JCK287158600-RXWireless Gaming Mouse Receiver

GIGA-BYTE TECHNOLOGY CO., LTD.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 16, 2010
Application Purpose: Original Equipment
Date of Application: Nov 11, 2010
Equipment Note: Wireless Gaming Mouse Receiver
Frequency Range: 2402.00000000 - 2479.00000000
Company: GIGA-BYTE TECHNOLOGY CO., LTD.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 USERS’ MANUAL Aivia M8600 Wireless Macro Gaming Mouse Model: 28715860000CBS Aivia M8600 Wireless Macro Gaming Mouse Receiver Model: 28715860000CBS-RX 2 Aivia M8600 Wireless Macro Gaming Mouse Aivia, an integrated acronymic word, is derived from its key features – advanced, intuitive, and versatile interface archetype. The series is to emphasize the combination of subconscious, design and function as well as the pursuit of archetype. GIGABYTE believes each mouse and keyboard are the scrupulous work of mankind’s brainpower. Aivia is not only an extension to the human intellect, but also an intuitive extension to the use of artificial intelligence. The Aivia M8600 has unleashed the limitation and been designed to set you free from cord while achieving the tough mission in game play. Having ultra-high precision and 2.4GHz gaming-grade wireless technology, Aivia M8600 not only shows its excellent performance but also incredible fast transmission even as a wireless gaming mouse. The battery life persists over 24 continuous hours in the gaming mode, joint the unique QSBS TM Technology – Quick-swap Battery System, makes it a fast and lag-free gaming mouse. 32KB onboard memory enables 5 profiles set on your M8600, and allows you to bring your personal settings wherever you go. Combine that with 5600DPI and 1000Hz report rate, the Aivia M8600 now becomes your extreme weapon than ever. Feature GamePlay™ Wireless Technology Over 24hr battery life in game play Dual mode wired/ wireless functionality GHOST™ Macro Engine 3 Mouse Introduction Default button assignments A Mouse button 1 – Left Click B Mouse button 2 – Right Click C Mouse button 3 – Middle Click and 4 ways Scrolling Wheel D Mouse button 4 – DPI Switching Up E Mouse button 5 – DPI Switching Down F Mouse button 6 – Forward G Mouse button 7 –Back H Mouse button 8 –Profile Change I Mouse button 9 – No function (reserved for the left hand mode) J Cable Lock/ Unlock Switch K Pro-laser Gaming Sensor L Battery Charging Connector M ID Connecting Button N Power on/off Switch O Battery Lock/Unlock Switch P Ultra-Durable TM Teflon feet Q Connecting Button R Charging Contact Bounce S Connector Jack for mini USB cable T Battery inserted jack 4 Installation Wireless Mode 1. Insert the battery into M8600 2. Switch on M8600. 3. Connect the Charging Dock to your computer with the mini-USB cable. 4. Press the connecting buttons on M8600 and Charging Dock at the same time. When the pairing process is completed, your M8600 is then ready for use in wireless mode. 5. To charge M8600 in wireless mode, just place it on the Charging Dock. There is also a spare charging battery to replace. Alternatively, M8600 can be charged through the mini USB cable as a wired mode. 6. To replace the battery with the spare battery, push the battery switch to the left as shown. The battery will pop out instantly. Wired Mode 1. Connect the mini-USB end of the cable to M8600. 2. Plug mouse into the USB port of your computer. M8600 is then ready for use as a wired mouse. Besides, its battery will start charging automatically in this wired mode. 3. To remove the cable, push the cable switch to the right as shown before pulling out the mini-USB connector. Charging Method There are three different charging methods below. • Place M8600 on the charging dock connected to your PC. There will be running green light on the front side of mouse to indicate charging process. • Insert your battery to battery inserted jack of the charging dock. Connect the charging dock to your PC. The red light on charging dock will turn into green to indicate charging process. When the battery is fully charged, the LED on charging dock will come back to red light. • Connect M8600 to your PC with the mini USB cable as a wired mode. The mouse will start charging automatically. 5 LED Light System M8600 has a profile/Battery/Sensitivity LED indicator on its front side, which displays the status of profile/ battery life/sensitivity/ stage. PROFILE INDICATOR The LED color of mode indicator would change along with profile switch. There are 5 different LED colors corresponding 5 profiles to change over on the mouse. The LED color could be selected from the GHOST Engine software based on your preference. BATTERY INDICATOR The GREEN LEDs show the rest battery life: 61 - 100% Battery: 3 green arrow LEDs 31 - 60% Battery: 2 green arrow LEDs 11 - 30% Battery: 1 green arrow LED Less than 10% Battery: 3 green arrow blinking LEDs SENSITIVITY STAGE INDICATOR The LEDs will turn into RED light while adjusting sensitivity. - Sensitivity Stage 1: 1 red LED - Sensitivity Stage 2: 2 red LEDs - Sensitivity Stage 3: 3 red LEDs - Sensitivity Stage 4: full red LEDs 6 GHOST TM Macro Engine GHOST TM Macro Engine supports Windows 98, Windows 2000, Windows XP, and Windows7. Install the software to assign buttons and set up your personal profile. Please make sure to connect your M8600 with mini USB cable to the PC as a wired mode while editing the function through GHOST TM Engine software. (In a wireless mode, you are only allowed to change sensitivity, left-handed/right-handed mode, and gaming/power saving mode in GHOST TM Engine.) Left-hand/Right-hand Mode Aivia M8600 is designed both for left-handed and right-handed user. You may simply switch the left hand/ right hand mode from the selection button of GHOST TM Engine. The description of the buttons then will swap around automatically. Gaming mode/ Power Saving Mode • Gaming mode: The mouse will go through standby stage for further action. Therefore, it would consume more energy as gaming mode. • Power Saving mode: BUTTON ASSIGNMENT User can assign various functions to buttons from both ”BASIC FUNCTION” and ”MACRO SCRIPTS”. All you have to do is drag the function icon and simply drop to the button you would like to assign. Remember that you may edit each macro script in the ”MACRO EDITING” tab. There are five default color LED lights on the panel which indicate five differen…

