JCK-GN-WPKGPCI Wireless LAN Card

GN-WPKG PCI Wireless LAN Card User’s Manual http://www.gigabyte.com.tw Rev. 1.0 First Edition Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance,any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Contents CHAPTER 1 PRODUCT OVERVIEW 1 1-1. INTRODUCTION...........................................................................................................1 1-2. FEATURES.................................................................................................................1 1-3. PHYSICAL DIMENSIONS/PACKAGING.............................................................................1 1-4. LED INDICATING LIGHT...............................................................................................2 1-5. SYSTEM REQUIREMENTS............................................................................................2 CHAPTER 2 INSTALLING THE WLAN CARD 3 2-1. INSTALLING THE DRIVER & UTILITY (WIN 98SE/ME) .....................................................3 2-2. INSTALLING THE DRIVER & UTILITY (WIN 2000/XP)......................................................8 CHAPTER 3 USING THE UTILITY 12 3-1. PROFILE..................................................................................................................12 3-2. LINK STATUS............................................................................................................15 3-3. SITE SURVEY...........................................................................................................16 3-4. STATISTICS..............................................................................................................17 3-5. ADVANCE.................................................................................................................17 3-6. ABOUT....................................................................................................................19 CHAPTER 4 TROUBLESHOOTING 20 CANNOT CONNECT TO AN AP.....................................................................................20 CAN CONNECT TO AN AP BUT I CANNOT CONNECT TO THE INTERNET.............................20 ALWAYS HAVE POOR LINK QUALITY AND LOW SIGNAL....................................................20 CHAPTER 5 SPECIFICATION 21 1 Chapter 1 Product Overview 1-1. Introduction This 802.11b/g Wireless Local Area Network (WLAN) card is composed of the MAC, Baseband, and radio components, PCI interface, and two built-in antennas. It operates in 2.4GHz frequency bands, providing fast (up to 54Mbps) and secure (support AES, 802.1x & WEP and WPA) connections to 802.11b and 802.11g networks from a single card. 1-2. Features „ Conforms to 802.11b/802.11g specification. „ Transmits data rate up to the maximum speed of 54Mbps. „ Dynamically scales the data rate. „ Automatic power management to reduce battery consumption. „ One external antenna. „ Seamless roaming between 802.11b and 802.11g networks. „ Supports AES (Advance Encryption System), enterprise-class 802.1x security and multiple levels of WEP encryption (64-bit /128-bit), and WPA (Wi-Fi Protected Access).. „ Driver supports Windows 98SE/Me/2000/XP. 1-3. Physical Dimensions/Packaging Dimensions: 134mm* 121mm* 22mm(134mm* 81mm* 22mm) Before the installation procedures, please ensure the components are not damaged during the shipping. The shipment of the GN-WPKG includes: One GN-WPKG Wireless LAN Card One Bracket One Installation CD (including User’s Guide and Driver) One User Guide Please contact your local distributor or authorized reseller immediately for any missing or damaged components. If you require returning the damaged product, you must pack it in the original packing material or the warranty will be voided. 2 1-4. LED Indicating Light Act OFF ON ON Link ON Blink Meaning No power applied to card Looking for network association the card has an active connection LED Blinking LINK ACT Condition of the Receiver Link Act 1-5. System Requirements 1-5-1. Supported Platform: IBM PC/AT compatible computer 1-5-2. Supported Operation System: Windows 98SE/Me/2000/XP 3 Chapter 2 Installing the WLAN Card 2-1. Installing The Driver & Utility (Win 98SE/ME) Step 1: …

Text truncated - open the document above for the full version.

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 1 of 4 Product : PCI Wireless LAN Card Model : GN-WPKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 2 of 4 Product : PCI Wireless LAN Card Model : GN-WPKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 3 of 4 Product : PCI Wireless LAN Card Model : GN-WPKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 4 of 4 Product : PCI Wireless LAN Card Model : GN-WPKG

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Model: GN-WPKG Product : PCI Wireless LAN Card PCI Wireless LAN Card Model No: GN-WPKG FCC IDJCK-GN-WPKG This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: [1] this device may not cause harmful interference and [2] this device must accept any interference received, including interference that may cause undesired operation. S/N Made in Taiwan

Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 1 of 3 Product : PCI Wireless LAN Card Model : GN-WPKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 2 of 3 Product : PCI Wireless LAN Card Model : GN-WPKG Company : GIGA-BYTE TECHNOLOGY CO., LTD. Page : 3 of 3 Product : PCI Wireless LAN Card Model : GN-WPKG

21 Chapter 5 Specification 1. System Host Interface PCI Operating Voltage 5VDC 5% 2. RF Performance 802.11g(BACKWARD COMPATIBLE TO 802.11b) Frequency Bands 2412-2484 MHz (subject to local regulations) Modulation Technology OFDM and DSSS Modulation Techniques 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK, DBPSK Date Rates 54, 48, 36, 18,12, 9, 11, 6, 5.5, 2, and 1 Mbps, auto fallback Typical Power Consumption Receive: 240 mA Transmit: 400 mA Peak Output Power 20 dBm @ Nominal Temp Range Receive sensitivity -70dBm @54Mbps; -87dBm@11Mbps Antenna External antenna with the gain of 2dBi 3.Safety Regulation and Operating Environment FCC Part 15 (USA) DGT (Taiwan) EMC certification CE (Europe) Temperature Range Operating: 0 ~ 55 deg C, Storing: -20 ~ 65 deg C Humidity Max. 90% Non-condensing 4. Software Support Driver Windows 98SE/Me/2000/XP Security WPA-PSK(TKIP,AES); 802.1X client for Windows XP ,64/128 bit WEP Roaming Seamless roaming among 802.11b/g access points. Management Utility Monitors the network situation. 5. Mechanical Dimensions 134mm*121mm*22mm (134mm*81mm*22mm) Weight 55.5(51.5)± 1 g Packaging Packaging specially used by Gigabyte. LED indicators Act and Link *This specification is subject to change without notice.

Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：JCK-GN-WPKG Report No.：ER04-04-003FRF Page 1 of 2 RF EXPOSURE EVALUATION According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 Friis Formula Friis transmission formula : Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. EUT Operating Condition A software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Ecom Sertech Corp. Rm. 258, Bldg. 17, NO.195, Sec. 4 Chung Hsing Rd.,Chu -Tung Chen, Hsinchu, Taiwan 310, R.O.C TEL:886 - 3 - 5918012 FAX : 886 - 3 - 5825720 FCC ID ：JCK-GN-WPKG Report No.：ER04-04-003FRF Page 2 of 2 Test Result of RF Exposure Evaluation Test Item ： RF Exposure Evaluation Data Test Mode ： Normal Operation Antenna Gain Antenna Gain：The maximum Gain measured in fully anechoic chamber is 2dBi linear scale. Output Power into Antenna & RF Exposure Evaluation Distance Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 19.84 0.030390 1 CH6 2437.00 19.86 0.030530 1 CH11 2462.00 19.30 0.026837 1 Note : 1. For Antenna 802.11b Mode (11Mbps). 2. The power density Pd (4th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required. Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density at 20cm (mW/cm 2 ) LIMITS (mW/cm 2 ) CH1 2412.00 15.64 0.011554 1 CH6 2437.00 15.97 0.012466 1 CH11 2462.00 15.38 0.010883 1 Note : 1. For Antenna 802.11g Mode (54Mbps). 2. The power density Pd (4th column) at a distance of 20cm calculated from the Friis transmission formula is far below the limit of 1 mW/cm 2 . The EUT is classified as mobile product. So, RF exposure limit warning or SAR test are not required.
