JCK-U21Notebook

Regulatory Notices CB : ● Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. ● Do not remove any batteries from the computer while it is powered on. ● Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. ● Recharge the batteries using the Notebook’s system. Incorrect recharging may make the battery explode. ● Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service personnel. ● Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode or leak if exposed to fire, or improperly handled or discarded. ● Keep the battery away from metal appliances. ● Affix tape to the battery contacts before disposing of the battery. ● Do not touch the battery contacts with your hands or metal objects. RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 0.585 W/kg when placed next to the body. CE Notice (European Union) : This symbol indicates this notebook complies with the EMC Directive 2004/108/EC and the European Union’s Low Voltage Directive 2006/95/EC. This symbol also indicates that this notebook meets the following tech- nical standards: ● EN 55022 — “Limitations and Methods of Measurement for the Radio Interferences of Information Technology Equipment.” ● EN 55024 — “Information technology equipment - Immunity characteristics - Limits and methods of measurement.” ● EN 61000-3-2 — “Electromagnetic compatibility (EMC) - Chapter 3: Limits - Section 2: Limits on the harmonic current emissions (Equipment input current up to and including 16 A per phase).” ● EN 61000-3-3 — “Electromagnetic compatibility (EMC) - Chapter 3: Limits - Section 3: Limits on the voltage fluctuations and flicker in low-voltage power supply systems for equipment with rate current up to and including 16 A.” NOTE: EN 55022 emissions requirements provide for two classifications. (1) Class A governs commercial use (2) Class B governs residential use Declaration of Conformity for EU countries Hereby, GIGABYTE, declares that this notebook PC series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Federal Communications Commission Notice : This equipment has been tested and found to comply with the limits for a Class B digital service, pursuantto Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmfulinterference in a residential installation. Any changes or modifications made to this equipment mayvoid the user’s authority to operate this equipment. This equipment generates, uses, and can radiateradio frequency energy, and if not installed and used in accordance with the instructions, may causeharmful interference to radio communications. However, there is no guarantee that interference will notoccur in a particular installation. If this equipment does cause harmful interference to radio or televisionreception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. ● All external cables connecting to this basic unit must be shielded. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The FCC RF safety requirement: The radiated output power of the wireless LAN Mini PCI Card and Bluetooth card is far below the FCC radio frequency exposure limits. Nevertheless, the Notebook series shall be used in such a manner that the potential for human contact during normal operation is minimized as follows: (1) Users are requested to follow the RF safety instructions on wireless option devices that are included in the user’s manual of each RF option device. Caution: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. NOTE: The wireless Mini PCI adapter implements a transmission diversity function. The function does not emit radio frequencies simultaneously from both antennas. One of the antennas is selected auto- matically or manually (by users) to ensure good quality radiocommunication. (2) An improper installation or unauthorized use may cause harmful interference to radio communications. Also any tampering of the internal antenna will void the FCC certification and your warranty. Notice: Canadian users CAN ICES-3 (*)/NMB-3(*) * Insert either “A” or “B” but not both to identify the applicable Class of ITE. BSMI Notice (Taiwan Only) ● The symbol above must be attached to the product indicating compliance with the BSMI standard. ● Most Notebook are classified by the Bure…

Text truncated - open the document above for the full version.

