JCK28713NEONTouch-charge Air Presenter Mouse

Aivia Neon Touch-Charge Air Presenter Mouse User’s Manual All other brands and trademarks are the properties of their respective owners. The product specifications are subject to change without notice. Introduction Congratulations on your purchase of the most innovative touch-charge air presenter mouse. With an incredible sensitivity to surface details and high tracking speed than other mice, this touch-charge air presenter mouse can track reliably on tricky wood-grain surfaces. It is much more advanced than you imagine and will make you more productive and comfortable. Features  Dynamic air presenter mouse  USB nano-receiver with touch and charge function  Accurate 1200DPI laser tracking system  Equipped with laser pointer  Free-Scrolling with laser pointer Hardware Installation 1. Make sure the Power on-off switch on the mouse in ON 2. The LED light will blink if the mouse power is on △ Note The unit offers a strong power saving management. Once the mouse accesses sleeping mode, to clip any key on the mouse is compulsory to wake it up. Power on/off: There is a power on/off switch designed to save the batteries power while non-usage of a longer period. Connect the Receiver 1. Turn on your PC 2. Connect the receiver to USB on PC Communication: The mouse & the Receiver The 2.4GHz RF mouse features a dual-way transmission technology which enables the mouse and the receiver auto-communication. Auto-link mode 1. Make sure the Power On/Off switch on the mouse is ON 2. Operate the mouse, and cursor’s movement is mapping mouse movement. Now the mouse and the receiver is auto-linked successfully. Manual-link mode If you find the communication channel does not connect well, you can use the software communication tool to re-connect the mouse & the receiver to reset a new channel ID. You are able to get to software on the website. △Note While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source out and transfer to another channel. During transferring, the cursor movement may have a second delay. Charge the batteries 1. Open the battery cover and attach to the USB nano-receiver. An indicator light will start to blink to show that the battery is charging. 2. Charge your mouse until the indication light stops blinking. △Note The red LED light indicates that batteries inside needs to be re-charged. Trouble Shooting 1. Make sure you have connected the receiver correctly on the PC’s USB port 2. For the best performance, we suggest you to locate the receiver with a distance from other electric devices, such as the computer monitor or external storage devices 3. Make sure you have set the communications between the receiver and the mouse. Refer to the communication section. 4. If you find the communication channel does not work well, you may use the software connection tool to re-connect the mouse & receiver and reset a new channel ID. You are able to get to software on the website. 5. Some system devices might conflict with the mouse. Confirm the IRQ/address settings of these devices for conflicts, and change the settings as required. 6. Make sure that you are not working the mouse on glossy or reflective surfaces. FCC Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example-use only shielded interface cables when connecting to computer or peripheral devices). This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) This device must accept any interference received, including interference that may cause undesired operation. This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end its life separately from your household waste. There are separate collection system for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product. Class 2 Laser Product Laser radiation Do not stare into beam

FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC EXTERNAL PHOTOGRAPHS OF EUT FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC EUT 1 EUT 2 FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC EUT 3 EUT 4 FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC EUT 5

Page: 1 of 27 TEST REPORT of FCC Part 15 Subpart C New Application; Class I PC; Class II PC Product : Touch-Charge Air Presenter Mouse Brand: GIGABYTE Model: GM-Neon Model Difference: N/A FCC ID: JCK28713NEON FCC Rule Part: §15.249 Applicant: GIGA-BYTE Technology Co., Ltd. Address: No.6, Bao Chiang Road, Hsin-Tien Dist., New Taipei City 231, Taiwan Test Performed by: International Standards Laboratory <Lung-Tan LAB> *Site Registration No. BSMI: SL2-IN-E-0013; MRA TW1036; TAF: 0997; IC: IC4067B-3; *Address: No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan *Tel : 886-3-407-1718; Fax: 886-3-407-1738 Report No.: ISL-13LR063FC Issue Date : 2013/04/29 Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. This report MUST not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory. -2 of 27- FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC VERIFICATION OF COMPLIANCE Applicant: GIGA-BYTE Technology Co., Ltd. Product Description: Touch-Charge Air Presenter Mouse Brand Name: GIGABYTE FCC ID: JCK28713NEON FCC Rule Part: §15.249 Model No.: GM-Neon Model Difference: N/A Date of test: 2013/04/12 ~2013/04/24 Date of EUT Received: 2013/04/12 We hereby certify that: All the tests in this report have been performed and recorded in accordance with the standards described above and performed by an independent electromagnetic compatibility consultant, International Standards Laboratory. The test results contained in this report accurately represent the measurements of the characteristics and the energy generated by sample equipment under test at the time of the test. The sample equipment tested as described in this report is in compliance with the limits of above standards. Test By: Date: 2013/04/29 Dion Chang / Engineer Prepared By: Date: 2013/04/29 Eva Kao / Technical Supervisor Approved By: Date: 2013/04/29 Vincent Su / Technical Manager -3 of 27- FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC Version Version No. Date Description 00 2013/04/29 Initial creation of document -4 of 27- FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC Table of Contents 1 GENERAL INFORMATION ........................................................................................... 5 1.1 PRODUCT DESCRIPTION .................................................................................................................... 5 1.2 RELATED SUBMITTAL(S) / GRANT (S) ............................................................................................... 5 1.3 TEST METHODOLOGY ........................................................................................................................ 5 1.4 TEST FACILITY .................................................................................................................................. 5 1.5 SPECIAL ACCESSORIES ...................................................................................................................... 5 1.6 EQUIPMENT MODIFICATIONS ............................................................................................................ 5 2 SYSTEM TEST CONFIGURATION .............................................................................. 6 2.1 EUT CONFIGURATION ....................................................................................................................... 6 2.2 EUT EXERCISE .................................................................................................................................. 6 2.3 TEST PROCEDURE .............................................................................................................................. 6 2.4 MEASUREMENT EQUIPMENT USED: .................................................................................................. 7 2.5 LIMITATION ....................................................................................................................................... 8 2.6 CONFIGURATION OF TESTED SYSTEM ............................................................................................. 10 3 SUMMARY OF TEST RESULTS ................................................................................. 11 4 DESCRIPTION OF TEST MODES .............................................................................. 11 5 CONDUCTED EMISSIONS TEST ............................................................................... 12 5.1 MEASUREMENT PROCEDURE: ......................................................................................................... 12 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................. 12 5.3 MEASUREMENT EQUIPMENT USED: ................................................................................................ 12 5.4 MEASUREMENT RESULT: ................................................................................................................ 13 6 RADIATED EMISSION TEST ...................................................................................... 15 6.1 MEASUREMENT PROCEDURE........................................................................................................... 15 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................. 15 6.3 MEASUREMENT EQUIPMENT USED: ................................................................................................ 16 6.4 FIELD STRENGTH CALCULATION .................................................................................................... 16 6.5 MEASUREMENT RESULT .........…

Text truncated - open the document above for the full version.

FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC PHOTOGRAPHS OF SETUP FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC Radiated Emission Setup Photos FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC Conducted Emission Setup Photos FCC ID: JCK28713NEON International Standards Laboratory Report Number: ISL-13LR063FC