Text truncated - open the document above for the full version.

Cover Letter(s)

No. 65, Ku Dai Keng St., Hsichih, Taipei 221, R.O. C. Tel: 886-2-2646-2550 FAX: 886-2-26464641 No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan, R.O.C. Tel: 886-3-407-1718 FAX:886-3-407-1738 FCC Labeling Requirements and Information Date: Nov. 8th, 2010 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 FCC ID: JCK287158600-RX Gentlemen: The following label information is required by the FCC Rules and Regulations for certified devices. Please find marketing information required by the FCC Rules and Regulations as following: Label Requirements An intentional radiator device subject to certification by the FCC shall carry a warning label which includes the following statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Due to the limitation on the label, this statement is addressed on page 10 of the user’s manual. The sample label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID: JCK287158600-RX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Sincerely, --------------------------------------- Jim Chu/ Director International Standards Laboratory

Cover Letter(s)

GIGA-BYTE TECHNOLOGY CO., LTD No. 6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan TEL: 886-2-89124000 FAX: 886-2-89124005 Letter of Agency Date: Nov. 8th, 2010 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 FCC ID: JCK28715860000CBS FCC ID: JCK287158600-RX To Whom It May Concern: Please be advised that GIGA-BYTE TECHNOLOGY CO., LTD. authorizes Mr. Jim Chu of International Standards Laboratory (ISL) to act on our behalf, until otherwise notified, for applications submitted to American Telecommunications Certification Body, Inc. (ATCB). Thank you for your attention to this matter. r _______________________ for Andy Chen / Director GIGA-BYTE TECHNOLOGY CO., LTD.

Cover Letter(s)

GIGA-BYTE TECHNOLOGY CO., LTD No. 6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan TEL: 886-2-89124000 FAX: 886-2-89124005 Letter of Declaration of Conformity Date: Nov. 8th, 2010 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 FCC ID: JCK28715860000CBS FCC ID: JCK287158600-RX This device complies with Part 15 of the FCC Rules. The test result has been shown in the ISL test report with number ISL-10LE392FB. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1)Product Name: Aivia M8600 Wireless Macro Gaming Mouse 1)Model: 28715860000CBS 2)Product: Aivia M8600 Wireless Macro Gaming Mouse Receiver 2)Model: 28715860000CBS-RX Name of Responsible Party: GIGA-BYTE TECHNOLOGY CO., LTD. Address of Responsible Party: No. 6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan Phone No.: 886-2-89124000 Fax: 886-2-89124005 We, GIGA-BYTE TECHNOLOGY CO., LTD. , hereby declare that the equipment bearing the trade name and model number specified above was tested conforming to the applicable FCC Rules under the most accurate measurement standards possible, and that all the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commissions requirements. r _______________________ for Andy Chen / Director GIGA-BYTE TECHNOLOGY CO., LTD.

External Photos

International Standards Laboratory Report Number: ISL-10LR039P -1- EUT-1. EUT-2.