繁體中文 7 繁體中文 6 Windows 8系統還原說明 系統還原使用說明 系統還原（修復您的筆記型電腦作業系統） 當作業系統使用上出現不穩定的情況，筆記型電腦原廠出貨的儲存裝置裡有一個隱藏磁區，其內容為 作業系統的完整備份映像檔，可以用來救援系統將儲存裝置裡的作業系統還原到出廠預設值。 執行還原前請注意 確認筆記型電腦已接上外接電源，還原系統會花費幾分鐘的時間。 注意 ̇ 如果儲存裝置有被更換過或刪除該隱藏磁區，還原功能將無法使用，需送維修中心還原。 ̇出廠規格為預搭作業系統時才有此還原功能，若是DOS銷售則不提供此功能。 啟動系統還原 系統還原功能是筆記型電腦出廠時被預先安裝的。該選項可以啟動Windows故障還原工具，重新安 裝作業系統為出廠預設值。 以下為簡要介紹如何啟動還原工具，並開始還原系統。 點擊“Choose your keyboard layout”選擇您的鍵盤語系。 請點擊“See more keyboard layouts”至第三頁面選擇 “Chinese (traditional) - US”為繁體中文。 關機並重新啟動筆記型電腦。 2 1 3 啟動筆記型電腦後，按著F9按鍵幾秒鐘以啟動還原 工具。 繁體中文 7 繁體中文 6 系統還原有兩種方式可供選擇 ̇ Refresh your PC - 重置電腦設定值 如果電腦因軟體或設定值不佳而不穩定，您可以重設電腦設定值而不遺失個人 檔案。 ̇ Reset your PC - 復原電腦 如果電腦因軟體或設定值不佳而不穩定，您可以復原電腦為出廠預設值並移除所 有個人檔案。 注意：將會遺失所有的個人資料與檔案。 4 選擇“Troubleshoot”進入系統還原及進階選項。 （您也可以選擇“Continue”直接進入Windows 8作業系統，先行備份個人資料 與檔案再作還原。或選擇“Turn off your PC”關機並重新啟動筆記型電腦。） 注意事項 ̇筆記型電腦裡的個人化設定不會被改變。 ̇筆記型電腦的設定值會被還原至出廠預設值。 ̇由Windows市集所安裝的Apps會保留。 ̇由網頁下載或光碟安裝的應用程式會被移除。 ̇被移除的應用程式的清單會被儲存在桌面上。 注意事項 ̇您所有的個人檔案與應用程式將會被移除。 ̇所有的電腦設定值將會被還原至系統出廠值。 ▓Refresh your PC - 選擇重置電腦設定值 【按下“Next”繼續下一步】>【選擇要被還原的作業系統】>【選擇“Windows 8”】> 【按下“Refresh”執行】。 5 ▓Reset your PC - 復原電腦 【按下“Next”繼續下一步】>【選擇要被還原的作業系統】>【選擇“Windows 8”】> 【選擇欲還原的方式】   Just remove my files - 只移除個人檔案 只移除個人檔案，但保留電腦設定值。  Fully clean the drive - 完整還原至出廠設定值 完整還原儲存裝置至出廠設定值，會花費較長的還原時間。 >【按 下“ R e s e t ”執 行】。 繁體中文 PB 繁體中文 8 „ 保固及客服資訊 : 相關保固條款及客服資訊請參考隨貨所附之保固保證書，或參考技嘉技術服務區網站。 http://www.gigabyte.tw/support-downloads/technical-support.aspx „ FAQ : 相關常見問題請參考技嘉常見問題網站。 http://www.gigabyte.tw/support-downloads/faq.aspx 附錄 備註 Advanced options其它或進階選項 更多系統還原的進階設定。 System Restore系統還原 選擇系統還原的記錄時間，將系統還原至該時間點。 System Image Recovery系統備份還原 使用之前備份的系統備份資料還原Windows系統。 Automatic Repair自動修復程序 自動修復及解決Windows系統問題。 Command Prompt命令提示字元 使用命令字元集執行進階的疑難排解。 UEFI Firmwar SettingsUEFI BIOS設定 重新啟動，變更UEFI BIOS設定值。 簡體中文 PB 1 簡體中文 感謝您選擇技嘉筆記本電腦！ 為協助您順利使用技嘉筆記本電腦，我們特地設計此快速安裝說明。如果您需要更多關於電腦功 能的資料，歡迎上技嘉官方網www.gigabyte.cn查詢。產品實際規格以出貨為准，如有異動不再另 行通知。 首次使用 GIGABYTE 技嘉筆記本電腦 2 1 3 4 1 將電源線接上適配器。 2 將電源適配器連接到電腦的電源插孔。 3 將電源線插入電源插座。 4 待電源指示燈亮起時，按下電源鍵啟動。 