W0115648 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Channel 11 This is the hard copy of our bandedge measurement generated by our bandedge testing program. The picture shown above is the bandedge of channel 11. 1. The lobe right by the fundamental side is already 20dB below the highest emission level. 2. The emissions recorded in the restricted band (>2483.5MHz) is do comply with the Part 15.209(a) – under the limited line marked in red color. 3. The equipment setting was RBW=100K, VBW=100K, Sweep time=100ms. 4. The restricted band 2483.5~2500M under the 15.205 limit. (See this plot)
Conducted Emissions Test Placement of Unintentional Conducted Emissions Test Placement of Intentional Spurious Emissions (Radiated) Test Instruments Configuration Front View of the Test Configuration of Unintentional Rear View of the Test Configuration Unintentional Front View of the Test Configuration of Intentional Rear View of the Test Configuration Intentional