ID Label/Location Info

Label & Location

Internal Photos

International Standards Laboratory Report Number: ISL-10LR039P -2- EUT-3. EUT-4. International Standards Laboratory Report Number: ISL-10LR039P -3- EUT-5. EUT-6. International Standards Laboratory Report Number: ISL-10LR039P -4- EUT-7. EUT-8. International Standards Laboratory Report Number: ISL-10LR039P -5- EUT-9. EUT-10. International Standards Laboratory Report Number: ISL-10LR039P -6- EUT-11.

Test Report

Report Number: ISL-10LR014V Issue Date: 2010/05/12 ISL-T10-R5-14 TEST REPORT of FCC Part 15 Subpart B & C Product : Aivia M8600 Wireless Macro Gaming Mouse Receiver Model: 28715860000CBS-RX Brand: GIGABYTE Applicant: GIGA-BYTE Technology Co., Ltd. Address: No. 6, Bau-Chiang Rd., Hsin Tien City, Taipei Hsien, Taiwan Test Performed by: International Standards Laboratory <Lung-Tan LAB> *Site Registration No. BSMI: SL2-IN-E-0013; TAF: 0997; IC: IC4067B-1; VCCI: R-1435, C-1440, T-1676, G-17, R-2598, C-2845, T-1464, G-16, G-211, NEMKO: ELA 113B *Address: No. 120, Lane 180, San Ho Tsuen, Hsin Ho Rd. Lung-Tan Hsiang, Tao Yuan County 325, Taiwan *Tel : 886-3-407-1718; Fax: 886-3-407-1738 Report No.: ISL-10LR039FC Issue Date : 2010/11/05 This report totally contains 38 pages including this cover page and contents page. Test results given in this report apply only to the specific sample(s) tested and are traceable to national or international standard through calibration of the equipment and evaluating measurement uncertainty herein. This report MUST not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. This test report shall not be reproduced except in full, without the written approval of International Standards Laboratory. FCC ID: JCK287158600-RX International Standards Laboratory Report Number: ISL-10LR039FC -i- Contents of Report 1. General ......................................................................................................... 1 1.1 Certification of Accuracy of Test Data ........................................................................ 1 1.2 Test Results Summary .................................................................................................. 2 1.3 Test Frequencies of the wireless module.................................................................... 2 1.4 Test Conditions.............................................................................................................2 2. Description of Equipment Under Test (EUT) .............................................. 3 2.1 Description of Support Equipment ............................................................................... 4 2.1.1 Software for Controlling Support Unit ...........................................................................................4 2.1.2 I/O Cable Condition of EUT and Support Units............................................................................. 4 3. TEST RESULTS .......................................................................................... 5 3.1 Powerline Conducted Emissions .................................................................................. 5 3.1.1 EUT Configuration ......................................................................................................................... 5 3.1.2 Test Procedure ................................................................................................................................ 5 3.1.3 EMI Receiver/Spectrum Analyzer Configuration (for the frequencies tested)............................... 5 3.1.4 Test Data:........................................................................................................................................ 6 3.2 Radiated Emission Measurement ................................................................................. 8 3.2.1 EUT Configuration ......................................................................................................................... 8 3.2.2 Test Procedure ................................................................................................................................ 8 3.2.3 EMI Receiver/Spectrum Analyzer Configuration (for the frequencies tested)............................... 8 3.2.4 Test Data:........................................................................................................................................ 9 3.3 Band Edge & Fundamental Emission Measurement .................................................. 17 3.3.1 Test Procedure .............................................................................................................................. 17 3.3.2 Test Setup ..................................................................................................................................... 17 3.3.3 Test Data:...................................................................................................................................... 18 3.4 Band Edge Restricted Bands & Fundamental Emission Measurement...................... 21 3.4.1 Test Procedure (Radiated & Fundamental)................................................................................... 21 3.4.2 Test Setup (Radiated & Fundamental).......................................................................................... 21 3.4.3 Test Data....................................................................................................................................... 22 4. Appendix .................................................................................................... 28 4.1 Appendix A: Measurement Procedure for Power line Conducted Emissions............ 28 4.2 Appendix B: Test Procedure for Radiated Emissions ................................................ 29 4.3 Appendix C: Test Equipment ..................................................................................... 30 4.3.1 Test Equipment List...................................................................................................................... 30 4.3.2 Software for Controlling Spectrum/Receiver and Calculating Test Data ..................................... 30 4.4 Appendix D: Layout of EUT and Support Equipment ............................................... 31 4.4.1 General Conducted Test Configuration ........................................................................................ 31 4.4.2 General Radiation Test Configuration ...…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: JCK287158600-RX The Front View of Highest Conducted Set-up For EUT FCC ID: JCK287158600-RX The Back View of Highest Conducted Set-up For EUT FCC ID: JCK287158600-RX The Front View of Highest Radiated Set-up For EUT The Back View of Highest Radiated Set-up For EUT