開啟筆記本電腦: 電源指示燈會顯示機器是否為通電的狀態。第一次開機時，在還未完全進入作業系統前請勿強制關 機。開啟電源後，直到該作業系統配置完成前，音量無法設定。 開始第一次使用U21: 根據您的筆記本電腦配置，當您第一次開機，第一個畫面會是微軟Windows ® 啟動畫面，按照該屏 幕上的提示和指示，完成作業系統的配置。當軟體許可條款顯示時，請務必開讀並同意後在繼續。 簡體中文 2 3 簡體中文 上視圖 左視圖 13 2 5 9 4 6 7 8 1 攝像頭指示燈 2 視頻攝像頭 3 環境光源感測器 4 麥克風 5 Windows鍵  6 身歷聲揚聲器 7 觸摸板 8 電池電量顯示鍵  9 LED 狀態指示燈   回到Windows 8 Style UI 首頁。  于關機狀態時，按下右鍵可檢視電池剩 餘電量。  藍牙指示燈 無線網路指示燈 硬盤存取指示燈 電池充電指示燈 電源狀態指示燈 23145 1 電源開關 2 USB 接口 3 HDMI 接口 4 USB 接口 5 USB 接口 (支援USB Charge) GIGABYTE 技嘉筆記本電腦導覽 簡體中文 2 3 簡體中文 右視圖 1 安全鎖插槽 2 耳機插孔 3 麥克風插孔 4 SD 讀卡器 5 USB 接口 6 音量調節鍵 7 屏幕自動旋轉開關 2345716 後視圖 1 電源插孔 2 SIM卡插槽 3 外接顯示器(VGA)接口 4 以太網口(LAN) 1234 底視圖 1 內存插槽 1 簡體中文 4 5 簡體中文 許多電腦的設定例如屏幕亮度，喇叭音量等可利用電腦的快速鍵直接調整。 如需使用快速鍵，請依下表先按住<Fn>鍵，再按下<F1>~<F12>等按鍵。 快速鍵 功能功能敘述 Fn+F1 睡眠模式讓電腦進入睡眠模式。 Fn+F2 無線區域開啟/關閉無線網卡。 Fn+F3 減弱亮度降低屏幕亮度。 Fn+F4 屏幕亮度提高屏幕亮度。 Fn+F5 屏幕顯示切換 在電腦屏幕以及外接顯示器或顯示器之間切 換視頻輸出，或者同時顯示。 Fn+F6 屏幕開關開啟/關閉屏幕。 Fn+F7 揚聲器靜音將揚聲器切換為靜音模式。 Fn+F8 減弱音量降低揚聲器音量。 Fn+F9 增大音量提高揚聲器音量。 Fn+F10 觸摸板開關開啟/關閉觸摸板。 Fn+F11 藍牙通訊開啟/關閉藍牙通訊裝置。 Fn+F12 攝像頭開啟/關閉內建攝像頭。 快速鍵 簡體中文 4 5 簡體中文 U21的屏幕可旋轉置放，作為平板電腦使用。請按照下列步驟操作： 1. 打開U21上蓋(屏幕顯示器)。 2. 屏幕的轉承軸處有標誌標示。 3. 按照標誌說明將屏幕順時針旋轉180度，使屏幕朝外。 4. 將旋轉後的屏幕向下蓋回。顯示器可置放在鍵盤上，即可將 U21作為平板電腦使用 5. 要回復為筆記本電腦功能時，請將上述步驟逆向操作一次 (豎起屏幕呈90度，並逆時針旋轉180度)。 注意: 此屏幕只能順時針旋轉180度。務必依照標誌說明旋轉屏幕。依錯誤角度強制旋轉屏幕會嚴重損壞 筆記本電腦。 將U21筆記本電腦當作平板電腦來使用 簡體中文 6 7 簡體中文 系統還原使用說明 系統還原（修復您的筆記本電腦操作系統） 當操作系統使用上出現不穩定的情況，筆記本電腦原廠出貨的儲存裝置裡有一個隱藏磁區，其內容為 操作系統的完整 備份映射檔，可以用來救援系統將儲 存裝置裡的操作系統還原到出廠預設值。 執行還原前請注意 確認筆記本電腦已接上外接電源，還原系統會花費 幾分鐘的時間。 注意 ̇ 如果儲存裝置有被更換過或刪除該隱 藏磁區，還原功能將無法使用，需送維修中 心還原。 ̇出廠規格 為預搭操作系統時才有此還原功能，若是DOS銷售則不提供此功能。 啟動系統還原 系統還原功能是筆記本電腦出廠時被預先安裝的。該選項可以啟動Windows故障還原工具，重新安 裝操作系統為出廠預設值。 以下為簡要介紹如何啟動還原工具，並開始還原系統。 Windows 8系統還原說明 Choose your k eyboard l ayo ut - 請選擇您的鍵盤語系。 請點擊“See more keyboard layo uts＂至第三頁面選擇 “Chinese (Simplified) - US＂為簡體中文。 關機並重新啟動筆記本電腦。 2 1 3 啟動筆記本電腦後，按著F9按鍵幾秒鐘以啟動還原 工具。 簡體中文 6 7 簡體中文 系統還原有兩種方式可供選擇 ̇ Refresh your PC - 重置電腦設定值 如果電腦因軟件或設定值不佳而不穩定， 您可以重設電腦設定值而不遺失個人 檔案。 ̇ Reset your PC - 復原電腦 如果電腦因軟件或設定值不佳而不穩定， 您可以復原電腦為出廠預設值並移除 所有個人檔案 注意：將會遺失所有的個人資料與檔案。 