JCK-GN-WLBZ201IEEE 802.11b USB STICK Storage/Wireless LAN

GN-WLBZ201 IEEE 802.11b USB STICK Storage/Wireless LAN Card User’s Manual http://www.gigabyte.com.tw Rev. 1.0 First Edition Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device complies with FCC RF Exposure limits set forth for an uncontrolled environment, under 47 CFR 2.1093 paragraph (d)(2). This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Contents CHAPTER 1. PRODUCT OVERVIEW1 1-1. INTRODUCTION TO THE WIRELESS LAN CARD............................................................. 1 1-2. FEATURES................................................................................................................. 1 1-3. PHYSICAL DIMENSIONS/PACKAGING............................................................................ 1 1-4. LED INDICATING LIGHTS............................................................................................ 1 1-5. SYSTEM REQUIREMENTS............................................................................................ 2 1-6. WRITE-PROPECT FUNCTION....................................................................................... 2 CHAPTER 2. INSTALLING THE WIRELESS LAN CARD4 2-1. INSTALLING THE DRIVER & UTILITY FOR PC................................................................. 4 CHAPTER 3. USING THE UTILITY ON PC6 3-1. INFO........................................................................................................................ 6 3-2. STATISTICS.............................................................................................................. 7 3-3. CONFIGURATION....................................................................................................... 7 3-4. ENCRYPTION............................................................................................................ 8 3-5. ADVANCED............................................................................................................... 9 3-6. ABOUT................................................................................................................... 10 3-7. ACCESS POINT (SUPPORTED UNDER WINDOWS XP).................................................. 10 3-8. BRIDGE SETUP (SUPPORTED UNDER WINDOWS XP).................................................. 12 3-9. IP SHARING (SUPPORTED UNDER WINDOWS 2000)................................................... 14 CHAPTER 4. SPECIFICATION16 1 Chapter 1. Product Overview 1-1. Introduction to The Wireless LAN Card WLBZ201 is designed for product differentiation with 32M/64M/128M Bytes Flash memory for data backup。This wireless Local Area Network (LAN) card is composed of the IEEE 802.11b MAC with USB STICK interface、Baseband、radio components and two built-in antennas。This product adopts the direct sequence spread spectrum (DSSS) technology using the DBPSK、DQPSK、and CCK modulations to provide a very stable wireless communication quality and an excellent signal receiver capability。 This product features the compact size、low power consumption and power management functions and provides a high-speed wireless data communication。Therefore this product is ideally suitable for being integrated into the personal mobile and handheld platform。 1-2. Features ! Flash Memory 32Mbytes /64Mbytes /128Mbytes. ! Two dimenional rotation of maximum 180 degree ! Conforms to IEEE 802.11b specification. ! Transmits data rate up to the maximum speed of 11Mbps. ! Dynamically scales the data rate to 11, 5.5, 2, and 1Mbps. ! Host Interface USB. ! Built-in diversity antenna. ! Supports 64-bit /128-bit WEP encryption. ! Driver supports Windows 98SE/Me/2000/XP. ! Free Software Access Point. 1-3. Physical Dimensions/Packaging Dimensions: 126mm* 25mm* 16mm Before the installation procedures, please ensure the components are not damaged during the shipping. The shipment of the GN-WLBZ201 includes: One GN-WLBZ201 Wireless LAN Card One Installation CD (including User’s Guide and Driver) One User Guide Please contact your local distributor or authorized reseller immediately for any missing or damaged components. If you require returning the damaged product, you must pack it in the original packing material or the warranty will be voided. 1-4. LED Indicating Lights This wireless LAN card conforms to the USB standard. There are six LED-indica…

Text truncated - open the document above for the full version.

Record NO: APP. Rev: Issue Date: Page: 1-1 GIGA-BYTE TECHNOLOGY CO., LTD. No. 6, Bau Chiang Road, Hsin-Tien, Taipei Hsien, Taiwan, ROC Tel: +886-6- 5053733, Fax: +886-6- 5053722 FCC ID: JCK-GN-WLBZ201 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, Eric Hsu / Project Manager GIGA-BYTE TECHNOLOGY CO., LTD. e-mail: [email protected] Tel: +886-6-5053733 Fax: +886-6-5053722

