JCK-GN-WBKGUSB STICK Wireless LAN Adapter

GN-WBKG 802.11b+g USB STICK Wireless LAN Adapter User’s Manual http://www.gigabyte.com.tw Rev. 1.0 First Edition Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance,any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Contents CHAPTER 1 PRODUCT OVERVIEW 1 1-1. INTRODUCTION...........................................................................................................1 1-2. FEATURES.................................................................................................................1 1-3. P HYSICAL DIMENSIONS/PACKAGING.............................................................................1 1-4. LED INDICATOR.........................................................................................................2 1-5. S YSTEM REQUIREMENTS............................................................................................2 CHAPTER 2 INSTALLING THE WLAN CARD 3 2-1. D RIVER & UTILITY INSTALLATION - WINDOWS ® 98SE ....................................................3 2-2. DRIVER & UTILITY INSTALLATION - WINDOWS ® ME .......................................................7 2-3. D RIVER & UTILITY INSTALLATION - WINDOWS ® 2000...................................................10 2-4. D RIVER & UTILITY INSTALLATION - WINDOWS ® XP ......................................................14 CHAPTER 3 USING THE GIGABYTE WLAN CONFIGURATION UTILITY 17 3-1. T HE PROFILE TAB....................................................................................................17 3-2. T HE LINK STATUS TAB.............................................................................................27 3-3. THE SITE SURVEY TAB.............................................................................................28 3-4. “S TATISTICS” SETTING.............................................................................................29 3-5. THE ABOUT TAB......................................................................................................30 CHAPTER 4 TROUBLESHOOTING 31 CANNOT ENABLE 802.1X, WPA OR WPA-PSK..........................................................31 CONNECT TO THE OTHER WIRELESS ETHERNET CARD.................................................31 C ANNOT ESTABLISH CONNECTION TO A WIRELESS NETWORK......................................31 CAN CONNECT TO AN ACCESS POINT, BUT CANNOT ACCESS THE INTERNET.................31 P OOR LINK QUALITY AND WEAK SIGNAL STRENGTH....................................................31 CHAPTER 5 HARDWARE SPECIFICATIONS 32 1 Chapter 1 Product Overview 1-1. Introduction This 802.11b/g Wireless Local Area Network (WLAN) card is composed of the MAC, Baseband, and radio components, USB STICK interface, Built-in antenna.. It operates in 2.4GHz frequency bands, providing fast (up to 54Mbps) and secure (support AES, 802.1x & WEP and WPA) connections to 802.11b and 802.11g networks from a single card. This product features the compact size, low power consumption, and power management functions, and provides a high-speed wireless data communication. Therefore, this product is ideally suitable for being integrated into the personal mobile and handheld platform. 1-2. Features „ Conforms to 802.11b/802.11g specification. „ Two dimenional rotation of maximum 180 degree „ Transmits data rate up to the maximum speed of 54Mbps. „ Dynamically scales the data rate. „ Automatic power management to reduce battery consumption. „ Built-in antenna. „ Seamless roaming between WLAN. „ Supports AES (Advance Encryption System), enterprise-class 802.1x security and multiple levels of WEP encryption (64-bit /128-bit), and WPA (Wi-Fi Protected Access).. „ Driver supports Windows 98SE/Me/2000/XP. 1-3. Physical Dimensions/Packaging Dimensions: 109mm 25mm16mm Please check that the package contents include: • GN-WBKG Wireless USB STICK Adapter • GN-WBKG Installation CD with Windows Drivers • User Manual In case of damaged or missing package contents, please contact your local distributor or authorized reseller immediately. Should you require returning the product, please include all original packing materials or the warranty will be voided. 2 1-4. LED …

Text truncated - open the document above for the full version.

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 1 of 4 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 2 of 4 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 3 of 4 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 4 of 4 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Model: GN-WBKG Product : 802.11b+g USB STICK Wireless LAN Adapter PCI Wireless LAN Card Model No: GN-WBKG FCC IDJCK-GN-WBKG This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 1 of 5 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 2 of 5 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 3 of 5 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 4 of 5 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 5 of 5 Product : 802.11b+g USB STICK Wireless LAN Adapter Model : GN-WBKG

32 GN-WBKG Specifications 1. SPECIFICATION GN-WBKG Wireless USB STICK Adapter Host Interface USB 2.0/1.1 Operating Voltage 5V from Host PC 2. RF Performance 802.11g(backward compatible to 802.11b) Frequency Bands 2412 ~ 2484 MHz (subject to local regulation) Modulation Technology OFDM and DSSS Modulation Techniques 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK, DBPSK Date Rates 54, 48, 36, 18,12, 9, 11, 6, 5.5, 2, and 1 Mbps, auto fallback Typical Power Consumption Receive: 270 mA Transmit: 320 mA Peak Output Power 20 dBm @ Nominal Temp Range Receive sensitivity Avg.-68dBm @54Mbps; -85dBm@11Mbps Antenna One internal chip antenna 3.Safety Regulation and Operating Environment FCC Part 15 (USA) DGT (Taiwan) EMC certification CE (Europe) Temperature Range Operating: 0 ~ 55 deg C, Storing: -20 ~ 65 deg C Humidity Max. 90% Non-condensing 4. Software Support Driver Windows 98SE/Me/2000/XP Security WPA-PSK(TKIP,AES); 802.1X client for Windows XP ,64/128 bit WEP Roaming Seamless roaming among 802.11b/g access points. Management Utility Monitors the network situation. 5. Mechanical Dimensions 109mm * 25mm * 16mm Weight 24 ± 1 g Packaging Packaging specially used by Gigabyte. LED indicators connecting statuses , scanning/the status of data transferring and indicating signal reception . *This specification is subject to change without notice.