4 選擇＂Troubleshoot＂進入系統還原及進階選項。 （您也可以選擇＂Continue＂直接進入Windows 8操作系統，先行備份個人資料 與檔案再 作還原。） 注意事項 ̇筆記本電腦裡的個人化設定不會被改變。 ̇筆記本電腦的設定值會被還原至出廠預設值。 ̇由Windows市集所安裝的Apps會保留。 ̇由網頁下載或光碟安裝的應用程序會被移除。 ̇被移除的應用程序的清單會被儲存在桌面上。 注意 ̇您所有的個人檔案與應用程序將會被移除。 ̇所有的電腦設定值將會被還原至系統出廠值。 ▓Refresh your PC - 選擇重置電腦設定值 【按下＂Next＂繼續下一步】>【選擇要被還原的操作系統】>【選擇 “Windows 8＂】>【按下＂Refresh＂執行】。 5 ▓Reset your PC- 復原電腦 【按下＂Next＂繼續下一步】>【選擇要被還原的操作系統】>【選擇 “Windows 8＂】>【選擇欲還原的方式】  J ust r emove my files - 只移除個人檔案 只移除個人檔案，但保留電腦設定值。  F ully clean the drive - 完整還原至出廠設定值 完整 還原儲存裝置至出廠設定值，會花費較長的還原時間。 >【按下＂Reset＂執行】。 簡體中文 8 PB 簡體中文 備註 Advanced options - 其它或進階選項 更多系統還原的進階設定。 System Restore - 系統還原 選擇系統還原的記錄時間，將系統還原至該時間點。 System Image Recovery - 系統備份還原 使用之前備份的系統備份資料還原Windows系統。 Automatic Repair - 自動修復程序 自動修復及解決Windows系統問題。 Command Prompt - 命令提示字元 使用命令字元集執行進階的疑難排解。 UEFI Firmware Settings - UEFI BIOS設定 重新啟動，變更UEFI BIOS設定值。 „ 保修及客服信息 : 相關保修條款及客服資訊請參考隨貨所附之保修保證書，或參考技嘉技術支援網站。 http://www.gigabyte.cn/support-downloads/technical-support.aspx „ FAQ : 相關常見問題請參考技嘉常見問題網站。 http://www.gigabyte.cn/support-downloads/faq.aspx 附錄 PB1 한국어한국어 기가바이트 노트북을 구매 하신 것을 감사 드립니다. 이 설치 가이드는 기가바이트 노트북을 더욱 손쉽게 사용하실 수 있도록 도움을 드리고자 제작되 었습니다. 기가바이트 홈페이지(www.gigabyte.com)를 방문하시면 더욱 상세한 정보를 확인하 실 수 있습니다. 제품의 사양은 출고기준에 따르며 예고없이 변동될 수 있습니다. 기가바이트 노트북 처음 으로 사용 하기 2 1 3 4 1전원선을 AC아답터에 연결 하십시오. 2AC 아답터를 노트북 오른쪽의 DC-In 잭에 연결 하십시오. 3파워 코드를 파워 아울렛에 연결 하십시오. 4배터리 표시등이 켜져 있을시, 전원 버튼을 눌러 노트북을 켜십시오. 전원 켜기: 전원 연결상태는 LED지시등을 통해 확인 가능합니다 처음 U21 노트북의 전원을 켜면, 운영체제 가 모두 셋팅 될 때까지 전원을 끄지 마십시오. 윈도우 셋업이 모두 마치기 전에는 오디오가 작동 하지 않을 수 있습니다. 처음으로 U21 부팅 하기: 노트북 환경 설정에 의하면 노트북 첫 부팅시 마이크로소프트 윈도우 부팅 화면이 보일것입니다. 안내 및 지시에 따라 운영체제 설치진행하며 개인정보를 입력하여 윈도우 운영체제 셋업을 마치 십시오. 23 한국어한국어 파노라믹 뷰 측면도 13 2 5 9 4 6 7 8 1웹캠 상태 LED표시등 2웹캠 3라이트 센서 4내장형 마이크 5윈도우 버튼  6스피커 7터치패드 8배터리 지시등 버튼  9LED 표시등   윈도우8 스타일 UI모드로 돌아 가기.  전원이 꺼져 있을시 터치패드의 오른쪽 버튼을 눌러 배터리 잔여량을 확인 하 십 시오.  블루투스 LED 무선 랜 상태 표시등 HDD 상태 표시등 배터리 상태 표시등 전원 상태 표시등 23145 1전원 버튼 2USB포트 3HDMI 포트 4USB 포트 5 USB 포트 (USB 충전 지원) 기가바이트 노트북 투어 23 한국어한국어…