Record NO: APP. Rev: Issue Date: Page: 1-1 GIGA-BYTE TECHNOLOGY CO., LTD. No. 6, Bau Chiang Road, Hsin-Tien, Taipei Hsien, Taiwan, ROC Tel: +886-6- 5053733, Fax: +886-6- 5053722 FEDERAL COMMUNICATIONS COMMISSION DECLARATION OF CONFORMITY (DoC) For the following equipment: Product Name: IEEE 802.11b USB STICK Storage / Wireless LAN Card Model No.: GN-WLBZ201 Trade Name: GIGABYTE Is herewith confirmed to be in compliance with the requirements of ANSI C63.4 & FCC part 15 regulations. The test result has been shown in the ADT test report with number D921011R04. And this compliance is subject to the following two conditions: This device may not cause harmful interference and, This device must accept any interference received, including interference that may cause undesired operation. The following local Manufacturer/Importer is responsible for this declaration: G.B.T. INC (Company Name) 17358 RAILROAD ST. CITY OF INDUSTRY, CA 91748 (Company Address) TEL ( 626 ) 854-9338 FAX ( 626 ) 854-9339 ERIC LU / GENERAL MANAGER (Name) / (Title) /2003.10.28 (Signature) / (Date)

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

label-WLBZ101 (484x236x16M jpeg)

Page 1 FCC Label Location

Page 4 Page 5 Page 6

FCC ID: JCK-GN-WLBZ201 ADT No.RF921011R04 Operational Description The transmitter of the EUT is powered by host equipment. The antenna type is Patch antenna with no connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: JCK-GN-WLBZ201 Report No.: SA921011R041Issued: Oct 30, 2003 SAR TEST REPORT REPORT NO.: SA921011R04 MODEL NO.: GN-WLBZ201 RECEIVED: Oct. 11, 2003 TESTED: Oct. 22, 2003 APPLICANT: GIGA-BYTE TECHNOLOGY CO., LTD. ADDRESS: No. 6, Bau Chiang Road, Hsin-Tien, Taipei Hsien, Taiwan, ROC ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 31 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. FCC ID: JCK-GN-WLBZ201 Report No.: SA921011R042Issued: Oct 30, 2003 Table of Contents 1.CERTIFICATION........................................................................................................................ 3 2.GENERAL INFORMATION........................................................................................................ 4 2.1GENERAL DESCRIPTION OF EUT.......................................................................................... 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................... 5 2.3GENERAL INOFRMATION OF THE SAR SYSTEM ................................................................. 5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION................................. 9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS................................................ 13 4.DESCRIPTION OF SUPPORT UNITS .................................................................................... 14 5.TEST RESULTS ...................................................................................................................... 15 5.1TEST PROCEDURES .............................................................................................................15 5.2MEASURED SAR RESULT ..................................................................................................... 16 5.3SAR LIMITS ............................................................................................................................. 18 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS .................................................................... 18 5.5TEST EQUIPMENT FOR TISSUE PROPERTY...................................................................... 20 6.SYSTEM VALIDATION ............................................................................................................21 6.1TEST EQUIPMENT ................................................................................................................. 21 6.2TEST PROCEDURE................................................................................................................ 21 6.3VALIDATION RESULT............................................................................................................. 23 6.4SYSTEM VALIDATION UNCERTAINTIES .............................................................................. 24 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES ...................................................... 25 7.1PROBE CALIBRATION UNCERTAINTY ................................................................................. 25 7.2ISOTROPY UNCERTAINTY .................................................................................................... 25 7.3BOUNDARY EFFECT UNCERTAINTY ................................................................................... 26 7.4PROBE LINEARITY UNCERTAINTY ...................................................................................... 26 7.5READOUT ELECTRONICS UNCERTAINTY .......................................................................... 26 7.6RESPONSE TIME UNCERTAINTY ......................................................................................... 27 7.7INTEGRATION TIME UNCERTAINTY .................................................................................... 28 7.8PROBE POSITIONER MECHANICAL TOLERANCE ............................................................. 28 7.9PROBE POSITIONING............................................................................................................29 7.10 PHANTOM UNCERTAINTY..................................................................................................... 29 7.11 DASY4 UNCERTAINTY BUDGET........................................................................................... 30 8.INFORMATION ON THE TESTING LABORATORIES............................................................ 31 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: JCK-GN-WLBZ201 Report No.: SA921011R043Issued: Oct 30, 2003 1. CERTIFICATION PRODUCT : IEEE 802.11b USB STICK Storage / Wireless LAN Card MODEL NO. : GN-WLBZ201 BRAND NAME : GIGABYTE APPLICANT : GIGA-BYTE TECHNOLOGY CO., LTD TEST ITEM: R&D SAMPLE STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on Oct.22, 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate, and it was tested according to the standards listed above. This device was found to be in compliance with the Specific Absorption Rate (SAR) requirement specified in FCC part 2.1093 under General Population / Uncontrolled Exposure condition. FCC ID: JCK-GN-WLBZ201 Report No.: SA921011R044Issued: Oct 30, 2003 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT IEEE 802.11b USB STICK Storage / Wireless LAN Card MODEL NO. GN-WLBZ201 POWER SUPPLY 5…