Text truncated - open the document above for the full version.

Intel Corporation 100 Center Point Circle Columbia, SC 29210 Intel 7260NGW Model Number Attestation Model 7260NGW FCC ID: PD97260NG and PD97260NGU IC: 1000M-7260NG This letter will attest that this device approved under the FCC and IC ID’s above includes the family sub-models listed below and that all sub-models are manufactured electrically identical with no differences in populated components or PCB layout design. All model differences are strictly within programmed firmware. All firmware programming is performed at the factory prior to device shipment and cannot be modified or altered by OEMs, users or any third party. All testing results provided within this filing are applicable to all sub-models. Model Number Supported Modes 7260NGW 802.11a/b/g/n/ac + Bluetooth 7260NGW AN 802.11a/b/g/n + Bluetooth 7260NGW NB 802.11a/b/g/n, no Bluetooth 7260NGW BN 802.11/b/g/n + Bluetooth

Report No：136255R-HPUSP09V01 Page: 4 of 10 EUT Photographs Report No：136255R-HPUSP09V01 Page: 5 of 10

GIGA-BYTE TECHNOLOGY CO., LTD. FCC ID.: JCK-U21 No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan Tel : 886-2-8912-4000 FCC ID Label

GIGA-BYTE TECHNOLOGY CO., LTD. FCC ID.: JCK-U21 No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan Tel : 886-2-8912-4000 The FCC ID and DoC will be placed on the equipment as shown in the photograph below.

Report No.: 136255R-RFUSP43V01 Page : 5 of 12 (9) EUT Photo (10) EUT Photo WLAN + Bluetooth Module Car d Report No.: 136255R-RFUSP43V01 Page : 6 of 12 (11) EUT Photo (12) EUT Photo Report No.: 136255R-RFUSP43V01 Page : 7 of 12 (13) EUT Photo (14) EUT Photo Report No.: 136255R-RFUSP43V01 Page : 8 of 12 (15) EUT Photo (16) EUT Photo Report No.: 136255R-RFUSP43V01 Page : 9 of 12 (17) EUT Photo (18) EUT Photo WLAN + Bluetooth Antenna Report No.: 136255R-RFUSP43V01 Page : 10 of 12 (19) EUT Photo (WLAN + Bluetooth Antenna) (20) EUT Photo Report No.: 136255R-RFUSP43V01 Page : 11 of 12 (21) EUT Photo (22) EUT Photo Report No.: 136255R-RFUSP43V01 Page : 12 of 12 (23) EUT Photo (24) EUT Photo

Report No. 136255R-RFUSP43V01 Page: 1 of 75 FCC Test Report Product Name Notebook Model No. U21 FCC ID. JCK-U21 Applicant GIGA-BYTE TECHNOLOGY CO., LTD. Address No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan Date of Receipt July 13, 2013 Issued Date Aug. 05, 2013 Report No. 136255R-RFUSP43V01 Report Version V1.0 The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government Report No. 136255R-RFUSP43V01 Page: 2 of 75 Test Report Certification Issued Date: Aug. 05, 2013 Report No.: 136255R-RFUSP43V01 Product Name Notebook Applicant GIGA-BYTE TECHNOLOGY CO., LTD. Address No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231,Taiwan Manufacturer 1. GIGA-BYTE TECHNOLOGY CO., LTD. (GBT) 2. G-STYLE Ltd. Model No. U21 FCC ID. JCK-U21 EUT Rated Voltage AC 100-240V, 50-60Hz EUT Test Voltage AC 120V/60Hz Trade Name GIGABYTE Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2012 ANSI C63.4: 2003, ANSI C63.10: 2009 Test Result Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by TAF or any agency of the U.S. Government Documented By: ( Senior Adm. Specialist / Genie Chang ) Tested By : ( Assistant Engineer / Andy Lin ) Approved By : (Manager / Vincent Lin ) Report No. 136255R-RFUSP43V01 Page: 3 of 75 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...............................................................................................................5 1.1. EUT Description......................................................................................................................................5 1.2. Operational Description...........................................................................................................................7 1.3. Tested System Details..............................................................................................................................8 1.4. Configuration of Tested System ..............................................................................................................8 1.5. EUT Exercise Software ...........................................................................................................................9 1.6. Test Facility ...........................................................................................................................................10 2. CONDUCTED EMISSION ................................................................................................................ 11 2.1. Test Equipment ......................................................................................................................................11 2.2. Test Setup ..............................................................................................................................................11 2.3. Limits.....................................................................................................................................................12 2.4. Test Procedure .......................................................................................................................................12 2.5. Uncertainty ............................................................................................................................................12 2.6. Test Result of Conducted Emission .......................................................................................................13 3. PEAK POWER OUTPUT ..................................................................................................................15 3.1. Test Equipment ......................................................................................................................................15 3.2. Test Setup ..............................................................................................................................................15 3.3. Limit .....................................................................................................................................................15 3.4. Test Procedure .......................................................................................................................................15 3.5. Uncertainty ............................................................................................................................................15 3.6. Test Result of Peak Power Output .........................................................................................................16 4. RADIATED EMISSION .....................................................................................................................18 4.1. Test Equipment ......................................................................................................................................18 4.2. Test Setup ..............................................................................................................................................18 4.3. Limits.....................................................................................................................................................19 4.4. Test Procedure .......................................................................................................................................20 4.5. Uncertainty ............................................................................................................................................20 4.6. Test Result of Radiated Emission ..........................................................................................................21 5. RF ANTENNA CONDUCTED TEST..........…

Text truncated - open the document above for the full version.

Report No. 136255R-RFUSP43V01 Page: 51 of 75 Product : Notebook Test Item : Band Edge Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) Fundamental Filed Strength Antenna Pole Frequency [MHz] Correction Factor [dB/m] Reading Level [dBuV] Emission Level [dBuV/m] Detector Horizontal 2480 68.95 101.106 101.106 Peak Horizontal 2480 53.9 86.056 86.056 Average Vertical 2480 68.47 99.882 99.882 Peak Vertical 2480 53.69 85.102 85.102 Average Note: 1:Spectrum Analyzer setting: Peak detector: RBW=1MHz, VBW=1MHz Average detector: RBW=1MHz, VBW=10Hz Band Edge Test Data Antenna Pole Test Frequency (MHz) Fundamental (dBuV/m) Δ (dB) Band Edge Field Strength (dBuV/m) Limit (dBuV/m) Detector Horizontal 2485.1 101.106 42.81 58.296 74.000 Peak Horizontal 2483.5 86.056 44.94 41.116 54.000 Average Vertical 2485.1 99.882 42.81 57.072 74.000 Peak Vertical 2483.5 85.102 44.94 40.162 54.000 Average Note: The Band Edge Field Strength was calculated using the Fundamental and Conducted Band Edge measurements per the Marker-Delta Method with the following formula: Band Edge field Strength = F - Δ F = Fundamental field Strength (Peak or Average) Δ = Conducted Band Edge Delta (Peak or Average) Report No. 136255R-RFUSP43V01 Page: 52 of 75 Peak Detector of conducted Band Edge Delta Average Detector of conducted Band Edge Delta Report No. 136255R-RFUSP43V01 Page: 53 of 75 7. Channel Number 7.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2013 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2013 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2013 Note: 1. All equipments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 7.2. Test Setup 7.3. Limit Frequency hopping systems operating in the 2400-2483.5 MHz bands shall use at least 75 hopping frequencies. 7.4. Test Procedure The EUT was setup to ANSI C63.10, 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 7.5. Uncertainty N/A SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 136255R-RFUSP43V01 Page: 54 of 75 7.6. Test Result of Channel Number Product : Notebook Test Item : Channel Number Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) Frequency Range (MHz) Measurement (Hopping Channel) Required Limit (Hopping Channel) Result 2402 ~ 2480 79 >75 Pass 2402-2421MHz 2422-2441MHz 2442-2461MHz 2462-2480MHz Report No. 136255R-RFUSP43V01 Page: 55 of 75 Product : Notebook Test Item : Channel Number Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) Frequency Range (MHz) Measurement (Hopping Channel) Required Limit (Hopping Channel) Result 2402 ~ 2480 79 >75 Pass 2402-2421MHz 2422-2441MHz 2442-2461MHz 2462-2480MHz Report No. 136255R-RFUSP43V01 Page: 56 of 75 8. Channel Separation 8.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2013 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2013 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2013 Note: 1. All equipments are calibrated every one year. 2. The test instruments mark by “X” are used to measure the final test results. 8.2. Test Setup 8.3. Limit Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of 25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater. 8.4. Test Procedure The EUT was setup to ANSI C63.10, 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 8.5. Uncertainty ± 150Hz SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 136255R-RFUSP43V01 Page: 57 of 75 8.6. Test Result of Channel Separation Limit Limit of (2/3)*20dB Channel No. Frequency (MHz) Measurement Level (kHz) (kHz) Bandwidth (kHz) Result 00 2402 1000 >25 kHz 746.7 Pass 39 2441 1000 >25 kHz 753.3 Pass 78 2480 1000 >25 kHz 746.7 Pass NOTE: The 20dB Bandwidth is refer to section 10. Channel 00 2402MHz Product : Notebook Test Item : Channel Separation Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) Report No. 136255R-RFUSP43V01 Page: 58 of 75 Channel 39 2441MHz Channel 78 2480 MHz Report No. 136255R-RFUSP43V01 Page: 59 of 75 Limit Limit of (2/3)*20dB Channel No. Frequency (MHz) Measurement Level (kHz) (kHz) Bandwidth (kHz) Result 00 2402 1000 >25 kHz 946.7 Pass 39 2441 1000 >25 kHz 946.7 Pass 78 2480 1000 >25 kHz 940.0 Pass NOTE: The 20dB Bandwidth is refer to section 10. Channel 00 2402MHz Product : Notebook Test Item : Channel Separation Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 3Mbps (8DPSK) Report No. 136255R-RFUSP43V01 Page: 60 of 75 Channel 39 2441MHz Channel 78 2480 MHz Report No. 136255R-RFUSP43V01 Page: 61 of 75 9. Dwell Time 9.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2013 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2013 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2013 Note: 1. All equipments are calibrated every one year. 2. The test instruments marked by “X” are used to measure the final test results. 9.2. Test Setup 9.3. Limit The dwell time shall be the average time of occupancy on any frequency shall not be greater than 0.4 seconds within a 30 second period. 9.4. Test Procedure The EUT was setup to ANSI C63.10, 2009; tested to FHSS test procedure of FCC Public Notice DA 00-705 for compliance to FCC 47CFR 15.247 requirements. 9.5. Uncertainty ± 25msec SMA Connecter EUT Spectrum Analyzer RF Cable Report No. 136255R-RFUSP43V01 Page: 62 of 75 9.6. Test Result of Dwell Time Product : Notebook Test Item : Dwell Time Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 1Mbps (GFSK) (Channel 00,39,78 –DH5) Frequency (MHz) Time slot length (ms) Hopping of Number Sweep time (ms) Duty cycle Dwell Time (Sec) Limit (Sec) Result 2402 2.880 13 50 0.75 0.300 0.4 Pass 2441 2.880 13 50 0.75 …

Text truncated - open the document above for the full version.

Report No.: 136255R-RFUSP43V01 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 136255R-RFUSP43V01 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 136255R-RFUSP43V01 Page : 3 of 3 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)
